Carmelli NG2325B Assembly Instructions Manual

Bounceback 9' table tennis
Hide thumbs Also See for NG2325B:

Advertisement

Quick Links

Download this manual
BOUNCEBACK 9' TABLE TENNIS
ASSEMBLY INSTRUCTIONS
NG2325B

Advertisement

loading
Need help?

Need help?

Do you have a question about the NG2325B and is the answer not in the manual?

Questions and answers

Related Manuals for Carmelli NG2325B

Summary of Contents for Carmelli NG2325B

  • Page 1 BOUNCEBACK 9' TABLE TENNIS ASSEMBLY INSTRUCTIONS NG2325B...
  • Page 2 THANK YOU! Thank you for purchasing this product. We work around the clock and around the globe to ensure that our products maintain the highest possible quality. However, in the rare instance that your product is defective or missing parts, contact your retailer, or call 800-759-0977, to submit parts requests or warranty claims.
  • Page 3 PARTS IDENTIFIER (NOT TO SCALE) ADDITIONAL EQUIPMENT REQUIRED: Please see Parts List at end of manual for part number when ordering parts. For replacement parts please call 800-759-0977.

  • Page 4: Assembly Tips

    ASSEMBLY TIPS 1. Find a clean, level surface to begin the assembly of your game table. The table will be partially assembled upside down and then turned over onto its legs. This is a heavy game and turning it over will require at least two strong adults. 2.
  • Page 5 ASSEMBLY INSTRUCTIONS 1. Unfold the outer (player end) pre-assembled leg to a straight upright position. 2. Attach the INNER (center end) LEG, #19, to the backside of the TABLE SURFACE, #1 and #2, with METAL BRACKETS, #8, using SCREWS, #5, in pre-drilled holes. Note: The Metal Bracket’s slot opening needs to point in the same direction as the other leg assembly (toward center end) with both Leg Pins in slots.
  • Page 6 ASSEMBLY INSTRUCTIONS (CONT.) 4. Thread LOCKING CASTERS, #11 onto the INNER LEG, #19, as shown. Attach the PLASTIC PLATE WITH STEEL FRAME, #3, to the INNER LEG, #19, with BOLTS, #13, and WASHERS, #7. 5. Carefully turn the two table surfaces over and attach the PLASTIC PLATE WITH STEEL FRAME, #3, to the opposite table leg, as shown, with BOLTS, #13, and WASHERS, #7.
  • Page 7 THANK YOU! ASSEMBLY INSTRUCTIONS (CONT.) 6. Attach the SAFETY LOCKS, #4 to the INNER LEGS, #19, with BOLTS, #10, WASHERS, #7, BUSHINGS, #9, and NUTS, #12, as shown below. Note: The Bushing will be positioned between the Safety Lock and the Leg. Safety Lock Assembly #7 #12 Outside...

  • Page 8: Care And Use

    CONGRATULATIONS! You have now assembled your Game Table. Please note the Care and Use instructions below to ensure years of trouble free use of your game table. CARE AND USE 1. This product is intended for INDOOR use only. 2. Do NOT sit, climb or lean on the table. 3.

  • Page 9: Year Limited Warranty

    1-YEAR LIMITED WARRANTY This product is warranted to the original purchaser to be free from defects in material or workmanship for a period of one year from the date of the original retail purchase. This warranty does not cover defects or damage due to improper installation, alteration, accident or any other event beyond the control of the manufacturer.
  • Page 10 9’ BOUNCEBACK TABLE TENNIS - NG2325B Parts List PARTS #1 NGP5931 #2 NGP5932 #3 NGP5933 #4 NGP5934 #6 NGP5935 #8 NGP5936 #11 NGP5937 LOCKING TABLE SURFACE SAFETY LOCK LINKAGE TUBE METAL BRACKET TABLE SURFACE LEG PANEL CASTER #14 NGP5938 #17 NGP5939...
