Page 1 5100 ES Models II/III Portable Radio 700 / 800 MHz Operating Manual Project 25 Analog FM Conventional Conventional SMARTNET / SmartZone ® ® Trunked Part of Part Number 002-5100-72000CD December 2006...
Page 3 5100 ES Models II/III Portable Radio Operating Manual 700 / 800 MHz Project 25 Conventional and Trunked Analog and Digital Conventional ® ® SMARTNET /SmartZone 7.2 VDC 2.5 Watt (700 MHz), 3 Watt (800 MHz) Part of Part Number 002-5100-72000CD December 2006...
Page 5 © Copyright 2006 by EFJohnson ™ ™ ® The EFJohnson logo, PC Configure , Trunked IP25 , and Call Guard are trademarks of EFJohnson. All other company and/or product names used in this manual are trademarks and/or registered trademarks of their respective manufacturers.
Page 7: Table Of Contents
5100 ES Models II/III Portable Radio Operating Manual December 2006 Table of Contents Features General Features ............. . . 1-1 Conventional Features.
Page 8 Table of Contents (continued) Backlight ..............3-11 Keypad Lock .
Page 9 Table of Contents (continued) Conventional Mode Features Monitoring Before Transmitting ........... 5-1 Automatic Channel Monitoring .
Page 10 Table of Contents (continued) Answering a Telephone Call ..........5-20 Call Alert .
Page 11 Table of Contents (continued) SmartZone and P25 Trunked Unique Features ........6-15 Busy Override .
Page 12 Table of Contents (continued) SecureNet™ ............. . 10-1 AES (Advanced Encryption Standard) .
Page 13 List of Figures Figure Page Front Panel Controls ........... 2-1 Top Panel Controls .
Page 14 List of Figures (continued) Figure Page viii 5100 ES Model II/III Portable Radio Operating Manual December 2006...
Page 15 List of Tables Table Page LED Indicators ............2-3 Initial Messages .
Page 16 List of Tables (continued) Table Page viii 5100 ES Model II/III Portable Radio Operating Manual December 2006...
Page 17: Federal Communications Commission Regulations
Safety Requirements RF Energy Exposure Awareness and Control Information, and Operational Instructions for FCC Occupational Use Requirements Before Using Your Portable Two-Way Radio, Read This Important RF Energy Awareness And Control Information And Operational Instructions To Ensure Compliance With The FCC’s RF Exposure Guidelines.
Page 18: Compliance With Rf Exposure Standards
Safety Requirements information. Your EFJohnson two-way radio has a RF exposure product label. Also, your EFJohnson user manual, or product manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. Compliance with RF Exposure Standards Your EFJohnson two-way radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) for human exposure to...
Page 19: Contact Information
Safety Requirements • Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the Push-To-Talk (PTT) button. To receive calls, release the PTT button. Transmitting 50% of the time, or less, is important because this radio generates measurable RF energy exposure only when transmitting (in terms of measuring for standards compliance).
Page 20: Battery Disposal
Safety Requirements Usage Compatibility Do NOT operate it in areas that are sensitive to RF energy such as aircraft, hospitals, blasting sites, and fuel storage sites. Areas with potentially flammable atmospheres are usually, but not always, clearly posted. These may include gas stations, fuel and chemical storage and transfer stations, below deck on boats, and areas where the air contains flammable chemicals or particles such as grain dust or metal powders.
Page 21: Features
E C T I O N Features Section 1 Note The availability of many of the following features is controlled by the model of your radio, factory coding of your radio, installed options, firmware version, and field programming. Refer to Sections 8 for more information. General Features •...
Page 22: Conventional Features
Features • User selectable high and low power output • Surveillance mode • Time-out timer • Keypad lock to prevent accidental key presses • Power up password to prevent unauthorized use. • Programmable and user adjustable tone volume • Programmable minimum volume level •...
Page 23: Smartnet/Smartzone Features
Features SMARTNET/SmartZone Features • Up to 512 talk groups programmable (channels select talk groups) • Group, Enhanced Private Conversation™, standard Private Conversation, and Telephone calls • Emergency alarms to alert a dispatcher of emergency conditions • Emergency calls for high priority system access •...
Page 24 Features 1-4 5100 ES Model II/III Portable Radio Operating Manual December 2006...
Page 25: Controls And Display
E C T I O N Controls and Display Section 2 Front Panel Controls Note The location of these controls is shown in Figure 2.1. Figure 2.1 Front Panel Controls Display Up/Down Sw In Various Modes: Menu/Option <F1> = Exit Keys <F2>...
Page 26 Controls and Display Microphone - The microphone is located behind the small opening shown in Figure 2.1. For best results, hold the radio 2-3 inches from you mouth and speak at a normal conversational level. Do not shout since it distorts your voice and does not increase range. Display - This is a graphical LCD (Liquid Crystal Display).
Page 27: Top Panel Controls
Controls and Display Top Panel Controls Figure 2.2 Top Panel Controls Antenna Power On-Off/ Connector Volume Adj Emergency Multi-Function Option Channel (Option) Indicator Switch Switch Switch Multi-Function Indicator - Indicates the following conditions: Table 2.1 LED Indicators LED Color LED Duration Description Tx: clear 125 ms ON 125 ms OFF...
Page 28: Side Controls
Controls and Display Channel Switch - This 16-position switch selects up to 16 channels in the current zone. Additional zones can be programmed to allow up to 512 channels to be selected by this switch. This control can be disabled as described in Section 3.3. Rotary Option Switch - This is a three-position switch that can be programmed to control various options.
Page 29: Display
Controls and Display Accessory Connector - This is the connection point for optional accessories such as a speaker/microphone or earphone. It is also the connection point for the computer when programming the radio or for data equipment when the P25 Packet Data feature is used (see Section 5.14.10).
Page 30 Controls and Display An interconnect (telephone) call is in progress (see Section 6.5). A Project 25 or SMARTNET/SmartZone private (unit-to-unit) call is in progress. 2-6 5100 ES Model II/III Portable Radio Operating Manual December 2006...
Page 31: General Operation
E C T I O N General Operation Section 3 Turning Power On and Setting Volume 3.1.1 Power Up Power is turned on and off by the top panel On-Off/Volume switch. When power is initially turned on, the following events occur: •...
Page 32: Enhanced Soft Power Feature
General Operation The soft power down feature prevents users from accidentally powering off the radio. A soft power down feature can be programmed to prevent radio power from being turned off by accidentally turning the on-off/volume control. Any side button can be programmed for this function in addition to its normal function.
Page 33: Setting Volume Level
General Operation The following fields must be completed in PC Configure (on the second page of the Global tab). Enable Via Button - This combo box allows the user to choose which side button protects the power knob. Pressing this side button while the power/volume knob is in the off position will power down the radio.
Page 34: Power-Up Password
General Operation Power-Up Password The power-up password feature prevents unauthorized use of the radio by disabling it when power is turned on until the proper password is entered. This feature is enabled or disabled by programming. When this feature is enabled, “Enter Pswd” is briefly displayed when power is turned on. The password can be 1-8 digits in length, and consists of digits 0-9.
Page 35: Channel Select
General Operation After the highest programmed zone is displayed, wrap-around to the lowest programmed zone occurs and vice versa. The selected zone is also displayed briefly on power up. If the selected zone alias needs to be displayed continuously, it must be programmed as part of the channel alias.
Page 36 General Operation Seq. Ch. No. Zone Channel Proceed as follows to select channels using this mode: 1 Enable the direct Channel Select mode by pressing the Channel Select option switch or selecting the “Chan Selct” menu parameter. The alias and sequential number of the current channel are alternately displayed.
Page 37: Combined Zone And Channel
General Operation channel 15 of the current zone is being displayed, rotating it to channel 4 selects channel 4 of the current zone. • If the rotary Channel Select switch is enabled, the radio always powers up on the channel it is selecting. If it is disabled, the radio can be programmed to power-up on the last selected or home channel number of the last selected or home zone.
Page 38: Battery And Accessory Connector
General Operation 3 Turn the up/down button to the location (1-16) where you want to store this favorite. The radio will automatically start at the first unprogrammed channel and if all channels are programmed, the radio will start at Channel 1. 4 To store the new channel in to the favorite zone, press the Select button which is <F2>...
Page 39: Low Battery Indication
General Operation 3.4.2 Low Battery Indication Note If the radio contains encryption keys and is not programmed for infinite key retention, be sure to reattach a battery within approximately 30 seconds to prevent the loss of these keys (see following). A low-battery condition is indicated by the icon in the display.
Page 40: Beltclip Installation
General Operation Do not expose the charger base to high level RF signals while a battery is being charged because this may cause a charger fuse to blow (especially in the UHF range). Radios programmed for SMARTNET/SmartZone operation, for example, may affiliate while in the charger which causes them to automatically key.
Page 41: Backlight
General Operation 4 Install the included locking screw in the latch tab in the location shown. Figure 3.4 Accessory Connector Install Lock Screw Here Accessory Connector Latch Hook Backlight The backlight for the display and option keys can be programmed to automatically turn on when any key is pressed.
Page 42: Setting Squelch
General Operation Keypad Lock and Permanent Lock functions. If this function is not selected, both the front and side panel keys are disabled. The PTT switch is never disabled. • The Channel Selector and Volume controls can be programmed so that they are locked by the Keypad Lock function.
Page 43: Conventional Mode
General Operation 3.9.1 Conventional Mode This is a non-trunked operating mode which accesses independent radio channels. There is no automatic access to several channels. Selecting a conventional channel selects a transmit and receive frequency and other channel parameters such as squelch control coding.
Page 44: P25 Trunked Mode
General Operation The control channel transmits and receives system information to and from all radios registered on the system. Therefore, once a control channel is found, it is continuously monitored for incoming call information and is used to make call requests. The radio automatically changes to a traffic channel to place and receive calls and then returns to the control channel when the call is complete.
Page 45: Channels
General Operation The maximum number of channels assignable to a system is limited to 512. Channels may also be limited by available memory space as described in the following information. 3.9.4.2 Channels A channel selects a radio (RF) channel or talk group as follows: Conventional Analog Mode - A channel selects a specific radio channel, Call Guard (CTCSS/DCS) squelch coding, and other parameters unique to that channel.
Page 46: Rf Test Mode
General Operation After pressing Side Button 2 during the self test, the radio completes the self test and displays the message “Service”. The radio cycles through several informational displays, which are summarized in Table 3.1. Table 3.1 Initial Messages 5100 ES Description Service Test Tune Mode initial message...
Page 47: Rf Test Mode Frequencies (Mhz)
General Operation Table 3.2 summarizes frequencies that can be tested. Table 3.2 RF Test Mode Frequencies (MHz) Test 700/800 700/800 Channel VHF Rx * VHF Tx * UHF Rx * UHF Tx * MHz Rx MHz Tx 136.075 136.025 380.075 380.025 764.0625 764.0125...
Page 48: Control Top And Keypad Test Mode
General Operation 3.10.2 Control Top and Keypad Test Mode Once Control Top and Keypad Test Mode is selected from the menu, all icons are displayed and the LED lights red. Upon release of the emergency button, the radio is in Control Top and Keypad Mode.
Page 49: Radio-Wide Features
E C T I O N Radio-wide Features Section 4 Option Switches Most all the buttons on this radio are programmable as follows: • On the side panel, the three buttons above the PTT switch (see Figure 2.3). • On the top panel, the rotary three-position switch and the orange button (see Figure 2.2). Note For descriptions of the functions controlled by these switches, refer to the section of this manual referenced in the last column of Table 4.1.
Page 50: Feature Enable/Disable
Radio-wide Features Table 4.1 Programmable Functions Function Function Interconnect Talk Group Select Keypad Lockout Tones Toggle Keypad Programming Tx Power Keypad Squelch Unit Call Keypress Tone Volume Adjust Unused Function Index 0f Key Select Unused Function Index 10 Menu Unused Function Index 17 Message Unused Function Index 1e Monitor...
Page 51: Menu Mode
Radio-wide Features Table 4.2 Features which May Be Enabled/Disabled using the Function Button SMARTNET/ Function Conventional SmartZone P25 Trunking Scan Selective Squelch (ON) / Normal Squelch (OFF) Site Lock Surveillance Mode Zone Lock Menu Mode Note For descriptions of the functions controlled by the menu mode parameters, refer to the section of this manual referenced in the last column of Table 4.1.
Page 52: Time-Out Timer
Radio-wide Features The menu mode operates as follows: 1 To select the menu mode, press the <F2> key. Up to three menu parameters are then displayed as shown in the preceding illustration. 2 To scroll up or down through the menu parameter list, press the Up/Down switch. The selected parameter is indicated by a dark bar.
Page 53: Power Output Select
Radio-wide Features Pressing and holding the Home Zone option switch until a tone sounds makes the currently selected zone the new Home zone. The radio is also programmed so that either the home or last selected zone is selected when power is turned on. Refer to Section 3.3 for more information.
Page 54: Surveillance Mode
Radio-wide Features Surveillance Mode The Surveillance mode totally disables the backlight, all alert tones, and front panel LED indicator in all operating modes. The radio can be fixed in this mode by programming or it can be turned on and off by the user if the Surveillance Mode option button or menu parameter is programmed.
Page 55: Radio Wide Scanning
Radio-wide Features • If the zone or channel is changed while scanning is selected, scanning continues on the same or a different scan list (see Section 4.10.1). Note Each SMARTNET/SmartZone and P25 trunked channel can be programmed so that scanning is automatically enabled when the channel is selected. 4.9.2 Radio Wide Scanning Note...
Page 56: Transmitting In The Scan Mode
Radio-wide Features 4.9.4 Transmitting in the Scan Mode 4.9.4.1 Priority Scan Mode: When the transmitter is keyed while scanning is enabled, the transmission may occur on various channels as follows. Conventional Operation - Transmissions can be programmed to always occur on the priority, selected, or receive channel (if applicable).
Page 57: Scan Lists
Radio-wide Features 4.10 Scan Lists 4.10.1 Priority Scan Lists Note The selected channel is always scanned. A scan list is simply the channels that are scanned when scanning is enabled. With all operating modes, as many priority scan lists as are required can usually be programmed (up to 256).
Page 58: Editing A Priority Scan List
Radio-wide Features SMARTNET/SmartZone and Project 25 Trunked Channels - Each channel (talk group) can be programmed so that one of the programmed lists is selected or scanning is disabled (No List). In addition, channels can be programmed so that scanning is automatically enabled (Auto Scan) when they are selected.
Page 59: Radio Wide Scan Lists
Radio-wide Features Note Priority channels can be deleted. 5 If the selected channel is in the scan list (scanned), the icon is displayed. To change the status of the displayed channel, press the <F2> (Enter) switch. With conventional channels only, if the selected scan list is programmed with fixed priority channel(s), the next press of <F2>...
Page 60 Radio-wide Features 3 If the selected channel is in the scan list (scanned), the icon is displayed. To change the status of the displayed channel, press the <F2> (Enter) switch. 4 To exit this mode and save the changes, press the <F1> (Exit) key or the RWS Edit option switch again.
Page 61: Conventional Mode Features
E C T I O N Conventional Mode Features Section 5 An overview of the conventional operating mode is located in Section 3.9.1. The following information describes the features unique to analog and digital (Project 25) conventional operation. Refer to the preceding “Radio Wide Features” (Section 4) for information on features common to all operating modes.
Page 62: Manual Channel Monitoring
Conventional Mode Features 5.1.2 Manual Channel Monitoring The automatic monitoring just described may occasionally disable the transmitter when the channel is not in use, such as if the repeater has extended hang time. In this case, you may not want to use automatic monitoring, but monitor the channel manually as follows: Busy Indicator - With scanning disabled, note if the multi-function indicator on the front panel is steady green.
Page 63: Busy Channel Lockout
Conventional Mode Features Busy Channel Lockout The Busy Channel Lockout feature (also called Transmit Disable on Busy) automatically disables the transmitter if the channel is busy when the PTT switch is pressed. When the transmitter is disabled by this feature, “Busy” is displayed, a busy tone sounds, and the transmitter is disabled.
Page 64: Call Guard Squelch Enable/Disable
Conventional Mode Features 5.4.1 Call Guard Squelch Enable/Disable The Normal/Selective option switch or menu parameter (if programmed) can be used to disable receive Call Guard squelch on analog channels or group ID code detection on P25 channels. When selective squelch is disabled, “Sq Normal” is flashed in the display, and when it is enabled, “Sq Select”...
Page 65: Selective Squelch Code Select (Ctcss/Dcs/Nac)
Conventional Mode Features 5.4.4 Selective Squelch Code Select (CTCSS/DCS/NAC) Note Call Guard codes can be permanently reprogrammed by keypad programming described in Section 5.15. This feature allows the normal transmit and receive Call Guard (CTCSS/DCS/NAC) programming to be temporarily overridden with a code selected from a pre programmed list.
Page 66: Penalty Timer
Conventional Mode Features Penalty Timer A penalty timer may be programmed on conventional systems to prevent transmissions for the programmed time after the time-out timer disables the transmitter (see Section 4.4). The penalty timer can be programmed for the same times as the time-out timer, and timing starts when the PTT switch is released.
Page 67: Displaying Transmit/Receive Frequency
Conventional Mode Features In the PC Configure Radio Wide screen, you can program one of the function buttons to the “Repeater Talkaround” function. With a button programmed as “Repeater Talkaround”, the user can press this button while on any conventional frequency, shifting the radio from operation through a repeater, to simplex operation on the repeater transmit frequency.
Page 68: Emergency Calls
Conventional Mode Features For an Emergency Alarm: • The DTMF Emergency ID is sent. • The MDC ID is sent with the emergency bit set. • The Five Tone ID is sent with the fifth tone being status type emergency. •...
Page 69: Emergency Hot Mic
Conventional Mode Features MDC, Five Tone Signaling, or Single Tone Signaling are sent for Analog Emergency Calls, depending on the setting of the Emergency Analog Signaling field in PC Configure. 5.9.2.1 Emergency Hot Mic If Emergency Hot Mic has been enabled for emergency calls, automatic transmitting occurs with microphone audio unmuted without having to manually press the PTT switch.
Page 70: Conventional Mode Scanning
Conventional Mode Features 5.10 Conventional Mode Scanning Channel scanning features common to all operating modes are described in Sections 4.9 and 4.10. The following information describes features unique to conventional operation. 5.10.1 Transmitting in Scan Mode Each conventional scan list can be programmed for one of the following modes. These modes determine if priority sampling occurs and also the channel on which transmissions occur while scanning.
Page 71: Changing The Priority Channel
Conventional Mode Features Either a single or dual priority channels can be programmed if desired. With dual priority, a call on the second priority channel is interrupted by a call on the first priority channel but not vice versa. When scanning and the selected channel is a single or first priority channel, is indicated in the display.
Page 72: Standard Conventional Calls
Conventional Mode Features • If “Sel Chan” is displayed, the priority channel is always the selected channel and cannot be changed. • If no indication displayed, the scan list may not be user editable or the channel may not be in the scan list. 5.11 Standard Conventional Calls Standard conventional calls are placed to other radio units monitoring the selected channel.
Page 73: Dtmf/Ani Signaling
Conventional Mode Features • MDC Three features use analog signaling: • Pre and Post ANI • Emergency Alarm • RTT 5.12.1 DTMF/ANI Signaling DTMF (Dual Tone Multi-Frequency) tones can be generated for ANI (Automatic Number Identification) and other purposes on conventional analog channels. One of the following options may be enabled on each channel: Pre-Tx ANI - A pre programmed ANI sequence is automatically sent each time the PTT switch is pressed.
Page 74: Five-Tone Signaling
Conventional Mode Features MDC1200 ANI - Both pre and post ANI are supported. MDC1200 Decode - MDC1200 decode functionality is supported so that the radio can handle the following MDC1200 features: • Process the system acknowledgement of emergency transmissions – so that the user knows that the emergency has been received •...
Page 75: Wireless Cloning
Conventional Mode Features Only zones with conventional analog and P25 channels can be transferred using this function. Any SMARTNET/SmartZone and P25 trunked information is not transferred. In addition, the P25 Unit ID, encryption keys, and the RSI ID and other OTAR information are not transferred.
Page 76: Project 25 Mode Features
Conventional Mode Features highlight “Complete” and press the <F2> key to begin the data transfer. This mode overwrites all this information currently in the slave radio. None of the previous information is retained except for the IDs as described in Section 5.13. 5.14 Project 25 Mode Features Note The following features are unique to conventional P25 channels.
Page 77: Changing A Channel Talk Group
Conventional Mode Features When a P25 group call is received, the alias (or frequency) of the selected channel is displayed. The radio can be programmed so that the following are also displayed for 0.5- 7.0 seconds or continuously during the call. P25 PTT ID- The unit ID of the radio placing the call is displayed.
Page 78: P25 Conventional Telephone Calls
Conventional Mode Features Place and receive a Unit Call as follows: 1 To transmit a Unit Call, press the Unit Call option switch or select the Unit Call menu parameter. The alias (tag) of the last Unit Call is displayed. 2 If required, press the Up/Down switch to display the desired call.
Page 79: Access/De-Access Codes
Conventional Mode Features 5.14.6.1 Access/De-Access Codes P25 conventional telephone calls utilize an access to access the system when placing a telephone call, and a de-access code to terminate the call when it is finished. These codes are pre programmed in pairs by the Access/De-Access Code list selected on the conventional Per System screen, and up to 16 pair can be programmed.
Page 80: Answering A Telephone Call
Conventional Mode Features 6 When the telephone call is finished or if it could not be completed for some reason, end it by pressing the Phone option key or <F1> key. This sends the de-access code which tells the system that the call is finished and that the repeater can be released. 5.14.6.3 Answering a Telephone Call 1 When a telephone call is received, “ringing”...
Page 81: Messaging
Conventional Mode Features 3 Press the PTT switch or the <F2> key and one of the following occur: • If five beeps sound, the system received the page and the paged radio is on the air and received it. The page mode is automatically exited. •...
Page 82: P25 Packet Data
Conventional Mode Features 5.14.10 P25 Packet Data P25 packet data transmission capability is available with model 5100 ES portables. A P25 Packet Data option button or menu parameter must be programmed to toggle the data mode on and off. The P25 Packet Data mode allows a subscriber unit to act as a packet data modem for a remote application connected to the subscriber unit via an RS-232 or SLIP (Serial Line Internet Protocol) connection.
Page 83: Menu Description
Conventional Mode Features Keypad programming allows conventional channel parameters such as the transmit and receive frequency, Call Guard squelch code, and encryption key to be changed. In addition, several conventional mode timers can be changed. It cannot be used to reprogram disabled channels or any SMARTNET/SmartZone/P25 Trunked information.
Page 84: Zone Password
Conventional Mode Features Press the <F2> (Select) key to select a highlighted parameter, and press the <F1> key from one of the main menus to exit keypad programming. Pressing it in the other menus returns to the previous menu. The Up/Down switch is also used in several menus to scroll through available selections.
Page 85: System Parameters
Conventional Mode Features 5.15.5 System Parameters Note If “Password” is briefly displayed when attempting to select a parameter, see Section 5.15.2. The “Sys Parms” menu parameter selects the conventional mode timers to be reprogrammed (see following). Press the <F2> switch to select the “Sys Parms” parameter and then press the Up/Down switch to display the desired parameter.
Page 86: Ctcss/Dcs Squelch Control (Analog Channel)
Conventional Mode Features Sq Adj (Analog Only) - Changes the preset squelch setting on that channel. The default setting is “0” and values of –7 to +7 can be selected. Increasing this setting toward +7 causes the squelch to open sooner so that weaker signals can be received, and decreasing it toward –7 causes the opposite to occur.
Page 87: Nac Squelch Control (Project 25 Channel)
Conventional Mode Features code type (CTCSS analog or DCS digital). Then press <F2> to select it and enter the code number similar to programming a channel frequency as just described. Rx Code - Selects the receive codes the same as Tx Code above. 5.15.6.2 NAC Squelch Control (Project 25 Channel) TX NAC - Programs the transmit Network Access Code (NAC) which can be any...
Page 88 Conventional Mode Features 5-28 5100 ES Model II/III Portable Radio Operating Manual December 2006...
Page 89: Analog And Digital Operation
E C T I O N SMARTNET/SmartZone/P25 Section 6 Trunked Features ® ® An overview of the SMARTNET /SmartZone and P25 Trunked operating modes is located in Section 3.9. The following information describes the features unique to these modes of operation. Refer to the “Radio Wide Features” section starting on page 1 for information on features common to all operating modes.
Page 90: Standard Group Calls
SMARTNET/SmartZone/P25 Trunked Features Standard Group Calls Standard group calls may be placed to another radio, group of radios, or a dispatcher, depending on programming. Most calls are probably this type. Proceed as follows to place and receive group calls. 6.3.1 Placing a Standard Group Call 1 Turn power on and set the volume as described in Section 3.1.
Page 91: Receiving A Standard Group Call
SMARTNET/SmartZone/P25 Trunked Features 6.3.2 Receiving a Standard Group Call Calls are received on only the talk group and/or announcement group programmed for the selected channel (with scanning disabled). When the selected channel is programmed with both Talk and Announcement groups, only the Talk and Announcement group IDs are detected.
Page 92: Placing An Enhanced Private Conversation Call
SMARTNET/SmartZone/P25 Trunked Features 6.4.1 Placing an Enhanced Private Conversation Call To recall from a list: 1 Momentarily press the Private Call option key or select that menu parameter and the alias of the last called radio is displayed. The private call mode is indicated by the display.
Page 93: Placing A Standard Private Conversation Call
SMARTNET/SmartZone/P25 Trunked Features • If your radio does not have the proper encryption key, “Keyfail” is displayed and the call must be made in the clear mode by pressing the Clear/Secure option key (if strapped to switchable). Otherwise, load the correct key. 4 When the call is finished or is not answered, end it by pressing the Private Call option key or the <F1>...
Page 94: Receiving A Private Call (All Types)
SMARTNET/SmartZone/P25 Trunked Features • If the call is in the secure mode and the radio does not have the proper encryption key, “KEYFAIL” is displayed and the call must be made in the clear mode by pressing the Clear/Secure option key or selecting that menu parameter (if strapped to switchable). Otherwise, load the correct key.
Page 95: Placing A Telephone Call
SMARTNET/SmartZone/P25 Trunked Features • List only - Telephone numbers can be selected from a pre programmed list only (direct entry using the keypad is not allowed). • Unlimited - Telephone numbers can be selected from a list and also dialed directly using the keypad.
Page 96: Answering A Telephone Call
SMARTNET/SmartZone/P25 Trunked Features • If the selected telephone number is not valid, “Invalid” is displayed and an alert tone sounds. Select a valid number. • If the system is busy, “Busy” is displayed and the busy tone sounds. The call will automatically proceed when the system becomes available.
Page 97: Enhanced Private Conversation Mode
SMARTNET/SmartZone/P25 Trunked Features 3 To answer the page as a private call (see Section 6.4), press the Private Call option switch or select that menu parameter and the alias of the radio paging you is displayed. Press the PTT switch and respond. 6.6.1.1 Enhanced Private Conversation Mode •...
Page 98: Sending Status Conditions
SMARTNET/SmartZone/P25 Trunked Features The messaging feature allows preprogrammed messages to be sent to a dispatcher. Up to 16 messages can be preprogrammed, and they are identified by an alias. If a Message option switch or menu parameter is programmed, messages are sent as follows: 1 Momentarily press the Message option switch or select that menu parameter.
Page 99: Emergency Alarms
SMARTNET/SmartZone/P25 Trunked Features • Emergency Alarms are transmitted on the Control Channel. If the emergency call checkbox is checked, the radio will transmit an emergency call on the selected talkgroup if no emergency talkgroup is programmed. If an emergency talkgroup is programmed, the call will be transmitted on the emergency talkgroup •...
Page 100: Emergency Calls
SMARTNET/SmartZone/P25 Trunked Features 6.9.2 Emergency Calls An emergency call urgently requests access to a voice channel (an emergency tone usually does not sound at the console). An emergency call is placed by pressing the PTT switch after pressing the Emergency option button or selecting the Emergency menu parameter. If the Emergency Hot Mic feature is enabled, the emergency call is automatically transmitted without having to press the PTT switch (see following description).
Page 101: External Emergency Feature
SMARTNET/SmartZone/P25 Trunked Features options. If “No Receive Activity During Emergency” is programmed, receive audio and the front panel LED are disabled in the receive mode. 5 To exit this mode, cycle radio power or press and hold the Emergency switch. 6.9.3 External Emergency Feature A special man-down switch (currently available only from third-party vendors) is attached...
Page 102: Priority Talk Group Sampling
SMARTNET/SmartZone/P25 Trunked Features permit scanning, it is automatically enabled again when a channel is selected that permits scanning. • Up to 256 scan lists, each with up to 512 talk groups from the same system can be programmed. The selected scan list can be temporarily changed and edited as described in Section 4.10.1.
Page 103: Smartzone And P25 Trunked Unique Features
SMARTNET/SmartZone/P25 Trunked Features 6.13 SmartZone and P25 Trunked Unique Features P25 Trunked and SmartZone modes can provide access to single or multi-site systems. The P25 Trunked mode can provide access to a single trunked site or roaming between several trunked sites. 6.13.1 Busy Override The busy override feature is enabled at the system level by the system manager and is not a programmable radio feature.
Page 104: Determining Current Site And Searching For New Site
SMARTNET/SmartZone/P25 Trunked Features 6.13.3 Determining Current Site and Searching For New Site To display the RSSI level of the current site, press the Site Search option switch or select that menu parameter. The display then indicates the current site number as “Site xx” and the RSSI level as “RSSI xx”.
Page 105: P25 Wide Area Scan
SMARTNET/SmartZone/P25 Trunked Features The result of this operation is that all radios with the same programmed home site are forced to the home site to communicate which ensures that they can continue to communicate. If the home site is not available, the Out-of-Range condition tells the user to attempt communication on another system or by some other means.
Page 106 SMARTNET/SmartZone/P25 Trunked Features 1 Assume TG1 is selected. If it is the first time this talk group is selected, normal searching for a control channel occurs according to the hunt methods previously described. 2 When another talk group is selected, the active valid site for TG1 is stored in EEPROM memory.
Page 107: Miscellaneous
E C T I O N Miscellaneous Section 7 Signaling Tones Information is communicated to users of the 5100 ES radio using signal tones and alerts and by LED signaling. Table 7.1 shows the information and signaling tones supported by If you are viewing a PDF of this manual on a computer equipped the 5100 ES radio.
Page 108 Miscellaneous Table 7.1 Tones for the 5100 ES Radios (Continued) Tone Message Name Message Description Audible Description Category Clear Alert Tone Radio receives a Secure call while in a Medium Pitched Beep Action Clear Mode - PCC Option DTMF Keypress DTMF Keypress Medium pitched continuous tone Action...
Page 109 Miscellaneous Table 7.1 Tones for the 5100 ES Radios (Continued) Tone Message Name Message Description Audible Description Category Return to Normal • Dynamic Regrouping has been Medium Pitched Beep followed by Action Canceled a higher pitched beep • Voltage has returned to Normal •...
Page 110: Error Messages
Miscellaneous The 5100 ES radio transfer standard functional display text information via the serial port. The radio signals the user via the LED when the radio is in code upgrade boot-load mode. The LED blinks green while in this mode. LED signaling states are described in Table 7.2. Table 7.2 LED Indicators LED Color LED Duration...
Page 111 Miscellaneous Bad Hrdwar - The ESN of the radio is not valid. This error is usually only seen in the factory when first programming brand new logic boards. Batt Low - The battery voltage has been detected as being low. Busy - A call has been attempted and the system has responded that no channels are available for assignment.
Page 112 Miscellaneous List Only - Direct entry of a unit ID or phone number is disabled. Locked - A selector lock command has been received and zone and channel changes are not accepted. Lost Signl - Signal from the infrastructure has been lost during an interconnect call. Low Power - The current channel is strapped to low power and that the user can not select high power at this time.
Page 113: System Operator Programming
Miscellaneous System Operator Programming As noted several times in this manual, programming determines the availability and specific operation of many features. This usually refers to the programming performed by the PC Configure programmer when the radio was set up, not to any programming a user can perform.
Page 114 Miscellaneous If “Unprogramd” is displayed, the cause could be any of the following: • An unprogrammed channel is selected. Select a programmed channel. • The selected channel is programmed for an option that is not installed or an error in programming was detected.
Page 115: Determining Available Options
E C T I O N Determining Available Options Section 8 This manual describes the operation of all features that are currently available for the 51xx ES radio. However, many of these features are optional and therefore may not be available in your radio.
Page 116: Upgrading A Radio With New Options
Determining Available Options • Digital SMARTNET/SmartZone Feature Options • Keypad programming (Federal Government users only) • 512 channels/talk groups (51xx ES, currently standard) • DTMF Keypad support • Zonefail site lock Currently, the only operating mode that is standard with all models is the conventional analog mode.
Page 117: Using Pc Configure To Determine Options
Determining Available Options Using PC Configure To Determine Options To determine what software options have been enabled in a particular radio, it is recommended that you use the PC Configure™ programming software to read and display what options are installed. Proceed as follows: 1 Connect the computer to the radio and start the program as described in the documentation included with the PC Configure software.
Page 118 Determining Available Options 8-4 5100 ES Model II/III Portable Radio Operating Manual December 2006...
Page 119: Password Description
E C T I O N Password Description Section 9 The following passwords may be set: • Four Power-On (User x) Passwords • Download and Upload Passwords • Master Password Programming Passwords Passwords are programmed using a password management screen displayed by the Tools >...
Page 120: Changing Password
Password Description 1 With PCTune 1.1.1.0 or later, select Radio > Reset Passwords. Only password information is erased. 2 With earlier versions of PCTune, after starting the PCTune program, press SHIFT <CTRL> E to toggle the following Erase EEPROM function (otherwise it is grayed and not selectable).
Page 121: Download/Upload Passwords
Password Description 9.2.2 Download/Upload Passwords Separate Download (write) and Upload (read) passwords can be programmed to prevent unauthorized downloading or uploading of radio programming parameters. When one or both of these passwords are used, the proper password must be entered to perform the operation.
Page 122 Password Description 9-4 5100 ES Model II/III Portable Radio Operating Manual December 2006...
Page 123: Secure Communication (Encryption)
E C T I O N Secure Communication (Encryption) Section 10 This radio may be equipped to provide secure communication on some or all channels. This feature encrypts the voice so that it can be understood only by someone using a radio equipped with a similar encryption device and encryption codes.
Page 124: Aes (Advanced Encryption Standard)
Secure Communication (Encryption) 10.1.2 AES (Advanced Encryption Standard) A new encryption standard called AES is replacing DES-OFB encryption on digital (P25) channels. It uses a 128-, 192-, or 256-bit encryption key instead of the 64-bit key used with DES. EFJohnson radios currently support only 256-bit AES keys. The type of encryption (DES or AES) is determined by the type of encryption key that is loaded (see Section 10.2), and not by the PC Configure programming software.
Page 125: Pid/Sln Key Management Modes
Secure Communication (Encryption) If an attempt is made to transmit a secure message without loading the corresponding key, “Keyfail” is displayed. The message must then be transmitted in the clear mode (this is possible only if the channel is strapped to “switchable”) or the key must be loaded. 10.2.1 Key and Algorithm IDs Each encryption key is programmed with a Key ID (also called Logical ID).
Page 126: Maintaining Keys In Memory
Secure Communication (Encryption) Number), typically from 0-4095. A Keys Table must then be programmed to link channel PIDs to a specific SLN. The use of this type of indirect linking allows keysets and key IDs to be changed via OTAR while keeping the mapping from the channel or talk group the same. For example, as shown in Figure 10.1, PID 4 selects SLN 24 which selects key slot 24 in both keysets.
Page 127: Encryption Key Erase
Secure Communication (Encryption) 10.2.5 Encryption Key Erase A Key Erase menu item can be programmed that allows the user to permanently erase all stored keys. If OTAR TEK and KEK keys are stored, all keys of both types are erased. This function can be used to ensure that unauthorized encrypted calls can no longer be placed or received by a radio.
Page 128: Receive Mode Options
Secure Communication (Encryption) Note If all channels/talk groups are strapped clear or secure and no Clear/Secure option switch or menu parameter is programmed, this parameter must always be selected (see following). If the Clear/Secure switch or menu parameter are not programmed, the radio is always in the last known state (usually Clear) and there is no way to change it.
Page 129: Encryption Key Types
Secure Communication (Encryption) The actual OTAR rekeying functions are performed by a Key Management Facility (KMF) that sends Key Management Messages (KMM) to the radios. These messages are themselves encrypted using an encryption key. Radios must be OTAR-compatible and programmed for OTAR for this type of rekeying to occur. OTAR is available only on P25 conventional and trunked channels, and only to program DES-OFB and AES keys.
Page 130: Key Management Facility
Secure Communication (Encryption) A diagram of a keyset is shown in Figure 10.2. Some information may be optional as shown. Figure 10.2 Keyset Diagram 16-Bit Keyset ID Keyset Name (Opt) SLN 1 SLN 2 SLN 4095 10.4.3 Key Management Facility The Key Management Facility (KMF) provides key management and OTAR functions to applicable radios within the radio system.
Page 131: Message Number Period (Mnp)
Secure Communication (Encryption) 10.4.4 Message Number Period (MNP) One of the parameters that is programmed in a radio utilizing OTAR is Message Number Period (MNP). This parameter is programmed as described in Section 10.5.2. This parameter is used to minimize the possibility of someone sending messages to “spoof” the system or radio.
Page 132 Secure Communication (Encryption) Crypto Group - A group of up to 16 keysets containing the same type of keys (either TEK or KEK). Although a crypto group can contain up to 16 keysets, only two are normally used. Only one keyset in a crypto group is active at a time. EFJohnson radios currently support only one crypto group for TEKs, crypto group 0.
Page 133: Radio Setup For Encryption
Secure Communication (Encryption) Logical Link ID (LLID) - An ID transmitted with a CAI data message to identify the destination of the message. Message Number Period (MNP) - The maximum difference between message numbers that can occur before a message is declared invalid (see Section 10.4.4). Over-The-Air-Rekeying (OTAR) - The process of sending new encryption keys over the air using an RF interface.
Page 134: Additional Setup For Otar
Secure Communication (Encryption) Options Enabled - The desired encryption type must have been enabled at the factory (DES, DES-OFB, AES-OFB). To determine what options are enabled, using the PC Configure programming software, select the Transfer > Read Options From Radio menu parameter.
Page 135: Motorola Third-Party Rnc Registration
Secure Communication (Encryption) 2 On the Global screen, Page 2, set the Unit RSI ID as desired (normally this ID is initially the same as the Digital Unit ID). It can be changed later by the KMF or keyloader if desired. Note these two IDs. 3 On the Per System Conventional screen, Page 2, for OTAR and Data Settings, select OTAR Enabled = On and Data Registration Enabled = On.
Page 136: Radio Otar Capabilities
Secure Communication (Encryption) MNP (Message Number Period) - Load the proper message number period into the radio (typically 1000). Refer to Section 10.4.4 for more information. Verify that the above information was properly stored in the radio by viewing it using the keyloader.
Page 137: Otar Option Switches
Secure Communication (Encryption) NEGATIVE ACK 0x16 NO SERVICE 0x17 REKEY ACK 0x1D OTAR REGISTRATION 0x25 OTAR REGISTARTION RESPONSE 0x26 REKEY 0x1E UNABLE TO DECRYPT 0x27 WARM START 0x20 ZEROIZE 0x21 ZEROIZE RESPONSE 0x22 10.6.3 OTAR Option Switches The following additional option switches can be programmed with the 5100 ES portable to control OTAR functions.
Page 138 Secure Communication (Encryption) Erase Keys - Erases all keys in the radio the same as the Erase Keys option switch described in the preceding section. 10-16 5100 ES Model II/III Portable Radio Operating Manual December 2006...
Page 139 Index Dynamic Regrouping ......6-14 Dynamic Zone ........3-7 Accessory Connector .
Page 140 Index (continued) Hot Mic ........5-9 6-12 Monitor Mode .
Page 141 Index (continued) Site Search .......6-16 Squelch Select List ......5-5 Radio Options Screen .
Page 142 Index (continued) Surveillance Mode .......4-6 Systems ........3-14 Talkaround Enable/Disable .
Page 144 1440 Corporate Drive, Irving, TX 75038-2401 Phone: 972-819-0700, 1-800-328-3911 Fax: 972-819-0639 www.efjohnson.com Printed in the U.S.A. Part of Part Number 002-5100-72000CD December 2006 ©Copyright 2006 EFJohnson EFJohnson logo® is a trademark of EFJohnson.
