DC750 (Rev 1)
Front
(A) Front Panel Controls and USB Port
Back
B) Power Supply
(
(C) Serial Port
(D) VGA Port
Included items:
•
Sourcefi re DC750 (Rev 1) or DC750 (Rev 2)
•
one power cord
•
one straight-through Cat 5e Ethernet cable
•
rack-mounting kit
Required items:
•
fl athead and Phillips screwdrivers for the
rack-mounting kit
•
laptop or monitor and keyboard to connect
directly to the Defense Center
!
WARNING!
This Sourcefi re appliance should be installed and maintained by
qualifi ed personnel only. Keep in mind the following safety
information to avoid system damage or personal injury:
•
Remove all factory packaging before using the appliance.
•
Provide adequate ventilation to prevent overheating. Do not
cover or block vents, or otherwise enclose the appliance.
•
The appliance must be properly grounded when connecting
power to the power outlet.
•
At all times, keep the chassis area free from dust.
•
Lifting the chassis for rack installation may require two people,
as the unit is heavy.
•
To avoid electrical shock, do not open or remove the chassis
covers or metal parts without proper instruction.
Quick Start Guide - DC750
(E) Management Interface
(F) Alternate eStreamer Interface
(G) USB Ports
QUICK START GUIDE
Defense Center 750
DC750 (Rev 2)
Front
(A) Front Panel Controls and USB Ports
Back
B) Power Supply
(
(C) Serial Port
(D) VGA Port
Thank you for choosing Sourcefi re.
Before installing this device, download and follow the
instructions in the Sourcefi re Support Welcome Kit
(https://support.sourcefi re.com) to get started with
Sourcefi re Support, and to set up your Customer
Center account.
Page 1 of 4
(E) Management Interface
(F) Alternate eStreamer Interface
(G) USB Ports
9770 Patuxent Woods Drive
Columbia, MD 21046 USA
800.917.4134 | +1.410.423.1901
support@sourcefi re.com
©2014 Cisco and/or its affi liates.
All rights reserved.
2014-5.2-3
Advertisement
Summary of Contents for Source fire DC750
- Page 1 (D) VGA Port (G) USB Ports (G) USB Ports (D) VGA Port Included items: • Sourcefi re DC750 (Rev 1) or DC750 (Rev 2) Thank you for choosing Sourcefi re. • one power cord • one straight-through Cat 5e Ethernet cable Before installing this device, download and follow the •...
- Page 2 Log into the web interface using admin as the user and Sourcefi re as the password and continue with Performing the Initial Setup on page 3. Note that the password is case-sensitive. Quick Start Guide - DC750 Page 2 of 4 2014-5.2-3...
- Page 3 IP address you confi gured in the previous procedure. Refer to the Sourcefi re 3D System Installation Guide for information to guide you through the start-up pages for the Defense Center. Quick Start Guide - DC750 Page 3 of 4 2014-5.2-3...
- Page 4 DC750 (Rev 1) only: A blinking amber light indicates that the system is in a non-critical error condition. DC750 (Rev 1) only: An amber light indicates that the system is in a critical or non-recoverable error condition. No light indicates POST/system stop.
