FLEX 360B4
Owner's Manual
Before using, please read these operating instructions carefully.
They contain important advice concerning the use and safety of your
notebook. Please use it for its intended purpose in accordance with
these operating instructions.
Any misuse of the product will void the warranty.
www.edugear.com
Advertisement
Table of Contents
Related Manuals for EDUGEAR Onebook Flex360B4
Summary of Contents for EDUGEAR Onebook Flex360B4
- Page 1 Before using, please read these operating instructions carefully. They contain important advice concerning the use and safety of your notebook. Please use it for its intended purpose in accordance with these operating instructions. Any misuse of the product will void the warranty. www.edugear.com...
-
Page 2: Table Of Contents
Contents Before You Start Taking Care of Your Notebook Your Notebook Tour Function Keys Getting Started Touchpad Windows Interface Setup and Connection Battery Windows Help and Troubleshooting Specifications FCC Declaration of Conformity... -
Page 3: Before You Start
Before You Start Make Sure You Have Everything When you receive your notebook, unpack it carefully, and check to make sure you have all the items listed below. For a pre-configured model you should have the following: • One Flex 360B4 notebook •... -
Page 4: Taking Care Of Your Notebook
You also can prop the notebook’s screen up in stand mode, which is ideal for viewing videos and presentations. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com... -
Page 5: Your Notebook Tour
Your Notebook Tour Front View Now that you are done setting it up, let us show you around your new notebook. 1. Front-Facing Camera Often for taking self-portraits as well as for video conferencing. 2. Microphone Used for sound and speech recording. 3. -
Page 6: Right View
This is where you rest the provided stylus. stationary object such as table. 3. USB 2.0 Port 6. Stylus Plug your USB devices here. Use it as an input device instead of your fingers on the touchscreen. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com... -
Page 7: Left View
Your Notebook Tour Left View 1. Charging Indicator 5. HDMI Port It shows the charging status of your laptop. Plug your HDMI-capable monitor here. It shows blue when the battery is fully charged. 6. Micro SD Card Slot 2. DC-in Plug your micro SD card here. -
Page 8: Function Keys
Mute or unmute your system. Decreases the volume level. Increases the volume level. Switches display output. Decreases the display brightness. Increases the display brightness. Opens the Settings screen. Play or Pause. Push here to talk to Cortana. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com... -
Page 9: Getting Started
Getting Started Powering On/Off Your Notebook If this is the first time you’re turning this computer on, connect the AC adapter and fully charge the battery before pressing the power button. Powering On Press the power button for 1 to 2 seconds. You should see the blue power indicator light turn on. -
Page 10: Putting Your Computer Into Sleep Mode
Waking up Your Computer Do one of the following: A: Press the power button briefly one time. B: Press any key on the keyboard, tap the touchpad, or open the lid of the notebook. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com... -
Page 11: Touchpad
Touchpad The most commonly used touchpad actions are gesture-based and provide shortcuts for quickly opening and working with windows and files. However, the actual available gestures are application dependent. Tap: Tap once to single-click and twice to double-click the cursor. Pinch: Move two fingers together or apart while touching the touchpad. -
Page 12: Windows Interface
The Desktop screen is as shown below and natively provides a virtual desktop feature. To launch the feature you can click the app icon as shown on the left or just press Window key and and Tab key on your keyboard at the same time. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com... -
Page 13: Start Menu
Taskbar The black bar on the bottom of the desktop is called Taskbar. It provides several key features and they are: • Start menu • Search box • App shortcuts area • Notification area Start Menu To open the Start menu you can either click the Windows icon (also known as the Start button) in the lower left of the screen or press the Windows key on the lower left of the keyboard and the Start menu will appear as shown below. - Page 14 Windows 10. Click here to finish the setup and you can control Cortana with either keyboard or voice commands, and use it to perform intelligent searches and more. After you setup the Cortana settings, the search box will look like: Call: 888.505.8878 Online: edugear.com Email: support@edugear.com...
-
Page 15: Notification Area
App Shortcuts Area In this area, you can put the shortcuts of your frequently used apps. Notification Area The right part of the taskbar holds several icons that show you the status of your laptop, as shown below. Click here to show more status icons Shows you the current battery status Shows you the status of your wireless network connection Click here to show the unread notifications... -
Page 16: Setup And Connection
1. Click the Windows icon in the lower left corner of the Desktop, or press the Windows key on the keyboard. 2. Select <Settings>. This will open the Settings screen, as shown below: Settings Screen Call: 888.505.8878 Online: edugear.com Email: support@edugear.com... -
Page 17: Windows Activation
Windows Activation To use all features of your Windows laptop, you may need to activate your Windows system. Follow the following steps to register and activate your Windows. 1. Open the Start menu and click <Settings > 2. Click <Update & security> 3. - Page 18 2. Select <Personalization> 3. In the Personalization screen, enable the option <Use Start full screen> After these steps, you will see the Start screen every time you turn on your laptop, as shown below: Call: 888.505.8878 Online: edugear.com Email: support@edugear.com...
- Page 19 Pinning an App to the Start Menu or Taskbar To add an app: 1. Open the Start menu and select <All Apps> 2. Right-click on the app that you want to appear on your Start menu or taskbar, and an option menu appears. 3.
-
Page 20: Connecting To A Wireless Lan
SD card. You can then save, move or delete data to and from the card as you would with any other storage device. To remove your memory card: 1. Press the card and release. The card will pop up. 2. Pull the card out by holding the end of the card. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com... -
Page 21: Connecting An External Device
Connecting an External Device Connecting to the USB port: Your computer comes with one USB 2.0 port and one USB 3.0 port compatible with USB devices. Once you plug a USB device into a USB port on your computer, Windows automatically loads a driver for that device. - Page 22 5. Open the Settings screen, select <System>and then <Display>. 6. Click <Multiple displays> to open the drop-down list. 7. From the list, select your desired monitor mode. 8. Click <Apply> and confirm your setting. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com...
-
Page 23: Battery
Battery Charging Your Battery 1. Plug the adapter into the DC-in, which you can find on the left side of your laptop. 2. Plug the adapter into a wall-socket. 3. You shall see the battery indicator starts blinking in blue. 4. - Page 24 When your laptop is not powered by the adapter, the color of the battery indicator shows you the approximate status of your battery: Battery Low : Blinking in red Battery High: Solid Red or LED dark. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com...
-
Page 25: Windows Help And Troubleshooting
Windows Troubleshooting Settings for Sleep Mode Your laptop is delivered with the factory settings. In the factory settings, for example, the idle time before going into the sleep mode is set as follows: • 4 minutes ( for Battery mode) or •... - Page 26 This page provides an option for you to edit your Power Plan settings. To do this, simply click on the <When the computer sleeps>. Then, the editing page will be displayed as shown below: Call: 888.505.8878 Online: edugear.com Email: support@edugear.com...
- Page 27 Troubleshooting This section describes some common problems and suggested solutions, and ways to recover your computer from a crash. Be aware that the problems and solutions described here are meant only as a guide. They are not definitive problem solving techniques. For certain problems, you might need help from your reseller or your service provider.
- Page 28 The computer does not return from sleep If your computer is in sleep mode, connect mode and the computer does not work. the AC adapter to the computer then press the power button. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com...
-
Page 29: Other Problems
Display Problem The screen is blank. Do the following: • If you are using the AC adapter, or using the battery, and the battery status indicator is on, press Fn+F8 to make the screen brighter. • If the power indicator is blinking, press the power button to resume from sleep mode. -
Page 30: Specifications
One MicroSD Card Reader One DC-in Camera Rotatable 2.0 MP Wireless 802.11 a/b/g/n & AC BT 4.0 Supports Miracast and WiDi Battery 8,100 mAh Power 7.4V Windows 10 Device Dimensions L 11.9" W 7.95" H 0.9" Call: 888.505.8878 Online: edugear.com Email: support@edugear.com... -
Page 31: Fcc Declaration Of Conformity
FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 32 It is your responsibility to hand it over to a designated collection point for the recycling of waste electrical and electronic equipment. For more information, please contact your local waste collection center or the point of purchase of this product. Call: 888.505.8878 Online: edugear.com Email: support@edugear.com...
- Page 33 FLEX 360B4 Need Support? Contact Us: 888.505.8878 support@edugear.com edugear.com...
