- Page 1 MANUAL ENGLISH DDP-610 MKII Ordercode: 50754/50755/50757 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
DDP-610 MKII Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Connection with the Single-Phase Power Network ....................4 Connection with the Three-Phase Power Network ....................4 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Frontside.................................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: Showtec DDP-610 MKII User manual Safety Instructions Every person involved with the installation, operation and maintenance of this device has to: ... - Page 4 If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
DDP-610 MKII Operating Determinations This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. The maximum ambient temperature t = 40°C must never be exceeded. ... -
Page 6: Return Procedure
DDP-610 MKII Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 7: Description Of The Device
Description of the device Features The Showtec DDP-610 MKII is a dimmer pack which combines all features of the most common dimmer packs. It has 6 channels which can handle a maximum load of 10A each. Each channel is completely patchable and it is possible to set a separate dimming curve for each of them. -
Page 8: Backside Ddp-610M (Ordercode 50754)
DDP-610 MKII Backside DDP-610M (ordercode 50754) Fig. 02 07) 3-pin DMX signal connector OUT 08) 3-pin DMX signal connector IN 09) Multiconnector output (6 outputs) Maximum load 10A per output. 10) Power input Total load should not exceed 32A per phase. Backside DDP-610S (ordercode 50755) Fig. -
Page 9: Backside Ddp-610T (Ordercode 50757)
DDP-610 MKII Backside DDP-610T (ordercode 50757) Fig. 04 17) 3-pin DMX signal connector IN 18) Analog IN 1-6 connector This connector allows you to control each channel with an analog DC voltage between 0-10V. 19) Analog through 1-6 connector This connector is wired parallel with the analog input 1-6 connector (18). 20) 3-pin DMX signal connector OUT 21) Cable entrances Make sure that you use good quality cables and cable glands. -
Page 10: Terminal Connections Ddp-610T (Ordercode 50757)
DDP-610 MKII Terminal connections DDP-610T (ordercode 50757) Always disconnect from electric mains power supply before cleaning or servicing. Damages caused by non-observance are not subject to warranty. Occupation of the XLR connection (All versions) Occupation of the analog connector (DDP-610S ordercode 50755/DDP-610T ordercode 50757) Ordercode: 50754/50755/50757... -
Page 11: Set Up And Operation
DDP-610 MKII Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Connect the device to the main power supply. -
Page 12: Menu Overview
DDP-610 MKII Menu Overview Ordercode: 50754/50755/50757... -
Page 13: Main Menu Options
DDP-610 MKII Main Menu Options Patching mode Dimming curve Minimum output level Maximum output level DMX failure settings 1. Patching mode With this menu you can set whether the DMX address is applied to all channels or just one channel at a time. -
Page 14: Dimming Curve
DDP-610 MKII 09) Press the UP/DOWN buttons to assign a separate address to each of the 6 channels. The adjustment range is between 001-512. 10) Once you have adjusted all the settings, press the ESC button to return to the previous menu. 2. -
Page 15: Minimum Output Level
DDP-610 MKII 3. Minimum output level With this menu you can set the minimum output level and set whether the output is applied to all channels or just one channel at a time. 01) While in the main menu, press the UP/DOWN buttons until the display shows 02) Press the MENU button to enter the submenu. -
Page 16: Dmx Failure Settings
03) The electric power supply cables must not show any damages or material fatigue. The Showtec DDP-610 MKII requires almost no maintenance. However, you should keep the unit clean. 01) Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. -
Page 17: Troubleshooting
02) Check power from the wall, all cables, the settings (return to default), etc. 03) Plug the unit in again. 04) If nothing happens after 30 seconds, unplug the device. 05) Return the device to your Showtec dealer. Product Specifications Model:... -
Page 18: Dimensions
DDP-610 MKII Dimensions Ordercode: 50754/50755/50757... -
Page 19: Notes
DDP-610 MKII Notes Ordercode: 50754/50755/50757... - Page 20 ©2017 Showtec...
