DR. BENDER

Innovative Elektrowerkzeuge

Manual for

Powerbox

Valid from 02.2006

DR. BENDER

Our website address is: http://www.dr-bender.de

GmbH

PB WX2

PB WX8-10

PB WX8-10 VB

GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91

PB WX2

PB WX8-10

PB WX8-10 VB

Art.-No. 101152

Art.-No. 100260

Art.-No. 101290

• e-mail:

Subject to alterations

info@dr-bender.de

230 V

400 V

Table of Contents

Need help?

Do you have a question about the PB WX2 and is the answer not in the manual?

Questions and answers

Summary of Contents for DR. BENDER PB WX2

Page 1 DR. BENDER GmbH Innovative Elektrowerkzeuge Manual for Powerbox 230 V PB WX2 400 V PB WX8-10 400 V PB WX8-10 VB Valid from 02.2006 PB WX2 Art.-No. 101152 Subject to alterations PB WX8-10 Art.-No. 100260 PB WX8-10 VB Art.-No. 101290 All rights reserved DR.
Page 2: Conformity Declaration
GmbH Innovative Elektrowerkzeuge EC Conformity Declaration for the following DR.BENDER stone processing machines PB WX2 PB WX8/10 PB WX8/10 VB DR.BENDER GmbH, as manufacturer, hereby declares that the electrical stone drilling machines mentioned above comply with the requirements of the following guidelines:...
Page 3: Table Of Contents
Application Safety Transport and storage Transport Storage Main dimensions and technical data Dimensions 4.1.1 PB WX2 Powerbox 4.1.2 PB WX8/10 and PB WX8/10 VB Powerbox Technical Data 4.2.1 PB WX2 Powerbox 4.2.2 PB WX8/10 and PB WX8/10 VB Powerbox Operating temperatures...
Page 4: Symbol- And Pictograph Description
You have no warranty if the machine breaks down because you not looking about this. Function description Handle Motor controller 230 V mains connection PB WX2: On-button HF- connecting sleeve 3.5 kW Off-button Cooling fins Emergency stop...
Page 5: General Instructions
The machine must be PB WX2: directly connected to 230 V mains using a personal safety switch (PRCD); PB WX8/10 und PB WX8/10 VB: connected to a duly grounded EEC socket (EEC 5 poles, 3P+PE 32A 6h – 400V). No zero conductor is required;...
Page 6: 2.3. Safety
2.3. Safety Warning Before using the machine for the first time, check the conformity of the data on the model plate with the mains voltage and frequency. Voltage deviations of ± 5 % and/or voltage deviations of ± 2 % are permissible. Repairs may be carried out only by adequately qualified persons, based on their training and experience.
Page 7: Main Dimensions And Technical Data
Main dimensions and technical data Dimensions 4.1.1 Powerbox PB WX2 4.1.2 Powerbox PB WX8/10 and PB WX8/10 VB Technical data 4.2.1 Powerbox PB WX2 Rated voltage Current consumption Power requirement 3,500 Frequency 50 – 60 Protection class IP 67 Cooling medium...
Page 8: Pb Wx8/10 And Pb Wx8/10 Vb Powerbox
In case of sufficient cooling of the system, the PB WX8/10 Powerbox takes on the cooling water temperature. The casing of the PB WX2 may take on temperatures of up to 80°C. You should not worry about this, as it is normal. That is why you should hold the PB WX2 Powerbox by the handles.
Page 9: Water Connection - Pb Wx8/10 And Pb Wx8/10 Vb Powerbox
The PB WX2 Powerbox is air-cooled and consequently requires no water connection. Powerbox operation Set the motor controller on the Powerbox to the desired speed.
Page 10: Automatic Overload Cut-Off
(PB WX8/10, below 340V),(PB WX2, below 200V), in case of uneven mains voltage (phase dissymmetry) or interruption of a phase (phase failure), for adjusting or fitting an accessory.
Page 11: Maintenance And Care
Maintenance and care Warning Pull out the mains plug before beginning any maintenance or repair work. You must have the tool checked by a specialized electrician after every repair (statutory regulation pursuant to VBG4 since 1.1.1990). Daily care Make sure no water flows out of the tool. This may adversely affect the electrical safety of the equipment. In this case, please seek assistance from an authorized service workshop.
Page 12: General Safety Instructions
General safety instructions Read and follow these instructions before you use the tool. Keep these safety instructions in a safe place. Keep your workplace tidy. Untidiness in the workplace can cause accidents. Protect yourself from electric shocks. Observe the applicable regulations. Avoid physical contact with earthed parts, such as pipes, heaters, furnaces and refrigerators.
Page 13 Earth” Professional Association must be satisfied. 25. Electrical safety and fire safety: just as DR. BENDER did in the last 20 years, the new version of VDE 0100 also recommends the additional safety protection and fire protection of each tool achieved by...
Page 14: 10.0 Spare Parts Lists
10.0 Spare parts lists 10.1 Powerbox PB WX2...
Page 15 Article number Description Pcs. 101152 Control - Box 101150 Casing – rear part 801774 Gasket 1 ** 401197 Sleeve 801712 Frequency changer, compl. 800076 Lock washer 900339 Allen screw 801397 Distance clip 801872 EMC-Filter 801749 EMC-Filter 802014 1 ** 801773 Protection grid 900702 Fillister screw...
Page 16: Pb Wx8/10 Powerbox
10.2 Powerbox PB WX8/10...
Page 17 Pos. Article number Description Pcs. 100260 Control - Box 100679 Casing - rear part 801774 Gasket 2 ** 200755 Cooling element 801772 Gasket 1 ** 801450 O-Ring 2 ** 800076 Lock washer 901092 Allen screw 901093 Allen screw 801909 Grounding cable complete 900412 Slotted pan head screw 101149...
Page 18: Pb Wx8/10 Vb Powerbox
10.3 Powerbox PB WX8/10 VB...
Page 19 Pos. Article number Description Pcs. 101290 Control - Box 100679 Casing - rear part 801774 Gasket 2 ** 200755 Cooling element 801772 Gasket 1 ** 800076 Lock washer 901092 Allen screw 901093 Allen screw 801909 Grounding cable complete 900412 Slotted pan head screw 101765 Intermediate plate 802071...
