User Manual
PRODUCT #:
LE04
FEATURES:
This Pro Salon model features full electronic control of table height, head panel and leg panel tilts. It incorporates the
LEC Quiettech motor/hydraulic system that is smoother, quieter and more reliable. Includes an 8-button hand control,
heavy duty foot pedal, Strata 4" Memory Foam with rounded corners, hard maple wood construction with louvered
cabinet, and half round neck roll. Choose from a variety of base cabinet styles - the base cabinet includes a power outlet
and can accommodate a hot towel cabinet or other electrical device. ADA compliant with low height range. Some models
shown here with Stain, Flexible Armrest and Manicure Arms upgrades. PivotPerfect Side Arms or Manicure Arms
upgrade available in 30" and 32" widths only. Lifting capacity is 650 lbs. Oversized item - ships by Truck.
SPECIFICATIONS:
Dimensions:
Electrical:
Suggested Outlet:
Plumbing:
Notes:
Warranty:
Certifications:
Country of Origin:
Installed By:
www.spaequip.com
ITEM:
Pro Salon Spa Table from Living Earth
Crafts
73"(185cm) L x 30"(76cm)W x 25 - 37" (63-94cm)H; also available in 28"(70cm) or 32"(81cm)
widths. Base Cabinet is 51"L x 25.5"W
110V AC, 2.4 Amps
Recessed Quad Outlet under table, not to exceed 2" High
None
None
LET:Limited lifetime warranty on the frame. 3 years on foam and vinyl. 2 years on motors &
controls
UL, cUL, CE
United States
SpaEquip (if setup is included with order) or Client
P: 707-737-1100 F: 707-737-1150
Product Code: LE04X
BRAND:
Living Earth Crafts
SOURCE FOR PURCHASE:
SpaEquip Inc.
211 Wappo Ave
Calistoga, CA 94515
(707) 737-1100
www.spaequip.com
Page 1 of 15
Advertisement
Table of Contents
Summary of Contents for SpaEquip LE04
- Page 1 LET:Limited lifetime warranty on the frame. 3 years on foam and vinyl. 2 years on motors & controls Certifications: UL, cUL, CE Country of Origin: United States Installed By: SpaEquip (if setup is included with order) or Client www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 1 of 15...
- Page 2 Product Code: LE04X OPERATION MANUAL PRO SALON™ MULTI-PURPOSE LIFT TABLE Classic Traditional Contemporary Cuvée For tables manufactured January 2007 forward (800) 358-8292 (760) 597-2155 Fax: (760) 599-7374 Rev.D – September 2007 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 2 of 15...
-
Page 3: Table Of Contents
MAINTENANCE ................page 8-9 Section 4: TROUBLE SHOOTING ..............page 10 Section 5: TECHNICAL PROBLEMS ..............page 11 Section 6: WARRANTY ...................page 12 Section 7: SPECIFICATIONS ................page 13 Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 3 of 15... -
Page 4: Important Safety Instructions
14. If this furnishing is not in use, the cord needs to be rolled up and stored out of the way to avoid damage. SAVE THESE INSTRUCTIONS Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 4 of 15... -
Page 5: Section 1: Important Safety Instructions
8. Never attempt to use the foot lift section to support concentrated weight such as sitting or standing. SAVE THESE INSTRUCTIONS Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 5 of 15... -
Page 6: Operating Instructions Standard Equipment
Use of Foot Control: The foot pedal controls the raising or lowering of the entire table. The left side raises the table and the right side lowers it. Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 6 of 15... -
Page 7: Optional Accessories
Replacement parts for a double-insulated product must be identical to the parts they replace. Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 7 of 15... - Page 8 Damage to table frame caused by misuse will not be covered under warranty. Trained personnel at our factory will assess any frame damage or warranty issues resulting from the use of wheels. SAVE THESE INSTRUCTIONS Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 8 of 15...
- Page 9 The result of this collision could be injury to your client or damage to your table and arms. Stop rotating your side arms in before contact is made with your table. SAVE THESE INSTRUCTIONS Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 9 of 15...
-
Page 10: Maintenance
Lubricate well on the exposed leg and raise and lower the table 2-3 times to distribute the lubricant. Wipe off excess at leg bottom. DO NOT USE soap and water for cleaning the legs. Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 10 of 15... -
Page 11: Section 3: Maintenance
5. If this furnishing is taken out of service, the electrical cord needs to be rolled up and placed inside the table to avoid damage while in storage. Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 11 of 15... -
Page 12: Trouble Shooting
Section 5, Technical Problems, and call Living Earth Crafts. If you are unable to resolve the problem with your table, please refer to Section 5, Technical Problems, and contact Living Earth Crafts. Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 12 of 15... -
Page 13: Technical Problems
4. Please remember that any unauthorized service will not be covered. Please be sure to contact us first. 5. As expressed in your warranty, damage from abuse or mishandling is not covered. Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 13 of 15... -
Page 14: Warranty
Lifetime warranty applies to original owner, as long as you own your table or 5 years after the model is discontinued or five years for private label tables Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 14 of 15... -
Page 15: Specifications
Amp. 2.7 A max. Input Amperage Rating Max. 12A Duty Cycle 10%, Max. 2 min./18 min. OUTLET STRIP Rated 12A - 125VAC - 60 Hz Operation manual – Pro Salon 04/30/10 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 15 of 15...
