advanio Wolf Series RS-485 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wolf series Remote IO Modules
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wolf Series RS-485 and is the answer not in the manual?

Questions and answers

Summary of Contents for advanio Wolf Series RS-485

  • Page 1 Wolf series Remote IO Modules User’s Manual...
  • Page 2 Advanio certified service technician, Advanio reserve the right to determine the warranty liabilities. Any kind of damage caused by human factors, improper installation and misuse, Advanio shall in no event be liable for any consequential and accidental damages whether by negligence specified above or otherwise.
  • Page 3 Wolf Series RS-485 Remote I/O Module Dear Customer, Please fill out this form (blue color sections) and email it to our sales representative for confirmation within 3 days while we process your request referring to the information stated on this RMA Request Form.
  • Page 4 Wolf Series RS-485 Remote I/O Module Certification Claims Technology Wolf Series Product is developed and tested by Advanio, all tests certified by EMC including EMI and EMS are designed for module protection. Hence, we strongly recommend pairing Wolf series modules with industrial chassis certified by CE.

  • Page 5: Table Of Contents

    Wolf Series RS-485 Remote I/O Module Table of Contents Chapter 1. Introduction ....................1 1.1 Product Overview .................... 1 1.2 System Specification ..................2 1.3 Set Up and Use....................2 1.4 Watchdog ......................3 1.5 Power Requirements ..................4 1.6 RS-485 Network Connections ................. 5 1.7 Environmental Safety..................
  • Page 6 Wolf Series RS-485 Remote I/O Module 3.3.1 Terminal Assignment ................33 3.3.2 Block Diagram ..................34 3.3.3 Channel Connecting ................36 3.3.4 IO Specifications .................. 36 3.3.5 Related Reference ................37 3.3.6 MODBUS Address ................41 3.4 W-M1B105/106 8/16 Channel Universal Analog Input Module....46 3.4.1 Terminal Assignment ................
  • Page 7 Wolf Series RS-485 Remote I/O Module 3.8.4 IO Specifications ................. 82 3.8.5 Related Reference ................83 3.8.6 MODBUS Address ................86 Chapter 4. Digital Module Information ................ 89 4.1 W-M1B301 16-Channel Digital Input MOdule ..........89 4.1.1 Terminal Assignment ................89 4.1.2 Block Diagram ..................
  • Page 8 Wolf Series RS-485 Remote I/O Module 4.5.6 MODBUS Address ................119 4.6 W-M1B404 16-Channel Relay Output Module ..........121 4.6.1 Terminal Assignment ................. 121 4.6.2 Block Diagram ................... 122 4.6.3 Channel Connecting ................123 4.6.4 IO Specifications ................123 4.6.5 Related Reference ................123 4.6.6 MODBUS Address ................

  • Page 9: Chapter 1. Introduction

    Wolf Series RS-485 Remote I/O Module Chapter 1. Introduction 1.1 Product Overview Thank you for selecting Wolf series. Wolf series is a remote I/O module providing 7 kinds of control mode: analog input, output, analog input/output, digital input, output, digital input/output and relay, all are connected by RS-485. Each control mode in Wolf series also provides different number of input/output channels for user’s...

  • Page 10: System Specification

    Wolf Series RS-485 Remote I/O Module 1.2 System Specification Power Requirement 10 ~ 60 VDC Watchdog Timer System (1.6 second Fixed) Communication (Programmable) Connector Plug-in-terminal block (#16~30 AWG) -25 ~ 70 ℃ Temperature (Operating) Humidity 5 ~ 95 %RH -30 ~ 75 ℃...

  • Page 11: Watchdog

    Wolf Series RS-485 Remote I/O Module 1.4 Watchdog There are module watchdog and system watchdog in Wolf Series module. Module watchdog is a hardware monitoring the operation status of module, when working in a harsh/noisy environment and encountering interference, the module can automatically reset and reboot by itself.

  • Page 12: Power Requirements

    Wolf Series RS-485 Remote I/O Module 1.5 Power Requirements DC ranged from 10V to 60V is applicable to Wolf Series Module; the reverse power protection is also available. Wolf series Remote IO Module User's Manual...

  • Page 13: Network Connections

    Wolf Series RS-485 Remote I/O Module 1.6 RS-485 Network Connections The most commonly used communication interface is adapted, co-called RS-485. It provides a remote transmitting and is applicable to all remote connect. Wolf series Remote IO Module User's Manual...

  • Page 14: Environmental Safety

    Wolf Series RS-485 Remote I/O Module 1.7 Environmental Safety Wolf series modules are EMC certified in many countries. With EMI and EMS FREE to ensure the environmental quality of modules. Wolf series Remote IO Module User's Manual...

  • Page 15: Dimension

    Wolf Series RS-485 Remote I/O Module 1.8 Dimension Wolf series module dimension as following: Unit : mm Wolf series Remote IO Module User's Manual...

  • Page 16: Chapter 2. Installation

    Wolf Series RS-485 Remote I/O Module Chapter 2. Installation 2.1 Basic Installation The following parts/devices are necessary when constructing Wolf Series module. 2.1.1 Host PC Requirement A PC equipped RS-232 or RS-485 communication port. It would be connecting Wolf modules directly by RS-485 port. Or an isolated RS-232-to-RS-485 converter from our company is necessary if this PC workstation is equipped RS-232 port only.
  • Page 17 Wolf Series RS-485 Remote I/O Module ModBus node address switch IO connector Detachable DIN RAIL fixed seat (Separated) Item Description Each modules connecting power and RS-485 via this fixed Detachable DIN seat. It support attach/detach module rapidly and easy RAIL fixed seat extendable.

  • Page 18: Installation

    Wolf Series RS-485 Remote I/O Module IO indicator Represent the status of each I/O channels IO label Note I/O function for after maintains. EEPROM slot Dedicate EEPROM to store system configuration. ModBus node Setup Modbus node address by fastest way.
  • Page 19 Wolf Series RS-485 Remote I/O Module Connecting pin array Step 2: Push modules together on DIN rail and connected by pin array. A chained fixed seat of module on DIN rail as shown as following figure: Wolf series Remote IO Module User's Manual...
  • Page 20 Wolf Series RS-485 Remote I/O Module Step 3: Insert each I/O modules to detachable fixed seats by vertical direction: Step 4: A complete module chain on DIN rail as show as following figure: 模塊串接塑膠 Plastic Buckle 固定片 Wolf series Remote IO Module User's Manual...
  • Page 21 Wolf Series RS-485 Remote I/O Module Wall mounting Wolf series modules also support wall mounting mechanism. Mounting fixed seat on wall by screws first. The locations of screw hole as shown as following figure: Screwing hole Insert each modules to fixed seats on wall, as shown as following figure：...
  • Page 22 Wolf Series RS-485 Remote I/O Module If not DIN rail typed installation, the grounding could be connected by power connector. The detail for the frame grounding installation as shown as following figure: DIN rail grounding When modules were installed on an aluminum DIN rail, A metal grounding tab could be installed between modules and rail.

  • Page 23: Power Supply

    Wolf Series RS-485 Remote I/O Module Plastic grounding tab 2.1.4 Power Supply Wolf series modules support wide range DC power input, the voltage from 10V up to 60V to fit industrial application, there is power regulator inside for system power stabilization to supply high quality power if supplied power is within support rang.
  • Page 24 Wolf Series RS-485 Remote I/O Module ※ Power level would be drop low when connected power line is too long, so strongly recommend the distance between power and module should be as short as possible in order to prevent the system unstable.

  • Page 25: Connecting Communication Interface

    Wolf Series RS-485 Remote I/O Module 2.1.5 Connecting Communication Interface Wolf M1B series modules follow the standard RS-485 to support communication. The RS-485 port and placement as following figure Besides, the next figure is show the RS-485 connection.. RS-485 RS-485 ※...

  • Page 26: Io Connection

    Wolf Series RS-485 Remote I/O Module 2.1.6 IO Connection User can choose the suitable I/O feature on module to fit specified application. Please refer to the section of module information and check if each I/O channel has been assigned appropriately.
  • Page 27 Wolf Series RS-485 Remote I/O Module Procedures of removing I/O terminal 1. Insert the flathead screwdriver into the 2. Push down the screwdriver position as shown as above. 3. Remove the terminal by pulling the hook of 4. Terminal removed up side.

  • Page 28: Indicators

    Wolf Series RS-485 Remote I/O Module 2.1.7 Indicators The functions of each indicator are described in the attached table: Power indicator System indicator Communication indicator Power COM. SYS. Indication Status ◎ ◎ ◎ Flash 3 times in 0.5 sec. System initial completed.

  • Page 29: Channel Label

    Tabs under the plastic film are accessible for user to record the assignment of each channel. If you want to change the tabs, please download Excel file via Advanio official website, print it and cut out the tabs. Remove the plastic film, insert the tab(s) and put the plastic film back.

  • Page 30: Setup Utility

    Wolf series module could be configured via setup utility directly on the PC workstation equipped with RS-485. Or, use a RS-232 port through RS-485 converter, USB to RS-485 converter. Utility and setup guideline could be obtained from Advanio website. 2.1.10 Communication Setup To setup Wolf series module, MODBUS node address should be determined first.
  • Page 31 The frame format and baud rate could be changed via utility or MODBUS command. The baud rate range is from 1200bps to 115.2Kbps. Even and Odd parity check. The setup utility could be downloaded via Advanio official website, set up MODBUS command of RS-485 as the following:...

  • Page 32: Factory Reset

    Wolf Series RS-485 Remote I/O Module 2.1.11 Factory Reset Use factory reset if modules failed to communicate. Press “Push Button” to complete INIT. “Push Button” functions are described as follows: Push INIT and hold for 3 seconds, the LED indication of power, communication and system will flash 3 times at 0.5 second interval.

  • Page 33: Isolated Type Rs-232/Rs-485 Converter (Optional)

    Wolf Series RS-485 Remote I/O Module 2.1.12 Isolated Type RS-232/RS-485 Converter (Optional) If only RS232 port is available, a converter to isolate RS232/RS485 will be needed. Setup of module address for the converter is not required. 2.1.13 Repeater (Optional) With a communication distance surpasses 4000 feet (1200m) or more than 32 modules are used, expanding repeaters may be needed.

  • Page 34: Example: Multiple Modules

    Wolf Series RS-485 Remote I/O Module 2.3 Example: Multiple Modules Construction of multiple modules featuring network connecting of Wolf series modules is show as figures below. Host RS-485 F.G. Power Supply 10~60VDC F.G. Local Power Supply Wolf series Remote IO Module User's Manual...

  • Page 35: System Configuration

    Wolf Series RS-485 Remote I/O Module 2.4 System Configuration Wolf series modules are all connected in parallel by cables. Thus, failing of one segment does not affect the entire network system. The modules applied are based on RS485 interface and MODBUS protocol. When communicating via host or terminal is required, RS485 would be taken in consideration in term of different system architecture.

  • Page 36: Star Topology

    Wolf Series RS-485 Remote I/O Module 2.4.2 Star Topology All the repeaters are connected to the main network through a cable and the modules are connected to the repeaters. It forms a tree. 2.4.3 Random Topology A combination of star and daisy chain topologies can be designated for every requirement.

  • Page 37: Module Replacement

    Wolf Series RS-485 Remote I/O Module 2.5 Module Replacement A quick replacement on site in case of module failure is indicated as follows: Module malfunction Prepare new module of same model Remove terminal, connectors and detach the module from fixed...
  • Page 38 Wolf Series RS-485 Remote I/O Module Procedures of remove EEPROM : To remove EEPROM, follow the steps below: Procedures of restore EEPROM: To restore EEPROM, follow the steps below: 更換 IO 標示牌步驟： 抽出壓克力板 進行更換標示 牌，再將壓克 力板裝入即可 安裝模組川接塑膠扣步驟： Wolf series Remote IO Module User's Manual...

  • Page 39: Chapter 3. Analog Module Information

    Wolf Series RS-485 Remote I/O Module Chapter 3. Analog Module Information 3.1 W-M1B101 (Coming Soon) Wolf series Remote IO Module User's Manual...

  • Page 40: W-M1B102 (Coming Soon)

    Wolf Series RS-485 Remote I/O Module 3.2 W-M1B102 (Coming Soon) Wolf series Remote IO Module User's Manual...

  • Page 41: W-M1B103/104 8/16 Channel Universal Analog Input Module With High

    Wolf Series RS-485 Remote I/O Module 3.3 W-M1B103/104 8/16 Channel Universal Analog Input Module with High Voltage Protection 3.3.1 Terminal Assignment W-M1B103 W-M1B104 Wolf series Remote IO Module User's Manual...

  • Page 42: Block Diagram

    Wolf Series RS-485 Remote I/O Module 3.3.2 Block Diagram W-M1B103 Front End Circuit 120Ω 2CH-ADC Photo- isolation Front End Circuit 120Ω RS485 Embedded Interface Controller 2CH-ADC Power Regulator Front End Circuit 120Ω Wolf series Remote IO Module User's Manual...
  • Page 43 Wolf Series RS-485 Remote I/O Module W-M1B104 Front End Circuit 120Ω 2CH-ADC Photo- isolation Front End Circuit 120Ω RS485 Embedded Interface Controller 2CH-ADC Front End Circuit 120Ω Front End Circuit 120Ω 2CH-ADC Front End Circuit 120Ω Embedded Controller Power 2CH-ADC...

  • Page 44: Voltage Protection

    Wolf Series RS-485 Remote I/O Module 3.3.3 Channel Connecting 3.3.4 IO Specifications W-M1B103 W-M1B104 Channels 8 channels 16 channel Voltage Range ±100mV, ±500mV, ±1V, ±5V, ±10V, 0~100mV, 0~500mV, 0 ~ 1V, 0 ~ 5V, 0 ~ 10V Current Input ±20mA, 4~20mA, 0~20mA (Slide switch select)

  • Page 45: Related Reference

    Wolf Series RS-485 Remote I/O Module 3.3.5 Related Reference 3.3.5.1 Input Signal Type Setup Input ranges & type for each analog signal is adjustable. Modbus command is shown below. Address Function Initial value 40705~40720 CH0~CH15 Input signal type setup 0x0106 (0x02C0~0x02CF) ※Caution: If “Current”...
  • Page 46 Wolf Series RS-485 Remote I/O Module 0x0104 0-500mV 0x0105 0-100mV ◎ 0x0106 ± 10 V 0x0107 ± 5 V 0x0108 ± 1 V 0x0109 ± 500 mV 0x010A ± 100 mV Current Input 0x0201 4~20mA 0x0202 0~20 mA 0x0203 ± 20 mA...
  • Page 47 Wolf Series RS-485 Remote I/O Module 3.3.5.3 Hexadecimal / Engineering Unit Setup the output value on Hexadecimal, or customer scaling. Modbus command is shown below. Address Function Initial value 40737 AI Value format 0x0000 (0x02E0) 0x0000: Hex 0x0001: Engineering 30513~30528...
  • Page 48 Wolf Series RS-485 Remote I/O Module Engineering Unit data range: Value Range Min. value Max. value Voltage Input 0x0101 0~10 V 10000 0x0102 0~5 V 50000 0x0103 0~1 V 10000 0x0104 0-500mV 50000 0x0105 0-100mV 10000 0x0106 ± 10 V...

  • Page 49: Modbus Address

    Wolf Series RS-485 Remote I/O Module (0x0280~0x028F) 0: normal 1: out of range 30513~30528 AI CH0 ~ CH15 Value 40513~40528 (0x0200~0x020F) 3.3.5.5 Temperature Offset Setting the temperature offset register with in the module. When selecting thermocouple intput mdoe, register can fine-tuning of temperature. Setting address is...
  • Page 50 Wolf Series RS-485 Remote I/O Module Address Function Initial Value 30513~30520 AI CH0 ~ CH7 Value 40513~40520 (0x0200~0x0207) 40577~40584 Temperature Compensation 0x0000 unit: 0.01℃, Range: -50.0℃ ~ 50.0℃ (0x0240~0x0247) 40609~40616 CJC Compensation 0x0000 (0x0260~0x0267) unit: 0.01℃, Range: -50.0℃ ~ 50.0℃...
  • Page 51 Wolf Series RS-485 Remote I/O Module 44106 Modbus response delay time (unit: ms) (0x1009) Range: 0~30 44107 COM port setting: 2bytes 0x0006 (0x100A) High Byte Low Byte 0x00: 8-N-1 0x03: 1.2K 0x01: 8-N-2 0x04: 2.4K 0x02: 8-E-1 0x05: 4.8K 0x03: 8-O-1 0x06: 9.6K...
  • Page 52 Wolf Series RS-485 Remote I/O Module (0x0200~0x020F) 40577~40584 Temperature Compensation 0x0000 unit: 0.01℃, Range: -50.0℃ ~ 50.0℃ (0x0240~0x0247) 40609~40616 CJC Compensation 0x0000 (0x0260~0x0267) unit: 0.01℃, Range: -50.0℃ ~ 50.0℃ 40641 CJC Value, Unit : 0.01℃ (0x0280) 40642 CH8~CH15 Value, Unit : 0.01℃...
  • Page 53 Wolf Series RS-485 Remote I/O Module 44107 COM port setting: 2bytes 0x0006 (0x100A) High Byte Low Byte 0x00: 8-N-1 0x03: 1.2K 0x01: 8-N-2 0x04: 2.4K 0x02: 8-E-1 0x05: 4.8K 0x03: 8-O-1 0x06: 9.6K 0x07: 19.2K 0x08: 38.4K 0x09: 57.6K 0x0A: 115.2K 44108 Watch dog timer (unit: 0.1s)

  • Page 54: W-M1B105/106 8/16 Channel Universal Analog Input Module

    Wolf Series RS-485 Remote I/O Module 3.4 W-M1B105/106 8/16 Channel Universal Analog Input Module 3.4.1 Terminal Assignment W-M1B105 W-M1B106 Wolf series Remote IO Module User's Manual...

  • Page 55: Block Diagram

    Wolf Series RS-485 Remote I/O Module 3.4.2 Block Diagram W-M1B105 Front End Circuit 120Ω 2CH-ADC Photo- isolation Front End Circuit 120Ω RS485 Embedded Interface Controller 2CH-ADC Power Regulator Front End Circuit 120Ω Wolf series Remote IO Module User's Manual...
  • Page 56 Wolf Series RS-485 Remote I/O Module W-M1B106 Front End Circuit 120Ω 2CH-ADC Photo- isolation Front End Circuit 120Ω RS485 Embedded Interface Controller 2CH-ADC Front End Circuit 120Ω Front End Circuit 120Ω 2CH-ADC Front End Circuit 120Ω Embedded Controller Power 2CH-ADC...

  • Page 57: Channel Connecting

    Wolf Series RS-485 Remote I/O Module 3.4.3 Channel Connecting 3.4.4 IO Specifications W-M1B105 W-M1B106 Channels 8 channels 16 channel Voltage Range ±100mV, ±500mV, ±1V, ±5V, ±10V, 0~100mV, 0~500mV, 0 ~ 1V, 0 ~ 5V, 0 ~ 10V Current Input ±20mA, 4~20mA, 0~20mA (Slide switch select)

  • Page 58: Related Reference

    Wolf Series RS-485 Remote I/O Module 3.4.5 Related Reference 3.4.6 MODBUS Address Function of W-M1B105 is the same with W-M1B103, funtcion of W-M1B106 is the same with W-M1B104, please refer to section 3.3.5 ~ 3.3.6 Wolf series Remote IO Module User's Manual...

  • Page 59: W-M1B107/108 8/16 Channels Thermoucouple Input Module

    Wolf Series RS-485 Remote I/O Module 3.5 W-M1B107/108 8/16 Channels Thermoucouple Input Module 3.5.1 Terminal Assignment W-M1B107 W-M1B108 Wolf series Remote IO Module User's Manual...

  • Page 60: Block Diagram

    Wolf Series RS-485 Remote I/O Module 3.5.2 Block Diagram W-M1B107 Front End Circuit 2CH-ADC Photo- isolation Front End Circuit RS485 Embedded Interface Controller 2CH-ADC Power Regulator Front End Circuit Wolf series Remote IO Module User's Manual...

  • Page 61: Channel Connecting

    Wolf Series RS-485 Remote I/O Module W-M1B108 Front End Circuit 2CH-ADC Photo- isolation Front End Circuit RS485 Embedded Interface Controller 2CH-ADC Front End Circuit Front End Circuit 2CH-ADC Front End Circuit Embedded Controller Power 2CH-ADC Regulator Front End Circuit 3.5.3 Channel Connecting...

  • Page 62: Io Specifications

    Wolf Series RS-485 Remote I/O Module 3.5.4 IO Specifications W-M1B107 W-M1B108 Channels 8 channels 16 channels Direct Sensor Input J, K, T, E, R, S, B, N Burn-out Detection Channel Independent Configuration Sampling Rates 2.5 samples/second per channel Resolution 16-bit Accuracy ±0.1% FSR...
  • Page 63 Wolf Series RS-485 Remote I/O Module Signals detect range: Value Input range Initial value Thermocouple Input ◎ 0x0301 Type J Thermocouple -210 ~ 1200 °C 0x0302 Type K Thermocouple -270 ~ 1372 °C 0x0303 Type T Thermocouple -270 ~ 400 °C 0x0304 Type E Thermocouple -270 ~ 1000 °C...
  • Page 64 Wolf Series RS-485 Remote I/O Module 30513~30528 AI CH0 ~ CH15 Value 40513~40528 (0x0200~0x020F) Hex Unit data range: Value Range Min. value Max. value Thermocouple Input 0x0301 Type J Thermocouple -210 ~ 1200 °C E999 (-5735) 7FFF (32767) 0x0302 Type K Thermocouple -270 ~ 1372 °C...

  • Page 65: Modbus Address

    Wolf Series RS-485 Remote I/O Module 00641~00656 CH0~CH15 Out of range (0x0280~0x0287) 0: normal 1: out of range 30513~30528 AI CH0 ~ CH15 Value 40513~40528 (0x0200~0x020F) 3.5.5.5 Temperature Offset Setting the temperature offset register with in the module. Setting address is...
  • Page 66 Wolf Series RS-485 Remote I/O Module 40513~40520 (0x0200~0x0207) 40577~40584 Temperature Compensation 0x0000 unit: 0.01℃, Range: -50.0℃ ~ 50.0℃ (0x0240~0x0247) 40609 ~ 40616 CJC Compensation 0x0000 (0x0260~0x0267) unit: 0.01℃, Range: -50.0℃ ~ 50.0℃ 40641 CJC Value, Unit : 0.01℃ (0x0280) 40657 Module CJC Compensation unit: 0.01℃, Range: -50.0℃...
  • Page 67 Wolf Series RS-485 Remote I/O Module 44107 COM port setting: 2bytes 0x0006 (0x100A) High Byte Low Byte 0x00: 8-N-1 0x03: 1.2K 0x01: 8-N-2 0x04: 2.4K 0x02: 8-E-1 0x05: 4.8K 0x03: 8-O-1 0x06: 9.6K 0x07: 19.2K 0x08: 38.4K 0x09: 57.6K 0x0A: 115.2K 44108 Watch dog timer (unit: 0.1s)
  • Page 68 Wolf Series RS-485 Remote I/O Module unit: 0.01℃, Range: -50.0℃ ~ 50.0℃ (0x0240~0x0247) 40609 ~ 40616 CJC Compensation 0x0000 (0x0260~0x0267) unit: 0.01℃, Range: -50.0℃ ~ 50.0℃ 40641 CJC Value, Unit : 0.01℃ (0x0280) 40642 CH8~CH15 CJC Value, Unit : 0.01℃...
  • Page 69 Wolf Series RS-485 Remote I/O Module 44107 COM port setting: 2bytes 0x0006 (0x100A) High Byte Low Byte 0x00: 8-N-1 0x03: 1.2K 0x01: 8-N-2 0x04: 2.4K 0x02: 8-E-1 0x05: 4.8K 0x03: 8-O-1 0x06: 9.6K 0x07: 19.2K 0x08: 38.4K 0x09: 57.6K 0x0A: 115.2K 44108 Watch dog timer (unit: 0.1s)

  • Page 70: W-M1B109/110 8/16-Channel Current Input Module

    Wolf Series RS-485 Remote I/O Module 3.6 W-M1B109/110 8/16-channel Current Input Module 3.6.1 Terminal Assignment W-M1B109 W-M1B110 Wolf series Remote IO Module User's Manual...

  • Page 71: Block Diagram

    Wolf Series RS-485 Remote I/O Module 3.6.2 Block Diagram W-M1B109 Front End Circuit 120Ω 2CH-ADC Photo- isolation Front End Circuit 120Ω RS485 Embedded Interface Controller 2CH-ADC Power Regulator Front End Circuit 120Ω Wolf series Remote IO Module User's Manual...

  • Page 72: Channel Connecting

    Wolf Series RS-485 Remote I/O Module W-M1B110 Front End Circuit 120Ω 2CH-ADC Photo- isolation Front End Circuit 120Ω RS485 Embedded Interface Controller 2CH-ADC Front End Circuit 120Ω Front End Circuit 120Ω 2CH-ADC Front End Circuit 120Ω Embedded Controller Power 2CH-ADC...

  • Page 73: Io Specifications

    Wolf Series RS-485 Remote I/O Module 3.6.4 IO Specifications W-M1B109 W-M1B110 Channels 8 channels 16 channels Current Input ±20mA, 4~20mA, 0~20mA Burn-out Detection 4~20mA Channel Independent Configuration Sampling Rates 2.5 samples/second per channel Resolution 16-bit Accuracy ±0.1% FSR 120Ω Input Impedance ±25 ppm/℃...
  • Page 74 Wolf Series RS-485 Remote I/O Module Value Input range Initial value Current Input ◎ 0x0201 4~20mA 0x0202 0~20 mA 0x0203 ± 20 mA 3.6.5.2 Hexadecimal / Engineering Unit Setup the output value on Hexadecimal, or customer scaling. Modbus command is shown below.

  • Page 75: Modbus Address

    Wolf Series RS-485 Remote I/O Module Address Function Initial Value 40737 AI Value format 0x0000 (0x02E0) 0x0000: Hex 0x0001: Engineering 00641~00656 CH0~CH15 Out of range (0x0280~0x0287) 0: normal 1: out of range 30513~30528 AI CH0 ~ CH15 Value 40513~40528 (0x0200~0x020F) 3.6.6 MODBUS Address...
  • Page 76 Wolf Series RS-485 Remote I/O Module 40578 CH0~CH7 Calibrate 0 level to each 0x0000 (0x02F5) channel. (Each bit map to corresponding channel) 40579 CH0~CH7 Perform internal calibration 0x0000 (0x02F6) to each channel. (Each bit map to corresponding channel) 40580 CH0~CH7 Calibration in process (Each...
  • Page 77 Wolf Series RS-485 Remote I/O Module 3.6.6.2 W-M1B110 Modbus address table Coil (0xxxx) / (1xxxx) Address Function Initial Value 00537 Allow calibration (0x0218) 0: Disallow 1: Allow 00641~00656 CH0~CH15 Out of range (0x0280~0x028F) 0: normal 1: out of range Holding Register( 4xxxx) / Input Register(3xxxx)
  • Page 78 Wolf Series RS-485 Remote I/O Module 44098~44105 Module name 16 Bytes (16 ASCII char) (0x1001~0x1008) 44106 Modbus response delay time (unit: ms) (0x1009) Range: 0~30 44107 COM port setting: 2bytes 0x0006 (0x100A) High Byte Low Byte 0x00: 8-N-1 0x03: 1.2K 0x01: 8-N-2 0x04: 2.4K...

  • Page 79: W-M1B111/112 8/16-Channel Voltage Input Module

    Wolf Series RS-485 Remote I/O Module 3.7 W-M1B111/112 8/16-Channel Voltage Input Module 3.7.1 Terminal Assignment W-M1B111 W-M1B112 Wolf series Remote IO Module User's Manual...

  • Page 80: Block Diagram

    Wolf Series RS-485 Remote I/O Module 3.7.2 Block Diagram W-M1B111 Front End Circuit 2CH-ADC Photo- isolation Front End Circuit RS485 Embedded Interface Controller 2CH-ADC Power Regulator Front End Circuit Wolf series Remote IO Module User's Manual...

  • Page 81: Channel Connecting

    Wolf Series RS-485 Remote I/O Module 3.7.3 Channel Connecting Wolf series Remote IO Module User's Manual...

  • Page 82: Io Specifications

    Wolf Series RS-485 Remote I/O Module 3.7.4 IO Specifications W-M1B111 W-M1B112 Channels 8 channels 16 channels Voltage Range ±1V, ±5V, ±10V, 0 ~ 1V, 0 ~ 5V, 0 ~ 10V Burn-out Detection Channel Independent Configuration Sampling Rates 2.5 samples/second per channel...
  • Page 83 Wolf Series RS-485 Remote I/O Module Value Input range Initial value Voltage Input 0x0101 0~10 V 0x0102 0~5 V 0x0103 0~1 V ◎ 0x0106 ± 10 V 0x0107 ± 5 V 0x0108 ± 1 V 3.7.5.2 Hexadecimal / Engineering Unit Setup the output value on Hexadecimal, or customer scaling.

  • Page 84: Modbus Address

    Wolf Series RS-485 Remote I/O Module 0x0108 ± 1 V -10000 10000 3.7.5.3 Signal Value Once completing the setup, please enter the measured value. This is to enable/ disable the channel(s) and check if the value is out-of-range (valtage contact loss is deemed to be “out of range”).
  • Page 85 Wolf Series RS-485 Remote I/O Module 40737 AI Result format of measurement 0x0000 (0x02E0) 0x0000: Hex 0x0001: Engineering 40577 CH0~CH7 Calibrate maximum value to 0x0000 (0x02F4) each channel. (Each bit map to corresponding channel) Ex. Bit 0 = 1, Calibrate CH0.
  • Page 86 Wolf Series RS-485 Remote I/O Module 44110 Status of system watch dog (0x100D) 0x0001: Timeout 0x0000: Normal 44111 Counter of communication frame 0x0000 (0x100E) 3.7.6.2 W-M1B112 Modbus address table Coil (0xxxx) / (1xxxx) Address Function Initial Value 00537 Allow calibration...
  • Page 87 Wolf Series RS-485 Remote I/O Module 40580 CH0~CH15 Calibration in process (0x02F7) (Each bit map to corresponding channel) 0: No operation 1: Calibration in process 44097 Firmware version 2 Bytes 0x1000 High Byte Low Byte Main version Sub-version 44098~44105 Module name 16 Bytes (16 ASCII char)

  • Page 88: W-M1B113 6-Channel Rtd Input Module

    Wolf Series RS-485 Remote I/O Module 3.8 W-M1B113 6-Channel RTD Input Module 3.8.1 Terminal Assignment Wolf series Remote IO Module User's Manual...

  • Page 89: Block Diagram

    Wolf Series RS-485 Remote I/O Module 3.8.2 Block Diagram 3.8.3 Channel Connecting 2-Wire Type RTD 3-Wire Type RTD 4-Wire Type RTD Wolf series Remote IO Module User's Manual...

  • Page 90: Io Specifications

    Wolf Series RS-485 Remote I/O Module 3.8.4 IO Specifications Channels 6 channels Platinum 100 α= 0.00385 (IEC) -200 ~ 600℃ Sensor Types Platinum 100 α= 0.00392 (JIS) -200 ~ 600℃ Platinum 1000 α= 0.00385 (IEC) -200 ~ 600℃ Cu 100@0℃α= 0.00421 -20 ~ 150℃...

  • Page 91: Related Reference

    Wolf Series RS-485 Remote I/O Module 3.8.5 Related Reference 3.8.5.1 Input Signal Type Setup Each channel of the module can be indpendently set various analog signal input range. Modbus command is shown below. Address Function Initial value 40705~40710 CH0~CH5 Input signal type setup...
  • Page 92 Wolf Series RS-485 Remote I/O Module 3.8.5.2 Hexadecimal / Engineering Unit Setup the output value on Hexadecimal, or customer scaling. Modbus command is shown below. Address Function R/W Initial value 40737 AI Value format 0x0000 (0x02E0) 0x0000: Hex 0x0001: Engineering...
  • Page 93 Wolf Series RS-485 Remote I/O Module (66.60Ω~ 380.31 Ω) Nickel 507.5Ωα=0.00520； -80 ~ 260 0x040A 0xD89E 0x7FFF °C (344.10Ω~ 1328.16 Ω) Nickel604Ωα=0.00518； -200 ~ 200 °C 0x040B 0xFFFE 0x7FFF (245.34Ω~ 1301.9 Ω) BALCO 500；-40 ~ 150 °C 0x040C 0xDDDE 0x7FFF (379.35Ω~ 802.36 Ω)

  • Page 94: Modbus Address

    Wolf Series RS-485 Remote I/O Module 3.8.5.3 Signal Value Once completing the setup, please enter the measured value. This is to enable/ disable the channel(s) and check if the value is out-of-range. Modbus command as following: Address Function Initial Value...
  • Page 95 Wolf Series RS-485 Remote I/O Module 00537 Allow calibration (0x0218) 0: Disallow 1: Allow 00641~00646 CH0~CH5 Out of range (0x0280~0x0285) 0: normal 1: out of range Holding Register( 4xxxx) / Input Register(3xxxx) Address Function Initial Value 30513~30518 AI CH0 ~ CH5 Value...
  • Page 96 Wolf Series RS-485 Remote I/O Module 44107 COM port setting: 2bytes 0x0006 (0x100A) High Byte Low Byte 0x00: 8-N-1 0x03: 1.2K 0x01: 8-N-2 0x04: 2.4K 0x02: 8-E-1 0x05: 4.8K 0x03: 8-O-1 0x06: 9.6K 0x07: 19.2K 0x08: 38.4K 0x09: 57.6K 0x0A: 115.2K 44108 Watch dog timer (unit: 0.1s)

  • Page 97: Chapter 4. Digital Module Information

    Wolf Series RS-485 Remote I/O Module Chapter 4. Digital Module Information 4.1 W-M1B301 16-Channel Digital Input MOdule 4.1.1 Terminal Assignment Wolf series Remote IO Module User's Manual...

  • Page 98: Block Diagram

    Wolf Series RS-485 Remote I/O Module 4.1.2 Block Diagram +5V(Internal) +5V(Internal) 8.6KΩ 8.6KΩ 2.2KΩ 2.2KΩ 1.2KΩ 1.2KΩ +5V(Internal) +5V(Internal) 8.6KΩ 8.6KΩ 2.2KΩ 2.2KΩ 1.2KΩ 1.2KΩ +5V(Internal) +5V(Internal) 8.6KΩ 8.6KΩ 2.2KΩ 2.2KΩ 1.2KΩ 1.2KΩ COM1 COM2 GND(Internal) GND(Internal) 4.1.3 Channel Connecting...

  • Page 99: Io Specifications

    Wolf Series RS-485 Remote I/O Module 4.1.4 IO Specifications Digital Input Digital Input Channels Dry Contact Logic Level 0 Open Logic Level 1 Close to GND Wet Contact Logic Level 0 3V maximum Logic Level 1 10 to 50V 10kΩ...
  • Page 100 Wolf Series RS-485 Remote I/O Module When Input Active Value Define as 1: External signal: Activated is 0 Inactivate is 1 4.1.5.2 Digital Input Status Following Modbus address can be used to read digital input channel status: Address Function Initial Value...
  • Page 101 Wolf Series RS-485 Remote I/O Module Refer following description for how counter works: When Input Active Value Define is 0: External signal： Rising edge counter: 1 active 0 Inactive Falling edge counter: 1 active 0 Inactive When Input Active Value Define is 1: External signal：...

  • Page 102: Modbus Address

    Wolf Series RS-485 Remote I/O Module When Input Active Value Define is 0: External signal: Activated is 1，Latch High is 1 Inactivate is 0，Latch Low is 1 When Input Active Value Define is 1: External signal Inactivate is 0，Latch Low is 1 Activated is 1，Latch High is 1...
  • Page 103 Wolf Series RS-485 Remote I/O Module 40129 DI CH0~CH15 Input Active Value 0x0000 (0x0080) Define 0x0000: input value 0 for non-signal; 0x0001: input value 1 for non-signal; 40137 DI CH0~CH15 Counter Edge Define 0x0000 (0x0088) (Each bit map to corresponding...

  • Page 104: W-M1B302 32-Channel Digital Input Module

    Wolf Series RS-485 Remote I/O Module 4.2 W-M1B302 32-Channel Digital Input Module 4.2.1 Terminal Assignment Wolf series Remote IO Module User's Manual...

  • Page 105: Block Diagram

    Wolf Series RS-485 Remote I/O Module 4.2.2 Block Diagram +5V(Internal) +5V(Internal) 8.6KΩ 8.6KΩ 2.2KΩ 2.2KΩ 1.2KΩ 1.2KΩ +5V(Internal) +5V(Internal) 8.6KΩ 8.6KΩ 2.2KΩ 2.2KΩ 1.2KΩ 1.2KΩ +5V(Internal) +5V(Internal) 8.6KΩ 8.6KΩ 2.2KΩ 2.2KΩ 1.2KΩ 1.2KΩ COM1 COM2 GND(Internal) GND(Internal) +5V(Internal) +5V(Internal) 8.6KΩ...

  • Page 106: Channel Connecting

    Wolf Series RS-485 Remote I/O Module 4.2.3 Channel Connecting Dry Contact Wet Contact Wolf series Remote IO Module User's Manual...

  • Page 107: Io Specifications

    Wolf Series RS-485 Remote I/O Module 4.2.4 IO Specifications Digital Input Digital Input Channels Dry Contact Logic Level 0 Open Logic Level 1 Close to GND Wet Contact Logic Level 0 3V maximum Logic Level 1 10 to 50V 10kΩ...
  • Page 108 Wolf Series RS-485 Remote I/O Module When Input Active Value Define as 1: External signal: Activated is 0 Inactivate is 1 4.2.5.2 Digital Input Status Following Modbus address can be used to read digital input channel status: Address Function Initial Value...
  • Page 109 Wolf Series RS-485 Remote I/O Module Refer following description for how counter works: When Input Active Value Define is 0: External signal： Rising edge counter: 1 active 0 Inactive Falling edge counter: 1 active 0 Inactive When Input Active Value Define is 1: External signal：...

  • Page 110: Modbus Address

    Wolf Series RS-485 Remote I/O Module When Input Active Value Define is 1: External signal Inactivate is 0，Latch Low is 1 Activated is 1，Latch High is 1 4.2.6 MODBUS Address Coil (0xxxx) / (1xxxx) Address Function Initial Value 00001~00032 DI CH0~CH31 Input Status...
  • Page 111 Wolf Series RS-485 Remote I/O Module 40137 DI CH0~CH31 Counter Edge Define 0x0000 (0x0088) (Each bit map to corresponding channel) 1=rising edge 0=falling edge 44097 Firmware version 2 Bytes 0x1000 High Byte Low Byte Main version Sub-version 44098~44105 Module name 16 Bytes (16 ASCII char)

  • Page 112: W-M1B401 16-Channel Digital Output Module

    Wolf Series RS-485 Remote I/O Module 4.3 W-M1B401 16-Channel Digital Output Module 4.3.1 Terminal Assignment Wolf series Remote IO Module User's Manual...

  • Page 113: Block Diagram

    Wolf Series RS-485 Remote I/O Module 4.3.2 Block Diagram 39KΩ 39KΩ GND1 GND2 GND1 GND2 39KΩ 39KΩ GND1 GND2 GND1 GND2 GND1 GND2 39KΩ 39KΩ PWR1 PWR2 GND1 GND2 GND1 GND2 GND1 GND2 4.3.3 Channel Connecting Wolf series Remote IO Module User's Manual...

  • Page 114: Io Specifications

    Wolf Series RS-485 Remote I/O Module 4.3.4 IO Specifications Digital Output Digital Output Channels Output Type Output Voltage Range 3.5~30V Normal Output Current 500mA Startup Value Setting Communication Safety Value Setting Power Consumption 0.5W @ 24V 4.3.5 Related Reference 4.3.5.1 Digital Output Active State...

  • Page 115: Modbus Address

    Wolf Series RS-485 Remote I/O Module 4.3.5.2 Digital Output Status Following Modbus address can be used to read digital output status: Address Function Initial Value 00257~00272 DO CH0~CH15 Output Status (0x0100~0x010F) 4.3.5.3 Power-on Value Module has the function of power-on value. Following Modbus address can be...
  • Page 116 Wolf Series RS-485 Remote I/O Module 40257 DO CH0~CH15 Power On Value All 0x0000 (0x0100) (Each bit map to corresponding channel) 40259 (0x0102) DO CH0~CH15 Safety Output Value All 0x0000 (Each bit map to corresponding channel) 40385 DO CH0~CH15 Output Active Value...

  • Page 117: W-M1B402 32-Channel Digital Output Module

    Wolf Series RS-485 Remote I/O Module 4.4 W-M1B402 32-Channel Digital Output Module 4.4.1 Terminal Assignment Wolf series Remote IO Module User's Manual...

  • Page 118: Block Diagram

    Wolf Series RS-485 Remote I/O Module 4.4.2 Block Diagram 39KΩ 39KΩ GND1 GND2 GND1 GND2 39KΩ 39KΩ GND1 GND2 GND1 GND2 GND1 GND2 39KΩ 39KΩ PWR1 PWR2 GND1 GND2 GND1 GND2 GND1 GND2 39KΩ 39KΩ GND3 GND4 GND3 GND4 39KΩ...

  • Page 119: Channel Connecting

    Wolf Series RS-485 Remote I/O Module 4.4.3 Channel Connecting 4.4.4 IO Specifications Digital Output Digital Output Channels Output Type Output Voltage Range 3.5~30V Normal Output Current 500mA Startup Value Setting Communication Safety Value Setting Power Consumption 0.7W @ 24V Wolf series Remote IO Module User's Manual...

  • Page 120: Related Reference

    Wolf Series RS-485 Remote I/O Module 4.4.5 Related Reference 4.4.5.1 Digital Output Active State Digital Output module supports invert digital output status, when the state is 0x0000, if the output channel is configured as 1, the digital output will be activated, if the output channel is configured as 0, the digital output will be inactivate;...

  • Page 121: Modbus Address

    Wolf Series RS-485 Remote I/O Module 4.4.5.3 Power-on Value Module has the function of power-on value. Following Modbus address can be used to configure the power-on value for all channel: Address Function Initial Value 40257 DO CH0~CH31 Power On Value...
  • Page 122 Wolf Series RS-485 Remote I/O Module 44097 Firmware version 2 Bytes 0x1000 High Byte Low Byte Main version Sub-version 44098~44105 Module name 16 Bytes (16 ASCII char) (0x1001~0x1008) 44106 Modbus response delay time (unit: ms) (0x1009) Range: 0~30 44107 COM port setting : 2bytes...

  • Page 123: W-M1B403 8-Channel Relay Output Module

    Wolf Series RS-485 Remote I/O Module 4.5 W-M1B403 8-Channel Relay Output Module 4.5.1 Terminal Assignment Wolf series Remote IO Module User's Manual...

  • Page 124: Block Diagram

    Wolf Series RS-485 Remote I/O Module 4.5.2 Block Diagram Wolf series Remote IO Module User's Manual...

  • Page 125: Channel Connecting

    Wolf Series RS-485 Remote I/O Module 4.5.3 Channel Connecting 4.5.4 IO Specifications Digital Output Relay Output Channels 4 Form A, 4 Form C Contact Rating 5A 250VAC/30VDC Dielectric Strength Operate Time 10ms Max. Relese Time 5ms Max. Electrical Endurance 1x10...
  • Page 126 Wolf Series RS-485 Remote I/O Module When Output Active Value Define is 0: Digital output Activated when do is 1 Inactivate when do is 0 When Output Active Value Define is 1 Digital output Activated when do is 0 Inactivate when do is 1 4.5.5.2 Digital Output Status...

  • Page 127: Modbus Address

    Wolf Series RS-485 Remote I/O Module 4.5.6 MODBUS Address Coil (0xxxx) / (1xxxx) Address Function Initial Value 00257~00264 DO CH0~CH7 Output Status (0x0100~0x0107) Holding Register( 4xxxx) / Input Register(3xxxx) Address Function R/W Initial Value 40257 DO CH0~CH7 Power On Value...
  • Page 128 Wolf Series RS-485 Remote I/O Module 44110 Status of system watch dog (0x100D) 0x0001: Timeout 0x0000: Normal 44111 Counter of communication frame 0x0000 (0x100E) Wolf series Remote IO Module User's Manual...

  • Page 129: W-M1B404 16-Channel Relay Output Module

    Wolf Series RS-485 Remote I/O Module 4.6 W-M1B404 16-Channel Relay Output Module 4.6.1 Terminal Assignment Wolf series Remote IO Module User's Manual...

  • Page 130: Block Diagram

    Wolf Series RS-485 Remote I/O Module 4.6.2 Block Diagram Wolf series Remote IO Module User's Manual...

  • Page 131: Channel Connecting

    Wolf Series RS-485 Remote I/O Module 4.6.3 Channel Connecting 4.6.4 IO Specifications Digital Output Relay Output Channels 8 Form A, 8 Form C Contact Rating 5A 250VAC/30VDC Dielectric Strength Operate Time 10ms Max. Relese Time 5ms Max. Electrical Endurance 1x10...
  • Page 132 Wolf Series RS-485 Remote I/O Module When Output Active Value Define is 0: Digital output Activated when do is 1 Inactivate when do is 0 When Output Active Value Define is 1 Digital output Activated when do is 0 Inactivate when do is 1 4.6.5.2 Digital Output Status...

  • Page 133: Modbus Address

    Wolf Series RS-485 Remote I/O Module 4.6.6 MODBUS Address Coil (0xxxx) / (1xxxx) Address Function Initial Value 00257~00272 DO CH0~CH15 Output Status (0x0100~0x010F) Holding Register( 4xxxx) / Input Register(3xxxx) Address Function R/W Initial Value 40257 DO CH0~CH15 Power On Value...
  • Page 134 Wolf Series RS-485 Remote I/O Module 44110 Status of system watch dog (0x100D) 0x0001: Timeout 0x0000: Normal 44111 Counter of communication frame 0x0000 (0x100E) Wolf series Remote IO Module User's Manual...

  • Page 135: W-M1B501 16-Channel Digital Input/16-Channel Digital Output Module

    Wolf Series RS-485 Remote I/O Module 4.7 W-M1B501 16-Channel Digital Input/16-Channel Digital Output Module 4.7.1 Terminal Assignment Wolf series Remote IO Module User's Manual...

  • Page 136: Block Diagram

    Wolf Series RS-485 Remote I/O Module 4.7.2 Block Diagram +5V(Internal) 8.6KΩ 2.2KΩ 1.2KΩ 39KΩ +5V(Internal) GND1 GND1 8.6KΩ 2.2KΩ 1.2KΩ 39KΩ GND1 GND1 +5V(Internal) 8.6KΩ GND1 2.2KΩ 39KΩ 1.2KΩ PWR1 COM1 GND1 GND1 GND1 GND(Internal) +5V(Internal) 8.6KΩ 2.2KΩ 1.2KΩ 39KΩ...

  • Page 137: Channel Connecting

    Wolf Series RS-485 Remote I/O Module 4.7.3 Channel Connecting Dry Contact Wet Contact Wolf series Remote IO Module User's Manual...

  • Page 138: Io Specifications

    Wolf Series RS-485 Remote I/O Module 4.7.4 IO Specifications Digital Input Digital Input Channels Dry Contact Logic Level 0 Open Logic Level 1 Close to GND Wet Contact Logic Level 0 +3V maximum Logic Level 1 +10 to 50V 10kΩ...
  • Page 139 Wolf Series RS-485 Remote I/O Module Address Function Initial Value 40129 DI CH0~CH15 Input Active Value Define 0x0000 (0x0080) 0x0000: input value 0 for non-signal; 0x0001: input value 1 for non-signal; When Input Active Value Define as 0： External signal:...
  • Page 140 Wolf Series RS-485 Remote I/O Module 40137 DI CH0~CH15 Counter Edge Define 0x0000 (0x0088) (Each bit map to corresponding channel) 1=rising edge 0=falling edge Refer following description for how counter works: When Input Active Value Define is 0: External signal：...
  • Page 141 Wolf Series RS-485 Remote I/O Module When Input Active Value Define is 0: External signal: Activated is 1，Latch High is 1 Inactivate is 0，Latch Low is 1 When Input Active Value Define is 1: External signal Inactivate is 0，Latch Low is 1 Activated is 1，Latch High is 1...

  • Page 142: Modbus Address

    Wolf Series RS-485 Remote I/O Module 4.7.5.6 Digital Output Status Following Modbus address can be used to read digital output status: Address Function Initial Value 00257~00272 DO CH0~CH15 Output Status (0x0100~0x010F) 4.7.5.7 Power-on Value Module has the function of power-on value. Following Modbus address can be...
  • Page 143 Wolf Series RS-485 Remote I/O Module 000129 DI CH0~CH15 Latch Clear (0x0080) 000145~000160 DI CH0~CH15 Counter Clear All 0 (0x0090~0x009F) 00257~00272 DO CH0~CH15 Output Status (0x0100~0x010F) Holding Register (4xxxx) / Input Register (3xxxx) Address Function R/W Initial Value 30001~30016 DI CH0~CH15 DI Counter Value...
  • Page 144 Wolf Series RS-485 Remote I/O Module 44107 COM port setting : 2bytes R/W 0x0006 (0x100A) High Byte Low Byte 0x00: 8-N-1 0x03:1.2K 0x01: 8-N-2 0x04:2.4K 0x02: 8-E-1 0x05:4.8K 0x03: 8-O-1 0x06:9.6K 0x07:19.2K 0x08:38.4K 0x09:57.6K 0x0A:115.2K 44108 Watch dog timer (unit : 0.1s)

  • Page 145: W-M1B502 16-Channel Digital Input/8-Channel Relay Output Module

    Wolf Series RS-485 Remote I/O Module 4.8 W-M1B502 16-Channel Digital Input/8-Channel Relay Output Module 4.8.1 Terminal Assignment Wolf series Remote IO Module User's Manual...

  • Page 146: Block Diagram

    Wolf Series RS-485 Remote I/O Module 4.8.2 Block Diagram +5V(Internal) 8.6KΩ 2.2KΩ 1.2KΩ +5V(Internal) 8.6KΩ 2.2KΩ 1.2KΩ +5V(Internal) 8.6KΩ 2.2KΩ 1.2KΩ COM1 GND(Internal) +5V(Internal) 8.6KΩ 2.2KΩ 1.2KΩ +5V(Internal) 8.6KΩ 2.2KΩ 1.2KΩ +5V(Internal) 8.6KΩ 2.2KΩ 1.2KΩ COM2 GND(Internal) Wolf series Remote IO Module User's Manual...

  • Page 147: Channel Connecting

    Wolf Series RS-485 Remote I/O Module 4.8.3 Channel Connecting Dry Contact Wet Contact 4.8.4 IO Specifications Digital Input Digital Input Channels Dry Contact Logic Level 0 Open Logic Level 1 Close to GND Wet Contact Logic Level 0 3V maximum...

  • Page 148: Related Reference

    Wolf Series RS-485 Remote I/O Module Counter Input Range Max.100Hz(16 bit) Latch Value Read Digital Output Relay Output Channels 4 Form A, 4 Form C 5A 250VAC/30VDC Contact Rating Dielectric Strength Operate Time 10ms Max. Release Time 5ms Max. 1x10...
  • Page 149 Wolf Series RS-485 Remote I/O Module 4.8.5.2 Digital Input Status Following Modbus address can be used to read digital input channel status: Address Function Initial Value 00001~00016 DI CH0~CH15 Input Status All 0 10001~10016 (0x0000~0x000F) 4.8.5.3 Read/Clear the Digital Input Counter Module has the function of counting the external pulse number of the digital signal.
  • Page 150 Wolf Series RS-485 Remote I/O Module When Input Active Value Define is 1: External signal： Rising edge counter: 1 Inactive 0 active Falling edge counter: 1 Inactive 0 active 4.8.5.4 Read/Clear Latch Status Module has the function of latch the external pulse of the digital signal.
  • Page 151 Wolf Series RS-485 Remote I/O Module 4.8.5.5 Digital Output Active State Digital Output module supports invert digital output status, when the state is 0x0000, if the output channel is configured as 1, the digital output will be activated, if the output channel is configured as 0, the digital output will be inactivate; when...
  • Page 152 Wolf Series RS-485 Remote I/O Module 4.7.5.7 Power-on Value Module has the function of power-on value. Following Modbus address can be used to configure the power-on value for all channel: Address Function Initial Value 40257 DO CH0~CH7 Power On Value...

  • Page 153: Modbus Address

    Wolf Series RS-485 Remote I/O Module 4.7.6 MODBUS Address Coil (0xxxx) / (1xxxx) Address Function Initial Value 00001~00016 DI CH0~CH15 Input Status All 0 10001~10016 (0x0000~0x000F) 00033~00048 DI CH0~CH15 Latch High Value All 0 (0x0020~0x002F) 00065~00080 DI CH0~C15 Latch Low Value...
  • Page 154 Wolf Series RS-485 Remote I/O Module 44097 Firmware version 2 Bytes 0x1000 High Byte Low Byte Main version Sub-version 44098~44105 Module name 16 Bytes (16 ASCII char) (0x1001~0x1008) 44106 Modbus response delay time (unit: ms) R/W 0 (0x1009) Range: 0~30...

  • Page 155: Chapter 5. Faq

    If the host is a PC with Windows Operation System installed, user can execute Utility software to check the availability of I/O module. (please download the software via Advanio official site. http: //www.advanio.com) . Setup the module into INIT mode, and have it communicate with the following parameters: address number 01, serial transmission rate is 9600bps, no parity bit and the communication protocol is Modbus.

  • Page 156: Read Data

    Wolf Series RS-485 Remote I/O Module 5.2 Read data If data collected from I/O module are abnormal, perform the following steps to check it: Abnormal data read may be resulted from the abnormal parameter storage in Memory, please use Utility software to check it or reset it to INIT mode.

  • Page 157: Chapter 6. Technical Support

    Wolf Series RS-485 Remote I/O Module Chapter 6. Technical support If any problem encountered during the application, please look up the user manual or contact us via Advanio website. Email: service@advanio.com Website: http://www.advanio.com Before Contacting our Technical Support, please prepare information as follows: 1.
