Summary of Contents for Real-HD technology RHDMX0404
- Page 1 U S E R M A N U A L 4x4 HDMI Matrix Model No:RHDMX0404 Enjoy the vivid world !
- Page 2 INTRODUCTION Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of HDMI switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient ,more comfortable, more productive and more cost- efficient.
- Page 3 The accessories with the machines lists as picture： 1、5V Power Adaptor 2、Remote 3、one pc of Manual Power Adaptor Remote Physical Connection Showing Picture： Figure 1.0 Front Panel Showing Picture Input 1- Input 4: HDMI input led status light IR : IR receiver LCD: Digital Tube Showing...
- Page 4 Connect one cable from each HDMI source devices into HDMI Matrix inputs. Connect one cable from each display (monitor or projector) into the HDMI Matrix outputs. Connect 5V power supply to the HDMI 4x4 Matrix. Alternatively, use an RS-232 control system to switch between sources. SPECIFICATIONS: RHDMX0404...
- Page 5 HDMI version………………………………………………………………………….. HDMI 1.3b HDCP version…………………………………………………………………………..HDCP1.2 HDMI resolution ………………………..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i Support video color format …………………………..…………….24bit/deep color 30bit,36bit Support audio format……………….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD Max bandwidth…………………………………………………………………………….225MHz Max baud rate…………………….………………….…………………………………..6.75Gbps Input/Output TMDS signal ………….…………………………..………...0.5~1.5Volts p-p(TTL) Input/Output DDC signal ……………………………………………..………… 5Volts p-p (TTL) Input cable distance..…... ……………………….…..≤15m AWG26 HDMI 1.3 standard cable Output cable distance…………………………….…...≤25m AWG26 HDMI 1.3 standard cable Max working current…………………………………………………………………………...2.6A Power adapter format………………..Input:AC (50HZ, 60HZ) 100V-240V;...
- Page 6 Binary Table Note ASCII Select Byte output 0x00 0x01 send out the 2 bytes circularly, the valid input will be sent to 0x00 0x02 corresponding output port 0x00 0x04 orderly 0x00 0x08 RS-232 Setting: Bits per second ......................9600 Data bits ........................8 Stop bits ..........................1 CRC bits………………………………………………………………………………………None Flow Control ......................
- Page 7 2. All parts will be free from the strong shake, hit, fall. 3. Touching the power adaptor with the wet hands is prohibited. 4. Pls hold the power adaptor head and do not pull the power cord when cut off from the socket.
