Overview
The GO2NFC141U NFC Reader is contactless smart card reader/writer developed based on the 13.56 MHz
Contactless (RFID) Technology. Unlike other NFC readers/writers, GO2NFC141U is very compact and
small.
GO2NFC141U is a plug-and-play USB device. It is compatible with different devices and applications.
Compliant with the ISO/IEC18092 standard for Near Field Communication (NFC), it supports not only Mifare
and ISO 14443 A and B cards but also all four types of NFC tags. It also could pushes or pulls data with
Android NFC phone. Although in a small size, the proximity operating distance of GO2NFC141U is 5 cm.
With an access speed of up to 424 kbps and a full USB speed of up to 12 Mbps, GO2NFC141U can also
read and write quickly and efficiently, depending on the type of contactless tag in use.
Software for GO2NFC141U is available for both Windows OS and Linux. Most important, the software is
open source, totally free for any changing and usage. The software contains operation function such as
reading/writing card, pushing URL to Android phone, pulling message from Android phone.
The GO2NFC141U NFC Reader is ideal for access control, e-payment, e-ticketing for events and mass
transit, toll road fare collection and network authentication.
Feature
GO2NFC141U Standard Features:
USB 2.0 Full Speed Interface
Smart Card Reader:
Read/write speed up to 424 kbps
Built-in antenna for contactless tag access, with card reading distance of around 50 mm (depending
on tag type)
Supports ISO 14443 Type A and B cards, Mifare, FeliCa, and all 4 types of NFC (ISO/IEC 18092)
tags
Supports pushing/pulling data with Android NFC phones
Very small size
User-controllable buzzer
HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED
GO2NFC141U NFC Reader
Mode: G141U

Advertisement

loading
Need help?

Need help?

Do you have a question about the GO2NFC141U and is the answer not in the manual?

Questions and answers

Summary of Contents for HK ELECHOUSE ELECTRONICS GO2NFC141U

  • Page 1 Android NFC phone. Although in a small size, the proximity operating distance of GO2NFC141U is 5 cm. With an access speed of up to 424 kbps and a full USB speed of up to 12 Mbps, GO2NFC141U can also read and write quickly and efficiently, depending on the type of contactless tag in use.

  • Page 2: Typical Applications

    HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Typical Applications  e-Government  Banking & Payment  Network Security  Access Control  e-Purse & Loyalty  Transportation Technical Specifications Dimensions 46.0mm (L) * 48.5mm (W) * 10.5mm (H) Weight 20 g (without USB cable)
  • Page 3 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Architecture Software Users could download the software through the following link: http://www.go2nfc.com/download/ Mobile phone users could scan the following code.
  • Page 4 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Operation Guide Windows Connect GO2NFC device with your computer with micro USB cable. Install the driver from “Device manager”. You could find the “DRIVER” folder which contains the driver in the software files. If the driver was installed well, you could find a COM port for this device.
  • Page 5 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Click the button “Refresh”. The software will find the COM ports available. Choose the right COM port and then click “Open”. Information will be shown at the bottom. Read card information Click the button “ReadID”.
  • Page 6 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Put a valid card on the device. You could get the card ID. Check the “VERBOSE”. It could read back more information.
  • Page 7 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED...
  • Page 8 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Read/Write the data stored in the card The following buttons controls data reading or writing To write/read data into the card, you need to read the data structure of the card. Choose the Block/Sector you want to operate.
  • Page 9 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Click the button “WriteBlock” and pop up new dialog...
  • Page 10 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED In the new dialog, users could read or write data. Block 3 is usually used to store password. Becareful if you want to write it. NFC with Phone The software also contains function to push/pull URL with phone.
  • Page 11 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Click the NDEF card On your smart phone, set the NFC function in the right way. Start a browser and visit a website such as www.google.com Click “Pull” button.
  • Page 12 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Within 5 seconds, put your phone on the device. On the phone, the browser would room in. Click it. The URL in the browser would be pushed to the software on PC.
  • Page 13 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED Input an URL (such as www.google.com) in the text box behind the button “Push”. Click the button “Push”. Put a phone on the device. The browser would pop up and open the website. Linux Download qt-linux-opensource-5.x.x-x86-offline.run...

  • Page 14: Fcc Compliance Statement

    HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED libfreefare autoreconf -vis ./configure --prefix=/usr make sudo make install libllcp autoreconf -vis ./configure --prefix=/usr make sudo make install libndef qmake mingw32-make lib files locate at libndef/libndef/release/, named libndef1.a and ndef1.dll, libndef/include/*.h is also needed.
  • Page 15 HK ELECHOUSE ELECTRONICS TECHNOLOGY CO., LIMITED If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...
