Summary of Contents for KingtronicRF PKE-C801
- Page 1 PKE-C801 Keyless Entry System With Car Alarm Installation & Operation Instructions Kingtronic RF Corp. www.kingtronic.tw office@kingtronic.tw...
-
Page 2: Trunk Open
PKE-C801 Keyless Entry System With Car Alarm Installation & Operation Instructions PKE-C801 – Keyless Entry System with Car Alarm System offers convenience and security in one package. Convenience Features: The PKE-C801 includes keyless entry. This will allow you to lock and unlock your car doors on vehicles equipped with power door locks. The remote trunk release feature is handy as well allowing you to open your cars trunk via the remote control. - Page 3 Main Unit ： P.S. Lock/Unlock, Trunk open, Siren output (+) positive or (-)negative can adjust for your different vehicle. Just change the PIN position. Installation：...
- Page 4 Operation Instructions： A. System Power ON： Confirmed vehicle’s door closed then connect the wire harness to the Main Unit after all wiring to vehicle is complete. LED ON and enter the disarming mode. B. Programming Transmitter： (＊Factory Default Setting) (2-programming method) The system state 1.
- Page 5 confirming chirp and transmitter’s LED flash once. The first transmitter is now programmed. 2. Press button on the second transmitter until the siren responds with 2-confirming chirp and transmitter’s LED flash once. The second transmitter is now programmed. 3. Apply the same procedure to program 3 、and 5 transmitter.
- Page 6 C. Active Disarming – Unlock & Disarm The system state --AUTO 1. Arming 2. Door lock 3. Ignition OFF. 4. AUTO 1. Transmitter is on AUTO state (Keyless entry function; auto-lock/unlock door) 2. When user take transmitter into effective range around the vehicle 2-meters. 3.
- Page 7 E. Auto-Lock The system state 1. Disarming 2. Door Unlock 3. AUTO/RKE 4. Vehicle’s door closed 1. When vehicle’s driving speed over 20km/h continue 20 seconds. The vehicle’s door will auto-lock. 2. When turn ignition switch from “ON” to “OFF”. The vehicle’s door will auto-unlock.
- Page 8 1. When vehicle’s Ignition switch ON position/ Door Open/Trunk Open . The Main Unit will pause transmit signal. 2. At this situation, transmitter can not working. G. Disarming without a Transmitter 1. If the transmitter is lost or inoperative. 2. Enter the Vehicle ,door closed and turn the ignition switch “ON” “OFF” 3 times stay in “ON”...
