- Page 1 P a g e SA985, SA975, SA935, SA915 SG985, SG884, SG834, SG814 SL987, SL957, SL937, SL917, SL907 Frequency & Phase Meter Instruction Manual Analog Arts Inc. www.analogarts.com...
-
Page 2: Table Of Contents
P a g e Contents Software Installation ..........................3 Specifications ............................3 Handling Precautions ..........................3 Operation Instruction ..........................3 Front & Back Panel Items ........................3 Initiating the Instrument ......................... 4 Calibration Sequence ..........................4 Menu Panel ............................. 4 Frequency &... -
Page 3: Software Installation
4- Do not use this instrument in strong magnetic fields. 5- Do not apply the instrument to voltages exceeding the maximum rating. Operation Instruction This section contains the required information to operate Analog Arts frequency & phase analyzer and reviews its associated options. Front & Back Panel Items... -
Page 4: Initiating The Instrument
P a g e Initiating the Instrument After installing the Analog Arts software, the Analog Arts icon appears on the desktop. Clicking on that icon initiates the instrument. Calibration Sequence At the start, the device goes through a calibration phase, which takes about one minute to complete. -
Page 5: Frequency & Phase Analyzer Panel
P a g e Frequency & Phase Analyzer Panel The instrument includes several panels as follows: 1- CH1 frequency 2- CH2 frequency 3- Channel 1 and channel 2 phase difference in seconds. 4- Channel 1 and channel 2 phase difference in degrees. 5- Channel 1 and channel 2 jitter in seconds. -
Page 6: Reference Channel Panel
Print: "Print" prints the instrument window by the user specified printer. Help: "Help" opens the Analog Arts' "Help" section, where the user can access view various topics , documentations and or ask his questions from an Analog Arts' application engineer. -
Page 7: Glossary
P a g e Glossary AC - Alternating Current. A signal that continually Envelope – The outline of a signal’s highest and changes in potential going from a minimum to a lowest points acquired over many displayed maximum voltage and back. waveform repetitions. - Page 8 P a g e Sampling – The conversion of a portion of an input trigger transient mode. Common trigger modes signal into a number of discrete electrical values for include normal and auto. the purpose of processing for display by the Trigger Slope –...
