- Page 1 MPAIO Manual (FCC ID: 2ABRWF-1020) User’s Manual . Please read the following warnings before using the product. . Shapes and colors of the images shown in this manual may differ from the actual products.
- Page 2 User’s guidance • This product is qualified by KCC, FCC/IC, CE, PCI-PTS(V3.1), EMV L1, L2(V4.3) compliances, and is thus governed by these qualifications safety regulations. • This user manual is protected by copyright. • This user manual has been created by the SAMIL CTS Inc. We have done our best not to create typos, editing errors, and leaving out any information.
-
Page 3: Table Of Contents
4. How to use with card 5. How to use with barcode 6. How to combine Brain & Sled 7. How to combine MAPIO & Galaxy note3 8. How to charge a battery 9. Product Information 10. Technical Specifications (MPAIO Brain) Q & A... -
Page 4: Notice Before Using Device
Notice Before Using Device WARNING This information is for your own safety. Please observe the following precautions. • Do not press power button on the device if the device is wet or do not touch charge cable with wet hands. There is risk of electric shock. -
Page 5: Precautions Before Using Battery
Precautions Before Using Battery WARNING These are safety precautions in order to prevent a dangerous accident. Please use the battery correctly and carefully observe the instructions. • If the battery is taken apart by impact, applied heat, submersion, or hole-drilling, there is a risk of a dangerous explosion. Please keep away from children and animals. -
Page 6: About The Product
2. The main unit (Brain & Sled), power cable, Bluetooth cover, bolts, driver, quick manual and battery are included in the package. If any items are missing or damaged, please contact us or your dealer for assistance. » All user manuals are available for download on our website: www.mpaio.com. Quick Manual... -
Page 7: Checking Names Of Parts
3. Checking names of parts 2D Barcode Barcode Button Barcode Button Contactless PIN PAD IC Card Power Button Micro USB... -
Page 8: How To Use With Card
4. How to use with card Contactless *Before MSR and IC cards insert, make sure to clean on it. Otherwise, it may cause low reliability and/or operational malfunction. BLUE GREEN WHITE YELLOW Barcode mode Battery Charging Power on Contactless Mode MSR/IC Card mode /Full Charged Battery... -
Page 9: How To Use With Barcode
5. How to use with barcode Laser aimer is appeared from camera right of top on the brain when the button pressed on the "buy" screen. For a good result, refer to following step and diagram. 1. Move the aiming position to the center of the barcode. 2. -
Page 10: How To Combine Brain & Sled
6. How to combine Brain & Sled 1) Put Brain in the line with the Sled rail. 2) Fix Brain to Sled with bolt using driver. 3) Completed As shown in the above, cross the back bottom of Brain and the front top of Sled. Disassemble is the reverse order of combination. -
Page 11: How To Combine Mapio & Galaxy Note3
7. How to combine MAPIO & Galaxy 1. Open the cover 2. Insert Galaxy phone into the cover to fit inside the rail 3. Close the cover WARNING: Please pay attention to your fingers when cover closed. -
Page 12: How To Charge A Battery
8. How to charge a battery As see in the below picture, connect the adapter with the power cable to charge the power. -
Page 13: Product Information
9. Product Information As shown in the below, the product information is provided by shortcut key. “5”: Bluetooth Address, Serial No & Firmware Version “X”: go to the Main Menu. ... -
Page 14: Technical Specifications (Mpaio Brain)
11. Technical Specifications (MPAIO Brain) Feature Parameters Secure MCU 192 MHz Flash 512 Mbyte Memory SDRAM 128 Mbyte Screen Size 2.3" LCD Screen Pixel 128 X 64 DOT Characters 8 Line, 16 Characters (each line) Magstripe Reader ISO7811, JIS II mode, 3 Track encrypted Head... -
Page 15: Q & A
Q & A Water went into my device. What do I do? First, remove the battery from the device and completely dry them in a dry place. After drying for a good period of time, try to turn it on. If it still does not turn on, the main-board or other parts needs to be replaced. Please contact to your service center. The device won’t turn on. - Page 16 Displayed “MAG Module Error” on the LCD. If MSR connection is unstable or MSR Module is defective, “MAG Module Error " is appeared on the LCD. The part must be replaced. Please contact the service center. Displayed “Secure Detect” on the LCD. If the device get shock, the Secure Detect"...
- Page 17 FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
