- Page 1 VN210 RF Modem User’s Manual Version 1.2 Created: May 18, 2009 Modified: Sept 2, 2009...
-
Page 2: Revision History
User Manual Revision History Date Revision Description Author 05/18/2009 Document Creation Szabolcs Zigovszki 08/24/2009 Include new antennas Edward Castro 09/02/2009 Changed section 6 Edward Castro Proprietary & Confidential Version 1.1... - Page 3 Table of Contents Purpose of Document .................... 1 Overview of the Radio Modem Hardware ............. 1 Operation of the Nivis Radio Modem ..............4 3.1. Getting started ...................... 4 4. RF Exposure Limit Warning ..................4 5. Compliance Statement (Part 15.19) ................. 4 6.
-
Page 4: Purpose Of Document
2. Overview of the Radio Modem Hardware The VN210 radio modem is an 802.15.4 wireless module that allows communication using a standard asynchronous serial data stream. The pin-out of the VN210 radio modem is presented in the figure below. Proprietary & Confidential Page 1 version 1.0... - Page 5 User Manual Name Description Type Comments UART2-RTS UART2 Request to Send Can be configured as GPIO UART2-CTS UART2 Clear to Send Can be configured as GPIO UART2-RXD UART2 Receive Data Can be configured as GPIO UART2-TXD UART2 Transmit Data Can be configured as GPIO UART1-RTS UART1 Request to Send Can be configured as GPIO...
- Page 6 User Manual ADC0 ADC pin 0 Analog Can be configured as GPIO ADC2-VREFH ADC2 reference, high pin Analog Can be configured as GPIO ADC2-VREFL ADC2 reference, low pin Analog Can be configured as GPIO Ground Supply voltage Ground RESET RESET pin JTAG-RTCK JTAG Return Clock / Can be configured as GPIO...
-
Page 7: Operation Of The Nivis Radio Modem
RX and TX lines. 3. Operation of the Nivis Radio Modem Communication with the VN210 radio modem happens through serial port 1. The baud- rate is set to be 115200, 8N1. 3.1. Getting started Open a terminal software on a serial port with the above settings and connect to the RF modem. -
Page 8: Oem Responsibility
User Manual 6. OEM Responsibility Only the approved antennas, which have been certified with this module should be used. The approved antennas are: ANT-2.4-CW-RCT-RP Linx Technologies (2.2 dBi) ANT-N-5 Mini-Box (5.5 dBi) FS1-F9915KB Yokogawa (2.0 dBi) 7. Warning (Part 15.21) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
