Zed Scooter

ASSEMBLY INSTRUCTIONS

Thank you for your purchase.

Please follow the instructions below for correct assembly.

SAFETY RULES:

1. Before every ride, check that the screws and clamping levers are

tight, that the folding mechanism has clicked into position and the

securing lever is locked tight.

2. Do not ride on any slopes.

3. We recommend adult supervision at all times.

4. Do not ride your scooter on the road, and abide with all local laws in

your area. Wear a helmet and footwear at all times when riding.

5. Your scooter is built for riding and not jumping.

6. Do not exceed 100kg.

7. Ride the scooter in flat, clear and dry areas. Avoid water, sand and

loose gravel.

8. Do not ride at night.

9. Please do not modify the scooter.

10. Please regularly check and tighten all parts on your scooter.

Before you use your scooter, read these instructions carefully and

make sure you keep them in a safe place for further reference.

mocka.co.nz | mocka.com.au

WARNING: Always wear a helmet, shoes and

protective equipment and observe all local road rules.

Need help?

Do you have a question about the Zed Scooter and is the answer not in the manual?

Page 1 Zed Scooter ASSEMBLY INSTRUCTIONS Thank you for your purchase. Please follow the instructions below for correct assembly. SAFETY RULES: 1. Before every ride, check that the screws and clamping levers are tight, that the folding mechanism has clicked into position and the securing lever is locked tight.
Page 2 Zed Scooter ASSEMBLY INSTRUCTIONS Overview 1. Handlebars 2. Handlebar grips 3. T-Bar 4. Quick release 5. Vertical adjustment 6. Folding mechanism 7. Brake 8. Rear wheel 9. Quick release 10. Front wheel mocka.co.nz | mocka.com.au...
Page 3 Zed Scooter ASSEMBLY INSTRUCTIONS Scooter Setup Open quick release lever (9) and unscrew. Pull and hold the folding Caution - make sure that the quick release lever (9) is always closed, as mechanism lever (6) and push handlebar column forward until the shown in [A] on the picture.
Page 4 Zed Scooter ASSEMBLY INSTRUCTIONS Locking the Handlebar RIDING Control your speed at all times, and ride within your abilities. BRAKING When you want to brake, put your foot on the rear brake and apply pressure. IMPORTANT: If you are too fast or if the rear wheel has picked up oil, water, stones etc.
