  • Page 1 Quick Start Guide *****************...

  • Page 2: Safety And Use

    Safety and use__________________________________________________________ We recommend that you read this chapter carefully before using this device. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use of this device or of use contrary to the instructions contained herein. Do not switch on your device when its use is prohibited or when using the device may cause interference or danger.
  • Page 3 Do not place your device or its accessories in containers with a strong electromagnetic field. Do not place magnetic storage media near your device. Radiation from the device may erase the information stored on them. Do not subject your device to high temperatures or use it in a place with flammable gas such as a petrol station. Keep your device and its accessories away from children.
  • Page 4 ____________________________________________________ Overview ALCATEL ONE TOUCH LINK Y850 is a portable wireless router, providing a simple way to share 4G with any Wi-Fi embedded device. 1.1 Package contents ● ● USB cable ● Quick start guide ONE TOUCH Y850 ● USB Wall charger ●...
  • Page 5 1.2 Application...

  • Page 6: Device Overview

    Device overview ④ ⑥ ① ③ ② ⑤ ⑦ Number Description ① Power on/off Key ② WPS Key ③ Reboot Button ④ Charging Pin* ⑤ SIM Card Cover ⑥ OLED screen ⑦ Micro USB Interface Note: *depending on your region and market...
  • Page 7 Use the device’s 3 buttons as follows: Button Description Long press to turn on/off the device ① Power On/Off Short press to put the OLED screen in either active or sleep mode. Long press to turn on WPS ②WPS Short press to display SSID and password Long press to reboot the device if the system freezes.
  • Page 8 1.4 Turning on the device Step 1: Push down on the SIM Card cover and install your SIM card as indicated on the device. Step 2: Press the Power On/Off button...

  • Page 9: Screen Display

    1.5 Screen display The screen display is interpreted as follows: Network Signal (dynamic graphic symbol ) Network type (4G/H+/3G/2G) SMS status (full, unread, incoming) Connection status(connected and disconnected ) Wi-Fi (number of user connected/WPS connection) Battery level (dynamic graphic symbol when charging) Name of the network registered Screen description:...
  • Page 10 Category Icon Display Signal Strength From 1 bar to excellent signal strength Network type : EDGE/GPRS : UMTS/HSDPA/HSUPA,H+: HSPA+,4G:LTE : SMS is available SMS status : Unread SMS : SMS full Connection Status connected...
  • Page 11 : Wi-Fi is active : Number of Wi-Fi users Wi-Fi status : WPS is active : WPS connected successfully : WPS connection failed : From 1 level to level 4 Battery : Low power Note: the information is displayed for 20 seconds, then the display powers off. You can reactivate the display with a short press on the Power key.
  • Page 12 Step 1: Use the Wi-Fi manager on the Wi-Fi embedded device to select network name (SSID). ◆From a Windows PC: Right-click Wireless network connection on the task bar, and select: View Available Networks. Choose SSID from the list of available networks. ◆From a Mac computer: Select System Preferences ->...

  • Page 13: Quick Setup

    2. Quick Setup___________________________________________________________ Open your browser, and input the address http://192.168.1.1 to access the login page. Default login password: admin Login and click "Quick Setup" to configure the basic settings. Admin Password:  Login Password: Set the password for login. Wi-Fi Settings: ...

  • Page 14: Charging The Device

    3. Charging the device_____________________________________________________ You have many ways to charge your device - the magnetic attraction of the device ensures that the ALCATEL ONETOUCH LINK Y850 maintains close contact with your Wall Charger/Cradle Adapter Wall Charger charging: Magnetic Charging Pin USB charging port Option1: Plug Wall Charger into power socket and put the ALCATEL ONETOUCH LINK Y850 on wall charger.
  • Page 15 When the device is powered off, charging will take a maximum of 4 hours. Cradle charging Connect the USB cable with the Cradle and put the ALCATEL ONETOUCH LINK Y850 on the Cradle. Lightly rotate the device to ensure it is securely located in the slot. Charging will then begin.
  • Page 16 Car charging Assemble Car Charger and Adapter as below, and plug into the cigarette lighter port of the Car. Place the ALCATEL ONETOUCH LINK Y850 on the Adapter and lightly rotate the device to ensure it is securely located in the slot. Charging will then begin.
  • Page 17 4. Certification___________________________________________________________ WEEE Approval This device is in compliance with the essential requirements and other relevant provisions of the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE Directive). RoHs Approval This device is in compliance with the restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2002/95/EC (RoHs Directive).
  • Page 18 FCC Regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 19 -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment.
  • Page 20 During SAR testing, this device is set to transmit at its highest certified power level in all tested frequency bands, and placed in positions that simulate RF exposure in usage near the body with the separation of 5 mm. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value.
  • Page 21 For more information you can go to Alcatel is a trademark of Alcatel-Lucent used under license by TCT Mobile Limited. All rights reserved © 2010-2012 TCT Mobile Limited. Address: Room 1910-12A, Tower 3, China HK City, 33 Canton Road, Tsimshatsui, Kowloon, Hong Kong...
