Getting Started

Plug your Hydroxyl Generator into power, your display will illuminate to one of these two states:
Indicates unit is on
NOTE:
ON/ OFF option
Fan Speed Increase
will not work
on this screen
Language
English
Chinese
Fan Speed Decrease
Powering On/Off the Device
™
To turn your MySpace device on or off, navigate your menu screen to any screen except
the language screen using the left and right buttons (
( ) once to turn your device on or off. Please note that device on/off option does not
work on the language screen.
Menu Screen Standby/Wakeup
™
Your MySpace device is designed to conserve energy and provide you with a distraction
free experience, therefore the menu screen of your MySpace
mode after 30 seconds of inactivity. In order to wake the menu screen, tap any of the
buttons once.
Language Selection
Once on the language selection menu (see previous section 'Getting Started'), select the
language that you want using the up and down arrows (
button ( ) to confirm selection and apply the language to the menus. You will see an
asterisk (*) on the selected language.
Copyright ©2017, HGI Industries Inc.
Document Ref.=MSP01LP010 _ Revision 20170425
6
MAIN
SCREEN
Indicates unit is off
Live data Access Point
Station Details
OH Run 1520 SSID:
SSID: OHAIR
OH Temp: 33.4 C OH-AIR_UI_0143
IP:
OH Humid: 41.0 % IP: 255.255.239.25
Live data
Access Point
Fan: 12.0 V
OH-AIR_UI_0143
OH Hours: 1666
IP: 255.255.239.25
Status: OK
pwd: admin007
Live data
FW ver: UI_3.03-17
DriveTemp: 55.2
Serial number:
Live data
DriveTemp: 55.8
Serial number:
UII_00...00143
), then tap the center button
™
device will go into standby
) and then press center
HGU™ Maintenance and Replacement
CAUTION: Your device MUST BE unplugged/disconnected from the mains.
Step 1- Refer to previous section 'Removing Cover for
Cleaning and Replacement' to remove the front cover.
B
A
C
Step 2 - To remove the metal cover plate, remove screws
D
"A-D" using PH1 Philips head screw driver. Lift up the plate
to remove it.
Step 3 - To remove the chamber cover, remove screw
"E" using PH1 Philips screw driver. Lift up the chamber
E
cover to expose the optic assembly (HGU™ assembly).
Step 4 - To remove the HGU™ assembly, remove two
HGU™ mounting screws "F" and "G". Grasp the center
baffle "H" and manipulate side to side whilst firmly pulling
F G
it away from the connector and lifting out.
Step 5 - Gently clean the optic with a glass cleaner and
a lint free cloth. Ensure optic is completely dry before re-
insertion.
H
Step 6 - While the HGU™ assembly is out, remove dust
and clean with dry cloth.
I
Step 7 - Carefully locate wafer connection "I" into black
socket,
See next page
