Introduction

Bar code technology enables efficient data collection in
various businesses including both commercial office and
industrial automation﹒Importantly﹐bar code technology
also ensures the accuracy of captured data﹒The bar code
readers described in this manual have been developed for
maximum efficiency﹐accuracy and ease of use in various
process scenarios﹒
FCC Statement
The federal communications commission ﹙ FCC﹚ requires
that all CCD readers must be labeled with FCC
approval﹒
This equipment complies with the requirements in part 15
of FCC rules for a class A computing device﹒These
limits are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment﹒This equipment
generates﹐uses and can radiate radio frequency energy
and﹐if not installed and used in accordance with the
instruction manual﹐may cause harmful interface to radio
communications﹒Operation of this equipment in a
residential area may cause unacceptable interference to
radio and TV reception requiring the operator to take
whatever is necessary to correct the interface﹒
1

Advertisement

Table of Contents
loading

Summary of Contents for GMW LTS 069

  • Page 1: Introduction

    Introduction Bar code technology enables efficient data collection in various businesses including both commercial office and industrial automation﹒Importantly﹐bar code technology also ensures the accuracy of captured data﹒The bar code readers described in this manual have been developed for maximum efficiency﹐accuracy and ease of use in various process scenarios﹒...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page Introduction--------------------------------------------- 1 Contents------------------------------------------------- 2 Chapter 1. Technical Data----------------------------- 3 Chapter 2. How to install your Bar Code Reader-- 4 Chapter 3. Pin Assignment---------------------------- 4~7 Chapter 4. Set up configuration---------------------- 7~8 1. Set Default Configuration------------ 9 2. Interface Options---------------------- 10 3.
  • Page 3: Chapter 1. Technical Data

    Chapter 1. Technical Data This User’s Manual introduces the technical specification of the bar code readers. The product features are described in later chapter e.g. installation﹐set-up and configuration as well as detailed technical specifications. Main Technical FEATURES Bar code width :...
  • Page 4: Chapter 2. How To Install Your Bar Code Reader

    Chapter 2. How to install your Bar Code Reader Installation: Step 1. Turn off the power on your terminal device. Step 2. Connect the bar code reader to the appropriate outlet on the technical device depending on the model / interface cable that you have, e.g. RS232, PS2, ……….
  • Page 5 2. RS-232 : 9 PIN and 25 PIN female RS-232 connector Phone Jack 9 Pin (F) 25 Pin (F) Function 16.25 K/B DATA K/B CLK SYS DATA SYS CLK GND Shield 3. WAND Emulation:9 PIN female and 5 DIN、6 DIN male connector Phone Dsub...
  • Page 6 4. Apple MACINTOSH:4 PIN female and 4 DIN male connector Phone Jack Function DIN-4M DIM-4F K/B DATA K/B CLK SYS DATA SYS CLK GND Shield 5. NEC 9800:8 PIN female and 8 DIN male connector Phone Jack Function DIN-8M DIM-8F K/B DATA K/B CLK SYS DATA...
  • Page 7: Chapter 4. Set Up Configuration

    6. TTL (CMOS):9 PIN female and 5 DIN、6DIN male connector Phone Jack Function Dsub 9P (F) VCC+5V DATA INDICATOR TRIGGER ENABLE SCAN GND Shield Chapter 4. Set Up Configuration 1. Example: In order to setup the program for the bar code reader, you must be familiar with the setup procedure.
  • Page 8 Example 2: → Start Place command to CCD → Flash mode Turning on Flash mode → Start Place command to CCD → Flash On/Off Turn on Flash on/off time setting → Appendix A "0",”6” Setting Flash on 0.6 sec → Appendix A "0",”A”...
  • Page 9: Set Default Configuration

    1. SET DEFAULT CONFIGURATION Default All programmed settings will be returned to the manufacture default setting after the scanning process. Other available option Show configuration Show version Abort setting Start up code If the scanner’s light is on, but it can not read. Try to scan the “start up code”.
  • Page 10: Interface Options

    2. INTERFACE OPTIONS Start *Keyboard AT Notebook RS-232 WAND Read the interface selection code for your particular application. Above interfaces, only one can be enabled, other interfaces will be disabled automatically, ie, scan “Start”→ “RS232”→ “End”. Mute If you scan “Mute”, the initial welcome music will be on “Mute”...
  • Page 11: System Type

    3. SYSTEM TYPE Start Apple Macintosh ADB PC XT NEC 9800 *PC AT, PS/2 50 60 70 80 IBM 5550 PS/2 25 30 ACER 7300 Other system types may be available upon request, please consult your supplier for details.
  • Page 12: Keyboard Wedge Setting

    4. KEYBOARD WEDGE SETTING Start Upper/Lower case Upper *Lower Number Keys *Alphanum Number lock Upper Caps Lock *OFF Alt+Number *OFF...
  • Page 13: Rs-232 Setting

    5. RS-232 SETTING Start Baud Rate 1200 *9600 2400 19200 4800 38400 Data Bits 7 bit *8 bit Parity *Disabled Even RS-232 Hand Shaking *Disabled Xon/Xoff RS232 RTS/CTS RS232...
  • Page 14: Wand Emulation Setting

    6. WAND EMULATION SETTING Start High / Low *High Scan Speed Highest *High Lowest...
  • Page 15: Scanning Control

    7. SCANNING CONTROL Start Type LED Light Bar Code On-with button pressed One bar code Off-with button depressed Trigger pressed On-for 3 seconds One bar code Off-any bar code scanned *Trigger on On-with button pressed, light on for 3 seconds One bar code Off-with button pressed again Trigger on/off...
  • Page 16 On-all the time Same bar code Off-never off or trigger off Continuous Saft time Default value is 1 sec read Continuous reading Scan “Start”+ “Safety time”+ Safety time 0.8 Appendix A “0”, “8” Set value is 0.8 Sec Safety time setting After turn ON or finish reading Barcode will continue on 60 sec than Flash...
  • Page 17: Turn On Various Bar Code Format

    8. TURN ON VARIOUS BAR CODE FORMAT Start Code 39* *Interleaved 2 of 5 *Industrial 2 of 5 *Matrix 2 of 5 Coda Bar* EAN-13* UPC-A* EAN-8* UPC-E*...
  • Page 18 *EAN/UPC Add-on 2/5 Code 128* Code 11* *MSI/Plessey *Telepen *China Postal Code *Code 93 *Laetus Phamacode All Barcodes Turn Off Turn On (expect Laetus Phamacode)
  • Page 19: Code Identifier

    9. CODE IDENTIFIER Start *Off USER Code 39 Interleaved 2 of 5 Industrial 2 of 5 Matrix 2 of 5 Coda Bar EAN-13 EAN-8 UPC-E Code 11...
  • Page 20: Code Identifier

    Code 128 Code 93 Plessey TELEPEN UPC-A Please refer the Appendix B-ASCII table for the ID character you need, for example:scan appendix A “5” “3” for S or scan “5” “0” for P. There is only one code identifier allowed on the specific type bar code.
  • Page 21: Code 39 Control

    10. CODE 39 CONTROL Start Turn On/Off C32 Italian Pharma Code *Off CIP39 *Off Code Type *Standard Full ASCII Gap Range Check Transmit start/stop character Verify MOD 43 checksum Transmit check character *Yes Lengths Range (01~23)* 3 fixed You may set up to 3 fixed bar code lengths or bar code min and max data lengths range if necessary.
  • Page 22: Interleaved 2 Of 5 Control

    11. INTERLEAVED 2 OF 5 CONTROL Start Turn On/Off *Off Verify MOD 10 checksum Transmit check digit *Yes Lengths Range (04~46)* 3 fixed You may set up to 3 fixed bar code lengths or bar code min and max data lengths range if necessary. 3 fixed bar code lengths Please refer to page 8.
  • Page 23: Industrial 2 Of 5 Control

    12. INDUSTRIAL 2 OF 5 CONTROL Start Turn On/Off *Off Verify MOD 10 checksum Transmit check digit *Yes Lengths Range (04~23)* 3 fixed You may set up to 3 fixed bar code lengths or bar code min and max data lengths range if necessary. 3 fixed bar code lengths Please refer to page 8.
  • Page 24: Matrix 2 Of 5 Control

    13. MATRIX 2 OF 5 CONTROL Start Turn On/Off *Off Verify MOD 10 checksum Transmit check digit *Yes Lengths Range (04~39)* 3 fixed You may set up to 3 fixed bar code lengths or bar code min and max data lengths range if necessary. 3 fixed bar code lengths Please refer to page 8.
  • Page 25: Coda Bar/Nw7 Control

    14. CODA BAR / NW7 CONTROL Start Turn On/Off Transmit Start/End Start/End ABCD/ABCD Transmit ABCD/TN*E type *ABCD/abcd ABCD/tn*e Gap Range Check Verify MOD 16 checksum Transmit check character MOD 10-CLSI Lengths Range (01~29)* 3 fixed You may set up to 3 fixed bar code lengths or bar code min and max data lengths range if necessary.
  • Page 26: Ean-13 Control

    15. EAN-13 CONTROL Start Turn On/Off Truncate leading digit Truncate leading 0 Transmit check digit *Yes...
  • Page 27: Upc-A Control

    16. UPC-A CONTROL Start Turn On/Off Truncate leading digit Transmit check digit *Yes...
  • Page 28: Ean-8 Control

    17. EAN-8 CONTROL Start Turn On/Off Truncate leading digit Transmit check digit *Yes 18. UPC-E CONTROL Start Turn On/Off Truncate leading digit Transmit check digit *Yes...
  • Page 29: Upc/Ean Conversion

    19. UPC/EAN CONVERSION Start UPC-A To UPC-E *Off UPC-E To UPC-A *Off UPCA To EAN13 *Off EAN8 To EAN13 *Off ISBN *Off 20. CODE 11 CONTROL Turn On/Off Verify checksum Transmit check digit *Yes 21. CODE 128 FNC1 GS CONTROL FNC1 GS character Default FFhex No output any character...
  • Page 30: Msi Code Control

    22.MSI CODE CONTROL Start MOD 10 *Yes MOD 10/ MOD 10 MOD 11/ MOD 10 Transmit check digit *Yes 23.TELEPEN MODE Numeric Alphanumeric Note: To read these commands the telepen family MUST be enabled. 24.LAETUS PHAMACODE CONTROL Please refer Appendix B Define Laetus phamacode number of bars Number of BARS...
  • Page 31: China Postal Code Control

    25. CHINA POSTAL CODE CONTROL Start Turn On/Off *Off Verify MOD 10 check digit Transmit check digit *Yes Lengths Range (04~39)* 3 fixed You may set up to 3 fixed bar code lengths or bar code min and max data lengths range if necessary. 3 fixed bar code lengths Please refer to page 8.
  • Page 32: End Of Text Message

    26. END OF TEXT MESSAGE Start None (for RS232 only) CR/LF (for RS232 only) Space Ctrl-C...
  • Page 33: Pc At Keyboard Nationality

    27. PC AT KEYBOARD NATIONALITY Start French Belgium Sweden Denmark Germany Netherlands Norway Spanish Italian Protugal Japan Hungary...
  • Page 34 Greece Swiss Finland Slovakia Yugoslavia Yugoslavia Cyrillic...
  • Page 35: Set Prefix

    28. SET PREFIX Start Prefix Please refer to Appendix B regarding the prefix string. You may add up to 12 characters as prefix. 29. SET SUFFIX Start Suffix Please refer to Appendix B regarding the suffix string. You may add up to 12 characters as suffix.
  • Page 36: Data Format

    30. DATA FORMAT Code ID number: EAN13 Code 93 EAN8 Code 11 UPC E Code 39 China Post Codabar UK Plessy Matrix 25 Telepen Industry 25 UPC A Interleved 25 Code 128 Example: Data 0 0 9 4 7 3 8 2 7 1 9 0 Reserve 01 02 Output 0 ×...
  • Page 37: Other Control

    31. OTHER CONTROL Start *Highest Medium Buzzer tone frequency Mute Buzzer duration *50msec 20msec Keystroke / *Fastest Fast Character Medium Slow Character inter delay time Default to 1msec Please refer to the hexadecimal table in Appendix A Hex 00~FF (00~255msec unit 1msec)
  • Page 38: Appendix A: Hexadecimal/Decimal Table

    Appendix A:Hexadecimal / Decimal Table...
  • Page 39: Appendix B: Hex And Numeric Table

    Appendix B:Hex and Numeric table (To read the desired hex and numeric selections) DEC HEX PC ASC II DEC HEX PC & ASCII 00 (Null) NULL & ☺ ☻ ∗ ◘ − º ▀ ♂ ♀ ♪ ♫ ☼ ▶ ◀...
  • Page 40 DEC HEX PC & ASC II DEC HEX PC & ASCII ∆ Ç ü é â ä à å ç ê ë è ï î ì Ä Å É æ Æ Ô ö Ò û ù...
  • Page 41 DEC HEX PC & ASCII DEC HEX PC & ASCII ÿ ╛ Ö ┐ Ü └ ¢ ⊥ £ ┬ ¥ ├ ₧ ― ƒ ┼ á ╞ í ╟ ó ╚ ú ╔ ñ ╩ Ñ ╦ ╠ ¿ ╬...
  • Page 42 DEC HEX PC & ASCII Σ σ μ Υ Φ θ Ω δ ∞ ψ ε ∩ ≡ ± ≧ ≦ ⌠ ⌡ ÷ ≈ ○ ● • √ η ² ■ (Bland)
  • Page 43: At Function Key

    AT SCAN CODE Home E0 6C E0 F0 6C E0 69 E0 F0 69 E0 7D E0 F0 7D Page up Page down E0 7A E0 F0 7A Insert E0 70 E0 F0 70 Delete E0 71 E0 F0 71 Numeric Keypad + 79 F0 79 66 F0 66 Back Space...
  • Page 44 AT SCAN CODE Left Shift 12 F0 12 Right Alt E0 11 E0 F0 11 Right Ctrl E0 14 E0 F0 14 Right Shift 59 F0 59 AB** Left Alt Make AC** Left Alt Break F0 11 AD** Left Ctrl Make 14 AE** Left Ctrl Break F0 14 E0 12 E0 7C E0 F0 7C E0 Print Screen...
  • Page 45 Start Barcode Function key *Off To scan a function key barcode with input data, please refer for function key value table (page 43,44) refer for function key barcodes (page 45,46) Home Page up Page down Insert Delete Numeric Keypad+ Back Space Enter ←...
  • Page 46 Numeric Keypad - Numeric Keypad * Numeric Keypad / Caps Lock Num Lock Print Screen Shift Tab...
