JUNIOR JNR-8153 Manual

Jnr 150 l wash
Hide thumbs

Advertisement

Table of Contents

Enlarged version
10

MAINTENANCE AND CLEANING

The following points have to be considered during the inspection:
1) All screws for installing the devices or parts of the device have to be tightly connected
and must not be corroded.
2) There must not be any deformations on the housing, color lenses, fixations and
installation spots (ceiling, suspension, trussing).
3) Mechanically moved parts must not show any traces of wearing and must not rotate with
unbalances.
4) The electric power supply cables must not show any damage, material fatigue or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
CAU T I O N
Disconnect from mains before starting maintenance operation.
In order to make the lights in good condition and extend the life time, we suggest a regular
cleaning to the lights.
1) Clean the inside and outside lens each week to avoid the weakneness of the lights due to
accumulation of dust.
2) Clean the fan each week.
3) A detailed electric check by approved electrical engineer each three month, make sure
that the circuit contacts are in good condition, prevent the poor contact of circuit from
overheating.
We recommend a frequent cleaning of the device. Please use a moist, lint- free cloth. Never
use alcohol or solvents.
There are no serviceable parts inside the device. Please refer to the instructions under
"Installation instructions".
Should you need any spare parts, please order genuine parts from your local dealer.
PR LIGHTING LTD.
http://www.pr-lighting.com
1582 Xingye Avenue, Nancun Panyu
Guangzhou, 511442 China
TEL: +86-20-3995 2888
JNR 150L Wash
JNR-8153

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JNR-8153 and is the answer not in the manual?

Questions and answers

Related Manuals for JUNIOR JNR-8153

Summary of Contents for JUNIOR JNR-8153

  • Page 1: Maintenance And Cleaning

    There are no serviceable parts inside the device. Please refer to the instructions under “Installation instructions”. Should you need any spare parts, please order genuine parts from your local dealer. JNR 150L Wash PR LIGHTING LTD. JNR-8153 http://www.pr-lighting.com 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888...

  • Page 2: Safety Instructions

    DMX CHANNELS SAFETY INSTRUCTIONS Mode/CH Function Values Description CAU T I O N Becareful with your operations.With a dangerous voltage you cansuffer a 0-255 PAN movement dangerous electric shock when touching wires! PAN-fine 0-255 Fine control of PAN movement TILT 0-255 Forwards infinite PAN rotation from slow to fast This device has left the factory in perfect condition.

  • Page 3: Menu Operations

    UNPACKING MENU OPERATIONS Function Dmx Address 001-XXX DMX address setting Thank you for choosing our JNR 150L Wash. For your own safety, please read this Mode CH12 Channel Mode Standard channel manual before installing the device. This manual covers the important information CH10 Vector channel on installation and applications.

  • Page 4: Features And Specifications

    For installations where the DMX cable has to run a long FEATURES & SPECIFICATIONS distance or is in an electrically noisy environment, such as 120 Ω Features in a discotheque, it is recommended to use a DMX • A 150W COB 4 1 LED lamp RGBW terminator.

  • Page 5: Dmx-512 Control Connections

    Regardless of the rigging option you choose for your JNR 150L Wash , always be sure to secure your fixture with a safety cable. The fixture provides a built-in rigging point for a safety cable on the hanging bracket as illustrated above. Be sure to only use the designated rigging point for the safety cable and never secure a safety cable to a carrying handle.

  • Page 6: Installations

    Never stand directly below the device when mounting, removing, or servicing the OPERATION INSTRUCTIONS fixture. from a ceiling, or set on a flat level surface (see illustration below). Be sure this fixture · The JNR 150L Wash is for wash effect for on-site decoration purpose. is kept at least 0.5m (1.5 ft) away from any flammable materials (decoration etc.).
