610
MODEL
NAILER
INSTRUCTION MANUAL AND SAFETY INSTRUCTIONS
DANGER
Improper and unsafe use of this Nailer will result in death or serious injury!
This Manual contains important information about product safety.
Read and understand this Manual before operating the Nailer.
Keep this Manual available for others before they use the Nailer.
Advertisement
Table of Contents
Summary of Contents for ET&F 610
- Page 1 MODEL NAILER INSTRUCTION MANUAL AND SAFETY INSTRUCTIONS DANGER Improper and unsafe use of this Nailer will result in death or serious injury! This Manual contains important information about product safety. Read and understand this Manual before operating the Nailer. Keep this Manual available for others before they use the Nailer.
-
Page 2: Table Of Contents
FOR USING NAILERS ............ 3 TESTING THE NAILER ............9 IMPORTANT SAFETY INSTRUCTIONS FOR USING ADJUSTING AIR PRESSURE .......... 10 MODEL 610 ..............5 LOADING PINS ..............10 EMPLOYER’S RESPONSIBILITIES ........5 NAILER OPERATION ............. 12 METHODS OF OPERATION ..........12 OPERATION ADJUSTING THE FASTENING DEPTH ...... -
Page 3: Safety
SAFETY IMPORTANT SAFETY INSTRUCTIONS MMMMFOR USING NAILERSMMlMM READ ALL INSTRUCTIONS DANGER 1. ALWAYS WEAR EYE PROTECTOR. When operating the Nailer, always wear eye protector, and make sure others in work area wear eye protector, too. Eye protector must conform to the requirements of American National Standards Institute, ANSI Z87.1 and provide protection against flying particles both from the front and side. - Page 4 7. STORE NAILER PROPERLY. 16. KEEP HANDS AND FEET AWAY FROM FIRING HEAD DURING USE. When not in use, the Nailer should be stored in a dry place. Keep out of reach of children. Lock the storage Never place your hands or feet closer than 8 inches area.
-
Page 5: Important Safety Instructions For Using Model 610
IMPORTANT SAFETY INSTRUCTIONS FOR USING MODEL 610 WARNING 1. DO NOT REMOVE DUST COVER. 3. DO NOT OPEN MAGAZINE FACING DOWN- WARD WHILE LOADING FASTENERS. -
Page 6: Operation
OPERATION NOTE: The information contained in this Manual is designed to assist you in the safe operation of the Nailer. Some illustrations in this Manual may show details or attachments that differ from those on your own Nailer. NAME OF PARTS Top Cover Exhaust Cover Trigger... -
Page 7: Specifications
SPECIFICATIONS Operating pressure 70 – 120 psi (4.9 – 8.3 bar 5 – 8.5 kgf/cm 11-1/16" × 11-7/8" × 5-1/8" Dimensions Length (without air plug) × Height × Width (281 mm × 302 mm × 130 mm) Weight 5.9 lbs (2.7 kg) Pin capacity 200 –... -
Page 8: Accessories
ACCESSORIES WARNING Never connect Nailer to pressure which potentially WARNING exceeds 200 psi (13.7 bar 14 kgf/cm Never use non relieving coupler on Nailer. Accessories other than those shown below can 1. Power source lead to malfunction and resulting injuries. Use only clean, dry, regulated compressed air as a STANDARD ACCESSORIES power source for this Nailer. -
Page 9: Lubrication
Air consumption table TESTING THE NAILER Operating pressure (bar) (5.5) (6.2) (6.9) (kgf/cm (5.6) (6.3) DANGER /cycle .042 .045 .052 Air consumption (ltr/cycle) (1.2) (1.3) (1.5) Air compressor size formula Amount of air required =number of Nailers × average pins driven each minute per Nailer ×... -
Page 10: Adjusting Air Pressure
(2) Adjust the air pressure to 70 psi (4.9 bar 5 kgf/cm according to the length of pins and the thickness of steel Connect the air hose. substrate workpiece. Do not load any pins in the Nailer. The correct air pressure is the lowest pressure which will do the job. - Page 11 For sheet-collated pins NOTE: Before loading pins in the magazine, adjust the The heads of the row of pins and the upper extent of the nail holder. If the magazine cover is forcibly closed collating sheet are inserted at guide slot 2 (the lower without adjusting the nail holder correctly, the nail slot).
-
Page 12: Nailer Operation
Label showing the pitch of pins Never drive pins from both sides of a wall at the same time. Pins can be driven into and through the wall and hit a person on the opposite side. Never use Nailer which is defective or operating abnormally. -
Page 13: Adjusting The Fastening Depth
possibility of bodily injury to you or others in the work Too Shallow Turn Adjuster Flush area. This is because it is less likely to drive an un- wanted pin if you keep the trigger pulled and acciden- tally bump the push lever against yourself or others. NOTE: Always handle pins and package carefully. -
Page 14: Maintenance
MAINTENANCE NOTE: The information contained in this Manual is designed to assist you in the safe maintenance of the Nailer. Some illustrations in this Manual may show details or attachments that differ from those on your own Nailer. MAINTENANCE AND INSPECTION 2. -
Page 15: Service And Repairs
Nail Stopper (A) SERVICE AND REPAIRS Shaft WARNING Nail guide Only service personnel trained by ET&F, distributor or employer shall repair the Nailer. Nail Stopper (B) Use only parts supplied or recommended by ET&F for repair. All quality Nailers will eventually require servicing or replacement of parts because of wear from normal use. - Page 16 Maintenance chart ACTION Drain air line filter daily. Prevent accumulation of moisture Open manual petcock. and dirt. Keep lubricator filled. Keep the Nailer lubricated. Fill with pneumatic tool lubricant. Clean filter element — then blow Prevent clogging of filter with dirt. Follow manufacturer’s instructions.
- Page 17 — 17 —...
-
Page 18: Parts List
— 18 —... - Page 19 76 610-877371 Nylon Nut 13 610-880513 Retaining Ring 77 610-880133 Magazine 14 610-874104 Cylinder O-Ring (I.D 68.3) 78 610-872971 Retaining Ring (E-Type) For D3 Shaft 15 610-880512 Cylinder Plate 79 610-877149 Stopper Spring 16 610-878961 O-Ring 80 610-880146 Magazine Stopper...
- Page 20 29019 Solon Road Solon, ohio 44139 Code No. C99107062 Printed in Japan...
