Summary of Contents for Zjiang ZJ-5890T
- Page 1 58mm Thermal Receipt Printer -Operating Manual...
- Page 2 Safety Precautions Version Feb, 2017 Please be sure to read this manual carefully before using the printer operation All Rights Reserved to ensure correct and safe use of the printer. Security Warning Warning：Don’t touch the printer paper cutter and tear serrated avoid scratching Warning: Print head for the heat-generating components, just after the end of the This manual is the Company's intellectual property rights, copyright protection printing process and print can not touch the print head and the surrounding parts,...
-
Page 3: Technical Parameters
58 mm Thermal Receipt Printer Operating Manual 1.Application Area 3.Installation Roll Paper 58 thermal printer using thermal 58mm paper roll, using easy paper loading mechanism, very convenient Cash register and POS System receipt printing EPT and POS System receipt printing paper loading. - Page 4 58 mm Thermal Receipt Printer Operating Manual ： 2 Choose the language you will use, and click” OK”, you will see following picture. Click “Next”: 5. Click “Next”, then you will find following picture, here choose “Install”. If your PC have any anti virus software, please allow this install.
- Page 5 58 mm Thermal Receipt Printer Operating Manual Select your printer port that matches the "port" option, select the printer you want to feature 7.Click “Begin Setup”,You will see following picture, choose “Install”, in the “device settings”. In conventional option "Print Test Page" to verify that OK. Then “install this driver anyway”...
- Page 6 58 mm Thermal Receipt Printer Operating Manual 、 2 Set network port shown as following: Choose “Port”, then click “Add port” 4. According Add Standard TCP / IP Printer Port Wizard, click Next continued following the installation, as shown below: 5..Input IP address which you can find on the self-test page, as shown below: 3.Choose the “standard TCP / IP port”, and then click the New Port, as shown below.
- Page 7 58 mm Thermal Receipt Printer Operating Manual 9.Return to the "General", click "Print Test Page", as shown below: 7.According Add Standard TCP / IP Printer Port Wizard, click “Finish “to complete the installation, as shown in the following figure: 8. Find the printer driver-pos58 , Click the “Printer property”, and choose the “Ports”, select the correct IP port, click "Apply", as shown below: 6.The operate instruction of RS232/Parallel port 6.1 For RS232 (COM)port (If you printer is rs232 port)
- Page 8 58 mm Thermal Receipt Printer Operating Manual 2.Select the list of ports "COM1" → "Configure Port", choose the right option. Here are our Click "Apply" again. default parameter, you can see the parameters of serial port from self-test page Return to the "General" tab, click "Print Test Page" as shown below: Click "Apply", then click "OK", you will see the following picture: (Note: This setting must consistent with the setting parameters of serial port from the self-test page, otherwise it may print garbled words will be garbled words)
- Page 9 58 mm Thermal Receipt Printer Operating Manual If the printer prints a normal page, then it shows that the work was successful. 6.2 Connection of Parallel port (if your choose to use parallel port) 6.3 Bluetooth port to be used (if your printer can support bluetooth function ) 1.
- Page 10 58 mm Thermal Receipt Printer Operating Manual 4:if you can see screen as below,then the device is searching the bluetooth printer,please wait. 7:if you can see the screen as below, that means the Bluetooth printer is already connected. Please notice the assigned COM ports ,then Click”Finish”. 5:Once the Bluetooth printer is found.
- Page 11 58 mm Thermal Receipt Printer Operating Manual Step 2: 2. Turn on the Bluetooth setting of IOS device , then click “POS-Printer”: - Find the File Named “ SDK” from the CD driver, Then follow the path : “ Android SDK BLUETOOTHDEMO ---bin---BT-POSPrinter.APK “...
- Page 12 58 mm Thermal Receipt Printer Operating Manual 4. Select the way of communication of printers, “Bluetooth” or “WIFI”: (Image 4) 5, If connect with Bluetooth, then you can click “ Select Printer” first, you will search the “Bluetooth Printer” (the default name of printer is Bluetooth Printer), click it to be connected.
-
Page 13: General Troubleshooting
58 mm Thermal Receipt Printer Operating Manual 8, Other features of this APP: 10.General Troubleshooting ① Send HEX: In the text box, enter the hexadecimal data, click “Send HEX”, then can send text box hexadecimal data to the printer. 1: Why serial port printer printing messy code? ②... - Page 14 58 mm Thermal Receipt Printer Operating Manual 12: Printing speed is very slow for serial printer A: follow this path and change the set accordingly : Driver -- Properties -- Device Settings -- Print Mode -- Print as soft font. 13: Water or other liquid spills into the printer A: Cut off the power,we can dry the main board or printer head with a hair dryer, careful of the temperature ( average 50 degree is ok )
