USER MANUAL FOR
3U GENESYS
TM
10kW/15kW High Voltage
Programmable DC Power Supplies
Document: 83-532-400 Rev A
Your distributor:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3U GENESYS and is the answer not in the manual?

Questions and answers

Summary of Contents for Schultz Electronic 3U GENESYS

  • Page 1 USER MANUAL FOR 3U GENESYS 10kW/15kW High Voltage Programmable DC Power Supplies Document: 83-532-400 Rev A Your distributor:...
  • Page 4 Genesys Manual Supplement For units equipped with the “IEMD” option, If IEEE-488 with Multi-drop is installed, also refer to IEMD User’s Manual 83-030-200 For units equipped with the “LAN” option, If Local Area Network with Multi-drop is installed, also refer to LAN User’s Manual 83-034-100...

  • Page 5: Table Of Contents

    Table of Contents WARRANTY ......................... 8 ENGLISH ..........................9 FRENCH ..........................12 GERMAN ..........................15 ITALIAN ..........................18 PORTUGUESE ........................21 SPANISH ..........................24 1 GENERAL INFORMATION ................... 27 User Manual Content ....................... 27 Introduction ........................27 Accessories ........................29 Model Number Format .....................
  • Page 6 CV/CC Signal ........................63 5.10 PS_OK Signal ........................63 5.11 Safe-Start and Auto-Restart Modes ................. 63 5.12 Front Panel Locking ......................64 5.13 Over-Temperature Protection (OTP)................64 5.14 Last Setting Memory ......................65 6 SERIES AND PARALLEL OPERATION ..............66 Series Operation ......................

  • Page 7: Warranty

    WARRANTY This TDK-Lambda Americas Inc. product is warranted against defects in materials and workmanship for a period of five years from date of shipment. During the warranty period, TDK-Lambda Americas Inc. will, at it’s option, either repair or replace products which prove to be defective. LIMITATION OF WARRANTY The warranty shall not apply to defects resulting from improper or inadequate usage or maintenance by the buyer, buyer supplied products or interfacing.

  • Page 8: English

    ENGLISH SAFETY INSTRUCTIONS CAUTION The following safety precaution must be observed during all phases of operation, service and repair of this equipment. Failure to comply with the safety precautions or warnings in this document violates safety standards of design, manufacture and intended use of this equipment and may impair the built-in protections within.

  • Page 9: Safety Instructions

    PARTS SUBSTITUTIONS & MODIFICATIONS Parts substitutions and modifications are allowed by authorized TDK-Lambda Americas Inc. service personnel only. For repairs or modifications, the instrument must be returned to an authorized TDK- Lambda Americas Inc. Service facility. SAFETY INSTRUCTIONS ENVIRONMENTAL CONDITIONS The Genesys Power Supply series safety approval applies to the following operating conditions: *Indoor use...
  • Page 10 FCC COMPLIANCE NOTICE: Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 11: French

    FRENCH CONSIGNES DE SECURITE ATTENTION Les consignes de sécurité suivantes doivent être observées pendant toutes les phases de l'utilisation, entretien et réparations de cet équipement. Le non-respect des consignes de sécurité et des avertissements dans ce document viole les normes sécurité de conception, fabrication et utilisation prévue de cet équipement et peut compromettre les protections incorporées en lui.

  • Page 12: Consignes De Securite

    CONSIGNES DE SECURITE SUBSTITUTIONS ET MODIFICATIONS DE PIECES Les substitutions et modifications de pièces ne peuvent être effectuées que par les techniciens d'entretien agréés TDK-Lambda Americas Inc. Pour les réparations ou les modifications, l'instrument doit être renvoyé à un centre d'entretien agréé TDK-Lambda Americas Inc. CONDITIONS ENVIRONNEMENTALES L'approbation sécurité...
  • Page 13 NOTE CONCERNANT LA CONFORMITE FCC : Nota : Cet équipement a été testé et s'est avéré conforme aux limites pour un appareil numérique Classe A selon la part 15 des règles FCC. Ces limites sont conçues pour assurer une protection raisonnable contre les interférences dangereuses lorsque l'équipement est utilisé...

  • Page 14: German

    GERMAN SICHERHEITSVORSCHRIFTEN VORSICHT Die folgenden Sicherheitsvorschriften müssen in allen Phasen des Betriebs, der Wartung und der Reparatur der Anlage eingehalten werden. Eine Missachtung der Sicherheitsvorschriften und Warnhinweise aus diesem Handbuch führt zur Verletzung der bestehenden Sicherheitsstandards für Design, Produktion und der zweckbestimmten Verwendung der Anlage und kann die integrierten Schutzvorrichtungen beschädigen.
  • Page 15 SICHERHEITSVORSCHRIFTEN EINGANGSLEISTUNG Verwenden Sie keine AC-Spannung, die die Eingangsleistung und Frequenzrate dieses Gerätes übersteigt. Die Eingangsspannung und Frequenzrate der Genesys Reihe der Netzgeräte verfügt über drei Eingangsbereiche, je nach bestelltem Bautyp. Die Bereiche sind 342-440VAC & 432-528VAC, 50- 60Hz. Aus Sicherheitsgründen sollten die Spannungsschwankungen der Hauptstromversorgung den oberen Spannungsbereich nicht übersteigen.
  • Page 16 SICHERHEITSVORSCHRIFTEN Das VORSICHTSYMBOL deutet auf eine Gefahr hin. Die Aufmerksamkeit wird auf ein Verfahren gelenkt. Eine Missachtung der korrekten Einhaltung des Verfahrens kann zu Materialschaden führen. Ein VORSICHTSYMBOL darf nicht übergangen werden bis alle angezeigten Umstände vollkommen verstanden und eingehalten werden. FCC EINHALTUNGSVERMERK: Hinweis: Das Gerät wurde geprüft und erfüllt die Grenzwerte für ein digitales Gerät der Klasse A gemäß...

  • Page 17: Italian

    ITALIAN NORME DI SICUREZZA ATTENZIONE La seguente precauzione di sicurezza deve essere osservata a tutti gli stadi del funzionamento, della manutenzione e della riparazione di questa apparecchiatura. L'inosservanza delle precauzioni o delle avvertenze di sicurezza contenute in questo documento viola gli standard di sicurezza della progettazione, della produzione e dell'uso previsto di questa apparecchiatura, e può...

  • Page 18: Norme Di Sicurezza

    NORME DI SICUREZZA SOSTITUZIONI E MODIFICHE DEI COMPONENTI I componenti devono essere sostituiti o modificati unicamente da addetti autorizzati di TDK-Lambda Americas Inc. Per riparazioni o modifiche, restituire lo strumento al centro assistenza di TDK-Lambda Americas Inc. CONDIZIONI AMBIENTALI L'approvazione della sicurezza della serie di alimentatori Genesys™ è valida in presenza delle condizioni d'uso seguenti: *Uso in interni *Temperatura ambiente: 0ºC - 50ºC...
  • Page 19 NORME DI SICUREZZA AVVISO DI CONFORMITÀ FCC: NB: Questa apparecchiatura è stata testata ed è risultata conforme ai limiti per i dispositivi digitali di Classe A, ai sensi della parte 15 dei Regolamenti FCC. Tali limiti sono formulati per offrire ragionevole protezione dalle interferenze pericolose quando l'apparecchiatura viene azionata in ambienti commerciali.

  • Page 20: Portuguese

    PORTUGUESE INSTRUÇÕES DE SEGURANÇA CUIDADO As seguintes precauções de segurança devem ser respeitadas em todas as fases de funcionamento, assistência e reparação deste equipamento. A não observância dos avisos e precauções de segurança constantes neste documento viola os padrões de segurança da concepção, fabrico e utilização pretendida deste equipamento, podendo danificar as protecções integradas no seu interior.
  • Page 21 INSTRUÇÕES DE SEGURANÇA CIRCUITOS SOB TENSÃO Os operadores não devem retirar a cobertura do instrumento. A realização de ajustes internos ou substituições de componentes só é permitida se realizada por pessoal especializado da TDK-Lambda Americas Inc. Nunca substitua componentes com o cabo de alimentação ligado. Para evitar ferimentos, desligue sempre a energia, descarregue os circuitos e desligue a fonte de tensão externa antes de tocar nos componentes.
  • Page 22 INSTRUÇÕES DE SEGURANÇA DECLARAÇÃO DE CONFORMIDADE FCC: Nota: Este equipamento foi testado e considerado estar dentro dos limites necessários para um dispositivo digital da Classe A, em conformidade com a parte 15 das normas da FCC. Estes limites estão concebidos de forma a fornecer uma protecção razoável contra interferências nocivas quando o equipamento é...

  • Page 23: Spanish

    SPANISH INSTRUCCIONES DE SEGURIDAD PRECAUCIÓN La siguiente precaución de seguridad debe ser respetada durante todas las fases de funcionamiento, mantenimiento y reparación de este equipo. El incumplimiento de las precauciones o advertencias de seguridad recogidas en este documento infringe las normativas de seguridad de diseño, fabricación y uso previsto de este equipo y puede afectar a las protecciones incorporadas en el mismo.
  • Page 24 INSTRUCCIONES DE SEGURIDAD CIRCUITOS ACTIVOS El personal operativo no debe retirar la cubierta del aparato. Los ajustes internos o el reemplazo de componentes sólo pueden ser realizados por el personal cualificado de TDK-Lambda Americas Inc. Desenchufe siempre el cable de alimentación antes de reemplazar los componentes. Para evitar lesiones, desenchufe siempre el cable de alimentación, descargue los circuitos y desconecte la fuente de tensión externa antes de tocar los componentes.
  • Page 25 INSTRUCCIONES DE SEGURIDAD El símbolo de PRECAUCIÓN indica un peligro. Llama la atención ante un procedimiento. Si el procedimiento no se realiza correctamente, el equipo podría sufrir daños. Cuando encuentre un símbolo de PRECAUCIÓN, no siga hasta que no haya comprendido y esté seguro de que se cumplen las condiciones indicadas. DECLARACIÓN DE CONFORMIDAD CON LA FCC: Nota: Este equipo ha sido ensayado y cumple con los límites establecidos para los dispositivos digitales de Clase A, de conformidad con lo dispuesto en el Apartado 15...

  • Page 26: General Information

    1 GENERAL INFORMATION 1.1 User Manual Content This User’s Manual contains the operating instructions, installation instructions and specifications of the Genesys 10kW and 15kW High Voltage (HV) Power Supply Series. The instructions refer to the standard HV power supplies, including the built-in RS-232/RS-485 serial communication. For information related to operation with the optional LAN programming, refer to the User’s Manual for Power Supply LAN Programming Interface.
  • Page 27  Remote sensing to compensate for voltage drop of power leads.  External Isolated Analog Program and Monitor standard (0-5V or 0-10V, user selectable).  Cooling fan speed control for low noise and extended fan life  Zero stacking-no ventilation holes on the top and bottom surface of the power supply. ...

  • Page 28: Accessories

    1.2.9 Cooling and Mechanical Construction The Genesys series is cooled by internal fans (with fan-speed control). At the installation, care must be taken to allow free airflow into the power supply via the front panel and out of the power supply via the rear panel.

  • Page 29: Model Number Format

    1.4 Model Number Format The model numbering system for Genesys power supply includes symbols for features and options. They are separated by dashes. The following chart explains the model number for the GEN Power Supply Family. GEN<xxxx>—<xxxx>—<xxxxx>—<xxxxx>—<xxxx> DC OUTPUT DC OUTPUT VOLTAGE CURRENT FACTORY...

  • Page 30: Specifications

    2 SPECIFICATIONS All specifications are subject to change without notice. Contact factory for specific model availability. 10kW 15kW 800-12.5 1000-10 1250-8 1500-6.7 2.1 MODEL (10kW) 1. Rated Output voltage (*1) 1000 1250 1500 2. Rated Output current (*2) 12.5 3. Rated Output power 10000 10000 10000...

  • Page 31: Remote Isolated Analog Control & Signals

    Over Voltage Protection (OVP) Inverter shutdown. Manual reset by AC input recycle, by FP OUT button, remote analog or by digital communication command. OVP programming accuracy ± 5% of Vo(rated) OVP programming range 10% to 110% of Vo(rated) and shall always be greater than 105% of the Output Voltage setting.

  • Page 32: Digital Programming & Readback

    2.8 DIGITAL PROGRAMMING & READBACK Vout Programming Accuracy ±0.5% of the rated Output voltage Iout Programming Accuracy ±0.5% of the rated Output current Vout Programming Resolution 0.02% of Vo(rated) Iout Programming Resolution 0.04% of Io(rated) Vout Readback Accuracy ±0.1% of Vo(actual) + 0.2% of Vo(rated) Iout Readback Accuracy ±0.1% of actual + 0.4% of Io(rated) Vout Readback Resolution...

  • Page 33: Safety

    2.13 SAFETY Applicable standards UL/cUL 60950-1, EN60950-1 recognized. 800= < Vout =< 1500V : Output is hazardous (J1 Analog output, and units with IEMD, LAN, and ISOL 420 are SELV to 1500V output). CE Mark: 400VAC and 480VAC inputs Withstand Voltage 400VAC/480VAC Input: Vout = 800VDC to 1500VDC models: Input-Ground: 2900VDC for 60s, Input-Output: 5040VDC for 60s, Output-Ground: 2500VDC for 60s, Input-SELV: 2900VDC for 60s, Output-SELV: 2500VDC for 60s.

  • Page 34: Outline Drawing

    2.16 Outline Drawing Figure 2-1. Outline Drawing 83-532-400 Rev A...

  • Page 35: Installation

    3 INSTALLATION 3.1 General This Chapter contains instructions for initial inspection, preparation for use and repackaging for shipment. Connection to the PC, setting the communication port and linking Genesys HV power supplies are described in Chapter 8. NOTE Genesys power supplies generate magnetic fields, which might affect the operation of other instruments.

  • Page 36: Rack Mounting

    3.4 Rack Mounting HV Power Supply Series is designed to fit in a standard 19” 3.4.1 The Genesys equipment rack. To Install the Power Supply in a Rack:  Use the front panel mounting tabs to install the power supply in the rack. ...
  • Page 37 WARNING Some components inside the power supply are at AC/DC voltage even when the front panel ON/OFF Switch is in the “Off” position. To avoid electric shock hazard, disconnect the AC input and load and wait 15 minutes before removing any AC input cover, DC output cover or the power supply cover.

  • Page 38: Turn-On Checkout Procedure

    3.7 Turn-On Checkout Procedure 3.7.1 Purpose The following procedure ensures that the power supply is operational. It may be used as a basic incoming inspection check. Refer to Figures 4-1 and 4-2 for the location of the controls indicated in this procedure. 3.7.2 Prior to Operation a) Ensure that the power supply is configured to the default setting:...
  • Page 39 d) Turn On the output by pressing the OUT pushbutton, (the front panel OUT LED should illuminate). e) Observe the power supply CURRENT display and rotate the CURRENT encoder. Ensure that the Output current varies while the CURRENT encoder is rotated. The minimum control range is from zero to the maximum rated Output current for the power supply model.
  • Page 40 3.7.7 Foldback Check WARNING Shorting the Positive and Negative Output connections together may expose the user to hazardous voltages. Observe proper safety procedures. Refer to Section 5.5 for explanation of the Foldback Protection (FOLD) function prior to performing the procedure below. a) Ensure that the front panel ON/OFF Switch is at the OFF position and the DVM connected to the output terminals shows zero Output voltage.

  • Page 41: Connecting The Load

    3.8 Connecting the Load WARNING Turn Off the AC input power before making or changing any rear panel connection. Ensure all live circuits are discharged and that all connections are securely tightened before applying power. There is a potential shock hazard at the Output of the power supply. The following considerations should be made when selecting the cables to connect the load to the power supply output: ...
  • Page 42 Maximum length in meters to Cross Sect. limit voltage drop to 1V or Resistivity Area OHM/Km less 8.21 12.0 5.09 18.6 3.39 29.4 14.8 1.95 51.2 25.6 Table 3.3. Maximum Wire Length for 1V drop on Lead (in meters) 3.8.2 Load Cable Terminations The load cables should be properly terminated with terminals securely attached.
  • Page 43 3.8.5 Inductive Loads Inductive loads can produce voltage spikes that may be harmful to the power supply. A diode should be connected across the output. The diode voltage and current rating should be greater than the power supply maximum Output voltage and Output current rating. Connect the cathode to the positive output and the anode to the negative output of the power supply.
  • Page 44 Figure 3-2. Load Wires Connection (800V – 1500V models) for Rear-Exit and Bottom-Exit 83-532-400 Rev A...
  • Page 45 WARNING Hazardous voltages exist at the outputs and the load connections. To protect personnel against accidental contact with hazardous voltages, ensure that the load and its connections have no accessible live parts. Also, ensure that the load wiring insulation rating is greater than or equal to the maximum Output voltage of the power supply.
  • Page 46 3.8.6.3 Connecting Multiple Loads, Radial Distribution Method Figure 3-5 shows multiple loads connected to one supply. Each load should be connected to the power supply’s output terminals using separate pairs of wires. It is recommended that each pair of wires be as short as possible and twisted or shielded to minimize noise pickup. The sense wires should be connected to the power supply output threaded studs or to the load with the most critical load regulation requirement.

  • Page 47: Local And Remote Sensing

    3.9 Local and Remote Sensing The rear panel J2 sense connector is used to configure the power supply for local or remote sensing of the Output voltage. See Figure 3-7 for the J2 sense connector location. 3.9.1 Sense Plug WARNING There is a potential shock hazard at the sense connector.
  • Page 48 3.9.2 Local Sensing The power supply is shipped with the rear panel J2 sense connector wired for local sensing of the Output voltage. See Table 3.4 for J2 terminals assignment. With local sensing, the Output voltage regulation is made at the output terminals. This method does not compensate for voltage drop on the load wires.

  • Page 49: Repackaging For Shipment

    3.10 Repackaging for Shipment To ensure safe transportation of the power supply, contact the TDK-Lambda Sales or Service Facility near you for Return Authorization and Shipping Information. Please attach a tag to the power supply describing the problem and specifying the owner, model number and the serial number of the power supply.

  • Page 50: Front And Rear Panel Controls And Connectors

    4 FRONT AND REAR PANEL CONTROLS AND CONNECTORS 4.1 Introduction The Genesys Power Supply series has a full set of controls, indicators and connectors that allow the user to easily setup and operate the unit. Before starting to operate the unit, please read the following sections for explanation of the functions of the controls and connectors terminals.
  • Page 51 Number Control/Indicator Description Section 5.2.1 VOLTAGE control High resolution rotary encoder for adjusting the Output 5.3.1 voltage. Also adjusts the OVP/UVL levels and selects the unit 5.4.1 Address 8.2.2 VOLTAGE indicator Green LED, lights for Constant-Voltage mode operation. VOLTAGE display 4 digit, 7-segment LED display.

  • Page 52: Rear Panel Connections And Controls

    5.12 Auxiliary function: Front Panel Lock. Press and hold PREV button to toggle between “Locked front panel” and “Unlocked front panel”. The display will cycle between “LFP” and “UFP”. Releasing the PREV button while one of the modes is displayed selects that mode. PREV indicator Green LED, lights when PREV button is pressed FINE button...

  • Page 53: Rear Panel Sw1 Setup Dip-Switch

    Number Control / Indicator Description Section M6 threaded stud (length ~ 0.7”) for ring lugs. Connect three AC input 3.6.1 phases of AC power plus safety ground. M6 threaded stud (length ~ 0.7”) suitable for ring lugs. DC output 3.8.6 J3-Remote In RJ-45 type connector, use for connecting power supplies to a 8.3.2...

  • Page 54: J1 Remote Analog Program And Monitor

    Figure 4-3. SW1 Setup DIP-switch 4.4.1 SW1 Position Function Refer to Table 4.3 for a description of the SW1 DIP-switch position functions. The factory default setting is DOWN for all positions. Position Function DOWN (Factory default) Output Voltage Output Voltage Remote Output Voltage SW1-1 programmed by Remote Analog...
  • Page 55 4.5.1 Making J1 Connections  J1 connector: TE Connectivity (AMP), P/N: 5747461-5 (On P/S Rear Panel)  J1 plug: TE Connectivity (AMP), P/N: 745211-2  Wire dimension range: 26-22AWG  Manual Pistol grip tool: o Handle: TE Connectivity (AMP), P/N: 58074-1 o Head: TE Connectivity (AMP), P/N: 58063-1 ...
  • Page 56 Signal name Function Section contact Enable/Disable the power supply output by dry-contact J1-1 ENA_IN (short/open) with ENA_OUT. J1-2 Isolated Interface Common. Return for the SO control, PS_OK IF_COM 5.7, 5.10 J1-3 signal and for the optional LAN, IEEE interface (Note 1) J1-4 No Connection J1-7...

  • Page 57: Local Operation

    5 LOCAL OPERATION 5.1 Introduction This Chapter describes how to operate the Power Supply using the front panel controls. Ensure that the REM/LOC LED on the front panel is Off indicating local front panel) control. If the REM/LOC LED is ON, press the front panel REM/LOC button to change the operation to Local control.

  • Page 58: Over-Voltage Protection (Ovp)

    c) Adjustment of the Output current can be made when the Power Supply output is Enabled (Output On) or Disabled (Output Off).  Disabled Output (Off): Press the PREV button and then rotate the CURRENT encoder knob. The CURRENT meter will show the programmed current for 5 seconds after the adjustment has been completed.

  • Page 59: Under-Voltage Limit (Uvl)

    To preview the OVP setting, press the OVP/UVL pushbutton so that the CURRENT display shows “OUP”. At this time, the VOLTAGE display will show the OVP setting. After 5 seconds, the display will return to its previous state. 5.3.2 Activated OVP Protection Indications When the OVP is activated the power supply output shuts down.

  • Page 60: Foldback Protection (Fb)

    5.5 Foldback Protection (FB) Foldback protection will shut down the power supply output if the load current exceeds the Output current limit setting level. This protection is useful when the load circuitry is sensitive to an overcurrent condition. 5.5.1 Setting the Foldback Protection To arm the Foldback protection, the FOLD button should be pressed so that the FOLD LED illuminates.

  • Page 61: Output Enable (Ena) Control Via Rear Panel J1 Connector

    detected after applying AC power to the unit. (In Auto-Restart mode, the output will be enabled after applying AC power; even if SO is set to an Off level). After an On-to-Off transition is detected, the SO will Enable or Disable the power supply output according to the signal level or the short/open applied to J1.

  • Page 62: Cv/Cc Signal

    5.9 CV/CC Signal J1-13 serves as the CV/CC signal. This signal indicates the operating mode of the power supply (Constant-Voltage or Constant-Current). It is an open-collector output (with a 30V parallel Zener diode), and is referenced to IF_COM at J1-2, -3 and -12. ...

  • Page 63: Front Panel Locking

    5.11.3 Auto-Restart Mode In the Auto-Restart mode, when the front panel AC switch is turned On, the power supply output will turn On automatically, if the output was On when the power supply was last powered-down. All other settings are the same as they were at the last power-down. In Auto-Restart, if certain non-latching faults occur and then clear, the output will turn On again automatically to the last settings.

  • Page 64: Last Setting Memory

    5.14 Last Setting Memory The power supply is equipped with Last Setting Memory, which stores specific power supply parameters in memory at each AC turn-off sequence. Stored Parameters:  Output is ON or OFF  Output voltage setting (PV setting) ...

  • Page 65: Series And Parallel Operation

    6 SERIES AND PARALLEL OPERATION Users may connect the outputs of Genesys power supplies together to produce: Voltages greater than any one power supply rating (series connection). Plus and minus polarity (series connection). More current than any one power supply rating (parallel connection). In addition to connecting the outputs together, analog control connections are used to ensure the power supplies are properly sharing the total voltage or current.
  • Page 66 POWER POWER SUPPLY SUPPLY LOAD LOAD (*) Diodes are POWER POWER user supplied. SUPPLY SUPPLY Fig.5-1: Series connection, local sensing Fig.5-2: Series connection, remote sensing Figure 6-1. Series connection, Local sensing Figure 6-2. Series connection, Remote sensing 6.1.2 Remote programming in Series Operation for Increased Output Voltage: For all GEN-3U HV models with rated Output voltage ≥...
  • Page 67 6.1.3 Series Connection for Positive and Negative Output Voltage In this mode, two (2) units are configured as a positive and negative output. Set the Output current limit of each power supply to the maximum that the load can handle without damage.

  • Page 68: Parallel Operation

    6.2 Parallel Operation Up to four (4) units of the same VOLTAGE and CURRENT rating can be connected in parallel to provide up to four times the current capability of one power supply. One of the units operates as a Master and the remaining units are Slaves. The Slave units are Analog programmed by the Master unit through their J1 Remote Analog connectors.
  • Page 69 d. Connect a wire jumper between J1-8 (LOC/REM) and J1-12 (COM) (refer to Table 4.4). e. Connect the Slave unit J1-10 (IPGM) to the Master unit J1-25 (P). Connect the Slave unit J1-23 (IPGM_RTN) to the Master unit J1-12 (IF_COM). During operation, the Slave units operate as a controlled current source, following the Master unit Output current.
  • Page 70 6.3.6 Connecting the Load In parallel operation, power supplies can be connected for Local or Remote sensing. Refer to Figure 6-5. The figure shows the connection of two (2) units, however, the same connection method applies for up to four (4) units. With Local sensing, it is important to minimize the wire length and resistance.

  • Page 71: Advanced Parallel Operation

    6.4 Advanced Parallel Operation In this method, multiple parallel power supplies can be configured to operate as a single power supply. The total load current and Output voltage are displayed by the Master unit and can be read back from the Master unit. The Slave units display only their operating status (On, Off or Fault condition).
  • Page 72 6.4.4 Current Display Accuracy In the “Advanced Parallel” operating mode, the Master unit calculates the total current by multiplying the Master unit’s current by the number of Slave units. In this method, the CURRENT display accuracy is 2% +/- 1 count. In cases where higher accuracy is required, it is recommended to use the “Basic Parallel”...

  • Page 73: Remote Analog Programming

    7 REMOTE ANALOG PROGRAMMING 7.1 Introduction The rear panel connector J1 allows the user to program the power supply Output voltage and Output current limit with an Analog device. J1 also provides monitoring signals to read the Output voltage and Output current. The program and monitor signals range can be selected between 0-5V or 0-10V using the SW1 Setup DIP-switch.

  • Page 74: Analog Remote Voltage Programming Of Voltage And Current

    J1-8 SW1-1 SW1-2 J1-21 signal Analog Mode DOWN DOWN OPEN Local: Voltage/Current Programming Local: Voltage Programming DOWN LOW = 0 to 0.6V Remote: Current Programming TTL “0” or Short Remote: Voltage Programming DOWN LOW = 0 to 0.6V Local: Current Programming Remote: Voltage/Current LOW = 0 to 0.6V Programming...

  • Page 75: Remote Resistive Programming Of Output Voltage And Current

    Figure 7-1. Remote Voltage Programming of Output Voltage and Current Note Use a shielded cable (Refer to Section 4.5 for more details) 7.5 Remote Resistive Programming of Output Voltage and Current For Remote Resistive voltage or current programming, internal current sources supply 1mA of current through external programming resistors connected between J1-9 &...

  • Page 76: Remote Monitoring Of Output Voltage And Current

    SW1-3 setting Output Voltage program Current limit program VPGM (J1-9) IPGM (J1-10) 0-10kohms 0-10kohms DOWN 0-5kohms 0-5kohms Table 7.4. SW1-3 Setting and Programming Range Figure 7-2. Remote Resistance Programming of Output Voltage and Current 7.6 Remote Monitoring of Output Voltage and Current The J1 connector, located on the rear panel, provides Analog signals for monitoring the Output voltage and Output current.
  • Page 77 3. Front panel (PREView button): Use the PREV button to display the Output voltage and Output current setting defined by the encoders or by Remote Digital communication. 4. Communication: Remote Analog mode power supply parameters can be programmed or read back via the Remote Digital communication port (RS-232/RS-485, etc.) except for the Output voltage and Output current setting.

  • Page 78: Rs-485 Remote Control

    8 RS-232 & RS-485 REMOTE CONTROL 8.1 Introduction This Chapter describes the operation of the Genesys 10kW and 15kW power supplies via the serial communication port. Details of the initial set-up, operation via RS-232 or RS-485, the command set and the communication protocol are described in this Chapter. 8.2 Configuration 8.2.1 Default setting...
  • Page 79 d) After 3 seconds with no adjustment, the display will revert and save the last communication port Baud rate setting. 8.2.5 Setting the Unit into Remote or Local Mode The unit will be put into Remote mode only via a serial communication command. Commands that will put the unit into Remote mode are: PV n OUT n...

  • Page 80: Connecting Power Supplies To Rs-232 Or Rs-485 Communication Bus

    8.2.8 Rear Panel RS-232/RS-485 Connector The RS-232/RS-485 interface is accessible through the rear panel J3 RS-232/RS-485 IN and RS-485 OUT connectors. The connectors are RJ-45 with eight contacts. The IN and OUT connectors are used to connect power supplies in a RS-232 or RS-485 chain to a controller. Refer to Figure 8-1 for the IN/OUT connections.
  • Page 81 Figure 8-3. RS-232 Cable with DB9 Connector (P/N: GEN/232-9) Figure 8-4. RS-485 Cable with DB9 Connector (P/N: GEN/485-9) 8.3.2 Multi Power Supply Connection to RS-232 or RS-485 Communication Bus Up to 31 units (0 – 30) can be connected on one RS-232 or RS-485 bus. The first unit connects to the controller via RS-232 or RS-485 (J3-IN) and the other units are connected with RS-485 bus.

  • Page 82: Communication Interface Protocol

    IMPORTANT: Unused pins 2, 7 and 8 must not be connected. Figure 8-6. Serial Link Cable with Shielded Connectors (P/N: GEN/RJ-45) 8.4 Communication Interface Protocol 8.4.1 Data format Serial data format is 8 bit, one start bit and one stop bit. No parity bit. NOTE The address (“ADR n”) command must return an “OK”...

  • Page 83: Error Messages

    8.4.8 Backspace The backspace character (ASCII 8) clears the last character sent to the power supply. 8.5 Error Messages The power supply will return error messages for illegal commands and illegal programming parameters. Refer to Table 8.1 for programming error messages and Table 8.2 for commands error messages.

  • Page 84: Initialization Control Commands

    8.6.3 Initialization Control Commands Command Description ADR n ADR is followed by Address, which can be 0 to 30 and is used to access the power supply. Clear status. Sets FEVE and SEVE registers to zero (refer to Section 8.10). Reset command.
  • Page 85 Sets the Foldback protection to ON or OFF. FLD n FLD 1 (or FOLD ON): Arms the Foldback protection FLD 0 (or FOLD OFF): Cancels the Foldback protection. When the Foldback protection has been activated, the OUT 1 command will release the protection and re-arm it, while FLD 0 will cancel the protection.

  • Page 86: Global Output Commands

    8.7 Global Output Commands 8.7.1 Description Global commands are a way to quickly set all power supplies on the RS-232/RS-485 digital communication bus to the same setting. For example, sending “GOUT OFF” is one way to turn a whole group of supplies OFF at nearly the same time. CAUTION After sending a global command, it is important that the controller wait 200milliseconds before sending any more RS-232/RS-485 messages.

  • Page 87: Fast Queries

    Current Programming Range (10kW) (15kW) Model Model Minimum Maximum Minimum Maximum Rated Output Rated Output (ADC) (ADC) (ADC) (ADC) Current Current (ADC) (ADC) 12.5 12.625 18.8 18.988 10.100 15.15 8.080 12.12 6.767 10.10 Table 8.5. Current Programming Range (10kW/15kW Models) OVP Programming Range (10kW/15kW) Model Rated Output...
  • Page 88 8.8.1 Fast Test for Connection This is an addressed query that is good for scanning to see what supplies are “on line”. If no response is returned within 10 ms, your control program has determined that no power supply is connected at that address. Query Format: Send two bytes of unreadable characters.

  • Page 89: Status And Error Commands

    Query Response: The power supply returns 12 characters: First is the minutes as a 32 Bit integer as 8 ASCII Hex bytes Then four printable characters: Dollar sign “$” Checksum (two ASCII hex characters) = “30” or “31” Carriage-return terminator 8.8.4 Service Request Messages A Genesys...

  • Page 90: Status, Error, And Srq Registers

    8.10 Status, Error, and SRQ Registers 8.10.1 General Description This Section describes the structure and operation of the six status, error, and SRQ registers. The registers can be set or read via the RS-232/RS-485 commands. The Status and Error Registers Diagram below is a summary of the register tree and the commands to read their contents or to enable latching any momentary events.

  • Page 91: Conditional Registers

    8.10.2 Conditional Registers The Fault Condition Register and the Status Condition Register are read only registers that the user may read to see the condition of the supply. Refer to Table 8.9 for description of the Fault Condition Register bits and Table 8.10 for the Status Condition register bits. Fault name Fault symbol Bit Set condition...
  • Page 92 A. Fault Enable Register (FENA nn, FENA?) The Fault Enable Register is set to the enable SRQs when a fault occurs. Enable Fault symbol Bit Set condition Bit reset condition bit name 0 (LSB) Spare bit SPARE User command: “FENA nn” where User command: AC Fail “FENA nn”...

  • Page 93: Serial Communication Test Set-Up

    D. Status Event Register (SEVE?) The Status Event Register will set a bit if a change in the power supply status occurs and it is enabled. The register is cleared when the “SEVE?” or “CLS” commands are received. A change in this register will generate a SRQ. Status name Status symbol Bit Set condition...
  • Page 94 8.11.2 Communication Test: Outlined below is a list of commands that may be sent from the computer (PC) using Hyperterminal or other terminal program. Power supply response: “OK” Select a power supply at PC write: ADR 6 Address 6: Power supply response: “OK” Command test: PC write: OUT 1 Power supply response: “OK”...

  • Page 95: 4-20 Ma Isolated Analog Programming Option

    4-20 mA ISOLATED ANALOG PROGRAMMING OPTION 9.1 Introduction The 4-20mA Isolated Analog is an option for Remote Analog Programming and monitoring of the Genesys Power Supply series. The option is factory installed and cannot be installed with LAN or IEMD Interfaces. Output voltage and current can be programmed and read back through optically isolated signals which are isolated from all other ground references in the power supply.

  • Page 96: Isolated Setup And Operating Instructions

    Range 4-20mA Terminal Signal name Function IS420 option Shield, connected internally to chassis SHLD Chassis GND of the supply. +VPROG_ISO Output Voltage programming input 4-20mA +IPROG_ISO Output Current programming input 4-20mA GND_ISO Ground for programming signals. Ground GND_ISO Ground for programming signals. Ground +VMON_ISO Output Voltage monitoring output...
  • Page 97 NOTE J1-8 and J1-12 must be shorted together with a jumper. h) Set the programming sources to the desired levels and turn the power supply ON. NOTE SW1-3 and SW1-4 must be in the UP position for operation with 4-20mA Isolated Programming and Monitoring.

  • Page 98: Maintenance

    10 MAINTENANCE 10.1 Introduction This Chapter provides information about maintenance, calibration and troubleshooting. 10.2 Units Under Warranty Units requiring repair during the warranty period should be returned to a TDK-Lambda Americas Inc. Authorized Service Facility. Refer to the address listing on the back cover of this User’s Manual.
  • Page 99 SYMPTOM CHECK ACTION Is the AC power cord defective ? Check continuity. Replace AC No output. All displays and indicators powerr cord if necessary. are blank. Is the AC input voltage within Check AC input voltage. range ? Connect to appropriate AC voltage source.
