Summary of Contents for PrefecTron PER6760A
- Page 1 Fanless Rugged System Version 1.1 Revision Date: Aug. 21, 2017 User’s Manual PER6760A Perfect Box, Fanless Rugged System User’s Manual www.perfectron.com...
-
Page 2: Safety Information
PER6760A User’s Manual V1.1 Safety information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. -
Page 3: Revision History
PER6760A User’s Manual V1.1 Revision History Revision Date (yyyy.mm.dd) Changes Version 1.0 2015.03.26 Initial release Version 1.1 2017.08.21 Power type updated Photo updated Packing list □ PER6760B-DP Fanless system □ CD (Driver + user's manual) □ Terminal block 3 PIN x 1pcs □... -
Page 4: Table Of Contents
PER6760A User’s Manual V1.1 Table Contents SAFETY INFORMATION ................................1 ....................................1 LECTRICAL SAFETY ....................................1 PERATION SAFETY STATEMENT ....................................1 REVISION HISTORY ..................................2 PACKING LIST ....................................2 OPTIONAL ITEMS ..................................2 ORDERING INFORMATION ................................2 TABLE CONTENTS ..................................3 CHAPTER 1: PRODUCT INFORMATION ............................ - Page 5 PER6760A User’s Manual V1.1 3.5 C ...................................... 29 HIPSET 3.5.1 PCH-IO Configuration ..............................30 3.5.1.1 USB Configuration ..................................31 3.5.1.2 PCH Azalia Configuration ................................32 3.5.2 System Agent (SA) Configuration ............................. 33 3.5.2.1 Graphics Configuration ................................. 34 3.5.2.2 Memory Configuration ................................. 35 3.6 B...
-
Page 6: Chapter 1: Product Information
PER6760A User’s Manual V1.1 Chapter 1: Product Information 1.1 Key Features Processor & System CPU Type Intel® 22nm Ivy Bridge Processor (Mobile) socket (rPGA988) Core™ i7-3610QE 2.3 GHz (6M Cache, 45W) Core™ i5-3610ME 2.7 GHz (3M Cache, 35W) Core™ i3-3120ME 2.4 GHz (3M Cache, 35W) Chipset Intel®... -
Page 7: Front Panel Components
PER6760A User’s Manual V1.1 1.2 Front Panel Components 1.3 Back Panel Components www.perfectron.com... -
Page 8: Mechanical Drawing
PER6760A User’s Manual V1.1 1.4 Mechanical Drawing www.perfectron.com... -
Page 9: Chapter 2: Connectors Definition
PER6760A User’s Manual V1.1 Chapter 2: Connectors definition Power Input: DC-in +9V~+24V PIN DEFINITION +9V~+24V USB Port: USB2.0 PIN DEFINITION PIN DEFINITION USBD- USBD- USBD+ USBD+ COM2~COM3: RS232 with +12V/+5V selection PIN DEFINITION PIN DEFINITION DCD- DTR- DSR- RTS- CTS-... -
Page 10: Com5: Rs232/422/485
PER6760A User’s Manual V1.1 COM5: RS232/422/485 PIN RS-232 RS-422 HALF DUPLEX RS-485 DCD- DATA- DATA+ DTR- DSR- RTS- CTS- VGA: VGA PIN DEFINITION PIN DEFINITION GREEN BLUE DDC DATA HSYNC VSYNC DDC CLOCK DVI-D: DVI-D PIN DEFINITION PIN DEFINITION TMDS2-... -
Page 11: Com1: Rs232/422/485 With +12V/+5V Selection
PER6760A User’s Manual V1.1 COM1: RS232/422/485 with +12V/+5V selection PIN RS-232 RS-422 HALF DUPLEX RS-485 DCD- DATA- DATA+ DTR- DSR- RTS- CTS- COM1P9SEL COM1P9SEL COM1P9SEL (Define by JP5) (Define by JP5) (Define by JP5) HDMI: HDMI PIN DEFINITION PIN DEFINITION... -
Page 12: Lan1_Usb12: Usb3.0 Port 0,1 And Lan Connector 1
PER6760A User’s Manual V1.1 LAN1_USB12: USB3.0 port 0,1 and LAN connector 1 LAN2_USB34: USB3.0 port 3,4 and LAN connector 2 UPPER USB LOWER USB PIN DEFINITION PIN DEFINITION PIN DEFINITION +5VDUAL +5VDUAL StdA_SSTX- StdA_SSTX- StdA_SSTX+ StdA_SSTX+ GND_DRIAN 7 GND_DRIAN 7... -
Page 13: Display Port
PER6760A User’s Manual V1.1 Display Port Pin Definition ML _L ane 0 (p) G ND ML _L ane 0 (n) ML _L ane 1 (p) G ND ML _L ane 1 (n) ML _L ane 2 (p) G ND ML _L ane 2 (n) -
Page 14: Chapter 3: Ami Bios Utility
PER6760A User’s Manual V1.1 Chapter 3: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. 3.1 Starting To enter the setup screens, perform the following steps: ... -
Page 15: Main Menu
PER6760A User’s Manual V1.1 3.3 Main Menu The Main menu is the first screen that you will see when you enter the BIOS Setup Utility. System Language Use this function to select the system language. www.perfectron.com... -
Page 16: Advanced Menu
PER6760A User’s Manual V1.1 System Date Use this function to change the system date. Select System Date using the Up and Down <Arrow> keys. Enter the new values through the keyboard. Press the Left and Right <Arrow> keys to move between fields. -
Page 17: Acpi Settings
PER6760A User’s Manual V1.1 3.4.1 ACPI Settings System ACPI parameters Enable ACPI Auto Configuration Enables or disables BIOS ACPI auto configuration. Enable Hibernation Enables or disables system ability to hibernate (OS/S4 Sleep State). This option may not be effective with some OS. -
Page 18: Cpu Configuration
PER6760A User’s Manual V1.1 3.4.2 CPU Configuration This section is used to configure the CPU. www.perfectron.com... - Page 19 PER6760A User’s Manual V1.1 Hyper-threading Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology). When disabled only one thread per enabled core is enabled. Active Processor Cores Number of cores to enable in each processor package.
-
Page 20: Sata Configuration
PER6760A User’s Manual V1.1 3.4.3 SATA Configuration This section is used to configure the SATA drives. SATA Controller(s) Enable or disable SATA device. SATA Mode Selection Determines how SATA controller(s) operate. SATA Test Selection Enable or disable Test Mode IDE Legacy/Native Mode Selection IDE Legacy/Native Mode Selection Serial ATA Port 0 –... -
Page 21: Thermal Configuration
PER6760A User’s Manual V1.1 3.4.4 Thermal Configuration Platform thermal configuration options 3.4.4.1 Platform thermal configuration www.perfectron.com... -
Page 22: Intel Rapid Start Technology
PER6760A User’s Manual V1.1 3.4.5 Intel Rapid Start Technology 3.4.6 Intel TXT(LT) Configuration Intel Trusted Execution Technology Intel TXT(LT) Support Enables or disables Intel TXT(LT) support www.perfectron.com... -
Page 23: Pch-Fw Configuration
PER6760A User’s Manual V1.1 3.4.7 PCH-FW Configuration This section is used to configure Management Engine Technology parameters. 3.4.8 Intel Anti-Theft Technology Configuration Disabling Intel AT allow user to login platform. This is strictly for testing only. This does not disable Intel AT services in ME www.perfectron.com... -
Page 24: Amt Configuration
PER6760A User’s Manual V1.1 Intel Anti-Theft Technology Enable or Disable Intel AT in BIOS for testing only Intel Anti-Theft Technology Rec Set the number of times Recovery attemped will be allowed. 3.4.9 AMT Configuration This section is used to configure Active Management Technology (AMT) options. - Page 25 PER6760A User’s Manual V1.1 Amt Wait Timer Set timer to wait before sending ASF_GET_BOOT_OPTIONS. Disable ME Set ME to Soft Temporary Disabled Enable/Disable Alert specification Format Activate Remote Assistance Process Trigger CIRA boot. USB Confirgure Enable/Disable USB configure function. PET Progress User can Enable/Disable PET Events progress to receive PET events or not.
-
Page 26: Usb Configuration
PER6760A User’s Manual V1.1 3.4.10 USB Configuration This section is used to configure the USB Legacy USB Support Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. -
Page 27: F81866 Super Io Configuration
PER6760A User’s Manual V1.1 USB Transfer time-out The time-out value for Control, Bulk, and Interrupt transfers. Device reset time-out USB mass Storage device start Unit command time-out. Device power-up delay Maximum time the device will take before it properly reports itself to the Host Controller. ‘Auto’ uses default value: for a Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor. -
Page 28: F81866 H/W Monitor
PER6760A User’s Manual V1.1 3.4.12 F81866 H/W Monitor This section is used to monitor hardware status such as temperature, fan speed and voltages. System Temperature Detects and displays the current system temperature. CPU Temperature Detects and displays the current CPU temperature. -
Page 29: Serial Port Console Redirection
PER6760A User’s Manual V1.1 3.4.13 Serial Port Console Redirection This screen provides information about functions for specifying the Serial Port Console Redirection configuration settings. Console redirection can be used to remotely operate system settings and the EFI console. Console Redirection Console Redirection Enable or Disable. -
Page 30: Cpu Ppm Configuration
PER6760A User’s Manual V1.1 3.4.14 CPU PPM Configuration CPU PPM configuration parameters EIST Enables or disables Intel SpeedStep. CPU C3 Report Enable or disable CPU C3 (ACPI C2) report to OS. Config TDP LOCK Lock the Config TDP control register Long duration power limit Long duration power limit in Watts, 0 means use factory default. -
Page 31: Pch-Io Configuration
PER6760A User’s Manual V1.1 3.5.1 PCH-IO Configuration This section allows you to configure the North Bridge Chipset. USB Configuration USB configuration settings PCH Azalia Configuration PCH Azalia configuration settings PCH LAN Controller Enable or disable onboard NIC. www.perfectron.com... -
Page 32: Usb Configuration
PER6760A User’s Manual V1.1 Wake on LAN Enable or disable integrated LAN to wake the system. (The Wake On LAN cannot be disabled if ME is on at Sx state.) PCIE LAN Controller Enable or disable onboard PCIE LAN Wireless LAN Controller Enable or disable onboard MPCIE LAN-Wireless LAN. -
Page 33: Pch Azalia Configuration
PER6760A User’s Manual V1.1 Allows for HS port switching between xHCI and EHCI. If disabled, port is routed to EHCI. If HS port is routed to xHCI, the corresponding SS port is enabled. xHCI Streams Enable or disable xHCI Maximum Primary Stream Array Size. -
Page 34: System Agent (Sa) Configuration
PER6760A User’s Manual V1.1 3.5.2 System Agent (SA) Configuration This section is used to configure the System Agent (SA) configuration. VT-d Check to enable VT-d function on MCH. Enable NB CRID Enable or disable NB CRID WorkAround. C-State Pre-Wake Controls C-State Pre-Wake feature for ARAT, in SSKPD*57+. -
Page 35: Graphics Configuration
PER6760A User’s Manual V1.1 3.5.2.1 Graphics Configuration Primary Display Select which of IGFX/PEG/PCI graphics device should be primary display or select SG for switchable Gfx. Internal Graphics Keep IGD enabled based on the setup options. DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) graphics memory size used by the internal graphics device. -
Page 36: Memory Configuration
PER6760A User’s Manual V1.1 3.5.2.2 Memory Configuration www.perfectron.com... -
Page 37: Boot Setting
PER6760A User’s Manual V1.1 3.6 Boot Setting This section is used to configure the boot features. Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock State Select the keyboard NumLock state. -
Page 38: Security
PER6760A User’s Manual V1.1 3.7 Security Use the Security Menu to establish system passwords Administrator Password Set administrator password. User Password Set User Password. Secure Boot Secure boot flow control. Secure boot is possible only if system runs in user mode. -
Page 39: Save And Exit
PER6760A User’s Manual V1.1 3.8 Save and exit This screen provides functions for handling changes made to the BIOS settings and the exiting of the Setup program. Save Changes and Exit Exit system setup after saving the changes. Restore Defaults Restore or Load Defaults values for all the setup options.
