MEDIAID 5340V User Manual

Pulse oximeter for veterinary use
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model 5340V
Pulse Oximeter for Veterinary Use
User's Manual
MEDIAID INC.
17517 Fabrica Way • Cerritos California 90703 USA
Tel.: 714-367-2848 • Fax: 714-367-2852
Web: www.mediaidinc.com
Email: info@mediaidinc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5340V and is the answer not in the manual?

Questions and answers

Summary of Contents for MEDIAID 5340V

  • Page 1 Model 5340V Pulse Oximeter for Veterinary Use User’s Manual MEDIAID INC. 17517 Fabrica Way • Cerritos California 90703 USA Tel.: 714-367-2848 • Fax: 714-367-2852 Web: www.mediaidinc.com Email: info@mediaidinc.com...
  • Page 3 Model 5340V Pulse Oximeter for Veterinary Use User’s Manual MEDIAID INC. 17517 Fabrica Way • Cerritos California 90703 USA Tel.: 714-367-2848 • Fax: 714-367-2852 Web: www.mediaidinc.com Email: info@mediaidinc.com © Mediaid Inc - All rights reserved...

  • Page 5: Table Of Contents

    Temperatu re Ind icator ............10 Alarm Indicato r ..............10 2.3 SY MBOLS ................12 Chapter 3: Operating the Model 5340V 3.1 M EASUR ING PULS E OX IM ETRY ........... 13 3.2 M EASUR ING BO DY TE MPER ATURE ........14 3.3 F A U L T Y R E A D IN G &...
  • Page 6 Inte rnal Memo ry Tes t – Test 9 ..........22 Set-Up Test – Tes t 10 ............23 Chapter 4: Maintaining the Model 5340V 4.1 CLE ANI NG INST RUCT IONS ..........25 4.2 TR OUBLESH OOT ING ............25 Chapter 5: Equipment Specifications 5.1 OX YGEN SATU RATI ON, PULS E R ATE &...

  • Page 7: Chapter 1: Principles Of Operation

    1.2 Principles of Pulse Oximetry The Mediaid Model 5340V Pulse Oximeter is designed to measure the percentage oxygen saturation (%SpO ) of functional hemoglobin. Non- invasive arterial oxygen saturation measurement is obtained by directing red and infrared light through a pulsating vascular bed.

  • Page 8: Mode Of Displaying Oxygen Saturation

    30 seconds. The display is updated each time a normal pulse is received. • A blinking display indicates that the Model 5340V has received no usable pulses for at least 30 seconds. The displayed pulse oximetry readings are at least 30 seconds old •...

  • Page 9: General Cautions

    • Become thoroughly familiar with the information in the User’s Manual and all accompanying documents before using the Model 5340V. • Take appropriate measures (such as powering off the Model 5340V) to Ensure animal safety in case of abnormal conditions during opera- tion of the Model 5340V.
  • Page 10 Principe d’Utilisation - 4 -...

  • Page 11: Chapter 2: Keys, Indicators, & Symbols

    Keys, Indicators and Symbols Chapter 2: Keys, Indicators & Symbols 2.1 Keys and Indicators - 5 -...
  • Page 12 (30 seconds or more) of significant patient movement or light-source interference. WARNING A blinking display indicates that the Model 5340V has received NO usable pulses for at least 30 seconds. The displayed pulse oximetry readings are at least 30 seconds old.
  • Page 13 For electric power, plug the adaptor into the pulse oximeter’s , and then plug the other end of the POWER CONNECTION adaptor into a standard electrical outlet. (All Mediaid pulse oximeters are designed to be used with the adaptor provided by Mediaid Inc. at the time of purchase.)
  • Page 14 Keys, Indicators and Symbols H. Power Indicator The green LED located on the bottom of the oximeter adjacent to the POWER CONNECTION illuminates when the Model 5340V is connected to electric power. I. Data Port The DATA PORT is used for serial and analog output. The DATA PORT should be used only for connection to equipment that complies with CSA/IEC/UL601-1.
  • Page 15 80%, it returns to 80% at the next power-up. The saturation alarm factory settings are: high 100% and low 85%. The high-saturation alarm can be disabled by setting it at 100%. The Model 5340V reverts to normal monitoring after a 5-second period of key inactivity.

  • Page 16: Audible Features

    Keys, Indicators and Symbols limits, the HI ALARM INDICATOR must be illuminated. To set the low alarm limits, the LO ALARM INDICATOR must be illuminated. P. Temperature Display When a thermistor sensor is being used, the two LED displays indicate the animal’s body temperature in degrees Celsius or Fahrenheit.
  • Page 17 Keys, Indicators and Symbols The MEDIUM PRIORITY alarm tones sound for 0.75 seconds every • 5 seconds at the highest frequency and highest volume. MEDIUM PRIORITY alarms are caused by measuring problems such as a disconnected sensor, too thin or thick tissue, or a faulty sensor. The LOW PRIORITY alarm tones sound for one second every 10 •...

  • Page 18: Symbols

    Keys, Indicators and Symbols 2.3 Symbols Symbol Definition %SpO2 Oxygen Saturation Percentage Heart Beats Per Minute (BPM) Power On/Off KEY Alarm Off KEY Oxygen Saturation Alarm KEY Pulse Rate Alarm KEY Increment KEY Decrement KEY Data Port Sensor Cable Connector Power Connection Low Battery Indicator Attention: Consult Accompanying Documents...

  • Page 19: Chapter 3: Operating The Model 5340V

    5) Power on the unit with one short The displayed pulse depression POWER oximeter readings are at least ON/OFF KEY. The Model 5340V 30 seconds old. tests displays indicators with initiated POWER-UP TEST.

  • Page 20: Measuring Body Temperature

    5) Power on the unit with one short depression of the POWER ON/OFF KEY. The Model 5340V tests the displays and indicators with the initiated POWER-UP TEST. 6) Check that all LED segments light up during the POWER-UP TEST.

  • Page 21: Faulty Reading & Sensor Complication Prevention

    3.4 Setting the Volume Level of the Audible Indicator The Model 5340V issues an audible tone that sounds for each pulse. There are three volume levels of audible pulse tones, and “off.” The tone varies in pitch with oxygen saturation - falling in pitch with reduced saturation and rising in pitch as saturation increases.

  • Page 22: Re Adi Ng & Sett Ing Level S

    Operating the Model 5340V 3.5 Reading and Setting Alarm Levels The Model 5340V provides high and low alarm levels for oxygen saturation and heart rate. The alarm levels are retained in memory until changed by the user, except when the low saturation alarm is set below 80%.

  • Page 23: Power

    ALARM OFF KEY. The LED displays show , the ALARM OFF AL OFF INDICATOR begins to flash, and the Model 5340V reverts to normal monitoring. Reactivate alarms with one of the following actions: Reactivate silenced alarms with one short depression of the ALARM •...

  • Page 24: Data Transmission

    Status byte, %SpO byte, Pulse Rate byte, Temperature byte Checksum byte. The Status byte contains flags as to the operational state of the Model 5340V: Bit 7 : Not used. Bit 6 : Pulse is lost, having previously been detected.

  • Page 25: Tests

    2) Verify that the data receiving device complies with CSA/IEC/UL160-1. 3) Verify that the Model 5340V is powered off. 4) Connect the DATA PORT/Serial Cable to the DATA PORT. 5) Power on the Model 5340V with the power adaptor. The data is transmitted automatically. Analog Data Transmission...

  • Page 26: Power-Up Test

    This number may enable Mediaid Inc. to better assist the user. Diagnostic Tests DIAGNOSTIC TESTS on the Model 5340V can be run automatically or be initiated manually. NOTE: While in the test mode, either a single test may be run or all of the tests may be run consecutively.

  • Page 27: Global Test - Tes T 0

    4) Select a test by one short depression of the ALARM OFF KEY. The test runs and stops automatically. 5) Revert to monitoring by first powering off the Model 5340V. Global Test - Test 0 This test automatically initiates all of the diagnostic tests, which run automatically and in order until either an error is detected, input is required, or the test sequence is completed.

  • Page 28: Seria L Co Mmunica Tion Test - Tes T 6

    Operating the Model 5340V circuit, and the pulse oximeter’s light-detection circuit are tested. This occurs by the emission of the sensor light at a preset frequency and level, and the monitoring of the received signal from the sensor detector. Serial Communications Port Test - Test 6 This test is used in the factory only and cannot be accessed by the user after production.

  • Page 29: Set-Up Test - Tes T 10

    Operating the Model 5340V Set-Up Test - Test 10 This test alternately displays %SpO , pulse rate and internal circuitry set- up values. A sensor needs to be applied to a subject. The instrument performs normal setup and monitoring functions, and periodically displays single digit setup numbers: 0 for thin tissue, 1 for medium tissue, or 2 for thick tissue.
  • Page 30 Principe d’Utilisation - 24 -...

  • Page 31: Chapter 4: Maintaining The Model 5340V

    Temperature reading above preset range Chirping Tone Data transmission failure WARNING Do NOT attempt to open the instrument case – doing so will VOID the Mediaid Inc. Warranty. Always refer to the Mediaid Inc. Warranty for service instructions. - 25 -...
  • Page 32 Principe d’Utilisation - 26 -...

  • Page 33: Chapter 5: Equipment Specifications

    Equipment Specifications Chapter 5: Equipment Specifications 5.1 Oxygen Saturation, Pulse Rate & Temperature Resolution %SpO Pulse: 1 BPM Temperature: 0.18º Fahrenheit (0.1º Celsius) Range %SpO 0 – 100% Pulse: 32 – 250 BPM Temperature: 76.1 – 108.5º Fahrenheit (24.5 – 42.5º Celsius) Accuracy %SpO 100 –...

  • Page 34: General

    Storage/Transport Temperature: -22 – l49° Fahrenheit (-30 – 65° Celsius) 5.9 Equipment Classification The Mediaid Model 5340V Pulse Oximeter is classified according to CAN/CSA C22.2 No. 601.1, EN 60601-1, and UL2601-1: Type of protection against electric shock: CLASS 1 INTERNALLY POWERED...

  • Page 35: Chapter 6: Warranty Information

    Items excluded from this five-year term are the batteries, power adaptor, sensor extension cables, sensors and other accessories. 6.3 Mediaid Inc. Problem Correction Plan Should your Mediaid Inc. product prove to be defective, contact Mediaid Inc. for repair at: (714) 367 2848 email: info@mediaidinc.com...

  • Page 36: Owner's Registration

    Mediaid Inc. Limited Warranty Information the current repair rate at the time of receipt by Mediaid Inc. All transportation charges shall be the customer’s responsibility. Mediaid Inc. shall not be liable for any damages including, but not limited to, incidental damages, consequential damages or special damages. This warranty does not cover any damage done to the equipment during shipping, which shall be the sole responsibility of the transportation company.

  • Page 37: Contact Information

    User References Chapter 7: User References 7.1 Contact Information For information on any other Mediaid Inc. products, visit the Mediaid home page at www.mediaidinc.com, or contact us at: Customer Service Telephone 17517 Fabrica Way, Suite H (714) 367 2848 Cerritos, CA 90703 USA...
  • Page 38 Principe d’Utilisation - 32 -...

  • Page 39: Warranty Registration Form

    Warranty Registration Form WARRANTY REGISTRATION FORM Please return to Mediaid Inc. / local distributor for validation MEDIAID INC. (Tel) 714-367-2848 (Fax) 714-367-2852 Email: info@mediaidinc.com Website: www.mediaidinc.com 17517 Fabrica Way Suite H, Cerritos, CA 90703 USA Model ______________________ Serial Number ___________________________...
