- Page 1 APS-Arduino Shield Evaluation Board for the APS Stepper Motor Power Stage TRANSLATION OF THE GERMAN ORIGINAL MANUAL 9/2013 Manual MA 2120-A002 EN...
- Page 2 We appreciate suggestions and criticisms for further improvement. Email address: doku@phytron.de Questions about the use of the product described in the manual that you cannot find answered here, please contact your representative of phytron (http://www.phytron.eu/) in your local agencies. MA 2120-A002 EN...
-
Page 3: Information
1 Information This manual: Read this manual very carefully before mounting, installing and operating the device and if necessary further manuals related to this product. - Please pay special attention to instructions that are marked as follows: DANGER –... -
Page 4: Safety Instructions
Manual APS-Arduino Shield Observe the following safety instructions! Qualified personnel WARNING – Serious injury possible! Serious personal injury or serious damage to the machine and drives could be caused by insufficiently trained personnel! Without proper training and qualifications damage to devices and injury... - Page 5 WARNING – Serious injury from electric shock! If the APS module is not operated with SELV/PELV voltages, the risk of dangerous voltages may be on the device. Touching these components carrying high voltages can cause serious injury or death from electric shock: - Always observe the safety concept SELV / PELV to ensure safe insulation and separation of low voltage supplies from the mains.
-
Page 6: Table Of Contents
Manual APS-Arduino Shield 2 Contents 1 Information ......................... 3 2 Contents ........................6 3 Overview ........................7 4 Block Scheme ......................9 5 Technical Data ......................10 5.1 Mechanical Data ....................10 5.2 Transport and Storage ..................10 5.3 Features ....................... 11 6 Installation ........................ -
Page 7: Overview
3 Overview APS-Arduino Shield is an evaluation board for the application of the high performance APS stepper motor power stage (5 A at 24 - 70 V ) in research, prototyping, model PEAK making and art installations. Fig.1 APS-Arduino shield module with APS power stage (left) and Arduino board (right) •... - Page 8 Pins: 2x10 and 2x12 – Reset button Manuals available • Manual APS-Arduino shield (this manual) • Manual APS WARNING – Damage by wrong motor current setting! The power stage is set on delivery to a defined current value. Please check the adjusted current for the stepper motor before installation (see the motor data).
-
Page 9: Block Scheme
4 Block Scheme Fig.2 Block scheme Power supply voltage: The APS supply (24 – 70 V) is not connected to the Arduino supply. APS Arduino Shield requires its own power supply to supply the APS power stage! The Arduino is not supplied by the APS supply (24-70 V).There is no electrical isolation of the supplies. -
Page 10: Technical Data
Manual APS-Arduino Shield 5 Technical Data 5.1 Mechanical Data Dimensions 53 x 84 mm Weight with APS: 57 g without APS: 41 g Mounting pluggable on Arduino board 5.2 Transport and Storage Permissible transport and storage conditions: Transport and storage -40 to +70 °C... -
Page 11: Features
5.3 Features Operation/Connection Motor voltage supply 24 V to 70 V input range of supply of the power stage Analogue outputs (motor) A, B, C, D for a 2 phase stepper motor connected as a 4-lead stepper motor 6- or 8-lead stepper motors should be connected as a 4-lead stepper motor. -
Page 12: Installation
Manual APS-Arduino Shield 6 Installation 6.1 Mechanical Installation The APS is delivered as a single module board. Unpack the module carefully in ESD protected area only. Fig.1 Dimension in mm CAUTION – Possible damage by ESD! The module consists of sensitive electronic components that can be destroyed by electrostatic discharge voltages. - Page 13 CAUTION – Possible damage! The module is designed for a maximum supply voltage of 70 V . If it is supplied with >70 V the card might be damaged. - Make sure that a power supply is used with less than 70 V to avoid damage.
-
Page 14: Electrical Installation
Manual APS-Arduino Shield 6.2 Electrical Installation Ensure sufficient bending radius of the cables during installation. Do not lay the cables in tension or bend them. If all the connections are made, the last step is to plug in the power supply to the mains. -
Page 15: Connector Assignment
6.2.2 Connector Assignment The following is the assignment of the PCB connectors: Fig.2 Connection MA 2120-A002 EN... -
Page 16: Aps Power Stage Module
Manual APS-Arduino Shield 6.2.3 APS Power Stage Module Fig.3 Pin assignment “BU1” Fig.4 Pin assignment “BU2” MA 2120-A002 EN... -
Page 17: Connection - Power Supply And Motor
6.2.4 Connection – Power Supply and Motor Permissible supply voltage range: 24 to 70 V Fig.5 Power supply and motor connection MA 2120-A002 EN... - Page 18 Manual APS-Arduino Shield Wiring Schemes Stepper motors with 0.1 to 5 A phase current can be controlled at a maximum of 70 PEAK with the APS module Arduino shield. Fig.6 Connection diagrams for 4,(6) and 8 lead stepper motors Stepper motors with 8 leads can be connected with the windings wired in parallel (1) or series (2).
- Page 19 For 6 lead stepper motors, wiring scheme (3) with series windings is recommended. If wiring scheme (3) cannot be used because of the motor construction, the motor may be operated with only two of the four windings energized according to wiring scheme (5).
-
Page 20: Commissioning
7 Commissioning Please follow the described order when you put into service the evaluation board: 1. Plug the APS power stage onto the socket connectors of the APS-Arduino shield. 2. Plug the shield onto the Arduino board. 3. Screw the wire ends of the motor cable to the 4-pin socket. -
Page 21: Service
Removal of a module: - Switch off the supply voltage - Disconnect the supply voltage - Carefully pull the APS module from the carrier board. - To send a module to phytron use ESD packaging only. MA 2120-A002 EN... -
Page 22: Warranty, Disclaimer And Registered Trademarks
9 Warranty, Disclaimer and Registered Trademarks Disclaimer Phytron GmbH has verified the contents of the manual to match with the hardware and software. However, errors and omissions are exempt and Phytron GmbH assumes no responsibility for complete compliance. The information contained in this publication is reviewed regularly and any necessary corrections are included in subsequent editions. -
Page 23: Circuit Diagram
10 Circuit diagram Fig.7 Circuit diagram of the APS-Arduino shield MA 2120-A002 EN... -
Page 24: Index
Manual APS-Arduino Shield 11 Index Copyright 2 Rotary switch mode 20 Handling 8 Service 21 Inductance 19 Warranty 22 Installation 14 Wiring scheme 19 Motor time constant 19 MA 2120-A002 EN...
