The Land of Nod Street Vendor Cart Assembly Instructions

Street Vendor Cart

This page lists the contents included in the box. Please take

time to identify the hardware as well as the individual

components of the product. As you unpack and prepare for

assembly, place the contents on a carpeted or padded area

to protect them from damage. Please follow the assembly

instructions closely. Improper assembly can result in

personal or property damage.

Note: 2 adults are required to safely assemble this product.

WARNING:

CHOKING HAZARD - SMALL PARTS

Small parts present in unassembled state.

Adult assembly required.

24 - Small

bolts

8135 River Drive • Morton Grove, IL 60053 • p: (800) 933-9904 • e: customerservice@landofnod.com • www.landofnod.com

Assembly Instructions

2 - Large

2 - Hex

bolts

nuts

1- Large

1 - Small

Allen wrench

2 - Flat

2 - Wheel

washers

caps

1 - Hex

wrench

4 - End

caps

Table of Contents

Need help?

Do you have a question about the Street Vendor Cart and is the answer not in the manual?

Page 1 Street Vendor Cart Assembly Instructions This page lists the contents included in the box. Please take time to identify the hardware as well as the individual components of the product. As you unpack and prepare for assembly, place the contents on a carpeted or padded area to protect them from damage.
Page 2 Street Vendor Cart Assembly Instructions 1 - Right 1 - Left 1 - Shelf 1 - Bottom frame frame frame frame 3- Large 5 - Small 1 - Awning 2 - Wheels poles poles 4 - Reversible signs 8135 River Drive • Morton Grove, IL 60053 • p: (800) 933-9904 • e: customerservice@landofnod.com • www.landofnod.com...
Page 3 Street Vendor Cart Assembly Instructions Attach 5 small poles and 3 large poles to left side frame with 8 small bolts as shown. Secure, but do not over tighten, bolts with a small Allen wrench. At this point, attach right side frame to frame assembly with 8 small bolts.
Page 4 Street Vendor Cart Assembly Instructions detail on the other side of the tire Insert 1 large bolt into 1 wheel as shown. On the other side of the wheel, thread 1 ﬂat washer and 1 hex nut onto the large bolt. Using the large Allen wrench, hold the large bolt in position and fasten hex nut with a Hex wrench.
Page 5 Street Vendor Cart Assembly Instructions Fit wheel cap over each wheel as shown. Press ﬁrmly to secure. awning sign NOTE: Signs are reversible Attach 4 signs onto frame assembly using Hook and Loop fasteners to secure. Fit awning over top of frame assembly.
