- Page 1 X4 AND X4M INSTALLATION OPERATION MANUAL...
-
Page 2: Table Of Contents
Table of Contents General Information ..........................2 Capacities & Specifications......................... 2 Acceptance Procedures ........................2 Installation............................2-4 Gas Piping ............................4-6 Wiring ..............................7 Start Up ............................7-11 Combustion Arrangement Requirements ..................11-12 Service/Maintenance Suggestions ....................12-13 Burner Parts List .......................... 13-14 Sequence of Operation for X4M Burners .................. -
Page 3: Burner Specifications
1. Do not try to light any appliance. Input Capacity BTU/Hr 2. Do not touch any electrical switch; do not use any phone in your building. X4-400 150,000 – 400,000 3. Immediately call your gas supplier from X4-700 200,000 – 725,000 a neighbor’s phone. -
Page 5: General Information
It only requires connection of 115V electrical supply, minor gas train piping, connection to gas service, and operating controls. All Power Flame burners are operationally fire tested at the factory. CAPACITIES & SPECIFICATIONS Burner Number X4-400 X4-700 X4M-400 X4M-700 Natural/LP Gas Flow x 1,000 BTU/HR... - Page 6 If the burner is to be mounted in an existing boiler or furnace, ensure that all fireside surfaces are clean and in good condition. All doors, cleanouts, cracks or other openings allowing excess air into the combustion chamber should be tightly sealed, whether the burner is to be fired under positive or negative combustion chamber conditions.
-
Page 7: Gas Piping
NOTE: Serious Damage To The Burner May Result If The Blast Tube Is Extended Into The Combustion Chamber. Secure the burner to the heat exchanger or boiler, using the burner-mounting flange. The burner- mounting flange must be secured to the blast tube at the selected location for proper insertion into the end or front wall of the fired unit. -
Page 8: Gas Piping
Install vent lines from main gas regulator (if used) and diaphragm gas valve where applicable. Vent lines should be run to the outside of the building, terminating clear of windows or fresh air intakes. Outside termination of vent should have a screen to prevent insects from building nests in vent pipe. - Page 9 Figure 4 Location of Side Orifice Figure 5 Typical Wiring Diagram for S8680J with Proved Pilot Ignition...
-
Page 10: Wiring
Figure 5A Typical Wiring Diagram for S89F with Direct Spark Ignition WIRING Refer to wiring diagram shipped with burner and typical wiring diagrams Figures 5 and 5A. The two power leads (black and white) are located inside the burner panel. Electrical installation must be made in accordance with the NEC NFPA 70 or Canadian Electrical Code, Part 1 and applicable local codes. - Page 11 Install stack thermometer and Flue Gas Analyzer sample line into breeching and connect the draft gauge to combustion chamber test point. Connect a microammeter to the Primary Safety Control as directed in the PSG control manufacturer’s instruction bulletin to determine flame detection system values. The meter is normally connected in series with the (SENSE) terminal on the S8600 or S89F series control.
- Page 12 Figure 6A Detail Pilot Assembly Frequently the cause for pilot problems relates to gas pressures that are too high and/or air dampers that are closed too far. Both conditions can cause a fuel rich mixture in the pilot chamber which can substantially delay or totally prevent pilot ignition. 7.11 With the leak gas cock closed and pilot gas cock open (if provided);...
- Page 13 Select and install the main orifice that corresponds to the desired firing rate. Make certain that the airflow setting provides the correct CO or O levels and other combustion values at the proper firing input rates. See Section 8 and Table 3 for firing rate information. Generally accepted values for natural gas are 8½...
-
Page 14: Combustion Arrangement Requirements
Table 3 Natural/LP Gas Orifice Pressure Settings/Flow Rate. NOTE: Pressure taken at Combination Valve Pressure Tap Upstream of Orifice. X4-400 Main MBH Natural Gas MBH LP Gas Approx. -
Page 15: Service/Maintenance Suggestions
The correct test instruments are: a. O analyzer (electronic or Fyrite absorption system) b. CO indicator (Monoxor or similar) c. Stack thermometer d. Draft gauge or inclined manometer e. U-tube manometer or calibrated 0-10” and 0-35” w.c. pressure gauge Combination volt/ammeter g. -
Page 16: Burner Parts List
In the event of extended shutdown, the main power should be turned off and the main manual gas shutoff valve should be closed. EMERGENCY SHUTDOWN: WARNING: Should over-heating occur: (1) shut off the manual gas valve to the appliance, (2) do not shut off the control switch to the feed water pump or blower. An additional source of information relative to trouble shooting can be found in the Flame Safeguard Control Manual supplied with the burner. -
Page 19: Sequence Of Operation For X4M Burners
11. SEQUENCE OF OPERATION FOR X4M BURNER 11.1 Refer to typical wiring diagram for X4M burner (Figure 11A). Upon a call for heat, the blower motor starts, closing the combustion air switch. Power is supplied to the 24-vac transformer. Initially power to the actuator is held out through one set of normally open contacts on the 24-vac relay. -
Page 20: X4M Wiring Diagram
Figure 11A - Typical Wiring Diagram For X4M Figure 11B – General Arrangement Diagram for X4M... -
Page 21: X4M Actuator
Figure 11C - Belimo LF24-SR-S Actuator Figure 11D – X4M Firing Rate vs Manifold Pressure Manifold Pressure vs. Firing Rate X4M-700 X4M-400 Firing Rate (MBH) The manifold pressures shown are the gas pressures taken at the 1” tee and represent a zero furnace pressure (net manifold pressure). -
Page 22: For Your Safety
OWNER OPERATING INSTRUCTIONS FOR YOUR SAFETY WARNING If you smell gas: Improper installation, adjustment, alteration, 1. Open windows service or maintenance can cause injury or 2. Do not touch electrical switches property damage. Refer to the burner manual for 3. Extinguish any open flame assistance or additional information consult 4.
