Summary of Contents for Micro Digital MDC-i6291VTD-66H
-
Page 1: Product Overview
MDC-i6291VTD-66H User’s Manual Part 1 MDC-i6291VTD-66H User’s Manual Part 1 (Product Overview) Micro Digital INC. www.microdigital.co.kr Micro Digital INC. -
Page 2: Table Of Contents
MDC- i6291VTD-66H Front Panel View ................8 2.2. MDC- i6291VTD-66H Rear Panel View ................9 2.2.1. CTL Port Description....................10 MDC- i6291VTD-66H HW installation and basic setup ............11 3.1. Before installation ......................11 3.2. Factory Default Condition ....................11 3.3. MDC- i6291VTD-66H Hardware Installation ..............11 Micro Digital INC. -
Page 3: Product Overview
Cable modem. You can monitor Video of MDC- i6291VTD-66H through the web browser, if MDC- i6291VTD-66H is connected to Network. MDC- i6291VTD-66H supports Video compression both Motion- JPEG and H.264 simultaneously so that user can choose appropriate Video compression for the purpose. Picture 1 : MDC- i6291VTD-66H Micro Digital INC. -
Page 4: Key Functions Of Mdc- I6291Vtd-66H
Support Various PTZ (Pan/Tilt/Zoom) Devices Support Sensor Input, Digital Output Support Transparent mode Built-in 2 way Audio transmission (1ch A-in, 1 A-out) Encryption function by user authentication Support Modem (Dial-in, Dial-out) Image transmission function via FTP, Email Micro Digital INC. -
Page 5: Technical Specification Of Mdc- I6291Vtd-66H
Remote system update via telnet, FTP OR web browser. PWR Supply DC 12V or AC 24V Dual Power Supply PWR Consumption DC 12V 850mA Temperature : -20° ~ 80°C Operating Environment Humidity : 20 ~ 90% RH(non-condensing) Micro Digital INC. - Page 6 User can be install user program daemon for event notification or sending image. Embedded operating system: Linux 2.6 HTTP, TCP/IP, FTP, Telnet, RARP, PPP, PAP, CHAP, DHCP, SMTP Supported protocols client(e- mail), NTP, RTP/RTSP Applications MicroDigital CMS, MicroDigital NVR Table 1 : MDC- i6291VTD-66H Specification Micro Digital INC.
-
Page 7: Packing List
Pictures) Bracket Screwer Video Test Cable Control Cable Table 2 : MDC- i6291VTD-66H Packing List Please check all the listed items are included in your package. For any missing items, please contact your local distributor. Micro Digital INC. -
Page 8: Hardware Description
Picture 2 : MDC- i6291VTD-66H Front & Rear Panel Name Description IR LED 66ea, 850nm Camera Module Camera module to input Video LAN Stopper PG13.5 Bracket Hole Power Cable Stopper Table 3 : MDC- i6291VTD-66H Front & Rear Panel Description Micro Digital INC. -
Page 9: Mdc- I6291Vtd-66H Rear Panel View
RED LED – LAN TX/RX(Light blinks when there is data transmission at LAN(Tx/Rx) LED the connected LAN. (RED/GREEN) GREEN LED – LAN LINK(Light blinks when LAN is physically connected.) Video Port CVBS Out Port OSD Port OSD Control Table 4 : MDC- i6291VTD-66H Inside panel Description Micro Digital INC. -
Page 10: Ctl Port Description
For RS-232 connection for Serial input device, Modem or Console (Hyperterminal.connection), RXD,TXD and GND are used. For connection to PC, RXD and TXD are used. RXD and TXD should be cross to communicate properly Picture 4 : CTL Port Description Micro Digital INC. -
Page 11: Mdc- I6291Vtd-66H Hw Installation And Basic Setup
Capital letters. 3.3. MDC-i4291VTD-66H Hardware Installation Following steps are the physical installation process for MDC- i6291VTD-66H. Connect cable to LAN port of MDC- i6291VTD-66H. Connect power cable and turn on power of MDC-i6291VTD-66H (Await until booting is finished) Micro Digital INC. - Page 12 First, Network Configuration by MD-installer. Second, Camera Configuration by MD-installer or admin-menu. Third, Service Configuration by MD-installer or admin-menu. You can configure most settings on Admin menu by Web Browser so you have to configure Network first. Micro Digital INC.
