Lyngsoe Systems tt8350LSA User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Page 1 of 34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the tt8350LSA and is the answer not in the manual?

Questions and answers

Summary of Contents for Lyngsoe Systems tt8350LSA

  • Page 1 Page 1 of 34...

  • Page 2: Table Of Contents

    Safety precautions................4 Getting started................8 Battery..................8 Installing the battery............... 8 Charging the battery............... 8 Removing and replacing the battery ..........9 Hand strap ................9 Starting the mobile computer..........9 Switch ON/OFF ................9 Touch screen and Stylus............... 10 Calibration window..............
  • Page 3 3.20 Volume & Sounds ..............23 Communication................24 Infrared (IrDA)..............24 USB and ActiveSync ............24 Scanning..................26 Scanning process..............26 Scanning position..............26 Printing..................27 Printing via Infrared ............. 27 Additional Programs ..............28 MagicKey................28 Camera ................. 28 Technical features ................

  • Page 4: Safety Precautions

    1 Safety precautions We thank you for the confidence you put in the t+t netcom´s industry handheld series. Before starting 1 - Check the packing of the handheld at its delivery. If you notice any damages due to the transport, immediately inform your dealer and send the handheld back to him.
  • Page 5 Safety precautions This symbol indicates information that, if ignored or applied incorrectly, creates the danger of death or serious personal injury. This symbol indicates information that, if ignored or applied incorrectly, create serious personal injury material damage. A circle with a diagonal line indicates something you should not do.
  • Page 6 Caution! Disassembly and modification ● Never try to disassemble the handheld in any way. This would break the war- ranty seal and void the warranty. Only removing the battery case and topcap (as described in this manual) has no impact on the warrantty Page 6 of 34...

  • Page 7: Battery Handling

    Caution! AC Power supply ● Do not use the power supply at a voltage other than the specified voltage of AC 100-240V. Also do not connect it to a multi-plug strip. Doing so may cause danger of fire and electric shock. ●...

  • Page 8: Getting Started

    2 Getting started 2.1 Battery The handhelds are powered by a rechargeable lithium-polymer battery. Charge the battery for 16 hours without any interruption before using it for the first time. Do not charge the handheld overnight in the car at minus temperatures, this would damage the battery.

  • Page 9: Removing And Replacing The Battery

    Removing and replacing the battery Attach the power supply to the Honda connector. Turn OFF the handheld by using the ON/OFF key. Unscrew the 4 screws of the battery case and remove the battery cover (picture 1). Remove the battery by using the notch (picture 8) and insert a new one. Screw the battery cover back again.

  • Page 10: Touch Screen And Stylus

    Touch screen and Stylus The high-contrast, non-reflective color display of the touch screen is clearly legible. To operate the touch screen, use only the stylus, which is located in the hand strap. Hold the stylus longer on an icon to have it run like a right mouse key (picture 23). Never use any sharp pens or objects! Calibration window The calibration window appears automatically after the firmware upgrade or when selecting...

  • Page 11: Keyboard

    Getting started Keyboard The keyboard of the handheld is by default automatically backlighted, as soon as the power key has been turned ON. Short key to start scanning process In non-scanning mode, keys to move inside the desktop or a text (left and right, up and down) 4 free programmable function keys, used for setting various program functions...
  • Page 12 Getting started Start button. Click to launch the Star t menu: Access to available Programs Files display in Favorites directory Files display in Documents directory Access to Control Panel / Network and Dial-up Connections / Taskbar and Start menu Access to Windows CE Help Running a program or application Indicates that th e battery is low...

  • Page 13: Reset

    2.4 Reset For a soft „Reset“, press the button at the back of the device by using a pen or the stylus (picture 25). For a „Hard reset“, press the Reset button at the same time as the ON/OFF key. 3 Settings - Control Panel This chapter provides basic instructions for customizing the mobile computer by adjusting settings.

  • Page 14: Certificates

    According to the program you want to open, do not forget to switch the correspon- ding button from Launch Application to Send Key Code. Confirm with or click to exit without saving the new entries. 3.3 Certificates This part is specially for the system administrator. Certificates are used by some applications for establishing trust and for secure communi- cations.

  • Page 15: Display

    3.5 Display Display Properties window is used to customize or change the desktop background image and appearance. Background Tab (picture 38) Select the desktop image from the drop-down list of the „Image“ field. To get an image from another folder, click Browse. To have the image cover the entire background, select „Tile image on background“.

  • Page 16: Password

    Fill in or edit the owner information. Select the Display Owner Identification check box to display this information when the mobile computer starts. Notes Tab Enter information in the Notes box to add more details if requested. Select Display owner notes box to include this information on the startup display. Network ID Tab (picture 47) Select the Network ID tab to setup identification for remote networks and enter the user name, password and domain name used to log on to the remote network.

  • Page 17: Regional Settings

    Power Properties are used to view and set the power parameters. Battery Tab (pictures 51 and 52) This window gives information about - actually used power source - battery or external (picture 51) - status of main battery - status of secondary battery (picture 52 - battery of Powerscan - only for tt8000) Schemes Tab (pictures 53 and 54) This window enables to setup the stand-by and suspend parameters.

  • Page 18: Remove Programs

    When opening the Number and Currency tabs, the keyboard input panel auto- matically appears. It can be used to input data in the different fields. If you want to close it, just double-click the k eyboard input panel icon the taskbar. Confirm with to apply changes and return to the main window.

  • Page 19: Stylus

    Confirm with OK to apply changes or click X to exit without saving the new entries. 3.15 Stylus Stylus Properties is used to adjust stylus double-click timing. Double Tap tab (picture 64) Double-click the checkerboard grid at a comfortable speed. Double-click the clapboard to test the settings.

  • Page 20: System Information

    3.17 System Information System Information gives information about the operating system version installed in the handheld, which is very important for any support request as well as about other features such as processor, RAM and ROM sizes... Page of 34...

  • Page 21: Ttn Device Tt8Xxx

    3.18 TTN Device tt8XXX TTN Device displays the control features special to the device and enables to define settings necessary for the use of additional devices. All settings must be defined before starting any application. ComPower Tab ComPower enables you to control Power Supplies (PSU) of the serial devices which are connected to the corresponding Com Ports.
  • Page 22 SetDefault Tab SetDefault enables you to re-boot your handheld in case of problems. Proceed as follows: Set Registry Default” will restore all registry settings to their default va- lues. This is usually done when registry settings are changed/corrupted manually or by some pure written application. Performing this operati- on must be confirmed by entering the following password:110793.

  • Page 23: Sounds

    3.19 Sounds 3.20 Volume & Sounds Volume & Sounds is used to set the audio parameters. Volume Tab Use the left and right arrow buttons to select the volume level. Select the options to which a sound will be applied. Sounds Tab Select the event from the Event field.

  • Page 24: Communication

    Communication 4 Communication 4.1 Infrared (IrDA) The Infrared interface is used to setup a direct connection in order to exchange or copy data between a PC or a mobile phone and the handheld, synchronize files between a PC and the handheld over ActiveSync, print on an Infrared compatible printer.
  • Page 25 Communication The installation starts. 3. window appearing => Get connected. Follow the instructions and click „Next“ to finish the installation. After ActiveSync installation is complete, the ActiveSync Setup Wizard helps to connect the mobile computer to the host computer. Set up a partnership to synchronize information bet- ween the mobile computer and host computer and customize synchronization settings.

  • Page 26: Scanning

    5 Scanning 5.1 Scanning process Depending on the version of tt7000/tt8000, the handheld may be equipped with a LASER SCANNER CLASS 2. DO NOT STARE INTO THE BEAM! The scanning process always runs in the background. Proceed as follows to start the scanning process: Double-click My Computer on the desktop.

  • Page 27: Printing

    6 Printing 6.1 Printing via Infrared It is possible to print via Infrared, provided that the printer has an Infrared interface. Proceed as follows to print: Activate the Infrared connection (see Communication - Infrared - page GB-28). Open the document to be printed. Select Print...

  • Page 28: Additional Programs

    7 Additional Programs 7.1 MagicKey 7.2 Camera Page 28 of 34...
  • Page 29 Additional programs Taskbar icons after having taken a photo Take a new photo without savin g the previous one Inactive Inactive Inactive Inactive Sets the photo brighter - click again to set the photo back in its original state Save the photo in the directory previously defined save directory 1- Define the photo...
  • Page 30 Additional programs Once the photo has been taken, different possibilities are available: Select the icon to make the photo brighter before saving it, Select the ic on to save the photo, Select the icon to delete the photo and take a new one. Photos are automatically saved in „jpg“-format 3- Correspondence between the camera functions and the keyboard of the handheld Delete the photo...

  • Page 31: Technical Features

    8 Technical features Operating system Windows CE .NET ® Version 5.0 Professional Processor Freescale i.MX21 350 MHz Memory 512 MB NAND Flash** RAM 64 MB SDRAM Additional memory* 1 x Compact Flash, 1 x SD/MMC Display Touch screen 3.5’’ Sharp TFT-LCD with LED backlight, 240 x 320 pixel, 65536 colors I/O Unit Keyboard...

  • Page 32: Special Hints

    Technical features 9 Special hints ActiveSync Only use the ActiveSync software version which is either delivered on CD together with your tt8000 or download it from www.tt-supprt.com. You can find the SDK for development purposes on the CD delivered together with your tt8XXX or download it from www.tt-support.com.

  • Page 33: Fcc Information To The User

    Canada L4Z 2A9 www.lyngsoesystems.com The Handheld Scanner TT8350LSA is certified for use in US and Canada for reading UHF passive tags compliant with the ISO 18000-6 B, Philips UCODE EPC 1.19 and EPCglobal UHF Class 1 Generation 2 protocols.

  • Page 34: Fcc Declaration Of Conformity

    This equipment was tested for FCC compliance under conditions that included the use of shielded cables and connectors between it and the peripherals. It is important that you use shielded cable and connectors to reduce the possibility of causing radio and television inter- ference.
