Breukhoven BMS 2 series Manual

Compound, monocular microscope

Advertisement

1: Scope of delivery (numbers refer to the photo on page 5):
1) Eyepiece WF 10x, with pointer
2) Monocular tube
3) Fixation screw to secure eyepiece
4) Microscope head, with prism. 360 º rotatable
5) Full metal stand
6) Full metal base with electrical parts and main lead.
7) Nose piece, revolving. Depending on model either triple or quadruple
8) Objectives, DIN Achromatic (with plastic containers)
4x/N.A. 0,10
10x/N.A. 0,25
40x/N.A. 0,65 spring loaded
100x/N.A. 1,25 spring loaded, oil immersion (only in models with quadruple
nose piece)
9) Coarse adjustment with slip clutch
10)Tension adjustment on coarse knob (9)
11)Fine adjustment
12)Fuse
13)On-off switch
14)Lamp house with condenser lens
15)Iris diaphragm adjustable to 100% opening. Abbe condenser N.A. 1,25 (only
in models with quadruple nose piece)
16) Fixed condenser lens N.A. 0,65 (only in models with triple nosepiece).
17)Filter holder
18)Blue filter
19) Stage
20) Stage clips (stainless steel)
21) Adjustable slide protection
22)Wrench, to adjust tension on coarse adjustment (9)
23) Dust cover
Manual for compound,
monocular microscope
The compound microscope allows you to study,
at cell level, structures and textures of botanical
and zoological nature. (e.g. slides of roots,
leaves and stems or blood, skin and hairs).
Depending on the chosen microscope, the total
magnification lies between 40-1000 times. By
using different accessories, this magnification
can be expanded.
Always disconnect mains plug from power point
before maintenance
Applicable for: BMS 2, BMS 100 and BMS 200
series.
For article numbers, see below.
