Summary of Contents for Enustech BHF-500
- Page 1 1. Getting Started 1) Connection, Battery, FM Status 2) Microphone 3) Multi-function button 4) FM/TTS Button 5) Volume Up Button 6) Volume Down Button 7) Charging Port 8) Speaker 2. Charging the Product Be sure to use the vehicle charger and USB charger cable provided.
- Page 2 (or TTS Message: Pairing succeeded). 3) Find the product (BHF-500) by using device find function on the mobile phone. 4) Enter the passkey 0000 on your mobile phone.
- Page 3 Power Off: Push the multi-function button of the product for 4 seconds to turn it off. 2) Connection To connect between the product and mobile phone, quick press on the Multi- function button. 3) Call Functions *Answer a call: Push with one quick press on the multi-function button. *End a call: Push with one quick press on the multi-function button.
- Page 4 9) Mute / Un-mute Hold down the Volume Down button for 1 second during the call. In this case, you will be able to hear the other person but they won’t be able to hear you. To un- mute the call, hold down the Volume Up or Volume Down button. 10) Remove a registered mobile phone name from a list.
- Page 5 13) Tuning a FM Frequency When the product is in FM Tuning mode, select 7 frequencies saved by pushing Volume Up and Volume down button. This function is operated only after exiting the selection mode. 15) Scanning one from available FM Frequency To save the frequency available, press on the FM/TTS button for 4 seconds while the product is paired with mobile phone.
- Page 6 1. Handsfree Status indication Hands free status LED indication Standby/Idle Connection LED blinks every 2 seconds connected Connection LED lights on continuously. Incoming call Call Status LED blinks every 1 second. Active call Call Status LED lights on continuously. 2. FM Transmitter indication. FM transmit state LED indication No transmit...
- Page 7 - Additional Page - Cautions Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance Information This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2.
