Introduction
Congratulations! You are now using a
quality product made by BARTEC PIXAVI.
The Orbit X EX is intrinsically safe and
can be used in hazardous areas. All you
need to get started can be found in this
quick guide.
Button combinations
Action Button
Short Press
1 Second Press
3 Seconds Press
Light Button
Short Press
1 Second Press
Power/Standby Button
Short Press
3 Seconds Press
Take a Picture
Start/Stop Video Rec.
Call/Hang Up Video Call
Video Light On/Max/Off
Laser On/Off
Standby/Wake up
Power On/Off
Advertisement
Summary of Contents for BARTEC PIXAVI Orbit X EX
- Page 1 Introduction Congratulations! You are now using a quality product made by BARTEC PIXAVI. The Orbit X EX is intrinsically safe and can be used in hazardous areas. All you need to get started can be found in this quick guide.
-
Page 2: Buttons And Ports
Buttons And Ports LED Video Light Camera Microphone 1 Laser Microphone 2 Status LED Action Button Light Button Power/Standby Button Rugged Alu Housing Audio Jack Wi-Fi LED Battery LED Micro USB... -
Page 3: Status Led
Status LED Calling Pulsate In Call Constant Ready To Record Pulsate Recording Constant Pairing Mode Pulsate Booting Pulsate Ready For Use Constant Standby 4 Sec Interval Snapshot One Blink Shutting Down Constant Battery and WIFI LED Strong Signal Fair Signal Not Connected Full Battery Ok Battery... - Page 4 Our Apps Sipido The Sipido video conferencing app is using SIP protocoll and allows you to do mobile video conference and live video streaming from the device over any network. Collaboration X Collaboration X is a Mobile Device Management solution that allows you to remotely manage your devices from your browser.
- Page 5 First time setup of your Orbit X The Orbit X works right out of the box. But in order to take advantage of advanced features like video conferenc- ing, MDM functionality, over the air updates and cloud media library storage you have to connect your Orbit X device to the internet using the Orbit X setup app or the Collaboration X website.
- Page 6 Head mount setup Mounting plate for flat surfaces (e.g. walls) Mounting plate for curved surfaces (e.g. helmet) Orbit X cradle with 2x 1/4” screw mount Quick release bracket Swivel brackets Screws The head mount system is designed to be flexible and fit different types of helmets and equipment.
-
Page 8: Special Conditions For Safe Use
Charging The Orbit X has a high quality, high capacity battery and shall only be charged using the charger supplied with the unit. Charging the Orbit X from 0% to 80% battery capacity takes approximately hours. Charging the remaining 80% to 100% takes 1 ½... -
Page 9: Audio Levels
Please make sure the connectors are dry before connecting a USB cable, headset or charging the unit. Audio Levels The device is compliant with the EN9650-1 standard. However, third party music players can exceed the recommended audio levels, and as such should be used with caution as prolonged listening to sound at high volumes can cause permanent damage. - Page 10 Ce produit répond aux exigences de la section 15 de la réglementation FCC. Son fonctionne- ment est soumis aux deux conditions suivantes: (1) cet appareil ne doit pas causer d'interférences nuisibles et (2) cet appareil doit accepter toute interférence reçue, y compris les interférences qui peuvent provoquer un fonctionnement indésirable.
- Page 11 Conditions For Use (ATEX & IECEx) The ambient temperature range of the Orbit X is -20°C to + 45°C The Orbit X shall be protected from contamination by liquid and dust; this is normally achieved by the operator carrying the device on their person. The USB port shall only be used for charging the Orbit X when in the non-hazardous area.
- Page 12 FCC/IC exposure guidelines when used with an accessory that contains no metal and that positions the device a minimum of 10 mm from the body. Such a device can i.e. be BARTEC PIXAVI camera cradle.
- Page 14 Quick guide...
