RX-Z9/DSP-Z9
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already
known and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service
departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and
specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please contact the
distributor's Service Division.
WARNING:
IMPORTANT:
Please note that no program is written into the micropro-
cessor supplied for servicing. Therefore, it is necessary to
write the program when the microprocessor is replaced.
(For the details, refer to "UPDATING FIRMWARE".)
CONTENTS
TO SERVICE PERSONNEL . . . . . . . . . . . . . . . . . . . . 2
FRONT PANELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
REMOTE CONTROL PANELS . . . . . . . . . . . . . . . . . . 4
REAR PANELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
SPECIFICATIONS /
参考仕様 . . . . . . . . . . . . . . . . .
INTERNAL VIEW . . . . . . . . . . . . . . . . . . . . . . . . . 13-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-31
自己診断機能(ダイアグ)
. . . . . . . . . . . . . . . . . . . 32-75
. . . . . . . . . . . . . . . . . . . 76-79
ファームウェアの更新方法
1 0 0 8 6 8
AV RECEIVER/AV AMPLIFIER

IMPORTANT NOTICE

Failure to follow appropriate service and safety procedures when servicing this product may result in personal
injury, destruction of expensive components, and failure of the product to perform as specified. For these reasons,
we advise all YAMAHA product owners that any service required should be performed by an authorized YAMAHA
Retailer or the appointed service representative.
The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
8-12
分解手順 . . . .
16-27
SERVICE MANUAL
SERVICE MANUAL
サービス供給されるマイコンはプログラムが書き込まれて
いないため、 修理でマイコンを交換した場合、 プログラム
の書き込みが必要です。 ( 詳細は 「ファームウェアの更新方
法」を参照してください。 )
. . . . . . . . . . . . . . . . . . . . . . . . 80-82
調整 . . . . . . . . . . . . . . . . . . . . .
DISPLAY DATA . . . . . . . . . . . . . . . . . . . . . . . . . . 84-85
IC DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86-105
BLOCK DIAGRAM . . . . . . . . . . . . . . . . . . . . . . 106-109
PRINTED CIRCUIT BOARD . . . . . . . . . . . . . . 110-129
PIN CONNECTION DIAGRAM . . . . . . . . . . . . . . . . 130
SCHEMATIC DIAGRAM . . . . . . . . . . . . . . . . . 131-144
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . 145-188
REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . 189
GUI REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . 190
83

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha DSP-Z9

  • Page 1: Table Of Contents

    This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already known and understood by the users, and have therefore not been restated.
  • Page 2: To Service Personnel

    RX-Z9/DSP-Z9 ■ TO SERVICE PERSONNEL AC LEAKAGE 1. Critical Components Information WALL EQUIPMENT TESTER OR Components having special characteristics are marked Z UNDER TEST OUTLET EQUIVALENT and must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models Only)
  • Page 3: Front Panels

    溶けた状態となるようにハンダ付けしてください。 placed and from the area around it completely before sol- dering, or make sure that the lead free solder and lead solder melt together fully. ■ FRONT PANELS ▼ RX-Z9 ▼ DSP-Z9...
  • Page 4: Remote Control Panels

    RX-Z9/DSP-Z9 ■ REMOTE CONTROL PANELS ▼ Remote Control ▼ GUI Remote Control...
  • Page 5: Rear Panels

    RX-Z9/DSP-Z9 ■ REAR PANELS ▼ RX-Z9 (U, C models) ▼ RX-Z9 (A model) ▼ DSP-Z9 (R model)
  • Page 6 RX-Z9/DSP-Z9 ▼ DSP-Z9 (B model) ▼ DSP-Z9 (G model) ▼ DSP-Z9 (T model)
  • Page 7 RX-Z9/DSP-Z9 ▼ DSP-Z9 (K model) ▼ DSP-Z9 (J model)
  • Page 8: 参考仕様

    SURROUND BACK (1 kHz, 10 % THD) YPAO (YAMAHA Parametric Room Acoustic Optimizer) R, T, K models (8 ohms) ......250 W f = 63 Hz to 16 kHz .
  • Page 9 RX-Z9 ....Black color (U, C, A models) 50 dB Quieting Sensitivity (IHF) DSP-Z9 ....Black color (R, G, J models) 1 kHz 100% MOD.
  • Page 10 “i.LINK” and the “i.LINK” logo are trademarks of Sony Corpora- tion. AAC ロゴマーク はドルビーラボラトリーズの登録商標です。 i.LINK と i.LINK ロゴ はソニー株式会社の登録商標です。 "SILENT CINEMA"is a trademark of YAMAHA CORPORATION. 「サイレントシアター/ SILENT THEATER 」はヤマハ株式会社の 登録商標です。 / 寸法図 DIMENSIONS 435 (17–1/8") Unit : mm (inch)
  • Page 13: Internal View

    RX-Z9/DSP-Z9 ■ INTERNAL VIEW ▼ Top View MAIN (R)-R P.C.B. POWER (1) P.C.B. MAIN (R)-L P.C.B. SUB TRANS (3) P.C.B. POWER TRANSFORMER MAIN (L)-R P.C.B. POWER (2) P.C.B. MAIN (L)-L P.C.B. SUB TRANS (5) P.C.B. SUB TRANS (1) P.C.B. SUB TRANS (2) P.C.B.
  • Page 14 RX-Z9/DSP-Z9 ▼ Right Side View MAIN (R)-R P.C.B. FUNCTION P.C.B. SUB TRANS (5) P.C.B. POWER (1) P.C.B. DSP1 (1) P.C.B. VIDEO BOTTOM P.C.B. VIDEO TOP P.C.B. ▼ Left Side View SUB TRANS (4) P.C.B. FUNCTION P.C.B. MAIN (L)-L P.C.B. 1394 P.C.B.
  • Page 15 RX-Z9/DSP-Z9 ▼ Front View SUB CHASSIS UNIT (サブシャーシユニット) OPERATION (7) P.C.B. OPERATION (1) P.C.B. OPERATION (3) P.C.B. OPERATION (5) P.C.B. OPERATION (6) P.C.B. OPERATION (2) P.C.B. ▼ Rear View SUB TRANS (5) P.C.B. FUNCTION P.C.B. SUB TRANS (1) P.C.B. SUB TRANS (2) P.C.B.
  • Page 16: Disassembly Procedures / 分解手順

    RX-Z9/DSP-Z9 ■ DISASSEMBLY PROCEDURES / 分解手順 (Remove parts in disassembly order as numbered.) (番号順に部品を取り外してださい。) 1. Removal of Top Cover 1. トップカバーの外し方 a. Remove 6 screws ( ), 6 washers ( ) and 1 screw のネジ6本、 のワッシャー6個、 のネジ1本を外し ます。 ( Fig. 1)...
  • Page 17 RX-Z9/DSP-Z9 ● Bottom View DC Fan Motors / DCファンモーター  DSP1 (1) P.C.B. 1394 P.C.B. DSP2 P.C.B. 5. Removal of Side Frame L/R 5. サイドフレームL/Rの外し方 のネジ6本と の ネジ2本を外し、 サイドフレーム L a. Remove 6 screws ( ) and 2 screws ( ) and then (Upper)を取り外します。...
  • Page 18 RX-Z9/DSP-Z9 6. Removal of Amp Unit L/R 6. アンプユニットL/Rの外し方 a. サイドフレーム L/R (Upper)を取り外します。 ( 5項参照) a. Remove the Side Frame L/R (Upper). (See procedure 5) の ネジ4本と の ネジ5本を外します。 ( Fig. 7) b. Remove 4 screws ( ) and 5 screws ( ) in Fig.
  • Page 19 RX-Z9/DSP-Z9 7. Removal of SUB TRANS (4) P.C.B. & SUB TRANS (5) 7. SUB TRANS (4) & SUB TRANS (5) P.C.B.の外し方 a. サイドフレーム L/Rを取り外します。 ( 5項参照) P.C.B. a. Remove the Side Frame L/R. (See procedure 5) b. アンプユニットL/Rを取り外します。 ( 6項参照)...
  • Page 20 RX-Z9/DSP-Z9 8. Removal of SUB TRANS (1) P.C.B. & SUB TRANS (2) 8. SUB TRANS (1) & SUB TRANS (2) P.C.B.の外し方 の ネジ2本を外し、 AC OUTLETを外します。 ( Fig. 11) P.C.B. a. Remove 2 screws ( ) and then remove the AC OUTLET.
  • Page 21 RX-Z9/DSP-Z9 9. Removal of Power Transformer 9. 電源トランスの外し方 a. Remove 1 bolt ( ) and then remove the Support の ボルトを外し、 サポート(TRUP)を取り外します。 (TRUP). (Fig. 12) (Fig. 12) b. Remove 2 screws ( ) and then remove the Support の ネジ2本を外し、 サポート(TOP)を取り外します。...
  • Page 22 RX-Z9/DSP-Z9 11. Removal of FUNCTION P.C.B. 11. FUNCTION P.C.B.の外し方 a. サイドフレーム L/Rを取り外します。 ( 5項参照) a. Remove the Side Frame L/R. (See procedure 5) b. Remove the Amp Unit L/R. (See procedure 6) b. アンプユニットL/Rを取り外します。 ( 6項参照) c. Remove the SUB TRANS (4) P.C.B. and SUB TRANS (5) c.
  • Page 23 RX-Z9/DSP-Z9 h. Remove 2 screws ( ) and 3 screws ( ) and then の ネジ2本と の ネジ3本を外し、 フレーム (CNT-L) を取り外します。 ( Fig. 14, 15) remove the Frame (CNT-L). (Fig. 14, 15) i. Remove 2 screws ( ) and 3 screws ( ) and then の...
  • Page 24 RX-Z9/DSP-Z9 12. Removal of Sub Chassis Unit 12. サブシャーシユニットの外し方 a. フロントパネルを取り外します。 ( 3項参照) a. Remove the Front Panel. (See procedure 3) b. Remove the Side Frame L/R. (See procedure 5) b. サイドフレーム L/Rを取り外します。 ( 5項参照) c. Remove 4 screws ( ).
  • Page 25 RX-Z9/DSP-Z9 Support (PCB)  サポート (PCB) POWER (1) P.C.B. POWER (2) P.C.B. CB904 CB903 CB701 CB862 SUB TRANS (4) P.C.B. Fig. 19 SUB TRANS (4) P.C.B. FUNCTION P.C.B. MAIN (L)-L P.C.B. VIDEO BOTTOM P.C.B. POWER (2) P.C.B. CB26 VIDEO TOP P.C.B.
  • Page 26 RX-Z9/DSP-Z9 14. Removal of DC Fan Motor 14. DCファンモーターの外し方 a. ボトムカバーを取り外します。 ( 4項参照) a. Remove the Bottom Cover. (See procedure 4) b. Remove the Side Frame L/R. (See procedure 5) b. サイドフレーム L/Rを取り外します。 ( 5項参照) c. Remove the Sub Chassis Unit. (See procedure 12) c.
  • Page 27 RX-Z9/DSP-Z9 Rear Panel Unit / リアパネルユニット  Fig. 22 VIDEO TOP P.C.B. MAIN (R)-R P.C.B. CB14 CB16 CB12 SUB TRANS (5) P.C.B. FUNCTION P.C.B. VIDEO BOTTOM P.C.B. CB13 CB16 CB15 DSP1 (1) P.C.B. POWER (1) P.C.B. CB12 CB14 CB11 Fig. 23 SUB TRANS (4) P.C.B.
  • Page 28: Disassembly & Repair Procedures / 分解修理方法

    RX-Z9/DSP-Z9 ■ DISASSEMBLY & REPAIR PROCEDURES / 分解修理方法 ・必要なツール : RX-Z9/DSP-Z9 修理用コネクター Ass y • Required tools : Connector kit for RX-Z9/DSP-Z9 repair (パーツ No:AAX56660) (Part No : AAX56660) 下記に内訳を示します。 This kit consists of the following items. Tag No. / タグ No.
  • Page 29 RX-Z9/DSP-Z9 2. Operation check of SUB TRANS (4), (5) P.C.B.s 2. SUB TRANS (4),(5) P.C.B. の動作チェック 1) アンプユニットを一旦外し、SUB TRANS (4) P.C.B. また 1) With the amplifier unit removed, release the SUB TRANS (4) P.C.B or SUB TRANS (5) P.C.B. and take it out.
  • Page 30 RX-Z9/DSP-Z9 4. サブシャーシユニットの動作チェック 4. Operation check of sub-chassis unit ・タグ No.7 のケーブルを使って OPERATION (1) P.C.B. • Using tag No.7 cables, extend OPERATION (1) P.C.B. W931 W931 を延長し、POWER (2) P.C.B. CB702 に接続します。 and connect it to POWER (2) P.C.B. CB702. なお、W956 は HP なので接続不要です。...
  • Page 31 RX-Z9/DSP-Z9 ・タグ No. 8 のケーブルを使って SUB TRANS (4) P.C.B. • Using the tag No.8 cable, extend SUB TRANS (4) P.C.B. W862 を延長し、VIDEO TOP P.C.B. CB20 に接続します。 W862 and connect it to VIDEO TOP P.C.B. CB20. • Using the tag No.6 cable, extend FUNCTION P.C.B. W6 ・タグNo.
  • Page 32: Self Diagnosis Function (Diag)

    RX-Z9/DSP-Z9 ■ SELF DIAGNOSIS FUNCTION (DIAG) / 自己診断機能 (ダイアグ) This product has a built-in self diagnosis function (DIAG) to 本機には、 検査、 測定、 不良個所の発見を目的にした自己診 facilitate inspection, measurement and determination of a 断機能 (ダイアグ) があります。 faulty item, if any. There are 24 DIAG menu items, each hav- ダイアグメニューは24種類あり、...
  • Page 33 RX-Z9/DSP-Z9 No. DIAG menu Sub-menu 9. TEST PATTERN 2 10. CUI MODE (GUI) 11. VIDEO INFO 10 i.LINK CNCT - - - 11 i.LINK CMD 1. RESERVED 2. EJECT 12 PCB CHECK 1. YSS 2. 1394 3. YG/MN 13 RESERVED...
  • Page 34 RX-Z9/DSP-Z9 No. DSP HIF STATUS menu FL Display Status (1) Status (2) Stream Info System (PLD, Sel, etc) Mute Info Channel Status (1) Channel Status (2) DIR Info (1) DIR Info (2) 10 ADI Info (1) 11 ADI Info (2)
  • Page 35 RX-Z9/DSP-Z9 ● Canceling DIAG ダイアグの解除 ● ダイアグを解除する前に、ダイアグメニュー No. 18 の Before canceling DIAG, execute setting for PRESET of PRESET (メモリーの初期化禁止 / またはメモリーの DIAG menu No.18 (Memory initialization inhibited or 初期化)の設定をします。 Memory initialized). ※ ユーザーメモリーを保持したい場合は、必ず PRESET In order to keep the user memory stored, be sure to se- INHIBITED(メモリー初期化禁止)を選択してください。...
  • Page 36 RX-Z9/DSP-Z9 プロテクション履歴がある場合: When there is a history of protection function: The FL display appears as shown below depending on the プロテクションの種類によって下記の表示が現れます。 type of the protection function. The protection function worked due to exces- スピーカーをショートさせた時などが原因で、 I PROTECT:xx プロテクションが働いたことを示します。 sive current through the amplifier. Causes...
  • Page 37 RX-Z9/DSP-Z9 ● メニュー動作中の表示 Display during menu operation ● ダイアグ中、モニター画面には起動画面の項で説明し During the DIAG operation, the menu list described in たメニュー一覧が表示されます。本体の FL ディスプ the section of the startup screen appears on the monitor レイには動作中の機能が表示されます。機能動作中の screen and the function at work is indicated on the FL 表示内容については、後述の機能詳細で記述します。...
  • Page 38 RX-Z9/DSP-Z9 ● Functions available during DIAG ダイアグ中の機能 ● In addition to the DIAG menu, the functions listed below ダイアグメニューの他に以下の機能が動作します。 are available. Each initial setting at the start of DIAG func- また、ダイアグ開始時のそれぞれの初期設定は右に記し ます。 tion is given at the right. ・INPUT:DVD ・MULTI CH INPUT:OFF •...
  • Page 39 RX-Z9/DSP-Z9 Details of DIAG menu ダイアグメニュー詳細 The DIAG menu items from "DIAG 1" to "DIAG 5" are for 「DIAG 1」から「DIAG 5」までのダイアグメニューは オーディオ経路及び設定確認用のメニューです。 confirmation of the audio signal path and settings. (The sig- (信号経路をブロック図で説明してます) nal path is shown in the block diagram.) 1.
  • Page 40 RX-Z9/DSP-Z9 • The input mode is Auto. When fs is 128kHz or more, Down ・入力モードは Auto です。fs ≧ 128kHz の場合は 1/2 に Sampling to 1/2 is executed. Down Sampling します。 1.DSP THROUGH INPUT: DVD ANALOG Input level Volume SUBWOOFER SPEAKERS OUT (1KHz)
  • Page 41 RX-Z9/DSP-Z9 2. DSP RAM THROUGH 2. DSP RAM THROUGH ・Digital PCM 入力の場合は、セレクタ(PLD)設定を • When using the digital PCM input, this is the signal path “DIAG MODE1”にして DIR 出力をデコーダー(SHARC) through which the DIR output signals are inputted to all の入力ポート全てに入力される信号経路です。その他は the input ports of the decoder (SHARC) with the selector 通常処理で再生します。...
  • Page 42 RX-Z9/DSP-Z9 3. BYPASS 3. BYPASS ANALOG BYPASS ANALOG BYPASS ・Analog 入力固定で、DIRECT ANALOG の信号経路です。 • This is the DIRECT ANALOG signal path with the analog ・DSP 基板の D/A → A/D は通りません。 input fixed. • On the DSP P.C.B., D/A and A/D are not used.
  • Page 43 RX-Z9/DSP-Z9 DSP BYPASS PCM1792 x 6 DIGITAL IC14 IC35 YSS930 X3566A0 (DIR) SL/SR SL/SR IC44 PCB DSP2 PCB DSP2 IC2, 4 IC22 C+/C- C+/C- IC6, 8 IC64 Analog IC10, 12 X3565A0 CS5361 IC14, 16 SBL/SBR SBL/SBR IC51 DECODER DSP ADSP21161N...
  • Page 44: Pure Direct

    RX-Z9/DSP-Z9 PURE DIRECT PURE DIRECT ・Pure Direct の信号経路です。本ダイアグでは DSP 及び • This is the Pure Direct signal path. When this DIAG menu is selected, the power of DSP and VIDEO is not turned off VIDEO 電源の OFF 処理は行わず、信号経路のみの設定 but only the signal path is set.
  • Page 45 RX-Z9/DSP-Z9 4. i.LINK AUDIO 4. i.LINK AUDIO • In this DIAG mode, any input other than i.LINK is invalid. ・本 DIAG モードでは、i.LINK 以外の入力は無効です。 PCM1792 x 6 DIGITAL IC14 IC35 YSS930 X3566A0 (DIR) SL/SR SL/SR IC44 PCB DSP2 PCB DSP2 IC2, 4...
  • Page 46 RX-Z9/DSP-Z9 5. PRO LOGIC/PRO LOGIC II 5. PRO LOGIC/PRO LOGIC II ・Pro Logic のオートインプットバランスオフの他は通常 • Other than when the auto input balance is OFF, Pro Logic 時と同じです。 functions in the same manner as usual. ・Pro Logic II は通常動作と同じです。 • Pro Logic II functions in the same manner as usual.
  • Page 47 RX-Z9/DSP-Z9 6. SPEAKER SET 6. SPEAKER SET ・入力は、 DD →DTS → AAC →PCM →アナログ (A/D) の優 • The input signals are automatically judged in the priority order of DD → DTS → AAC → PCM → Analog (A/D). 先順で自動判別します。 ・ DSP部からは、 No. 1 DSP THROUGHの0dBと同様の信号が...
  • Page 48 RX-Z9/DSP-Z9 The analog switch settings for each sub-menu are as shown 各サブメニューにおけるアナログスイッチの設定は以下の in the table below. 通りです。 Sub-menu FRONT SP CENTER SP SUR SP SUR.B SP LFE/BASS PRESENCE 1 CENTER: NONE LARGE NONE LARGE LARGE x 2 SWFR ST 2 SURROUND: NONE...
  • Page 49 RX-Z9/DSP-Z9 7. MANUAL SET 7. MANUAL TEST • The noise generation circuit built into the DSP outputs the ・DSP 内蔵のノイズ発生回路によって、サブメニューで 指定したチャンネルへテストノイズを出力します。 test noise to the channels specified by the sub-menu. 7.MAN , L TEST 7.MAN , L TEST FRONT L 7.MAN , L TEST...
  • Page 50 RX-Z9/DSP-Z9 8. VFD CHECK 8. VFD CHECK • This program is used to check the FL display section. The ・FL 表示部のチェックプログラムです。 サブメニュー操作 により、 表示状態が以下のように変わります。 display condition varies as shown below according to the ・マイコン制御による映像信号の内部/外部同期切り替え sub-menu operation. は、 強制外部同期となります。 • Internal /external synchronization of the image signals sub- ject to the microprocessor control is set to forced external synchronization.
  • Page 51 RX-Z9/DSP-Z9 9. VIDEO 9. VIDEO • This menu is intended for checking the video circuit. ・ビデオ回路のチェックを行う為のメニューです。 • Various signal path and operation checks are performed ・サブメニューを切り替えることにより、 各種信号経路 by changing the sub-menu. チェック ・ 動作チェックを行います。 DIGITAL THROUGH 480i DIGITAL THROUGH 480i ・解像度...
  • Page 52 RX-Z9/DSP-Z9 DIGITAL BYPASS DIGITAL BYPASS ・IC30 (YGV619)及び IC40 (FLI2310)をバイパスした経路 • The signals are output through the path bypassing IC30 (YGV619) and IC40 (FLI2310). で信号出力します。 9.VIDEO DIGITAL BYPASS COMPONENT COMPONENT IC40 FLI2310 IC22 HD input XV750B (I/P conversion)  IC28 IC30 (Resolution conversion) ...
  • Page 53 RX-Z9/DSP-Z9 DIGITAL THR 480p DIGITAL THR 480p • The signals are output after 480p conversion. ・480p 変換して信号出力します。 9.VIDEO DGTL THR 480p COMPONENT COMPONENT IC40 FLI2310 IC22 HD input XV750B (I/P conversion)  IC28 IC30 (Resolution conversion)  D5 (J only) (A/D) D5 (J only) (Aspect conversion) ...
  • Page 54 RX-Z9/DSP-Z9 DIGITAL THR 720p DIGITAL THR 720p • The signals are output after 720p conversion. ・720p 変換して信号出力します。 。 9.VIDEO DGTL THR 720p COMPONENT COMPONENT IC40 FLI2310 IC22 HD input XV750B (I/P conversion)  IC28 IC30 (Resolution conversion)  D5 (J only) (A/D) D5 (J only) (Aspect conversion) ...
  • Page 55 RX-Z9/DSP-Z9 TEST PATTERN 2 TEST PATTERN 2 • The test pattern is output from IC28 (ADV7310). ・IC28 (ADV7310)からテストパターンを出力します。 9.VIDEO TEST PATTERN 2 COMPONENT COMPONENT IC40 FLI2310 IC22 HD input XV750B (I/P conversion)  IC28 IC30 (Resolution conversion)  D5 (J only) (A/D) D5 (J only) (Aspect conversion) ...
  • Page 56 RX-Z9/DSP-Z9 10. i.LINK CONNECTION 10. i.LINK CONNECTION (現在、 対応していません) (This function is not currently supported.) GUID of the equipment which is i.LINK connected currently 現在i.LINK接続されている機器のGUIDを表示します。 GUIDとはGlobal Unique IDの略で、 各メーカー及び各機器1 is displayed. GUID stands for Global Unique ID and means 台ごとに割り当てられたIDを意味します。...
  • Page 57 RX-Z9/DSP-Z9 12.PCB CHECK Display indicating existence of an error: NGxxxxx YSS:NGxxxxxx エラー有りの表示 : NGxxxxxx 3rd byte 2nd byte 1st byte “xxxxxx” はYSS930 #0ー#7でのエラー箇所の詳細を16進数 "xxxxx" represents details of the error point in YSS930 #0- #7 expressed in hexadecimal. で表示しています。 <第 1 バイト>...
  • Page 58 RX-Z9/DSP-Z9 YSS930 同士の SDO → SDI ラインのチェック結果について Check result of SDO -> SDI line between YSS930 and YSS930 When the value "xx" is converted into binary, "1" appears “xx”を 2 進数に変換した時に、エラーがある箇所に“1”が where there is an error. 立つようになっています。 1st bit: Check result of SDO -> SDI connection between 1bit 目:IC4 - IC8 間の...
  • Page 59 RX-Z9/DSP-Z9 1394 1394 • The 1394 P.C.B. is self-checked and the result is displayed. ・1394基板のセルフチェックを行い、 結果を表示します。 12.PCB CHECK エラー無しの表示 : NoEr Display indicating no error : NoEr 1394:NoEr 12.PCB CHECK Display indicating existence of an エラー有りの表示 : NGxx 1394:NGxx error : NGxx “xx”...
  • Page 60 RX-Z9/DSP-Z9 14. RS-232C 14. RS-232C This menu is used to check transmission and reception of データ送受信チェック、ハードウェアフローポートチェッ the data and the flow port of the hardware. クを行うメニューです。 With the power turned off, short between pins No.2 (RxD) パワーオフ状態にしてから、RS-232C端子の2ピン(RxD)と3 and No.3 (TxD) and between pins No.7 (RTS) and No.8 (CTS) ピン(TxD)、7ピン(RTS)と8ピン(CTS)をショートさせます。...
  • Page 61 RX-Z9/DSP-Z9 15. BOOT DSP 15. BOOT DSP RS-232C経由でDSPマイコン及びデコーダ用ROMの書き込 This item is used to write in ROM for the DSP microproces- みを行う際にこの項目を設定します。 sor and decoder through RS-232C. FLASH WRITE FLASH WRITE This indicates that the menu is for writing the DSP (micro- DSP (...
  • Page 62 RX-Z9/DSP-Z9 16. BOOT 1394 16. BOOT1394 This item is used to write the program in FLASH ROM in the RS-232C経由で1394基板内のフラッシュROMにプログラム を書き込みを行う際にこの項目を設定します。 1394 P.C.B. through RS-232C. FLASH WRITE FLASH WRITE 1394基板内のフラッシュROM書き込みメニューであること This indicates that the menu is for writing in FLASH ROM in を示します。...
  • Page 63 RX-Z9/DSP-Z9 18. PRESET 18. PRESET This menu is used to reserve/inhibit initialization of the back- バックアップ用RAM (音場プログラムのパラメーターや セットメニュー内容等) の初期化を予約/禁止します。 up RAM (Parameters and set menu contents, etc. of the sound field program). PRESET INHIBIT (Initialization inhibited) / PRESET INHIBIT (初期化禁止)...
  • Page 64 RX-Z9/DSP-Z9 19. AD/FAN 19. AD/FAN With this sub-menu used, the key scanning, A/D value of the キースキャン、 異常検出 (プロテクション) ポート電圧のA/D voltage at the abnormality detect (protection) port, etc. are 値などを表示します。 displayed. Also, this is the menu for executing the FAN drive またFANの駆動テストを行うメニューです。...
  • Page 65 19.AD/FAN K0:100 K1:100 [Table 1] Display (%) The keys of the main unit are DSP-Z9とRX-Z9 ( TUNER有 0 ± 4 – SPEAKERS B different between DXP-Z9 無) で本体キーが異なります 10 ± 4 BALANCE –...
  • Page 66 Select EXIST or NOT. TUNER:NOT チューナー非搭載機種(D S P - Z 9 )で Do not use the "EXIST" setting for the model not equipped with a tuner (DSP-Z9). “EXIST”には設定しないでください。 ● Selection of existence of AAC decoder function ● AAC デコーダ機能の有無選択 20.SOFT SWITCH EXIST (有り)...
  • Page 67 Checksum 22.1394 INFO マイコンチェックサム Microprocessor checksum MS:xxxx/AS:xxxx ARMコードチェックサム ARM code checksum 22.1394 INFO モデル名表示です。 Model name MDL:DSP-Z9 (DSP-Z9もしくはRX-Z9) (DSP-Z9 or RX-Z9) Vender name 22.1394 INFO ベンダ名表示です。 VND:YAMAHA (YAMAHA) (YAMAHA) 22.1394 INFO 各メーカーごとに割り当てられたID表示 Vender ID assigned to VID:00A0DE each manufacturer です。...
  • Page 68 RX-Z9/DSP-Z9 23. VIDEO INFO 23. VIDEO INFO The video microprocessor software version information and サブメニュー操作により、 ビデオマイコンソフトウェアバー ジョン情報や関連情報などを表示します。 related information are displayed by the sub-menu opera- tion. Video microprocessor software version ビデオマイコンソフトウェアバージョン 23.VIDEO INFO (It can take a minute or more to display.) 表示です。...
  • Page 69 RX-Z9/DSP-Z9 Details of video microprocessor related information / ビデオマイコン関連情報の詳細 ● 23.VIDEO INFO CPU:37000120 * The numeric value in the diagram is for reference. ※図中数値は参考例です。 4th byte 3rd byte 2nd byte 1st byte <第 1 バイト:映像遅延時間> <1st byte: Image delay time>...
  • Page 70 RX-Z9/DSP-Z9 24. MAIN INFO 24. MAIN INFO The information such as main microprocessor software ver- サブメニュー操作により、 メインマイコンソフトウェアバー ジョン情報などを表示します。 sion is displayed by the sub-menu operation. Main microprocessor software version. メインマイコンソフトウェアバージョン 24.MAIN INFO 表示です。 VER. C39CD11BD Main microprocessor software checksum 1.
  • Page 71 RX-Z9/DSP-Z9 ● HIF status for DSP microprocessor signal detection / DSPマイコン信号検出用HIFステータス HIF stands for Host Interface. HIFはHost Interfaceの略です。 任意のダイアグメニュー時に “INPUT MODE” キー操作をす It is possible to have the information on the status inside of る、 あるいはMULTI JOG等でメニューを送ることで、 DSPマ the DSP microprocessor displayed by operating the "INPUT イコン内部ステータスの情報を表示することができます。...
  • Page 72 RX-Z9/DSP-Z9 <第 2 バイト> <2nd byte) 再生信号の Fs 情報(bit 7-4)とオーディオコードモード情 Indicates the Fs information (bit 7-4) and audio code mode information (bit 3-0) of the reproduction signals. 報(bit 3-0)を示します。 <3rd byte> <第 3 バイト> Indicates the format information of the reproduction signals.
  • Page 73 RX-Z9/DSP-Z9 0x0* 0x1* 0x2* 0x3* 0x4* 0x*0 input Unlock RESET 0x*1 2/8ch SP SP/HP DIR INT DECODE Input Mode 0x*2 − YSS930 VBIT FORMAT Others 0x*3 − SHARC RED_DTS 0x*4 CONFIG ACMOD YPAO − − 0x*5 − − KARAOKE WAIT 0x*6 −...
  • Page 74 RX-Z9/DSP-Z9 Details of STATUS 1 / STATUS 1の詳細 ● DSP HIF STATUS Indicate ST1:0502001000 0 0 0 0 0 0 0 0 5th byte 7 6 5 4 3 2 1 0 4th byte Indicate Indicate 3rd byte 2nd byte 1st byte * The numeric value in the diagram is for reference.
  • Page 75 RX-Z9/DSP-Z9 <3rd byte> / <第 3 バイト> Format information of reproduction signal 再生信号のフォーマット情報 XXX_ANY is judged by upper 4 bits. 上位 4bit で XXX_ANY 判定 DD/dts is FLAG judged by lower 4 bits. DD/dts は下位 4bit でフラグ判定 0x00 Analog (Unlock)
  • Page 76: Updating Firmware

    Pin No.7 RTS Pin No.3 TxD Pin No.3 TxD Pin No.8 CTS Pin No.8 CTS Pin No.5 GND Pin No.5 GND RX-Z9/DSP-Z9 side PC side  Pin No.7 RTS Pin No.7 RTS ・ RS232C変換アダプター (Part #: AAX24910) Pin No.8 CTS Pin No.8 CTS...
  • Page 77 RX-Z9/DSP-Z9 Z9 メインマイコンの場合 [For Z9 Main Microprocessor] Connect the power cable of the amplifier to the AC outlet. アンプの電源をコンセントに接続します。 Execute the firmware loading program (YAV Boot. exe) ファームウェア書き込み用プログラム(YAVBoot.exe)を 立ち上げます。 Select the model. 次にモデルを選択します。 Select MAIN among Type choices. Type の中から MAIN を選択します。...
  • Page 78 RX-Z9/DSP-Z9 Z9 ビデオ、Z9 DSP 外 ROM、Z9 iLINK、Z9 DSP [For Z9 Video, Z9 DSP External ROM, Z9 iLINK, Z9 DSP Microprocessors] マイコンの場合 Automatic loading function is available only with the main 自動書き込みはメインマイコンのバージョン D52 以降に限 microprocessor of version D52 or after. り可能です。...
  • Page 79 RX-Z9/DSP-Z9 MULTI JOG を回し、書き込むメニューを選択します。 Select the menu to be loaded by turning the MULTI JOG knob. ビデオ ....... 17 DSP マイコン、DSP 外...
  • Page 80: Video Signal Processing / ビデオ信号について

    D/A 変換・カラーエンコード D/A conversion, color encoding Various image signal information addition 各種映像信号情報付加 DSP-Z9のビデオ信号はそのほとんどがデジタル処理さ Most of the video signals of RX-Z9/DSP-Z9 are digitalized. れています。しかし、A/D変換ができる信号はNTSC However, only NTSC (480i)/PAL (576i) signals can be A/ (480i)/PAL(576i)のみなので480p/576p/1080i/720p等の信 D converted and 480p/576p/1080i/720p and other sig- 号入力時はビデオ信号処理が行われな...
  • Page 81 RX-Z9/DSP-Z9 The video signals that can be digitalized are NTSC (480i)/ デジタル処理が可能なビデオ信号はNTSC(480i)/PAL (576i)のみです。 PAL(576i) only. When 480p/576p/1080i/720p signals are input, none of 入力信号が480p/576p/1080i/720p の場合は、解像度・ア the image related functions such as resolution, aspect スペクト変換、画質調整機能等の映像系に関する機能は conversion and image quality adjustment is usable.
  • Page 82 応しています。 * The non-interlace type composite • signal can be handled. DSP-Z9の解像度変換は、1080i/720pの設定でも著作権保 When converting the resolution of RX-Z9/DSP-Z9, the 護された信号では 480p/576p変換になります。 copyright protected signals are subject to the 480p/576p conversion even if 1080i/720p setting is used.
  • Page 83: Amp Adjustment / 調整

    RX-Z9/DSP-Z9 ■ AMP ADJUSTMENT / 調整 ● IDLING CURRENT ADJUSTMENT ● アイドリング調整 電源投入後、 無信号状態で10分間経過した後に無信号状態 Wait for 10 minutes with no signal applied after turning on で調整を行ってください。 the power and then make adjustments with no signal ap- plied. Item / チャンネル...
  • Page 84: Display Data

    RX-Z9/DSP-Z9 ■ DISPLAY DATA V901 : 32-BT-09G (WB585900) PATTERN AREA ● PIN CONNECTION Pin No. Connection Pin No. Connection Note : 1) F1, F2 ..Filament 2) NP ..No pin 3) DL ..Datum Line 4) 1GA ~ 16GA, 1GB ~ 16GB ..Grid 5) IC ..
  • Page 85 RX-Z9/DSP-Z9 ● ANODE CONNECTION 16GA 15GA ~ 1GA 16GB 15GB ~ 1GB 1-1A 1-1B MULTICH 2-1A 2-1B 3-1A 3-1B 4-1A 4-1B MATRIX 5-1A 5-1B DISCRETE 1-2A 1-2B HiFi DSP 2-2A 2-2B 3-2A 3-2B 4-2A 4-2B 5-2A 5-2B P10A P10B 1-3A...
  • Page 86: Ic Data

    RX-Z9/DSP-Z9 ■ IC DATA IC14 : LC89057W-VF-E (DSP1 P.C.B.) Digital Audio Interface Transceiver SDIN SLRCK SBCK RDATA XMODE RLRCK DGND DVDD LC89057W-VF4-E DVDD DGND TMCK/PIO0 RBCK TBCK/PIO1 RMCK TLRCK/PIO2 AGND TDATA/PIO3 AVDD TXO/PIOE *: Pull-down resistor internal RXOUT Microcontroller Cbit, Ubit...
  • Page 87 RX-Z9/DSP-Z9 IC14 : LC89057W-VF-E (DSP1 P.C.B.) Digital Audio Interface Transceiver Name Function RXOUT Input bi-phase selection data output pin TTL-compatible digital data input pin Coaxial-compatible digital data input pin with built-in amplifier TTL-compatible digital data input pin TTL-compatible digital data input pin...
  • Page 88 RX-Z9/DSP-Z9 IC18 : PM4007A (DSP1 P.C.B.) AC-3 RF Demodulator AVDD CPIN CMIN AGND DOUT DOUTB WINGT SYST0 SYST1 ADST0 ADST1 BUNRI AGND AVDD Name Function Ground (0V) +5V power supply RESET System resetting terminal (reset at “L”) OSCON Oscillation control terminal. Oscillation ON at “H”, set to “H” normally and to “L” when in standby state...
  • Page 89 RX-Z9/DSP-Z9 IC18 : PM4007A (DSP1 P.C.B.) AC-3 RF Demodulator Name Function External RAM address output. Address 6 External RAM address output. Address 7 Ground terminal (0V) +5V power supply External RAM address output. Address 12 External RAM address output. Address 14 (MSB) External RAM write enable signal, active at “L”...
  • Page 90 RX-Z9/DSP-Z9 IC18 : PM4007A (DSP1 P.C.B.) AC-3 RF Demodulator Name Function AVDD +5V power supply for analog comparator CPIN Analog comparator input, positive side (Non-reverse side: QPSK input) CMIN Analog comparator input, negative side (reverse side) AGND Ground terminal for analog comparator (0V)
  • Page 91 RX-Z9/DSP-Z9 IC27 : M30624FGNFP (DSP1 P.C.B.) 16 bit μ-COM (DSP CPU) Port Name Function P96/SOUT4 CPU I/F DSP → Video VIDEO CPU I/F Clock P95/CLK4 DVCK DIR Validity (event timer Interrupt) P94/TB4in VBIT CS for DIR P93/TB3in P92/SOUT3 SDMY Tx for YSS/PLD/DIR/DAC...
  • Page 92 RX-Z9/DSP-Z9 IC27 : M30624FGNFP (DSP1 P.C.B.) 16 bit μ-COM (DSP CPU) Port Name Function P43/A19 /DMT Digital MUTE (mute=L) for PLD IRQ to SHARC (reserve) P42/A18 /IRQS2 Parallel: /REQ to SHARC P41/A17 /REQ FLASH A16 Control(H → A16=H) P40/A16 A16C...
  • Page 93 RX-Z9/DSP-Z9 IC2, 4, 6, 8, 10, 12, 14, 16 : YSS930-SZ (DSP2 P.C.B.) VDD2 RAMA11 RAMD9 RAMA12 RAMD8 RAMA13 RAMD7 RAMA14 RAMD6 RAMA15 RAMD5 RAMA16 RAMD4 RAMA17 RAMD3 VDD1 RAMD2 RAMD1 RAMD0 VDD1 IOPORT19 IOPORT18 SDWCK IOPORT17 SDBCK IOPORT16 SDI7...
  • Page 94 RX-Z9/DSP-Z9 IC2, 4, 6, 8, 10, 12, 14, 16 : YSS930-SZ (DSP2 P.C.B.) Name Function Digital ground terminal Terminal for connecting crystal oscillator Terminal for connecting crystal oscillator (12.288 ~ 15.0MHz) IOPORT0 I+/O General purpose input/output terminal, SDO0 Lch zero-flag output terminal, input/output terminal for branching program conditions...
  • Page 95 RX-Z9/DSP-Z9 IC2, 4, 6, 8, 10, 12, 14, 16 : YSS930-SZ (DSP2 P.C.B.) Name Function RAMD14 I+/O Data input/output terminal 14 for external memory RAMD15 I+/O Data input/output terminal 15 for external memory CASN Column address strobe output terminal for external DRAM...
  • Page 96 RX-Z9/DSP-Z9 IC56 : M30805SGP (VIDEO TOP P.C.B.) 16 bit μ-COM (Main CPU) P10/D8 P44/CS3/A20 P07/D7 P45/CS2/A21 P06/D6 P46/CS1/A22 P05/D5 P47/CS0/A23 P04/D4 P125 P114 P126 P113 P127 P112 P50/WRL/WR/CASL P111 P51/WRH/BHE/CASH P110 P52/RD/DW P03/D3 P53/BCLK/ALE/CLKout P02/D2 P130 P01/D1 P131 P00/D0 P157...
  • Page 97 RX-Z9/DSP-Z9 IC56 : M30805SGP (VIDEO TOP P.C.B.) 16 bit μ-COM (Main CPU) Pin function Function Name Detail of function P96/ANEX1/TxD4/SDA4 TxD4 TXDR 232C Transmit/Yokogawa Data Transmit 232C RTS Output/Yokogawa Clock Input P95/ANEX0/CLK4 CLK4 232C CTS Input P94/DA1/TB4in/CTS4/RTS4/SS4 FAN Control P93/DA0/TB3in/CTS3/RTS3/SS3...
  • Page 98 RX-Z9/DSP-Z9 IC56 : M30805SGP (VIDEO TOP P.C.B.) 16 bit μ-COM (Main CPU) Pin function Function Name Detail of function P136 P136 /VMCR Video Microprocessor Reset I/OL EVOL DC Bias Initialize P135 P135 /ICEV Enable Output for Toshiba IC (DSP) P134...
  • Page 99 RX-Z9/DSP-Z9 IC56 : M30805SGP (VIDEO TOP P.C.B.) 16 bit μ-COM (Main CPU) Pin function Function Name Detail of function P15/D13/INT3 KEEP P14/D12 KEEP P13/D11 KEEP P12/D10 KEEP P11/D9 KEEP P10/D8 KEEP P07/D7 KEEP P06/D6 KEEP P05/D5 KEEP P04/D4 KEEP Current Protection...
  • Page 100 RX-Z9/DSP-Z9 IC33 : M30805SGP (VIDEO BOTTOM P.C.B.) 16 bit μ-COM (Video CPU) P10/D8 P44/CS3/A20 P07/D7 P45/CS2/A21 P06/D6 P46/CS1/A22 P05/D5 P47/CS0/A23 P04/D4 P125 P114 P126 P113 P127 P112 P50/WRL/WR/CASL P111 P51/WRH/BHE/CASH P110 P52/RD/DW P03/D3 P53/BCLK/ALE/CLKout P02/D2 P130 P01/D1 P131 P00/D0 P157...
  • Page 101 RX-Z9/DSP-Z9 IC33 : M30805SGP (VIDEO BOTTOM P.C.B.) 16 bit μ-COM (Video CPU) Port Name Function P96/SDA4 SDA4 IIC Data FLI2310 INT ↓ P95/CLK4 /INTF DAC fs Select P94/DA1 DACSEL Vsync INT P93/TB3in /VSY P92/TxD3 TXYDC YDC TXD YDC RXD P91/RxD3...
  • Page 102 RX-Z9/DSP-Z9 IC33 : M30805SGP (VIDEO BOTTOM P.C.B.) 16 bit μ-COM (Video CPU) Port Name Function P133 Recout Source Select P132 RSRC +3.3V P131 /ZINH Zone2 Monitor Inhibit Video Monitor Inhibit P130 /VINH P53/BCLK P52/RD P51/WRH /WRH /WRL/for Flash (Vcc) P50/WRL...
  • Page 103 RX-Z9/DSP-Z9 IC33 : M30805SGP (VIDEO BOTTOM P.C.B.) 16 bit μ-COM (Video CPU) Port Name Function P06/D6 P05/D5 P04/D4 P114 P113 P112 P111 P110 P03/D3 P02/D2 P01/D1 P00/D0 P157 P156 P155 P154 P153 P152 P151 P150 +3.3V PAL/NTSC Detect PAL=Hi P107/AN7...
  • Page 104 RX-Z9/DSP-Z9 IC10 : HD6413008VF25 (1394 P.C.B.) 1394 CPU Name Description Function Connected to Power supply Power supply +3.3V I/O Port P80 Clock Gen. Control IN/OUT CY22381 (OE) + 10K Ω PD I/O Port P81 Unused IN/OUT Test Point I/O Port P82...
  • Page 114 R365...
  • Page 115 R727 R365...
  • Page 140 X-Decoder Y-Decoder...
  • Page 145: Parts List

    RX-Z9/DSP-Z9 PARTS LIST ■ ELECTRICAL PARTS ■ WARNING Components having special characteristics are marked Z and must be ● ● 印のある部分は、安全確保部品を示しています。部品の交換が必要な場合、 replaced with parts having specifications equal to those originally installed. パーツリストに記載されている部品を使用してください。 ● For the capacitor not found in the list, refer to the schematic diagram.
  • Page 146 RX-Z9/DSP-Z9 P.C.B. FUNCTION Ref. PART NO. Description Remarks Markets 部品名 Rank WB744500 P.C.B. FUNCTION PCBファンクション   WB744600 P.C.B. FUNCTION PCBファンクション   WB744700 P.C.B. FUNCTION RTKBG PCBファンクション   VB389800 CN.BS.PIN 2P ベースピン VB389900 CN.BS.PIN 3P ベースピン LB919030 CN.BS.PIN 3P ベース付ポスト UP652220 C.POL 220pF 100V ポリエステルコン...
  • Page 147 RX-Z9/DSP-Z9 P.C.B. FUNCTION Ref. PART NO. Description Remarks Markets 部品名 Rank * C195 V5690500 C.PP 100pF 100V PPコン         * C196 V5690500 C.PP 100pF 100V PPコン         C197-202 UU137470 C.EL 47uF ケミコン         C203 V9415400 C.EL 47uF ケミコン         C204 V9415400 C.EL 47uF ケミコン        ...
  • Page 148 RX-Z9/DSP-Z9 P.C.B. FUNCTION Ref. PART NO. Description Remarks Markets 部品名 Rank C471 UU167220 C.EL 22uF ケミコン         C472 UU167220 C.EL 22uF ケミコン         * C473 V5690500 C.PP 100pF 100V PPコン         * C474 V5690500 C.PP 100pF 100V PPコン         C491 UU167220 C.EL 22uF ケミコン        ...
  • Page 149 RX-Z9/DSP-Z9 P.C.B. FUNCTION & DSP1 Ref. PART NO. Description Remarks Markets 部品名 Rank V4806600 JACK.PIN ピンジャック       V4807000 JACK.PIN ピンジャック       V4807000 JACK.PIN ピンジャック       V4807100 JACK.PIN ピンジャック       V4807100 JACK.PIN ピンジャック       V4807000 JACK.PIN ピンジャック       PJ10 V4807100 JACK.PIN ピンジャック       PJ11 V4806600 JACK.PIN ピンジャック       PJ12 V8179900 JACK.PIN...
  • Page 150 RX-Z9/DSP-Z9 P.C.B. DSP1 Ref. PART NO. Description Remarks Markets 部品名 Rank VR169200 C.MYLAR.ML ECQ-V1H474JL3 積層マイラーコン     * C88 VE325800 C.POL.MLT 0.068uF 積層マイラーコン     UA653100 C.MYLAR 1000pF マイラーコン C119 UN837470 C.EL 47uF BPケミコン      01 * C198 WB758800 C.PP 1200pF 100V PPコン         * C199 V9415400 C.EL 47uF ケミコン      ...
  • Page 151 RX-Z9/DSP-Z9 P.C.B. DSP1 Ref. PART NO. Description Remarks Markets 部品名 Rank C265 UU167100 C.EL 10uF ケミコン         C266-69 UA652150 C.MYLAR 150pF マイラーコン       C270 UU167100 C.EL 10uF ケミコン         C271 UU137470 C.EL 47uF ケミコン         * C276 WB758900 C.PP 2700pF 100V PPコン         C279 UU167470 C.EL 47uF ケミコン        ...
  • Page 152 RX-Z9/DSP-Z9 P.C.B. DSP1 Ref. PART NO. Description Remarks Markets 部品名 Rank * C345 WB758900 C.PP 2700pF 100V PPコン         * C346 WB758800 C.PP 1200pF 100V PPコン         * C347 V5691400 C.PP 1500pF 100V PPコン         * C350 V5691400 C.PP 1500pF 100V PPコン         C351 UU167100 C.EL...
  • Page 153 RX-Z9/DSP-Z9 P.C.B. DSP1 Ref. PART NO. Description Remarks Markets 部品名 Rank C431 UU167100 C.EL 10uF ケミコン         C432 UU167100 C.EL 10uF ケミコン         * C433 V5691500 C.PP 2200pF 100V PPコン          * C438 WB758700 C.PP 820pF 100V PPコン         C439 UA653100 C.MYLAR 1000pF マイラーコン...
  • Page 154 RX-Z9/DSP-Z9 P.C.B. DSP1 Ref. PART NO. Description Remarks Markets 部品名 Rank IC10 XR038A00 IC NJM2904M OP AMP IC * IC11 X3721A00 IC 74VHCU04MTCX ロジックIC       IC12 X4150A00 IC 74VHCT00AMTCX ロジックIC       * IC13 X2709A00 IC SN74AHCT245PWR ロジックIC       IC14 X3566A00 IC LC89057W-VF4-E IC          ...
  • Page 155 RX-Z9/DSP-Z9 P.C.B. DSP1 Ref. PART NO. Description Remarks Markets 部品名 Rank IC66 X3505A00 IC NJM2068MD-TE2 IC * IC67 XV763A00 IC OP275GSR OP AMP アンプIC SOP    * IC68 X3447A00 IC CS5361-KS IC           * IC69 X3447A00 IC CS5361-KS IC           * IC70 X4537A00 IC PCM1792DBR D/Aコンバーター   ...
  • Page 156 RX-Z9/DSP-Z9 P.C.B. DSP2 & OPERATION Ref. PART NO. Description Remarks Markets 部品名 Rank WB746500 P.C.B. DSP(2) PCB DSP(2)   * CB1-3 WB188500 CN 22P TE コネクタープラグ     C323 WB715400 C.EL 10uF 100V ケミコン         * IC1 X4202A00 IC CY7C1041CV33-12ZCT メモリIC        X3567A00 IC YSS930-SZ IC          ...
  • Page 157 RX-Z9/DSP-Z9 P.C.B. OPERATION Ref. PART NO. Description Remarks Markets 部品名 Rank C972 UM407220 C.EL 22uF ケミコン D901 VU305200 DIODE.ZENR PTZ 7.5BTE25 7.5V ツェナーダイオード   01 D902 V2598200 LED SIR-505ST LED          D951 VT332900 DIODE 1SS355 ダイオード        D952 VT332900 DIODE 1SS355 ダイオード        D953 VU171900 DIODE.ZENR UDZ5.1B 5.1V...
  • Page 158 RX-Z9/DSP-Z9 P.C.B. VIDEO TOP Ref. PART NO. Description Remarks Markets 部品名 Rank WB747100 P.C.B. VIDEO TOP PCBビデオトップ    WB747200 P.C.B. VIDEO TOP PCBビデオトップ    WB747300 P.C.B. VIDEO TOP PCBビデオトップ    WB747400 P.C.B. VIDEO TOP PCBビデオトップ    WB747500 P.C.B. VIDEO TOP PCBビデオトップ    WB747600 P.C.B. VIDEO TOP PCBビデオトップ   ...
  • Page 159 RX-Z9/DSP-Z9 P.C.B. VIDEO TOP Ref. PART NO. Description Remarks Markets 部品名 Rank C653 UU137470 C.EL 47uF ケミコン         C657 UU137470 C.EL 47uF ケミコン         C663 UU137470 C.EL 47uF ケミコン         C664 UU137470 C.EL 47uF ケミコン         C665 UU137470 C.EL 47uF ケミコン         C670 UU137470 C.EL 47uF ケミコン        ...
  • Page 160 RX-Z9/DSP-Z9 P.C.B. VIDEO TOP Ref. PART NO. Description Remarks Markets 部品名 Rank IC82-86 X0428A00 IC OPA2652U OP AMP アンプIC        * IC87-102 X4344A00 IC NC7WB66K8X 2BIT ロジックIC       * IC103 XT163A00 IC TC74HC238AF ロジックIC       IC104 XY879A00 IC TC74HC4053AF(EL) ロジックIC SOP   IC105 XY879A00 IC TC74HC4053AF(EL) ロジックIC SOP  ...
  • Page 161 RX-Z9/DSP-Z9 P.C.B. VIDEO BOTTOM Ref. PART NO. Description Remarks Markets 部品名 Rank WB746600 P.C.B. VIDEO BOTTOM PCBビデオボトム    WB746700 P.C.B. VIDEO BOTTOM PCBビデオボトム    WB746800 P.C.B. VIDEO BOTTOM PCBビデオボトム    WB746900 P.C.B. VIDEO BOTTOM TABG PCBビデオボトム    VQ048000 CN.BS.PIN 31P FFCコネクター     VQ045100 CN.BS.PIN 21P FFCコネクター...
  • Page 162 RX-Z9/DSP-Z9 P.C.B. VIDEO BOTTOM Ref. PART NO. Description Remarks Markets 部品名 Rank C231 UU137470 C.EL 47uF ケミコン         C236 UU137470 C.EL 47uF ケミコン         C241 UU137470 C.EL 47uF ケミコン         C251 UU137470 C.EL 47uF ケミコン         C263 UU137470 C.EL 47uF ケミコン         C264 UU137470 C.EL 47uF ケミコン        ...
  • Page 163 RX-Z9/DSP-Z9 P.C.B. VIDEO BOTTOM Ref. PART NO. Description Remarks Markets 部品名 Rank IC19 X3402A00 IC PQ033EZ01ZP 3.3V 電源IC         * IC20 X3010A00 IC SM5301AS-G-ET IC           * IC21 X3010A00 IC SM5301AS-G-ET IC           * IC22 X3711A00 IC XV750BQ1-01 IC           * IC23 X2484A00 IC TA1318AF IC          ...
  • Page 164 RX-Z9/DSP-Z9 P.C.B. SUB TRANS Ref. PART NO. Description Remarks Markets 部品名 Rank WB744800 P.C.B. SUB TRANS PCB サブトランス   WB744900 P.C.B. SUB TRANS PCB サブトランス   WB745000 P.C.B. SUB TRANS PCB サブトランス   WB745100 P.C.B. SUB TRANS PCB サブトランス   WB745200 P.C.B. SUB TRANS PCB サブトランス   WB745300 P.C.B. SUB TRANS PCB サブトランス  ...
  • Page 165 RX-Z9/DSP-Z9 P.C.B. SUB TRANS Ref. PART NO. Description Remarks Markets 部品名 Rank D856 iF004600 DIODE 1SS133 ダイオード       01 D857 iF004600 DIODE 1SS133 ダイオード       01 D876-79 iF004600 DIODE 1SS133 ダイオード       01 D880 VU647200 DIODE.SHOT RB441Q-40 T-77 ショットキーダイオード  D881 iF004600 DIODE 1SS133 ダイオード       01 D882 iF004600 DIODE 1SS133 ダイオード       01...
  • Page 166 RX-Z9/DSP-Z9 P.C.B. SUB TRANS & MAIN (L) Ref. PART NO. Description Remarks Markets 部品名 Rank * TE852 WB753800 TERM.SP LTS0415-3005F スピーカターミナル    * TE876 WB406700 TERM.SP LTS0415-3004F JUCRTA スピーカターミナル    * TE876 WB753800 TERM.SP LTS0415-3005F スピーカターミナル    * TE877 WB406900 TERM.SP LTS0815-3005F JUCRTA スピーカターミナル   ...
  • Page 167 RX-Z9/DSP-Z9 P.C.B. MAIN (L) Ref. PART NO. Description Remarks Markets 部品名 Rank * C340 V5691300 C.PP 1000pF 100V PPコン         * C341 V5691300 C.PP 1000pF 100V PPコン         C342 VE326200 C.MYLAR.ML 0.15uF 積層マイラーコン     C343 VE324800 C.MYLAR.ML 0.01uF 積層マイラーコン     C344 Vi862100 C.POL.MTL 0.047uF 100V メタライズドポリコン  01...
  • Page 168 RX-Z9/DSP-Z9 P.C.B. MAIN (L) Ref. PART NO. Description Remarks Markets 部品名 Rank * C475 V5692000 C.PP 0.01uF 100V PPコン         * C476 V5692000 C.PP 0.01uF 100V PPコン         C477 UU197100 C.EL 10uF 100V ケミコン         C478 UU197100 C.EL 10uF 100V ケミコン         D301-04 VG438000 DIODE.ZENR MTZJ6.2B 6.2V ツェナーダイオード   01...
  • Page 169 RX-Z9/DSP-Z9 P.C.B. MAIN (L) Ref. PART NO. Description Remarks Markets 部品名 Rank Q326 iA097030 TR 2SA970 GR,BL トランジスタ      01 Q327 iC224030 TR 2SC2240 GR,BL トランジスタ      01 Q328 iA097030 TR 2SA970 GR,BL トランジスタ      01 Q329 VE198700 TR 2SA1145 O,Y トランジスタ      01 Q330 VE198700 TR 2SA1145 O,Y トランジスタ      01...
  • Page 170 RX-Z9/DSP-Z9 P.C.B. MAIN (L) Ref. PART NO. Description Remarks Markets 部品名 Rank Q449 VP872700 TR 2SC4488 S,T トランジスタ       Q450 VP872600 TR 2SA1708 S,T トランジスタ       * Q451A iX609750 TR 2SA1492 O,Y トランジスタ       Q451C iX609760 2SC3856 O,Y トランジスタ       * Q453A iX609750 TR 2SA1492 O,Y トランジスタ      ...
  • Page 171 RX-Z9/DSP-Z9 P.C.B. MAIN (L) Ref. PART NO. Description Remarks Markets 部品名 Rank R404 HV753470 R.CAR.FP 4.7Ω 1/4W 不燃化カーボン抵抗   01 R405 HL214100 R.MTL.OXD 10Ω 酸化金属被膜抵抗    01 R406 HV753470 R.CAR.FP 4.7Ω 1/4W 不燃化カーボン抵抗   01 R407 HV753470 R.CAR.FP 4.7Ω 1/4W 不燃化カーボン抵抗   01 * R409-12 VR150200 R.WW 0.22Ω...
  • Page 172 RX-Z9/DSP-Z9 P.C.B. MAIN (L) & MAIN (R) Ref. PART NO. Description Remarks Markets 部品名 Rank * VR421 WB756200 VR.TRIM B330Ω RH063LCN2R 半固定VR        * VR422 WB756300 VR.TRIM B680Ω RH063LCW2R 半固定VR        * VR423 WB756300 VR.TRIM B680Ω RH063LCW2R 半固定VR        WB745800 P.C.B. MAIN(R) PCB メイン(R)  ...
  • Page 173 RX-Z9/DSP-Z9 P.C.B. MAIN (R) Ref. PART NO. Description Remarks Markets 部品名 Rank * C661 WB759300 C.PP 100pF 200V PPコン         C662 UU167100 C.EL 10uF ケミコン         * C663 WB759300 C.PP 100pF 200V PPコン         C664 UU197470 C.EL 47uF 100V ケミコン         C665 UU197470 C.EL...
  • Page 174 RX-Z9/DSP-Z9 P.C.B. MAIN (R) Ref. PART NO. Description Remarks Markets 部品名 Rank D671 VC398400 DIODE MA185 ダイオード       01 D672 VC398400 DIODE MA185 ダイオード       01 D673-76 VG438000 DIODE.ZENR MTZJ6.2B 6.2V ツェナーダイオード   01 D683 VC398400 DIODE MA185 ダイオード       01 D684 VC398400 DIODE MA185 ダイオード       01 D685 VG442900 DIODE.ZENR MTZJ27B ツェナーダイオード   01...
  • Page 175 RX-Z9/DSP-Z9 P.C.B. MAIN (R) Ref. PART NO. Description Remarks Markets 部品名 Rank Q339C iX609760 2SC3856 O,Y トランジスタ       Q340 iC224030 TR 2SC2240 GR,BL トランジスタ      01 Q601 iE104500 FET 2SK389 GR,BL FET         03 * Q602 WB519700 FET 2SJ109 GR,BL FET          Q621 iE104500 FET 2SK389 GR,BL FET         03...
  • Page 176 RX-Z9/DSP-Z9 P.C.B. MAIN (R) Ref. PART NO. Description Remarks Markets 部品名 Rank R314 VP941900 R.MTL.OXD 15KΩ 酸化金属皮膜抵抗    01 R323 HV755120 R.CAR.FP 120Ω 1/4W 不燃化カーボン抵抗   01 R324 HV756330 R.CAR.FP 3.3KΩ 1/4W 不燃化カーボン抵抗   01 R325 HV755560 R.CAR.FP 560Ω 1/4W 不燃化カーボン抵抗   01 R326 HV755120 R.CAR.FP 120Ω...
  • Page 177 RX-Z9/DSP-Z9 P.C.B. MAIN (R) & POWER Ref. PART NO. Description Remarks Markets 部品名 Rank R688 HV754470 R.CAR.FP 47Ω 1/4W 不燃化カーボン抵抗   01 R689 HV756120 R.CAR.FP 1.2KΩ 1/4W 不燃化カーボン抵抗   01 R690 HV755100 R.CAR.FP 100Ω 1/4W 不燃化カーボン抵抗   01 R691 HV755100 R.CAR.FP 100Ω 1/4W 不燃化カーボン抵抗   01 R692 HV755330 R.CAR.FP 330Ω...
  • Page 178 RX-Z9/DSP-Z9 P.C.B. POWER Ref. PART NO. Description Remarks Markets 部品名 Rank CB752 VP206500 HOLDER.FUS EYF-52BCT ヒューズホルダー CB902 VD004500 CN.BS.PIN 2P ベースピン CB903 VD004600 CN.BS.PIN 3P ベースピン CB904 VD004600 CN.BS.PIN 3P ベースピン CB905 VD005000 CN.BS.PIN 7P ベースピン C701 UU167100 C.EL 10uF ケミコン        ...
  • Page 179 RX-Z9/DSP-Z9 P.C.B. POWER Ref. PART NO. Description Remarks Markets 部品名 Rank C952 VJ599100 C.CE.TUBLR 0.1uF 円筒セラコン C954 UU137470 C.EL 47uF ケミコン         C956 UU149100 C.EL 1000uF ケミコン         C957 UU137470 C.EL 47uF ケミコン         C958 UU166100 C.EL ケミコン         C959 VJ599100 C.CE.TUBLR 0.1uF 円筒セラコン...
  • Page 180 RX-Z9/DSP-Z9 P.C.B. POWER & 1394 Ref. PART NO. Description Remarks Markets 部品名 Rank BB070700 GND.MTL アース金具 EG330360 SCR.BND.HD 3x6 MFZN2BL バインド小ネジ     01 WB875500 P.C.B. 1394 PCB 1394     * CB1 WB677000 CN 4P SE IEEE1394 I/Oコネクター     * CB2 WB677000 CN 4P SE IEEE1394 I/Oコネクター    ...
  • Page 181 RX-Z9/DSP-Z9 CHIP CAPACITORS Ref. PART NO. Description Remarks Markets 部品名 Rank UF017220 C.EL.CHP 22uF 6.3V チップケミコン     01 UF017470 C.EL.CHP 47uF 6.3V チップケミコン      UF018100 C.EL.CHP 100uF 6.3V チップケミコン     01 UF427330 C.EL.CHP 33uF チップケミコン      UF428100 C.EL.CHP 100uF チップケミコン      UF437100 C.EL.CHP 10uF チップケミコン      UF437470 C.EL.CHP 47uF チップケミコン     ...
  • Page 182 RX-Z9/DSP-Z9 CHIP RESISTORS Ref. PART NO. Description Remarks Markets 部品名 Rank RD253220 R.CHP 2.2Ω 1/10W チップ抵抗       01 RD254100 R.CHP 10Ω 1/10W チップ抵抗       01 RD254470 R.CHP 47Ω 1/10W チップ抵抗       01 RD350000 R.CHP 0Ω 1/16W チップ抵抗       01 RD353220 R.CHP 2.2Ω 1/16W チップ抵抗        RD353470 R.CHP 4.7Ω 1/16W チップ抵抗       01...

This manual is also suitable for:

Rx-z9

Table of Contents
