Cubic COM5000-8 Instruction And Maintenance Manual

Hf-ssb 5-kw linear power amplifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
351804-1 Rev. 100
COM5000-8 TECHNICAL MANUAL
Instruction and Maintenance Manual
COM5000-8
HF-SSB 5-kW Linear Power Amplifier
THIS DOCUMENT CONTAINS DATA WHICH IS PROPRIETARY TO, OR A TRADE SECRET OF, CUBIC
DEFENSE APPLICATIONS, INC. THIS DOCUMENT AND THE DATA CONTAINED THEREIN SHALL
NOT BE USED, DUPLICATED, DISCLOSED OR ALTERED WITHOUT THE EXPRESS WRITTEN CONSENT
OF CUBIC DEFENSE APPLICATIONS, INC. NO RIGHT, TITLE, OR INTEREST IS GRANTED, EXPRESSLY
OR BY IMPLICATION, IN OR TO ANY DATA CONTAINED HEREIN BY VIRTUE OF ITS DISCLOSURE
TO OR USE BY THE HOLDER/RECIPIENT. DISCLOSURE MAY NOT BE MADE TO ANY THIRD
PARTY FOR ANY PURPOSE. ALL STATUTORY AND COMMON LAW RIGHTS ARE HEREBY RESERVED.
Cubic Defense Applications, Inc.
9333 Balboa Ave
San Diego, CA. 92123
Telephone: (858) 505-2024
Telefax (858) 505-1593
Manual Part No. 351804-1
