KSJ MG26-F2 User Manual

Glossmeter
Hide thumbs Also See for MG26-F2:
Table of Contents

Advertisement

Quick Links

Download this manual
MG26-F2
USER's MANUAL
Please read this manual seriously before using !

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MG26-F2 and is the answer not in the manual?

Questions and answers

Related Manuals for KSJ MG26-F2

Summary of Contents for KSJ MG26-F2

  • Page 1 MG26-F2 USER's MANUAL Please read this manual seriously before using !
  • Page 2 Made in China Add.: Middle of Binnan Street, Dongbin Industrial Zone, Donghai Bincheng, Quanzhou, Fujian 362000, China Tel.: +86-595 22391040 Fax: +86-595 22391048 Website:www.ksj.cn www.glossmeter.cn E-mail: sales@ksj.cn sales@hidea.cn...

  • Page 3: Table Of Contents

    CONTENTS ......Brief Introduction ......Specifications ......Main Functions ......Construction ......Measurement ......Warning And Notice ......Menu Operation ......Using Software ......Trouble shooting ......Warranty ......Packing List...

  • Page 4: Brief Introduction

    BRIEF INTRODUCTION Thanks for your choice to purchase MG26-F2. MG26-F2 is designed and manufactured according to ISO2813 and GB9754. It is also compatible with the standards of ASTM D523 , ASTM D2457 , GB/T13891, GB7706, and GB8807. The technical parameters conform with JJG696-2002.

  • Page 5: Specifications

    SPECIFICATIONS Specifications MG26-F2 Glossmeter Unit 0.0 119.9 120 2000 Measuring Range 0.0 119.9 120 1000 Resolution Repeatability Reproducibility 1.5% Deviation Zero-point Deviation Operating Temperature...
  • Page 6 SPECIFICATIONS Specifications MG26-F2 Glossmeter Unit Storage Temperature Up to 85%, no moisture condensation, for operation Relative Humidity 9 10 Measuring Spot 9 16 Power Supply One AA-sized battery, 1.2V 1.5V,Rechargeable or alkaline. It's different to battery types. An alkaline battery Consumption may support 20000 measurements or more.

  • Page 7: Main Functions

    Large memory for measurement data. In 2-angle mode, more than10000 measurements or 999 groups can be allowed to stored in MG26-F2. Inquiry for data in memory. Through menu operation you can browse the data in memory.
  • Page 8 20000 measurements. The power for communicating is taken from a PC. Prompt for low battery and full memory. Automatic shutoff. If no operation MG26-F2 will be turned off by itself in a preset time interval.

  • Page 9: Construction

    CONSTRUCTION Whole set of MG26-F2 Ô Display Window Menu Wheel Front Shell Rear Shell Bat. Chamber Cover Holder...
  • Page 10 CONSTRUCTION Main Device RS232 Port Measuring Button Rear Shell Mark For Location Front Shell Incidence Direction Label Measurement Aperture...
  • Page 11 CONSTRUCTION Holder With Calibrating Standard Calibrating Standard Gloss Value Label Holder...
  • Page 12 CONSTRUCTION Battery in Position Battery Chamber Cover Battery With Positive Pole Up! AA or LR6, Alkaline or Rechargeable. Rear Shell Front Shell...

  • Page 13: Measurement

    MEASUREMENT Turn on the meter Lay the main unit into the holder, then push down the Menu Wheel t o turn on the meter The infos of model and series number will be shown in the Display Window, meanwhile the meter performs self-diagnose and self-calibrating. After passing this procedure the display should turn to measuring mode, the meter would be ready for operation.
  • Page 14 MEASUREMENT Measuring and measurement interface Remove the holder and lay the Measur ement Aperture just against the position that you want to measure. Then push the Measuring Button. Within 2 seconds a measurement will be completed. Meanwhile the result will be shown the Display Window as below and stored into the memory automatically.
  • Page 15 MEASUREMENT Deleting measurements To delete a current measurement please push down operation button for more than 2 seconds. Note Only the measurements in a current group can be deleted one by one. Turn off the meter The meter will shut off automatically according to the preset time. See page 25.. Note After turning off the meter will be in a sleeping state which consume little power.
  • Page 16 MEASUREMENT Notice The holder removed from the main device should be kept in a safe and clean place to prevent from damage or pollution. While measuring please keep environment light f rom directly irradiating into the Measurement Aperture. If necessary, especially under strong light, shade it with a piece of light-tight cloth.
  • Page 17 MEASUREMENT If memory is full of data, a prompt would be shown as below in Display Window. In this case measuring operation will be in order, but the results can't be stored into memory any more. It is better to upload the data in memory to PC and clear the memory. FULL When a battery runs out, the following message will be shown.

  • Page 18: Warning And Notice

    WARNING AND NOTICE The whole set of the meter should be kept in dry and non-corrosive environment under the temperature between to +60 . Although the exterior parts of the meter are made of good quality plastic, they may not resist some chemicals, especially some strong solvents, such as acetone and so on.

  • Page 19: Menu Operation

    MENU OPERATION Menu interface On the measurement Interface, push the Menu Wheel to enter the menu interface as below. M e a s u r e m e n t D a t a C a l i b r a t i o n S e t u p Option selecting Turn up or down the Menu Wheel to select the options.
  • Page 20 MENU OPERATION Measurement Option Select this option and push down the Menu Wheel to return to measurement interface. Data menu and its submenu I n q u i r y G r o u p N o . 0 0 1 D a t a I n q u i r y Data...
  • Page 21 MENU OPERATION Inquiry submenu In data menu select inquiry option and push down the Menu Wheel to enter the inquiry submenu. Turn up and down to set the group number that you want to inquire and then push down the Menu Wheel to enter the inquiry interface. Here you can browse all the measurements in this group by turning the Menu Wheel.
  • Page 22 MENU OPERATION Delete All submenu Enter the submenu and turn the Menu Wheel to select to clear all data in memory. Or else select to exit. Calibration Menu and its submenu C a l i b r a t i o n Modify Values 20"...
  • Page 23 MENU OPERATION Modify Values submenu Enter the submenu, turn the Menu Wheel to select a value and push down the Menu Wheel to confirm, then turn the Menu Wheel to modify the value, push down the Menu Wheel to confirm again. It is the same operation for other values. Calibrate option Calibration...
  • Page 24 MENU OPERATION Setup menu and its submenu A n g l e M o d e " 6 " 2 " 6 " S e t u p S h u t o f f T i m e A n g l e M o d e 3 0 S Setup S h u t o f f T i m e...
  • Page 25 MENU OPERATION Angle Mode submenu S i n g l e _ A n g l e " 6 " 2 0 " 6 " Enter the sub menu , select an option and push down the Menu Wheel to confirm. Then it will be changed to the measurement interface automatically.
  • Page 26 MENU OPERATION Group submenu Enter the menu, turn the Menu Wheel to set a number of measurements in a group and confirm. Then it will return to the measurement interface automatically. Note The range is between 1 to 99.

  • Page 27: Using Software

    Then we can process the data uploaded and export them to an E xcel file or as a printout. We can also operate on a PC to set the measuring conditions for MG26-F2 and clear its memory. Software installation and uninstall To use KSJ Data Operator, you need the following: an IBM compatible PC with a CD-ROM.
  • Page 28 USING SOFTWARE How to connect between MG26-F2 and a PC There are two connecting cables for MG26-F2 to connect with a PC. One is a RS232 Cable (9 pins), and the other is a USB Adapter ( optional extra). Using a COM port Simply onnect one terminal to MG26-F2 and the other to a COM port on a PC.
  • Page 29 USING SOFTWARE Software interface Interface of Current Data (default) Title Bar Menu Bar Tool Bar Upload Area Data Area Function Area...
  • Page 30 USING SOFTWARE Interface of Historical Data Title Bar Menu Bar Tool Bar Query Area Data Area Function Area...
  • Page 31 Menu commands Data Operation Current Data Connect MG26-F2 and a PC, turn on MG26-F2, run KSJ Data Operator, set the upload date, then click Upload button to upload data. Notes The data is uploaded one by one group with sounds and flash indicating..
  • Page 32 USING SOFTWARE Meter Setup This group of commands is used to set the measuring conditions of MG26-F2 in a communication state. Angle Mode There are six options to be select including single angle, double angle and treble angle. Group Presetting To preset a number of measurements in a group, you can choose from 1 to 99.
  • Page 33 There are three options to be selected. Clear Memory This is for cllearing all the data stored in the memory of MG26-F2 permanently. And so It is better to reconsider before clearing. Help...
  • Page 34 USING SOFTWARE Tool bar Current Data : Equivalent to the corresponding menu command. Historical Data Equivalent to the corresponding menu command. Print Equivalent to the function button of print. Print Equivalent to the corresponding menu command. Function Button Delet Button To delete selected data shown in the Data Area permanently.

  • Page 35: Trouble Shooting

    TROUBLE SHOOTING Errors in self-diagnose and self- calibration When the meter is turned on with the Holder, the P l e a s e warning message (on right hand side) may come 1 . C l e a n S T D . out.
  • Page 36 TROUBLE SHOOTING 3. Recalibrate. Recalibate the meter. A big temperature difference between environment and the meter would badly affect measuring, and the warning message will be shown. In this case please wait for a period of time till the temperature get to a balance and then calibrate the meter. Moisture condensation When the meter is taken from a cold location to a hot environment, moisture conden- sation occurs easily.
  • Page 37 It is all right to use a Series Port to carry out a communication. Problems u sually occur because : MG26-F2 don't connect with a PC properly. MG26-F2 is not in a turn-on state. No data is in the meter's memory.
  • Page 38 TROUBLE SHOOTING How to verify your glossmeter A glossmeter is a kind of metrical instruments. It is important and necessary to keep its accuracy. For this reason the meter must be verified in a period of time, usually a year. Then, we recommend you to verify the glossmeter as follow: Send it to a public organization which is authorised by the government and able to perform the gloss verifying.

  • Page 39: Warranty

    The limited warranty period is one year commencing on the date of purchase. If your meter needs service, carry it to the local reseller or contact us at http://www.ksj.cn for repair. We provide spare parts anytime for distributors and customers.

  • Page 40: Packing List

    PACKING LIST Main Device, Model MG26-F2 1 Unit Holder With Calibrating Standard 1 Unit RS232 Cable 1 Piece KSJ Data Operator 1 CD Carrying case 2 Piece User's Manual 1 Piece Tracable Certificate 1 Piece Note: The USB Adapter is provided as an optional accessory.
