Installation and Operating Instructions
RT 10
Room temperature controller for
heating appliances with
ROOM TEMPERATURE CONTROLLER
bus-enabled Heatronic 3 and TD 200
FOR WORCESTER HEATING APPLIANCES
RT 10
WITH BUS-ENABLED HEATRONIC 3 AND TD 200
7719 002 505
Order no. 7 719 002 505
INSTALLATION,
USER INSTRUCTIONS &
CUSTOMER CARE GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RT 10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Worcester RT 10

Summary of Contents for Worcester RT 10

  • Page 1 RT 10 Room temperature controller for heating appliances with ROOM TEMPERATURE CONTROLLER bus-enabled Heatronic 3 and TD 200 FOR WORCESTER HEATING APPLIANCES RT 10 WITH BUS-ENABLED HEATRONIC 3 AND TD 200 Order no. 7 719 002 505 INSTALLATION, USER INSTRUCTIONS &...
  • Page 2 Dear customer, Congratulations on having decided in favour of a top-quality product from our company. The RT 10 offers everything you can expect from a modern heating control: It is both reliable and energy saving. Like all Bosch Group products, the...

  • Page 3: Table Of Contents

    Contents Contents Safety precautions General information Symbols Troubleshooting Technical data for the accessory item Standard package Technical data Accessories Description of function Installation Assembly Electrical connections Operation Change required room temperature, time limited (a) 11 Advance the next switching time and the associated operating mode to the current time (b) (Advance Heating)

  • Page 4: Safety Precautions 4 4 General Information

    Safety precautions Safety precautions Symbols B These instructions must be Safety instructions in observed to ensure correct opera- this document are identi- tion. fied by a warning-trian- B The accessories should be installed gle symbol and are by an authorised heating installer printed on a grey back- only.

  • Page 5: Technical Data For The Accessory Item

    0.5 K increments ing appliance and permissible ambi- TD 200. ent temperature 0... +50 °C Class of protection The RT 10 allows the control of the Type of room temperature of an unmixed heat- protection IP20 ing circuit. Standard package Accessories...

  • Page 6: Description Of Function

    Factor for room heating: 1 K in 10 minutes • If Automatic mode is active on the TD 200, it is possible via the RT 10 To reach the desired room tempera- to set the required room temper- ture, the heating requires 50 minutes ature restricted to a certain time on account of the 5 K difference.

  • Page 7: Installation

    Assembly The control quality of the RT 10 depends on the installation location. 6 720 612 218-04.1R Fig. 2 Remove front casing The installation location must be suita- ble for controlling the entire heating system.
  • Page 8 Installation 3,5 mm 6 mm 6 mm 3,5 mm 6 720 612 218-05.1R Fig. 3 Fasten base plate to the wall B Make all electrical connections (see Fig. 4). B Replace front cover. 6 720 612 218 GB (05.09)

  • Page 9: Electrical Connections

    Installation Electrical connections B Bus connection from the RT 10 to B To avoid inductive influences, sepa- additional devices using the bus rate all leads carrying low voltage (e. g. TD 200): from lines of 230 V or 400 V (mini- Use electrical cables correspond- mum spacing 100 mm).

  • Page 10: Operation

    Operation Operation Operating elements Symbols Current room temperature auto High Frost auto Automatic mode Fig. 5 Next switching time and associated operating mode = High Operating elements = Low Selection knob = Frost Change the required room advanced to the current time temperature until the next Burner on symbol switching time of the heating...

  • Page 11: Change Required Room Temperature, Time Limited (A)

    TD 200 applies = Low again. = Frost If the RT 10 calls for heat, the boiler to the current time. operates until the set room temper- is shown on the display and the ature is reached.

  • Page 12: Frost Protection

    The TD 200 enables the room temper- ature for the Frost operating mode to be set from 5˚C to 30˚C. With the default setting the room temperature for the room in which the RT 10 is mounted is 7 °C. 6 720 612 218 GB (05.09)
  • Page 13 Ventilate fully for a short time (com- pletely open windows). • The temperature in the room where the RT 10 is installed acts as a • Turn the thermostatic valve during guide parameter for the entire heat- ventilation or switch to low setting.
  • Page 14 In the event of a fault in the heating appliance, the display will show e.g. A7 E. In the event of a fault in the RT 10, the display will show e.g. 1A4 E. Here the figure 1 stands for a fault in...
  • Page 15 Choose a better installation temperature is RT 10 not suitable, e.g. location (see Chapter 2.1) and greatly outer wall, proximity to win- have the RT 10 moved by a exceeded dow, draught, ... professional. Excessive room Temporary effect of heat...
  • Page 16 USER INSTRUCTIONS & CUSTOMER CARE GUIDE Worcester, Bosch Group Cotswold Way, Warndon, Worcester WR4 9SW. Tel. 01905 754624 Fax. 01905 754619 www.worcester-bosch.co.uk Worcester Bosch Group is a trading name of BBT Thermotechnology UK Ltd. 6 720 612 218 (05/09) OSW...
