Summary of Contents for Da-Lite SCB-100
- Page 1 POWER PRESENTATION PRODUCTS Installation and Operating Instructions For DA-LITE SCREEN COMPANY, INC. 3100 North Detroit Street Post Office Box 137 SERIAL CONTROL BOARD SCB-100 Warsaw, Indiana 46581-0137 Phone: 574-267-8101 800-622-3737 Fax: 574-267-7804 www.da-lite.com e-mail: info@da-lite.com...
- Page 2 This manual covers installation for both the external SCB-100 and the built-in SCB-100. If you have the external SCB -100, refer to diagrams 1, 2 and 3 for wire connections. If your screen has the SCB-100 built into the screen case, refer to diagram 4 for wire connections.
- Page 3 Screen Motor The SCB-100 has two motor outputs. This allows control of two screens or a screen and a projector lift independently. 1. Connect the motor wires in the screen junction box to the SCB-100 as shown in diagram 2.
- Page 4 2. Use 3-conductor 20-24 gauge wire to extend the switch wire to the required length. 12VDC Out The SCB-100 supplies power to the optional NET-100 network adaptor. If you are using the NET-100 adaptor, connect the power wire from the NET-100 to the 12VDC output terminal.
