- Page 1 ㅜ...
-
Page 2: Table Of Contents
Table of Contents 1. What is the SenseView DESKTOP?.......... 1 2. Safety Precaution ..............2 3. Package ..................3 4. Overview ..................4 5. How to install ................5 (1) Connect the power cable ............ 5 (2) Using DVI-D cable .............. 6 6. - Page 3 8. Additional features ..............14 (1) Adjusting the monitor position ........... 14 (2) Light on/off ................ 15 9. Troubleshooting ............... 16 10. Technical Specifications ............17 11. Warranty ................18...
-
Page 4: What Is The Senseview Desktop
User Manual - SenseView DESKTOP 1. What is the SenseView DESKTOP? The SenseView DESKTOP is an electronic magnifier for low vision and the elderly to read books, manuals, grocery information with the large screen monitor. Not as same as general optical magnifier, it magnifies a large range so convenient to read lots of text at once. -
Page 5: Safety Precaution
User Manual - SenseView DESKTOP 2. Safety Precaution To protect both yourself and the equipment, observe the following precautions. Do not use damaged power plug or unsuitable outlet to prevent electronic shock or fire. Do not touch power plug with wet hands to prevent electronic shock. ... -
Page 6: Package
User Manual - SenseView DESKTOP 3. Package The SenseView DESKTOP consists of the following items. DVI-D cable x1 SenseView DESKTOP Monitor adapter User manual Main frame adapter... -
Page 7: Overview
User Manual - SenseView DESKTOP 4. Overview (1) LCD Monitor (2) Front Controller (3) Cable Cover (4) Table Lock (5) Reading table (6) Camera (7) Camera Module (8) Monitor arm... -
Page 8: How To Install
User Manual - SenseView DESKTOP 5. How to install (1) Connect the power cable After purchasing the unit, you need to connect the power cable of monitor and the power cable of the body to start using SenseView DESKTOP. ① Connect the power cable of the monitor to monitor connection cable which is set to SenseView DESKTOP as shown below. -
Page 9: Using Dvi-D Cable
User Manual - SenseView DESKTOP ③ Connect the Power cable to the body through the lower hole on the Cable cover and replace the Cable cover. ④ Plug the Power cable and Monitor cable into outlets. ⑤ Turn on the power (2) Using DVI-D cable To use DVI-D cable, disconnect VGA cable. - Page 10 User Manual - SenseView DESKTOP ③ Tie up the cables with the cable clamp and screw into the Monitor arm. ④ Pull the Cable cover out and connect the DVI-D cable to the body through the hole on the Cable cover. It should be connected upper DVI-D port.
-
Page 11: Easy Guide
User Manual - SenseView DESKTOP 6. Easy guide (1) Power on The Power button is the first key from the right in the front controller. To start using the unit, press the Power button. While it's on, the LED located at the top of the right side in the front controller will be turned on with green color. -
Page 12: Changing The Magnification Rate
User Manual - SenseView DESKTOP The Table lock, a blue lever at the front of the Reading table, allows you to fix the Reading table. To lock the Reading table, move the lever all the way to the right. To unlock the Reading table, move the lever to the left. -
Page 13: Changing The Contrast
User Manual - SenseView DESKTOP (6) Changing the contrast To adjust contrast to see the image clearly irrespective of the material being viewed. The Contrast key is the first key from the left. Tip) Rotate the Contrast key to the left for the letters with weak contrast and rotate to the right for strong contrast. -
Page 14: Using The Front Controller
User Manual - SenseView DESKTOP 7. Using the Front controller You can use the Front controller to set the options. (1) Magnification rate The SenseView DESKTOP can magnify from 3X to 50X. The Zoom key is located in the center of the Front controller. ... -
Page 15: Changing The Contrast
User Manual - SenseView DESKTOP Press the Mode key once again. “CONFIRM” will show up and it is saved If you don’t want to save, rotate the Mode key and when “SAVE? NO” shows up, press the Mode key. “EXIT” will show up and it is canceled. ③... -
Page 16: Using The Focus Lock
User Manual - SenseView DESKTOP (4) Using the Focus lock The SenseView DESKTOP provides Automatic focus, so to prevent to focus your hand or the pen when you write, use the Focus lock. Press the Contrast key, “F/LOCK” will show up and disappear. ... -
Page 17: Additional Features
User Manual - SenseView DESKTOP 8. Additional features (1) Adjusting the monitor position You can adjust the monitor for your convenience. Hold both sides of the monitor and move up or down and swivel left or right. Pulling the monitor down Pulling the monitor up Turning the monitor to the left Turning the monitor to the right... -
Page 18: Light On/Off
User Manual - SenseView DESKTOP Tilting the monitor forward Tilting the monitor backward ※ (Note) Pulling monitor too aggressively can cause the monitor to fall down, and it can bear a serious damage. When adjusting the position, please be careful, and try to adjust it slowly (2) Light on/off When you turn on the SenseView DESKTOP, the light is on. -
Page 19: Troubleshooting
User Manual - SenseView DESKTOP 9. Troubleshooting (1) The screen is blank. Check if the power of monitor is on. It may be turned off the monitor accidently. Check the monitor cable. When the cable is not connected correctly, it doesn’t display accurately. -
Page 20: Technical Specifications
User Manual - SenseView DESKTOP 10. Technical Specifications Magnification 3X~50X (19" monitor) Power 12V / 3A 340mm(w) x 467mm(d) x 361mm(h) Size (except the monitor and Displaying Module) 1. True Color 2. Black text on White background Basic Color Mode 3. -
Page 21: Warranty
User Manual - SenseView DESKTOP 11. Warranty (1) Warranty term is 2 years from your purchasing. (2) Warranty does not cover the problem due to the user’s fault. ※ Note: The warranty term will be different from each country. - Page 22 User Manual - SenseView DESKTOP NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation.
