- Page 1 Package Contents Microuter User guide USB power adapter is sold separately WIRELESS ROUTER USER GUIDE ver. 20170704.1...
- Page 2 HARDWARE Repair / Reset If you cannot access the web-based setup page or cannot connect to the router, you can use a pin to press the Reset button: Press and hold for 3 seconds then release to repair your network. HOTSPOT POWER Press and hold for 10 seconds then release to reset the router...
- Page 3 Visit http://192.168.8.1 in your browser to begin Set up the Internet (see Internet Setting) broadcast a Wi-Fi signal with the SSID: setting up your router; start by choosing your and share the network. GL-USB150-xxx. preferred language. GL-USB150-xxx. Default Wi-Fi key is goodlife...
- Page 4 with Laptop Disable your laptop’s Wi-Fi Plug into your laptop Set up your Microuter Surf the Internet Disable the internal wireless adapter of Microuter will create a wired network in Visit http://192.168.8.1 in your browser to begin Set up the Internet (see Internet Setting) your laptop.
-
Page 5: Web Interface
WEB INTERFACE If connected successfully, icon color will change from grey to green WLAN Clients Internet_WiFi LAN Clients GL-USB150-xxx A1:B2:C3:D4:E5:D6 The wireless network Your Microuter’s Your Microuter’s SSID Number of clients that you're connecting to MAC address... -
Page 6: Internet Setting
INTERNET SETTING Click to set up your Internet: Scan Wi-Fi around On the Internet Setting page, you need to click Scan to search Known Networks Scan available Wi-Fi networks around for the first time, and then select one network from the list. Alternatively, you can pick up one from Known Networks that you have used before. - Page 7 On the Hotspot Setting page, you can change your Wi-Fi Name (SSID) and Wi-Fi Key to increase the security of your Microuter. New changes will be in effect after you click Apply. Current Wi-Fi Name Apply GL-USB150-xxx Hotspot switch GL-USB150-xxx Wi-Fi Name (SSID)
-
Page 8: Openvpn Client
OPENVPN CLIENT This router supports OpenVPN client. Using OpenVPN will slow down your Internet speed because of data encryption. Click APPLICATIONS > VPN Client to access the VPN client setting page. The first time it will ask you to upload your OpenVPN client configuration (ovpn files). Click Add a New VPN Configuration, and then upload your ovpn files in the popup window. -
Page 9: Connect To Vpn
Connect to VPN Now you can choose a configuration and click Connect as OpenVPN client. Force all connected clients to use VPN VPN Connection Only Current VPN Configuration MyVPN Change your configuration file MyVPN OfficeVPN Connect Connect to VPN To protect agains DNS leaks, you must customize your DNS servers: MORE SETTINGS >... - Page 10 Click the icon button to view a list of ovpn files under one Remove Select configuration, and change the ovpn file by clicking Select. You can USA-Los-Angeles.ovpn also Remove any individual ovpn file from the list. To get more detailed instructions or information of compatible VPN service providers, please visit www.gl-inet.com/docs...
- Page 11 SPEC Atheros 9331, @400MHz DDR2 64MB / 16MB Nor Flash RAM / ROM IEEE 802.11 b/g/n. max 150Mbps Wireless 1A, USB Power Supply Power Input Less than 1 Watt Power Consumption Weight Dimension 82mm x 24mm x 11mm 0 - 45°C (32 - 113°F) Working Temperature...
-
Page 12: Warranty
Pictures on the instructions are only for reference. We reserve the right to change or modify these materials without further notice. Technical Supports & General Enquiry For more detailed and updated instructions, please visit our website www.gl-inet.com/docs For further questions, you can get help from the following ways: 1.
