RF Serial Data Link
UART - 2.4 GHz
Easily transfer serial data over 2.4 GHz RF with these reliable RF
modem. Enables transparent bi-directional communication for
microcontroller & computer for wireless data logging and sensor
reading.
A quality product, proudly made in India by
http://www.sunrom.com/m/1418
Electronics
Sunrom Part#
1418
User's
Manual
Doc Version: 1
22-Mar-16
Advertisement
Table of Contents
Summary of Contents for Sunrom RF Serial
- Page 1 RF Serial Data Link Sunrom Part# 1418 UART - 2.4 GHz Easily transfer serial data over 2.4 GHz RF with these reliable RF User's modem. Enables transparent bi-directional communication for Manual microcontroller & computer for wireless data logging and sensor reading.
-
Page 2: Table Of Contents
1418 RF Serial Data Link UART - 2.4 GHz Table of Contents Introduction ............................ 3 Typical Application ......................... 3 Features ............................3 Applications ............................ 4 Interfacing with Microcontroller or USB-UART TTL..............4 Specifications ..........................5 Module Pin Details.......................... 5 Board Schematic ..........................6 Top Side Component Layout ......................7... -
Page 3: Introduction
1418 RF Serial Data Link UART - 2.4 GHz Introduction This is a RF data modem working at 2.4 GHz frequency in half duplex mode with automatic switching of receive/transmit mode with LED indication. Receives and Transmits serial data of adjustable baud rate of 9600/115200 bps at 5V or 3V level for direct interfacing to microcontrollers. -
Page 4: Applications
1418 RF Serial Data Link UART - 2.4 GHz Applications • Sensor Networks / Data collection • Wireless metering • Access control / Identity discrimination • IT home appliance • Smart house products / Security Systems • Remote control / Remote measurement system •... -
Page 5: Specifications
1418 RF Serial Data Link UART - 2.4 GHz Specifications Parameter Value Working Voltage 3.3V to 5V DC regulated power supply Current Consumption 25 mA Frequency of Operation 2.4 GHz Serial Baud rate 9600 bps or 115200 bps depending on jumper setting Baud rate format 8-N-1;... -
Page 6: Board Schematic
1418 RF Serial Data Link UART - 2.4 GHz Board Schematic STM8S003F3 nRF24L01+ 100n NRST MISO NRST SPI_MISO/PC7 MOSI SPI_MOSI/PC6 MOSI SPI_SCK/PC5 MOSI MISO SWIM MISO 100n I2C_SCL/PB4 TLED I2C_SDA/PB5 VCAP PD5/TX PD6/RX RLED SWIM 662K 1uF 1206 SWIM NRST... -
Page 7: Top Side Component Layout
1418 RF Serial Data Link UART - 2.4 GHz Top Side Component Layout Page 7/10 Doc Version: 1 22-Mar-16 http://www.sunrom.com/m/1418... -
Page 8: Jumper Settings
1418 RF Serial Data Link UART - 2.4 GHz Jumper Settings Frequency Channel There are two jumpers to set frequency channel of operation. If you want to operate multiple pairs on same premises without interfering with each other you can set this frequency channel selection jumper. -
Page 9: Product Dimensions
1418 RF Serial Data Link UART - 2.4 GHz Product Dimensions Board Dimensions in mm Page 9/10 Doc Version: 1 22-Mar-16 http://www.sunrom.com/m/1418... -
Page 10: Support
Disclaimer Sunrom Electronics assumes no responsibility or liability for any errors or inaccuracies that may appear in the present document. Specification and information contained in the present schematic are subject to change at any time without notice.
