DTL Broadcast Routemaster 5SV2975F 16x1 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
DTL Broadcast Ltd
Johnson' s Estate
Silverdale Road
Hayes
Middx UB3 3BA, UK.
P hone: +44 (0) 20 8813 5200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Routemaster 5SV2975F 16x1 and is the answer not in the manual?

Questions and answers

Summary of Contents for DTL Broadcast Routemaster 5SV2975F 16x1

  • Page 1 DTL Broadcast Ltd Johnson’ s Estate Silverdale Road Hayes Middx UB3 3BA, UK. P hone: +44 (0) 20 8813 5200...
  • Page 2 Fax: +44 (0) 20 8813 5022 Email: info@dtl-broadcast.com Internet: www.dtl-broadcast.com...

  • Page 3: Table Of Contents

    Contents Routemaster Range User’s G uide P lease note the contents list covers modules currently available in the range. Your User’ s Guide may only include relevant sections. G eneral Introduction Overview of the range Safety and pre-installation checks Warranty Video matrices 16x1 video matrices 16x4 video matrices (1U)

  • Page 4: General

    1 General Introduction This User’ s Guide provides information on installing and operating Routemaster systems. Section 1.3 ‘ Safety and P re-installation checks’ includes instructions which must be followed. Whilst every effort has been made to ensure the accuracy of this guide, DTL Broadcast Ltd cannot be held responsible for errors or omissions.

  • Page 5: Warranty

    Warranty DTL Broadcast Ltd (the company) supplied products are warranted against defects in materials and workmanship for a period of one year from the date of shipment. At its option, the company will repair or replace products that prove to be defective during the warranty period, provided they are returned to the company with advance notification freight prepaid.

  • Page 6: Video Matrices

    2 Video matrices 16x1 video matrices Features The 16x1 Routemaster video matrix is a proven unit designed with a variety of options to allow it to be easily installed, used and integrated into existing and future systems. (The 5SV2987 & 5SV2987F YUV/RGB component video matrices comprise three 16x1 composite matrices married together.) •...
  • Page 7 2 Video matrices Installation P lease read section 1.3 ‘ Safety and P re-Installation checks’ before proceeding. For a single level matrix with local control simply connect the video inputs and outputs as shown on the rear panel (terminating any unused BNC’ s at 75Ω), connect the mains mating IEC connector to a suitable 230v supply (NB Earth MUST be connected at all times) and the matrix is ready for use.
  • Page 8 2 Video matrices Connection for married operation: Connect all units in daisy-chain fashion via the 9 way ‘ D’ type male connector at the rear of the unit using 4C014 married cable or a cable made up of ‘ D’ type female connectors connected in parallel as below.
  • Page 9 2 Video matrices Altogether 4 button-per-crosspoint panels can be used to control a 16x1, (3 remotes if local control is fitted) each panel with a unique priority level (see 5S2935 Control P anel section). Operation Selecting a source on the front panel or on a remote button per cross-point panel switches the output to that source so long as the slider switch on the control panel is in the enable position.
  • Page 10 2 Video matrices <-46dB @ 4.43MHz Output return loss <-46dB @ 15KHz <-40dB @ 4.43MHz Frequency response ±0.1dB @ 6MHz -0.5dB @ 10MHz 2T pulse & bar 0.2%K 2T bar 0.2%K 2T pulse 0.2%K 50Hz square wave 0.2%K Differential phase 0.1º...
  • Page 11 2 Video matrices 4C014 Married cable (for use with 2 or more matrices) 5S2935 16 button per cross-point panel 4C009 Control cable for 5S2935&8 10m 4C009/15 Control cable for 5S2935&8 15m 4C009/20 Control cable for 5S2935&8 20m 4C009/25 Control cable for 5S2935&8 25m 4C009/30 Control cable for 5S2935&8 30m 4C009/35...

  • Page 12: 16X4 Video Matrices (1U)

    2 Video matrices 16x4 video matrices (1U) Features 5SV2976 16x4 video matrix The 5SV2976 16x4 Routemaster video matrix is a proven unit designed with a variety of options to allow it to be easily installed, used and integrated into existing and future systems. (The 5SV2978 YUV/RGB video matrix comprises three 5SV2976 composite matrices married together.) •...
  • Page 13 2 Video matrices Installation P lease read section 1.3 ‘ Safety and P re-Installation checks’ before proceeding. For a single level matrix, connect the video inputs and outputs as shown on the rear panel (terminating any unused BNC’ s at 75Ω) then connect the mains mating IEC connector to a suitable 230v supply (NB Earth MUST be connected at all times).
  • Page 14 2 Video matrices control should be connected to the video unit. If being married to other component levels ensure the unit designated Y/G is connected appropriately so that sync is derived from the correct level. Connection for remote control: 16x4 video Routemasters can be controlled by a 5S2935 button-per-crosspoint control panel for each output, by the 5SX4100 XY panel or by a mixture of both.
  • Page 15 2 Video matrices When using only the 5SX4100 XY control panels A splitter cable (specific to your particular requirement) is supplied with each system. This should be connected to the 16x4 Routemaster(s) as shown by the labels on its connectors and to the socket marked P L1 on the rear of the XY panel using control cable 4C025, which is available in a variety of lengths from 10 to 50 metres.
  • Page 16 2 Video matrices Section 4.2 contains details on the 5S2935 16 button-per-crosspoint control panels and section 4.3 details on the XY panel. Operation The 16x4 Routemaster is controlled remotely using button-per-crosspoint and/or XY control panels. Section 4.2 contains full details on operating the 5S2935 16 button-per-crosspoint control panels and section 4.3 full details on operating the XY panel.
  • Page 17 2 Video matrices Control panel connectors Four 9 way D type sockets Married connector 9 way D type plug P ower connector P ower 230VAC 50Hz Temperature range 0-40ºC Height 44mm (1U) Width 483mm (19”) Depth 360mm Weight Ordering inf ormation 5SV2976 16x4 video matrix with terminating inputs and dual outputs 5SV2978...

  • Page 18: 16X4 & 16X8 Video Matrices (2U)

    2 Video matrices 16x4 & 16x8 video matrices (2U) Features 5SV2908 16x8 video matrix The 5SV2908 16x8 Routemaster video matrix is a proven unit designed with a variety of options to allow it to be easily installed, used and integrated into existing and future systems.
  • Page 19 2 Video matrices • Can be married to other video levels for component (YC, YUV, RGB or RGBS) operation and to audio units for audio follow video with break-away available dependant on the type of control panel fitted. Installation P lease read section 1.3 ‘ Safety and P re-Installation checks’ before proceeding. For a single level matrix, connect the video inputs and outputs as shown on the rear panel (terminating any unused BNC’...
  • Page 20 2 Video matrices should be connected to the video unit. If control cables are not supplied see ‘ connection for remote control below. Connection for married operation: Connect all units in daisy-chain fashion via either of the 9 way ‘ D’ type male connector at the rear of the unit using 4C014 married cable or a cable made up of ‘...
  • Page 21 2 Video matrices For more complex married systems with multiple levels of video and/or audio, the remote control panels should be connected to the composite video matrix (or the Y/G matrix for component video). Altogether 4 button-per-crosspoint panels can be used to control any one output, each panel with a unique priority level (see 5S2935 Control P anel section 4.2).
  • Page 22 2 Video matrices When 5S2935 16 button-per-crosspoint control panels are being used in addition to an XY panel, the splitter cable also has 9 way ‘ D’ type female connectors for connecting 4C009 control cables to the button-per-crosspoint panels. (See the previous ‘...
  • Page 23 2 Video matrices Crosstalk <-60dB @ 4.43MHz Noise luminance weighted <80dB RMS Timing spread ±1º @ 4.43MHz Electrical length Typical 25ns Video connectors 75Ω BNC Control panel connectors Eight 9 way D type sockets Married connector Two 9 way D type plugs P ower connector P ower 230VAC 50Hz...

  • Page 24: 5X1 Component Matrix

    2 Video matrices 5x1 component matrix Features The 5x1component video Routemaster is a proven matrix designed with a variety of options to allow it to be easily installed used and integrated into existing and future systems. • Compact 5x1 component matrix for YUV, RGB &YC signals. •...
  • Page 25 2 Video matrices Installation P lease read section 1.3 ‘ Safety and P re-Installation checks’ before proceeding. For a single level matrix with local control simply connect the video inputs and outputs as shown on the rear panel (terminating any unused BNC’ s at 75Ω), connect the mains mating IEC connector to a suitable 230v supply (NB Earth MUST be connected at all times) and the matrix is ready for use.
  • Page 26 2 Video matrices given below. Note that screened cable must be used, with the screen connected to the shell of the ‘ D’ type connectors at both ends to meet EMC requirements. Operation Selecting a source on the front panel or on a remote button per cross-point panel switches the output to that source so long as the slider switch on the control panel is in the enable position.
  • Page 27 2 Video matrices Maximum input DC ±2V Black level var ±20mV Maximum output DC Input return loss <-52dB @ 15KHz <-46dB @ 4.43MHz Output return loss <-46dB @ 15KHz <-40dB @ 4.43MHz ±0.1dB @ 6MHz Frequency response -0.5dB @ 10MHz 2T pulse &...
  • Page 28 2 Video matrices 4C009 Control cable for 5S2935&8 10m 4C009/15 Control cable for 5S2935&8 15m 4C009/20 Control cable for 5S2935&8 20m 4C009/25 Control cable for 5S2935&8 25m 4C009/30 Control cable for 5S2935&8 30m 4C009/35 Control cable for 5S2935&8 35m 4C009/50 Control cable for 5S2935&8 50m Issue 4 Page 2.4 - 5...

  • Page 29: Audio Matrices

    3 Audio matrices 16x1 mono & stereo matrices Features The 16x1 Routemaster is a proven matrix designed with a variety of options to allow it to be easily installed used and integrated into existing and future systems. • The 5SA3075F 16x1 stereo audio routing matrix has a front panel mounted button per cross-point control panel.
  • Page 30 3 Audio matrices • Can be married to other audio levels and to video units for audio follow video with break-away available dependant on the type of control panel fitted. Issue 4 Page 3.1 - 2...
  • Page 31 3 Audio matrices Installation P lease read section 1.3 ‘ Safety and P re-Installation checks’ before proceeding. For a single level matrix with local control simply connect the audio inputs and outputs as shown on the rear panel (and detailed in ‘ signal wiring’ below), connect the mains mating IEC connector to a suitable 230V supply (NB Earth MUST be connected at all times) and the matrix is ready for use.
  • Page 32 3 Audio matrices Signal wiring: Inputs and outputs are via 4 way locking Molex connectors: Mating connectors are supplied which should be crimped onto audio cable with the appropriate crimping tool (available from RS Components - part number 210- 5012). Connection for married operation: Connect all units in daisy-chain fashion via the 9 way ‘...
  • Page 33 3 Audio matrices remotes if local control is fitted) each panel with a unique priority level (see 5S2935 Control P anel section). Control panels connect to 16x1 Routemasters at the female 9 way ‘ D’ type connector on the rear of the unit. Use control cable 4C009/m (available in a variety of lengths from 10 to 50 metres).
  • Page 34 3 Audio matrices Impedance >10kΩ Balance <-70dB @ 1kHz Isolation <-100dB @ 1kHz Level 0dB, +24dBu max. Outputs Number 1 double Impedance 50Ω Balance <-70dB @ 1kHz typical Isolation <-85dB @ 1kHz Level +24dBu max. Unwanted outputs Crosspoint type Balanced solid state Control type Crosstalk <-86dB 20Hz-20kHz...
  • Page 35 3 Audio matrices 5S2935 16 button per cross-point panel 4C009 Control cable for 5S2935&8 10m 4C009/15 Control cable for 5S2935&8 15m 4C009/20 Control cable for 5S2935&8 20m 4C009/25 Control cable for 5S2935&8 25m 4C009/30 Control cable for 5S2935&8 30m 4C009/35 Control cable for 5S2935&8 35m 4C009/50 Control cable for 5S2935&8 50m...

  • Page 36: 16X4 Audio Matrices

    3 Audio matrices 16x4 audio matrices Features The 5AA2984 16x4 Routemaster is a proven matrix designed with a variety of options to allow it to be easily installed, used and integrated into existing and future systems. • 1U rack mounting units with dual outputs. •...
  • Page 37 3 Audio matrices Installation P lease read section 1.3 ‘ Safety and P re-Installation checks’ before proceeding. For a single level matrix, connect the inputs and outputs as shown on the rear panel (and detailed in ‘ signal wiring’ below), then connect the mains mating IEC connector to a suitable 230v supply (NB Earth MUST be connected at all times).
  • Page 38 3 Audio matrices Signal wiring: Inputs and outputs are via 4 way locking Molex connectors: Mating connectors are supplied which should be crimped onto audio cable with the appropriate crimping tool (available from RS Components - part number 210- 5012). Connection for married operation: Connect all units in daisy-chain fashion via the 9 way ‘...
  • Page 39 3 Audio matrices When using only the 5S2935 16 button-per-crosspoint control panels Control panels are connected to 16x4 Routemasters using the female 9 way ‘ D’ type connector on the rear of the unit. Use control cable 4C009, which is available in a variety of lengths from 10 to 50 metres.
  • Page 40 3 Audio matrices For the simplest system when an XY panel only controls a single 16x4 matrix, the splitter cable has four 9 way ‘ D’ type male connectors which connect to the four control sockets on the rear of the matrix, and a 25 way ‘ D’ type female connector for the cable to the XY panel.
  • Page 41 3 Audio matrices Crosstalk <-86dB 20Hz-20kHz ±0.1dB 20Hz-10kHz, ±0.25dB @20kHz, Frequency response -3dB @ 40kHz (with CCIR filtering) Signal to noise ratio <-86dB 20Hz-20kHz CCIR un-weighted Total harmonic <0.03% @ 0dB 20Hz-20kHz distortion <0.05% @ +20dB 20Hz-20kHz Power Mains input 230Vac ±10% 50Hz Rating 30VA...
  • Page 42 3 Audio matrices 16x8 audio matrices Features The 5AA2982 16x8 Routemaster is a proven matrix designed with a variety of options to allow it to be easily installed, used and integrated into existing and future systems. • 2U rack mounting units with dual outputs. •...
  • Page 43 3 Audio matrices Installation P lease read section 1.3 ‘ Safety and P re-Installation checks’ before proceeding. For a single level matrix, connect the inputs and outputs as shown on the rear panel (and detailed in ‘ signal wiring’ below), then connect the mains mating IEC connector to a suitable 230v supply (NB Earth MUST be connected at all times).
  • Page 44 3 Audio matrices Signal wiring: Inputs and outputs are via 4 way locking Molex connectors: Mating connectors are supplied which should be crimped onto audio cable with the appropriate crimping tool (available from RS Components - part number 210- 5012). Connection for married operation: Connect all units in daisy-chain fashion via either of the 9 way ‘...
  • Page 45 3 Audio matrices When using only the 5S2935 16 button-per-crosspoint control panels Control panels are connected to Routemasters using the female 9 way ‘ D’ type connector on the rear of the unit. Use control cable 4C009, which is available in a variety of lengths from 10 to 50 metres.
  • Page 46 3 Audio matrices eight control sockets on the rear of the matrix, and a 25 way ‘ D’ type female connector for the cable to the XY panel. When a number of matrices are being used for different levels of video and/or audio, the splitter cable also includes 9 way ‘...
  • Page 47 3 Audio matrices Frequency response ±0.1dB 20Hz-10kHz, ±0.25dB @ 20Hz -3dB @ 40kHz (with CCIR filtering) Signal to noise ratio <-86dB 20Hz-20kHz CCIR un-weighted Total harmonic <0.03% @ 0dB 20Hz-20kHz distortion <0.05% @ +20dB 20Hz-20kHz Power 230Vac ±10% 50Hz Mains input Rating (stereo 16x1) 30VA Operating temperature...

  • Page 48: Control

    4 Control Sample Routemaster systems Issue 4 Page 4.1 - 1...
  • Page 49 4 Control 5S2935 16 button-per-crosspoint control panel Features The Routemaster 16 button-per-crosspoint control panel provides flexible control for our range of Routemaster audio and video matrices. The panel is compact, occupying only 1U of 19" rack space. • Full control of a 16x1 Routemaster system or one level of a larger matrix •...
  • Page 50 4 Control Up to 4 control panels can be connected on one 16x1 Routemaster, 4 remote or 3 remote + local. Control panels can be configured with priority by setting links within the unit as shown in the table below. Priority 1 Priority 2 Priority 3...
  • Page 51 4 Control • • • • • • • • • • • • • • • • • • • • CONTROL PANEL LINK SETTING S FOR 16X1 ROUTEMASTER Operation Control panels derive power from the Routemaster itself. When the Routemaster is powered control panel defaults to input 1, which will show on the control panel tally led.
  • Page 52 4 Control 5SX4100 XY control panel Features • Full control of a 16x4 system (4 outputs of other systems) • Married or breakaway control of video & audio • P rovision to connect a joystick override to any output • Ergonomic controls requiring minimum keystrokes to operate and with clear LED monitoring of video and audio crosspoints (including joystick override)
  • Page 53 4 Control Any of up to sixteen sources may be selected and routed to any of up to four destinations. Sources may be selected as audio, video or married. Full monitoring is provided by coloured LED's showing which audio and video sources have been selected for any destination.
  • Page 54 4 Control Operation The XY panel is delivered configured to control either four or eight outputs depending on the customer's requirement. M ma rried/breakaw ay Destinations (1-4) V/A video/a udio Enable /disa ble Sources (1-16) Figure 1 Controlling up to f our destinations As shown in figure 1 above, the panel has three banks of control buttons.
  • Page 55 4 Control Selecting Select 'MODE' (married or breakaway, audio or video) then the required 'DESTINATION', followed by the relevant 'SOURCE'. Decisions made are tallied at all times by the LED's. Controlling more than f our destinations The XY panel will control 16x8 audio matrices, 16x8 video matrices or married 16x8 audio follow matrices (for which audio/video breakaway is not available).
  • Page 56 4 Control Internal switches select the correct mode (see Appendix B). At the rear of the XY panel the 25 way 'D' type connectors carry the interfaces for the relevant Routemaster matrices. The 9-way 'D' type connector interfaces to a joystick over-ride.
  • Page 57 4 Control Connector schedules Synchronous control connections - 25 way 'D' type plug ( PL1) (For all systems except 16x1 and 5x1.) Description Connector pin no. Supply +5V Supply 0V Data (Ch. A) DA0 Data (Ch. A) DA1 Data (Ch. A) DA2 Data (Ch.
  • Page 58 4 Control Asynchronous control connections - 25 way 'D' type socket ( SKT1) (For 16x1 and 5x1 systems only.) Description Connector pin no. Supply +5V Supply 0V Data (Ch. A) DA0 Data (Ch. A) DA1 Data (Ch. A) DA2 Data (Ch. A) DA3 Data (Ch.
  • Page 59 4 Control Joystick over-ride connections - 9 way 'D' type socket ( SKT 2) The joystick socket is located at the rear of the unit. The connections are arranged in a matrix format. Any 1 of 16 sources can be selected. The pin configuration is detailed below.
  • Page 60 4 Control Splitter cable A splitter cable is provided when complex systems are being controlled. (Typically complex systems comprise 16x4 matrices for video & audio. Often 3 video matrices for component video & 2 audio matrices for stereo audio. Often with an XY panel and a button per cross point panel for each output.) Whilst the splitter cables are manufactured to satisfy the requirements of a specific system, they are based on the following.
  • Page 61 4 Control The pin connections are as follows: LABEL Data DA0 Data DA1 Data DA2 Data DA3 Strobe 1 Strobe 2 Strobe 3 Strobe 4 Data DB0 Data DB1 Data DB2 Data DB3 Reset 1 Reset 2 Reset 3 Reset 4 Output1 Line 1 Output2 Line 1 Output3 Line 1...
  • Page 62 4 Control Internal switch settings The position of internal switches is detailed below. Main control board ( all functions except disabling the 'Married' switch). SK1 25W D SK2 9W D PL1 25W D Battery Internal switches have the following functions: - SW1-A} SW1-B } Select any one of four "A"...
  • Page 63 4 Control Switch board ( disabling the 'Married' switch). LK 1( E) LK 2( D) LK1(E) on } LK2(D) off} Married switch enabled (default). LK1(E) off} LK2(D) on } Married switch disabled. (This setting is for 16x8 operation.) Active and relevant switches are mentioned. All unspecified switches must be set to off.
