AHU WITH HEAT RECOVERY

Smarty 2X P

Smarty 3X P

Mounting and installation instructions

Subject to technical modification

Smarty 2X-3X P_MI_P0112_AZ_0002

Table of Contents

Need help?

Do you have a question about the Smarty 2X P and is the answer not in the manual?

Questions and answers

Summary of Contents for Salda Smarty 2X P

Page 1 AHU WITH HEAT RECOVERY Smarty 2X P Smarty 3X P Mounting and installation instructions Subject to technical modification Smarty 2X-3X P_MI_P0112_AZ_0002...
Page 2: Table Of Contents
Connection of Remote Control Panel or ModBus Fire Protection Signal Input (Fire protection input (NC)) Connection of the unit to electric network Start-uprecommendations System protection Recommendations before the start of the unit (before the final user) Possible faults and troubleshooting Notes www.salda.lt...
Page 3: TechnicalData
In exceptional cases harmful gases could be drawn out of the chimney or extraction ducting back PAVADINIMAS into the room. In this case we strictly recommend to turn off SaldaAntifrost and use an external preheater for heat exchanger anti-frost protection (see SaldaAntifrost function on the Remote controller manual) 0.084 kW;...
Page 4: AirFlowDiagrams
** ‒ Version 1.3 is provided without circulation dampers and does not meet the requirements of Eco design Optional heating elements *- only pre-heater or heater Duct based Air Duct based Pre-Heater Air Heater Smarty 2X P 1.1 Mini MCB Premium Smarty 2X P 1.2 Mini MCB Basic Advanced Smarty 2X P 1.3...
Page 5 Smarty 2X/3X P Smarty 2X P 1009 mm 326 mm ø 21,3 mm ø 21,3 mm G3/8" ø 125 mm/160 mm* Using air ducts of 125 mm, an NPU 125 coupling is required. 1043 mm Smarty 3X P 1225 mm 408,5 mm ø...
Page 6 Device protection class IP 32 IP 32 IP 32 IP 32 IP 32 IP 32 LWA, dB(A) Smarty 2X P LWA total, dB(A) 125 Hz 250 Hz 500 Hz 1 kHz 2 kHz 4 kHz 8 kHz Supply...
Page 7 Smarty 2X/3X P operational limits power consumption Smarty 2X P Smarty 3X P Supply air Supply air v [l/s] v [l/s] P [W] P [Pa] stat [Pa] v [l/s] P [W] v [l/s] stat P [W] P [Pa] v [l/s]...
Page 8 Place of operation outdoors with special accessories Operation in explosive environment impossible Transporting of the polluted air impossible Outdoor air temeperature without preheater (SaldaAntifrost** off) -5/+40* [°C] Outdoor air temeperature without preheater (SaldaAntifrost** on) -15/+40 [°C] Outdoor air temperature limits with a selected pre-heater on an air duct -40/+40 [°C]...
Page 9 Smarty 2X/3X P Smarty 2X P Smarty 3X P 1. Mounting bracket with anti-vibration mounts - 4 pcs. 10. Flange 4 pcs. 2. Outdoor air filter and the cover (IF) 11. Condensate tray 3. Outdoor air temperature sensor (TL) 12. Exhaust air fan (IV) 4.
Page 10 MPL (F7) ZFEPF124 EKA NIS (optional) Ptouch PRGPU081 Remote control panels Stouch PRGPU51 MB Gateway Net module PRGPU082 Smarty 2X P legs GAGKS- Legs MARTY168_1005_0 Condensate pump MAXI BLUE SET PRGSIK002 MAXI BLUE S-KFF-U S-RFF-U-D-F2 Channel humidity transmitter S-KFF-U ZAKKT0051...
Page 11 EKA 160-5.0-2f PSIEKA16007 EKA NIS 160-5,0-2F PSIEKANIS27 AKS 150-6 GSOAKS064 AKS 150-9 GSOAKS048 Smarty 3X P MPL (G4) MPL (F7) AKS 150-10 GSOAKS106 legs AKS 150-12 GSOAKS086 Silencers AKS 160-6 GSOAKS005 AKS 160-9 GSOAKS006 AKS 160-10 GSOAKS029 AKS 160-12 GSOAKS039 www.salda.lt...
Page 12: Unpacking
Max. number of transported pack- Dimensions of a single package Dimensions of multipackage ages Unit H1 [mm] L1 [mm] W1 [mm] H2 [mm] L2 [mm] W2 [mm] [pcs.] Smarty 2X P 1120 2240 1155 Smarty 3X P 1400 2167 1430 www.salda.lt...
Page 13 Exhaust air temperature sensor (** - shall be ordered TE** Stouch Control panel separately) Motion detector Outdoor air damper actuator Smoke detector Exhaust air damper actuator Supply and exhaust air grilles KE (EKA) Electric heater PE (EKA Electric preheater AKS*** Silencer (*** - recomendet) NIS/EKA) www.salda.lt...
Page 14 Exhaust air temperature sensor (** - shall be ordered TE** Stouch Control panel separately) Motion detector Outdoor air damper actuator Smoke detector Exhaust air damper actuator Supply and exhaust air grilles KE * (EKA) Electric heater ByPass motor AKS*** Silencer (*** - recomendet) www.salda.lt...
Page 15 Exhaust air temperature sensor (** - shall be ordered TE** Stouch Control panel separately) Motion detector Outdoor air damper actuator Smoke detector Exhaust air damper actuator KE* (EKA) Supply and exhaust air grilles Electric heater AKS*** Silencer (*** - recomendet) www.salda.lt...
Page 16: Mounting
Smarty 2X/3X P Smarty 2X P Smarty 3X P Space for door opening Z [mm] 1270 1550 • Installation should only be performed by qualified and trained staff. • When connecting air ducts, consider the notices indicated on the casing of the unit.
Page 17 Condensate discharge system should be used in premises, where the ambient temperature must not be lower than 1° C! If it falls below 0°C, system must be protected using thermal insulation! It is not necessary to install the loop (3) of the pipe under the heat recovery unit (1), but it must be lower than the level of heat recovery unit (1). www.salda.lt...
Page 18: Drainage
Smarty 2X/3X P Smarty 2X P: VIII * Drain (I-XI) of the condensate is installed when the device is set in position b* or c* (shown in the illustrations above). Before installing lateral condensate drainage, it is necessary to remove a plate (VI) in a metal part of the housing and make a hole. The cover (I-III) should be removed, and a bath (IV-V), caps should be removed from the hole.
Page 19 Note. If the collector is situated upstream, install a system with a condensate pump (offered as an accessory). Before every heating season the condensate tube shall be filled with water as indicated during the first start-up! Before every heating season the condensate tube shall be filled with water as indicated during the first start-up! www.salda.lt...
Page 20 Before starting the system carefully check whether the work was performed properly. For “Smarty 2X P” it is possible to use air ducts of two sizes: ø D1 - 125 mm (a), ø D2 - 160 mm (b). NOTE. Using air ducts of ø D1 - 125 mm diameter, a coupling NPU 125 is required.
Page 21 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 +24VDC PCB POWER SUPPLY 3 2 1 3 2 1 3 2 1 4 3 2 1 www.salda.lt...
Page 22 12VDC Electric Preheater manual protection (NC) 12VDC Bypass closed (NC) 12VDC Not used 12VDC AI1 (NTC) Supply air temperature sensor AI2 (NTC) Fresh air temperature sensor AI3 (NTC) Extract air temperature sensor AI4 (NTC) Exhaust air temperature sensor (optional) www.salda.lt...
Page 23 DO3 (Open) DO4 (Close) 0,5A DO3 (L(L2)) DO4 (L(L2)) DO5 (L(L2)) N(L1) Not used N(L1) Supply fans power line - PV DO6 (L(L2)) DO6 (L(L2)) N(L1) Extract fans power line - IV L(L2) N(L1) 230VAC Power supply for X13, X14, X15, X16 www.salda.lt...
Page 24 AI1 (0-10V) A1-Supply air CO or RH (input 0-10VDC) 24VDC Electric/Water heater control (output 0-10VDC) AO1 (0-10V) Hydraulic heater water temperature sensor AI2 (NTC) Working indication output (START). 24VDC; 1,2W max. 24VDC Alarm indication output (STOP). 24VDC; 1,2W max. 24VDC www.salda.lt...
Page 25 A Heater and pre-heater can be connected to “Smarty 2X P” or “Smarty 3X P”, version 1.1. Only one device - heater or pre-heater - can be connected to “Smarty 2X P” or “Smarty 3X P”, versions 1.2 and 1.3.
Page 26: WiringDiagram
Control 0-10V Control 0-10V Power up to 2,0 kW - 1f Power over 0,6 kW - 1f (2f) DUTIES / NAME SIGNATURE DATE SP58 - PE - 0-10V UAB"SALDA 2016-06-23 DRAWN BY ernal heater 2016-06-23 CHECKED BY Principle connection scheme 2016-06-23 CHECKED BY www.salda.lt...
Page 27 A Heater and pre-heater can be connected to “Smarty 2X P” or “Smarty 3X P”, version 1.1. Only one device - heater or pre-heater - can be connected to “Smarty 2X P” or “Smarty 3X P”, versions 1.2 and 1.3. Heater controlled using ON/OFF or 0-10 V.
Page 28 Control 0-10V Control 0-10V Power up to 0,6 kW - 1f Power over 0,6 kW - 1f Book # DUTIES / NAME SIGNATURE DATE SP55 UAB"SALDA" 2016-06-16 DRAWN BY External heater Drawin 2016-06-16 CHECKED BY Principle connection scheme 2016-06-16 CHECKED BY...
Page 29 Power up to 0,6 kW - 1f Power over 0,6 kW - 1f SP60 Book # DUTIES / NAME SIGNATURE DATE SP56 =miniMCB1 =miniMCB1 UAB"SALDA" 2016-06-16 DRAWN BY External heater Drawing 2016-06-16 CHECKED BY PE L1 N Principle connection scheme PE (L1) (L2)
Page 30 When using the supply air heater, the supply air sensor External heater 2016-06-23 CHECKED BY Principle connection scheme (SS) shall be installed downstream the heater (or cool- 2016-06-23 CHECKED BY er) as the sensor cable allows or until the first branch- ing, bend of the air transportation system. www.salda.lt...
Page 31 AKS*** (EKA) Installation diagram It is installed in the air duct of exhaust air. Control board PE* (EKA NIS/EKA) AKS*** Exhaust Wiring diagram air temp. Automation controller A (X6) zone sensor(optional) 1 2 3 4 5 6 7 8 www.salda.lt...
Page 32: Supply Air Co Or Rh (Input 0-10Vdc)
1 2 3 Transmiter 1 Extract air CO or RH (input 0-10VDC) connection. Installation diagram. Transmitter shall be installed inside extract air duct or room. Wiring diagram. Automation controller A zone X7. 1 2 3 4 5 6 7 8 www.salda.lt...
Page 33 Tool for drilling holes are required for its installation. 3000 Effect on an individual 2500 Reduced concentration, drowsi- ness, headache, etc. 2000 1500 Pettenkofer limit Disturbs 1000 Pettenkofer limit Pleasant Outdoor air Duration of the presence in the room in hours www.salda.lt...
Page 34 • The power cable can be replaced only by a qualified specialist upon the evaluation of the rated power and current. The manufacturer does not assume any liability for personal injuries and property damage due to non- conformance with the provided instructions. www.salda.lt...
Page 35 Too low air flow at rated fan speed Clogged supply and/or extract air filter(s) Filter replacement needed Filters are clogged and no message is shown Shorten filter timer time till the message of Wrong time in filter timers on the remote control clogged filters www.salda.lt...
Page 36 Smarty 2X/3X P www.salda.lt...
