- Page 1 Multistandard Video Capture Devices Models 2464/3364 Hardware Manual Ver. 1.0.0 | July 2017 SENSORAY | p. 503.684.8005 | email:info@SENSORAY.com | www.SENSORAY.com 7313 SW Tech Center Drive | Portland, OR 97203...
-
Page 2: Table Of Contents
SDI option ......................9 DVI option ......................10 Recommended adaptors ..................11 Analog Audio Accessory Board ................. 12 Software......................... 13 Firmware updates ....................14 Model 3364 firmware update ................14 Model 2464 firmware update ................14 Revision history ...................... 16... -
Page 3: Limited Warranty
Sensoray specifications for two years from the date of shipment to purchaser. Sensoray will, at its option, repair or replace equipment that proves to be defective during the warranty period. This warranty includes parts and labor. -
Page 4: Introduction
DVI, VGA or component video source (with appropriate adaptors), and output DVI. SDI models accept SDI signals per SMPTE 259M(C), SMPTE 292M, and SMPTE 424M. Models 2464 and 3364 are available as a bare boards or in a robust metal enclosure. -
Page 5: System Requirements
1080p60 video. Supported operating systems: Windows 7, 8, 10; Linux 2.6, 3.x, 4.x. Model 2464 requires a 100Base-TX Ethernet connection. Power-over-Ethernet (POE) is supported, as well as an external 5V power supply. The default Ethernet address is 192.168.24.64, net mask 255.255.0.0. -
Page 6: Block Diagrams
Block Diagrams Fig.1. Model 3364 block diagram. - Page 7 Fig.2. Model 2464 block diagram.
-
Page 8: Connectors
Connectors Input/output connectors for SDI and DVI versions, with and without optional audio board (3364TA). -
Page 9: Specifications
71x100 mm (PCB outline, does not include connectors) Mass 40 g (without an enclosure) Operating temperature 0º to 70º C Interface 3364 USB 3.0, USB 3.0 micro B connector 2464 100 Base-TX Ethernet, RJ-45 Power 3364 USB bus powered 2464 5 V power supply or POE... -
Page 10: Dvi Option
71x100 mm (PCB outline, does not include connectors) Mass 40 g (without an enclosure) Operating temperature 0º to 70º C Interface 3364 USB 3.0, USB 3.0 micro B connector 2464 100 Base-TX Ethernet, RJ-45 Power 3364 USB bus powered 2464 5 V power supply or POE... -
Page 11: Recommended Adaptors
Recommended adaptors DVI to VGA: Dynex DX-D1114, or similar. The following pins of the DVI connector carry VGA signals: Signal Green Blue Hsync Vsync 3,11,15,19, Ground 22,29,30,32 DVI to component: Monoprice DVI-I-3-RCA adaptor/cable, or similar. The following pins of the DVI connector carry component signals: Signal Green Blue... -
Page 12: Analog Audio Accessory Board
Analog Audio Accessory Board Analog audio can be captured and played back (along with the video) with the help of an accessory board, model 3364TA. It is available separately, or as part of an enclosed version, DVI or SDI. Audio embedded in the SDI signal can be extracted as well. -
Page 13: Software
Software Software (Windows and Linux) Driver UVC video Library wrappers around the DirectShow (Windows) or V4L2 (Linux) APIs... -
Page 14: Firmware Updates
The firmware update is initiated using web interface. That requires a computer, located on the same network as the 2464. Using any browser connect to the 2464, and select Firmware Update, which will bring up the window that displays the versions of the device's firmware components and the serial number. - Page 15 the device, click the Reset Parameters button. That will reset the network settings as well, but the change to those will take effect only after the power is cycled. This allows setting an IP address different from the default (192.168.24.64) even after parameters reset, if necessary.
-
Page 16: Revision History
Revision history Version Notes 1.0.0, July 2017 Initial release.
