Summary of Contents for EKOBUY ekb10075
- Page 1 U S E R M A N U A L EKOBUY 4K HDMI SWITCH 4x1 ekb10075 Enjoy the vivid world!
- Page 2 INTRODUCTION 4x1 4K HDMI Switch The 4x1 hdmi switch support four HDMI ports by remote control or manual button to switch to a display terminal. The HDMI switch can support all hd formats including 720p, 1080i, 1080p multichannel audio.This product comes with two digital audio outputs (optical fiber and coaxial) and one 3.5 mm headphone output all the way, so it is more suitable for home theater systems...
- Page 3 5.1 Audio output showing picture Product picture...
- Page 4 FEATURES Support HDMI1.4b Support 3D Support HDCP1.4 Support highest video resolution 3840*2160/30Hz Support 3.4Gbps data rate for tmds clock up to 340MHz Support 24/30/36 bit deep color Support standard AWG26 cable, input up to 8 metres ,output up to 8 metres ...
-
Page 5: Specifications
SPECIFICATIONS HDMI version ………………………………..……..…………….. HDMI 1.4b HDMI resolution ……………………………………………..Up to 3840*2160/30Hz Support video format................3D Support video color format ………………………..… 24/30/36 bit deep color Support audio format....DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD bandwidth……………………………………………………. …………….340MHz rate……………….…….………………….……..…………….. 3.4Gbps baud Input cable distance..…... ………………..……≤8m AWG26 HDMI standard cable Output cable distance…………………….…...≤8m AWG26 HDMI standard cable Max working current………………………………….………………………..800mA Power adapter format Input..AC (50HZ, 60HZ) 100V-240V;... - Page 6 1) Press the key 1 to switch to the input indicator lights 2) Press the key 2 to switch to the input indicator lights 3) Press the key 3 to switch to the input indicator lights 4) Press the key 4 to switch to the input indicator...
- Page 7 Audio output showing picture Operating and Connecting...
-
Page 8: Ir Remote Control
1 Connect the HDMI source device and HDMI switch input ports with four HDMI cables 2 Connect HD displayer device (monitor or projector) with HDMI switch output ports with one HDMI cable. 3 Connect 5V/1A power adapter with the HDMI switch . Audio Channel switching operations Press the “Select”...
