Summary of Contents for MAXTEK 77437
- Page 1 Parasol Light with Bluetooth Speaker ® MODEL NUMBER: 77437 USER GUIDE After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL: enquiries@quesh.co.uk...
-
Page 2: Table Of Contents
Contents Welcome Section 2-3. General Information & Safety Instructions Contents & Features Checking The Adaptor • Adaptor Information Charging The Speaker • Charging • Use On Connected Power Fitting The Speaker • Installation Power On/Off •Turning On/Off Bluetooth ® • Pairing •Playing Music LED Lights •... -
Page 3: Welcome Section
Welcome Section Congratulations! You have made an excellent choice with the purchase of this quality MAXTEK product. ® By doing so you now have the assurance and peace of mind which comes from purchasing a product that has been manufactured to the highest standards of performance and safety, supported by the high quality standards of Quesh Ltd. -
Page 4: General Information & Safety Instructions
General Information & Safety Instructions This powerbank is powered by a 4000mAh lithium battery. Do not dispose of batteries in your household waste. Please contact your local authority for details on safe disposal. • Never throw batteries into a fire or expose to excessive heat sources. •... - Page 5 General Information & Safety Instructions STROBE EFFECT LIGHTING This product may potentially trigger seizures for people with photosensitive epilepsy If you experience any of the following symptoms: dizziness, altered vision, eye or muscle twitching, involuntary movements, loss of awareness, disorientation or convulsions, IMMEDIATLEY disable the ‘party mode’...
-
Page 6: Contents & Features
Contents & Features Contents 1 x Parasol Bluetooth Speaker ® 1 x Charge Cable Features • 4000mAh rechargeable lithium battery • 1 x 5/1 amp USB charge port • Constant LED lighting • Sound reactive party mode LED lighting • Built in powerbank •... -
Page 7: Checking The Adaptor
Checking The Adaptor Adaptor Information Before using a USB mains adaptor please check the “Output” information on the plug face label. For This device 5V/1A or 5V/1000mAh is the maximum output required to charge the battery. Using a stronger output can damage the battery and/or product. -
Page 8: Charging The Speaker
Charging The Speaker Charging Open the larger dust cover to reveal the micro USB charge port. Connect the charge cable (supplied) to the micro USB port and the other end to a PC/Laptop USB port or an appropriate USB mains adaptor that is no greater the 5V/1A (see page 5). -
Page 9: Fitting The Speaker
Fitting The Speaker Installation The speaker will clamp on to most parasol shafts. The clamp diameter supports 20mm to 52mm sized parasol shafts. Press the base of the clip where is says ‘PUSH’ to release the catch and open the speaker. Place the speaker at the top of the parasol shaft and close the speaker, making sure the clip... -
Page 10: Power On/Off
Once the speaker has been turned on it will automatically go into pairing mode. Turn on the bluetooth on the device that you want to pair with the speaker. Search for ‘MAXTEK’ on available devices list and select it. The device will automatically pair with the speaker. -
Page 11: Led Lights
LED Lights Using The LED Lights By pressing the button you can cycle through the LED light options. These are: Constant, Party Mode, and Off. Constant LED This mode will provide 3W of constant white LED light. Party Mode This mode will enable up to 7 different coloured LEDs to flash with the music that is played through the speaker. -
Page 12: Specification
Specification Parasol Bluetooth Speaker with Powerbank ® General Size: 200mm Diameter x 45mm Approx Weight: 495g Clamp diameter: 20mm to 52mm (±0.1) Battery Battery Type: Rechargeable Li-ion Battery Capacity: 4000mAh Charge Time: Up to 4 hours Charging Requirements Min: 5V/500mAh Charging Requirements Max: 5V/1A Charging Port Type:... -
Page 13: Faq's
Problem Cause Solution Bluetooth dropping out after Full device cache. Manually clear the device’s cache & restart the device. a few minutes. Low Power. Turn the speaker off and recharge them. Stuttering/delay music. Too many processes running Close unused apps. on device. - Page 14 Warranty Certificate Warranty This product is warranted to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour.
- Page 15 Warranty Card Parasol Light With Bluetooth Speaker ® Model Number: 77437 Please keep your purchase receipt together with your warranty card Name: Address: Date of purchase: Location of purchase: Fault Description: We recommend that you attach a photocopy of your receipt, showing the date of purchase, to this warranty card and keep it for your reference.
