Summary of Contents for Rotary Gate Systems SL-1000 R
- Page 1 RESIDENTIAL / LIGHT COMMERCIAL SLIDE GATE OPERATOR ROTARY GATE SYSTEMS, INC. ALL RIGHTS RESERVED 2008 REV. 1.1 1-877-331-4RGS (4747)
- Page 2 INTRODUCTION The Rotary Gate Systems SL -1000 R slide gate operator has been designed to be the most reliable and easiest to install product in its field. The straight forward, compact design ensures that this will be the operator of choice for installer, s ervice technicians and customer alike.
-
Page 3: Table Of Contents
Table of contents Pre-Installation Information …………………………………..4 Dual Gate Installations ……………………………………….22 Before you begin Gate Operation…………………………………………………22 Always check the gate’s action Open button Gate operator classifications Close button Approved obstruction detection device Stop button Safety Information and Warnings ……………………………..4 Single input Regulatory warnings Fire department input Wiring specifications ……………………………………………5... -
Page 4: Pre-Installation Information
Pre-installation Information Safety Information and Warnings Before you begin… FOLLOWING FORMATS USED Before unpacking, inspect the carton for exterior damage. If SAFETY NOTES IN THESE INSTRUCTIONS. you find damage, advise the delivery carrier of a potential claim. Inspect your package carefully . Claims for shortages will be honored for only 30 days from the date of shipment. -
Page 5: Wiring Specifications
-in surge and lightning protection circuitry to work effectively. All ROTARY GATE SYSTEMS gate operators are supplied with a power disconnect switch to turn on and off the power available to the operators. Following wiring specifications below, incoming power should be brought into the operator and connected to the appropriate wires from the disconnect box. -
Page 6: Safety Information
Safety Information Gate system designers, sellers, installers, tec hnicians, and users should familiarize themselves with the proper layout designs required to ensure the safe operation of the gates and any accessories associated with them. Any gate system design must include safety devices of sufficient quantity and plac ement to protect the customer, the general public and technicians working on the system from potential harm. -
Page 7: Access Control Devices
Access Control Devices The SL-1000 R is compatible with any type of access control device which provides a dry contact relay for activation. Installation Figure 2. Gate and Post Layout... - Page 8 Figure 3.
-
Page 9: Mounting Operator
General The SL-1000 R control box is separate from the operator to allow for easy mounting in a convenient location and to al low for locating it on columns or walls up to 25 feet away from the gate with the proper wire . -
Page 10: Limit Switch And Magnet Switch Installation
Option 2: Remote Mounting If mounting the SL-1000 R control box remotely from the gate, run wires from the control box for the operator motor, limit switches, photo beams, loops and opening accessories. AC power and low voltage wiring should always be installed in separate conduits. - Page 11 WHIP ANTENNA ANTENNA CONNECTOR OPERATION AND POWER OPERATION PROGRAMMING INDICATORS BUTTONS INDICATORS DISPLAY PROGRAMMING SOLAR BUTTONS PANEL TERMINALS INPUT POWER MOTOR TERMINALS BOARD COVER ACCESSORY POWER TERMINALS BATTERY TERMINALS RESET BUTTON TERMINALS PRIMARY/ PLUG-IN SECONDARY LOOP COMM LINK DETECTOR TERMINALS CONNECTORS SINGLE INPUT...
-
Page 12: Indicator Descriptions
Indicator Descriptions INDICATOR DEFINITION INDICATION WHEN LIT INDICATION WHEN LIT DURING NORMAL OPER ATION DURING PROGRAMMING OPERATION PROGRAMMING 24 VOLT INPUT LOW VOLTAGE AC POWER IS PRESENT POWER 24 VOLT DC LOW VOLTAGE DC POWER IS PRESENT ACCY POWER OPEN SIGNAL PRESENT FROM THE INTERNAL RECEIVER OR AN EXTERNAL DEVICE OPEN CONNECTED TO THE OPEN INPUT TERMINAL... -
Page 13: Terminal Descriptions
Terminal Descriptions TERMINAL GROUP FUNCTION AC N FACTORY CONNECTED TO 24 VAC FROM TRANSFORMER OR 24 VDC FROM CONTINUOUS DUTY DC SUPPLY. 24 VOLT INPUT DC - ACCESSORY POWER PROVIDES 24 VOLT DC POWER FOR ACCESSORIES. DC + RESET RESET BUTTON FACTORY CONNECTED TO THE CONTROLLER’S RESET BUTTON. -
Page 14: Operator Accessory Connections
Operator Accessory Connections 3-BUTTON STATION TELEPHONE ENTRY PHOTOEYE FOR REVERSE KEYPAD KEYSWITCH PHOTOEYE FOR CLOSE OBSTRUCTION FIRE ACCESS SWITCH SOLENOID LOCK EXTERNAl POWER PHOTOEYE FOR OPEN OBSTRUCTION SINGLE-CHANNEL RADIO RECEIVER MAGLOCK GATE EDGE SENSOR FOR REVERSE TWO CHANNEL RADIO RECEIVER WARNING STROBE OR AUDIBLE SOUNDER CHANNEL #1 OPEN/CLOSE... -
Page 15: Field Wiring Description
FIELD WIRING LAYOUT THE FOLLOWING TERMINALS ARE LABELED FOR FIELD CONNECTION: 24 VAC/DC Factory connection of transformer power wires. DO NOT CONNECT 110 VAC !. 110 VAC WIRES ARE UNDER TRANSFORMER. MOTOR Connect motor wires from SL -1000 R gate operator. LIMIT SWITCHES: Connect to the wires from the limit switches. -
Page 16: Basic Controller Programming
Basic Controller Programming PROGRAM INDICATOR Programming Overview DOWN The controller can be programmed with various options for the operator. The programming fields are defined as “functions” that have “options”. To make setup easier for PROGRAM INDICATOR PRESS DOWN AND WILL LIGHT WHEN the installer, the Controller’s programming is divided into UP BUTTONS SYSTEM IS IN... -
Page 17: Run Alarm And Pre-Start Alarm
Basic Controller Programming (Cont.) Run Alarm and Pre-start Alarm The factory default is Run alarm on and a 3 -second Pre-start Alarm. The operator’s beeper will sound 3 seconds before the operator starts. The options are: Run Alarm Off and Pre -start Alarm Off Run Alarm On and Pre -start Alarm Off Run Alarm On and Pre -start Alarm On for 3-9 seconds Maximum Open Direction Current Setting... -
Page 18: Entering Advanced Programming Mode
Advanced Controller Programming Entering Advanced Programming Mode To access and program the advanced Programming functions, for each programming session. Advanced Programming must be enabled. After exiting programming, the Advanced Programming functions will be available on the programming display during the next programming session unless the operator has run 50 or more cycles. -
Page 19: Auxiliary Relay Mode
Advanced Controller Programming (Cont.) Auxiliary Relay Mode The Auxiliary Relay in the SL-1000 R is not used to release the magnetic brake inside the operator as in the other RGS operators. The auxiliary relay has normally open and normally closed contacts. -
Page 20: Soft Start/Stop Duration
Advanced Controller Programming (Cont.) Soft Start/Stop Duration This function causes the operator to start and stop slowly, reducing wear and tear (at the full open or closed positions only). The factory default sets the Soft Start/Stop Duration to 3 seconds. NOTE: AFTER ADJUSTING THIS SETTING, THE OPEN (OC) AND CLOSE (CC) CURRENT SENSING SETTINGS WILL HAVE TO BE READJUSTED. -
Page 21: Radio Enable
Advance Controller Programming (Cont.) Radio Enable The controller contains a built in MegaCode® radio receiver to allow activation from up to 40 access control transmitters and two Model MGT (gate edge) transmitters. The factory default enables the internal radio receiver. Alternately, the internal receiver can be disabled. -
Page 22: Dual Gate Installations
Dual Gate Installations Gate Operation Two operators can be used in dual gate installations. Open Button The operators communicate with each other through the Opens the gate. If the controller is programmed to stop 3-wire COMM LINK terminals. opening the gate at mid -travel, a constant press of the OPEN button will override the Mid -travel Stop and completely open When one operator activates, the COMM LINK... -
Page 23: Operator Indications
If any MGT transmitters are used with the operator, their supervision feature will alert the controller if there is any trouble with the transmitter. MGT transmitters send hourly status Operation Indications reports and will send low battery reports when the transmitter During normal operation, the controller’s display will indicate has a low battery. -
Page 24: Troubleshooting
Troubleshooting Preventative maintenance Contacting Technical Support Always disconnect power from operator before For technical questions regarding ROTARY GATE SYSTEMS servicing. Keep clear of gate during operation. gate operators, please contact the Technical Support Department at 1-877-331-4747. General RGS gate operators are designed for many years of trouble -... -
Page 25: Warranty
Rotary Gate System, Inc. If the SL-1000 R requires service, contact the dealer who originally installed it. If that dealer is not available, call 1-877-331-4747 to be referred to a dealer in your area.
