Base Components
1
2
3
Front View
1
Base antenna / headset holder
2
CHARGE indicator (LED)
3
PAGE key
4
DC power input
5
Telephone line jack
2
4
5
Back View
Front View
2
3
4
5
6
1
Headset Jack
2
MESSAGE WAITING* indicator (LED)
3
TALK / FLASH key
4
PHONEBOOK / LEFT (Phonebook / left cursor) key
5
DOWN key
6
UP key
7
END key
8
CID / RIGHT (Caller ID* / right cursor) key
9
MENU / SEL (Menu / Select) key
10
INT'COM / CLEAR (Intercom / Clear) key
11
VOICEMAIL */ MUTE key
12
PAUSE / REDIAL key
* For more information, see Subscription Services on page 21.
