IOGear GWHDMS52MB User Manual

Long range wireless 5x2 hd matrix pro
Hide thumbs Also See for GWHDMS52MB:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
User Manual
Long Range Wireless 5x2 HD Matrix Pro
GWHDMS52MB
PART NO. M1275
www.iogear.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GWHDMS52MB and is the answer not in the manual?

Questions and answers

Related Manuals for IOGear GWHDMS52MB

Summary of Contents for IOGear GWHDMS52MB

  • Page 1 User Manual Long Range Wireless 5x2 HD Matrix Pro GWHDMS52MB PART NO. M1275 www.iogear.com...
  • Page 2 ©2014 IOGEAR. All Rights Reserved. Part No. M1275 IOGEAR, the IOGEAR logo is trademarks of IOGEAR. Microsoft and Windows are registered trademarks of Microsoft Corporation. IOGEAR makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to...

  • Page 3: Table Of Contents

    Table of Contents Important Information Introduction Package Contents System Requirements Overview Hardware Installation > Step 1: Setup the Transmitter > Step 2: Setup the Receiver > Step 3: Setup the IR blaster extender cable and IR sensor extender cable > Step 4: Mounting the Receiver to a Wall (Optional) Basic Operation Advanced Operation >...

  • Page 4: Important Information

    Important Information Please take the time to read this user manual • Power cord: Be sure the power cord is before using the Transmitter and Receiver. routed so that it will not be stepped on or It contains important information about pinched by heavy items operating your Full HD video wireless kit.
  • Page 5 Special Notice System Warning FEDERAL COMMUNICATIONS • Never use this product nearby an COMMISSION INTERFERENCE aircraft or medical facility. It can cause STATEMENT interference or undesirable effect on the This equipment has been tested and found operation result to comply with the limits for a Class B digital • Use of this product in the following device, pursuant to Part 15 of the FCC locations may result in abnormal video and...
  • Page 6 CAUTION: Canada, Industry Canada (IC) Notices Using the System in the US This Class B digital apparatus complies with • Any changes or modifications not Canadian ICES-003 and RSS-210. expressly approved by the grantee of this Operation is subject to the following two device could void the user’s authority to conditions: (1) this device may not cause operate the equipment.
  • Page 7 This device has also been evaluated and NOTE IMPORTANTE: shown compliant with the IC RF Exposure Déclaration d’exposition aux radiations: limits under mobile exposure conditions. Cet équipement est conforme aux limites (antennas are greater than 20cm from a d’exposition aux rayonnements IC établies person’s body).

  • Page 8: Introduction

    Introduction Wireless HDMI IOGEAR’s Long Range Wireless 5x2 HD Matrix Pro is the first to send full uncompressed HD 1080p, connects up to 5 source devices and allows you to switch and independently select any source between 2 HDTVs. The solution consists of a Wireless Transmitter and a Wireless Receiver with connections for HDMI and Component, along with a loop through (local port) for an advanced 2 HDTV set ups.

  • Page 9: Package Contents

    Package Contents 1 x Wireless Transmitter 1 x Wireless Receiver 2 x Remote Controls w/ batteries 1 x Component Adapter Cable 1 x IR Blaster Cable (Transmitter) 1 x IR Sensor Extender Cable (Receiver) 2 x Power Adapter 1 x HDMI Cable 1 x User’s Guide 1 x Warranty Card System Requirements...

  • Page 10: Overview

    Overview Transmitter Top view 1. Source LEDs These LED indicators lights solid green to show current input. 2. Source Selection Button Press to switch the source inputs connected to the transmitter. 3. Power Button with LED Indicator Press to turn the transmitter on / off. The indicator in the power button lights solid green when the power is on, and turns red when in standby mode.
  • Page 11 Receiver Front View 1. Power Button with LED Indicator Press to turn the receiver on / off. The indicator in the power button lights green when the power is on, and turns red when in standby mode. 2. Source Button S ource Press this button for Source device input selection.
  • Page 12 Remote Control 1. Power on / Power off Buttons Press Power ON to turn the Transmitter & Receiver ON. Press Power OFF to turn the Transmitter and Receiver OFF. When both Transmitter & Receiver Power LEDs POWER POWER are red, press Power ON to the receiver to wake up both the Receiver and Transmitter automatically.

  • Page 13: Hardware Installation

    Hardware Installation Step 1: Setup the Transmitter Connect up to 5 Audio / Video Source Devices and 1 HDTV to the transmitter: 1. Connect the supplied power adapter to the DC IN jack on the transmitter and a wall socket. The LED indicator in to POWER button lights green when it is connected to power.

  • Page 14: Step 2: Setup The Receiver

    Step 2: Setup the Receiver 1. Connect the supplied mini USB power adapter to the DC IN jack of the receiver and a wall socket. The POWER LED indicator lights green when the receiver is connected to power. 2. Connect an HDMI cable to the HDMI OUT port on the receiver and to the HDMI IN port on the HDTV (or and HD projector).

  • Page 15: Step 3: Setup The Ir Blaster Extender Cable And Ir Sensor Extender Cable

    Step 3: Setup the IR blaster extender cable and IR sensor extender cable The IR relays infrared commands from your remote control to your device. Users can control their A / V devices by pointing their remote control to the receiver or IR sensor extender cable. (IR distance from remote to receiver / IR sensor cable is 30 feet line of sight.) A: Transmitter 1.

  • Page 16: Step 4: Mounting The Receiver To A Wall (Optional)

    Step 4: Mounting the Receiver to a Wall (Optional) 1. Refer to the drawing at the right that has a relative position of the main holes that will be needed to be drilled into the wall. 2. Drill two ¼” pilot holes. 3.

  • Page 17: Basic Operation

    Basic Operation 1. After the power adapter is plugged into the electrical outlet, the device will turn ON automatically. 2. If the transmitter is in Power on mode (Power LED on the transmitter is green), press the power button on transmitter and then the transmitter and receiver will enter the standby mode simultaneously.
  • Page 18 Video HDMI S-Video HDMI IN HDMI IN 6. When the GWHDMS52MB is powered on for the first time, the input default is set to Source 1. Note that anytime a source input is switched, it will take approximately 15~20 seconds for the image to appear. There are 3 ways to switch between connected source devices:...
  • Page 19 A. Press the SOURCE button on the top of the receiver or transmitter to switch the source inputs until you see the desired video program being broadcasted from your source device. HDMI IN HDMI IN POWER POWER B. Remote Arrow Keys Switching INFO • Transmitter side: By pressing the SOURCE...
  • Page 20 7. If operation is normal, the POWER / Wireless status LED and Source Status LED will glow in solid green. Please refer to the LED status table below that contains detailed LED indicator and OSD descriptions for the transmitter and receiver: Status Tx / Rx Tx/Rx Source...
  • Page 21 E. On Screen Display (OSD) vs. Remote Control Instruction (1) In Active mode, press the POWER (4) Press the IR button and then the “Up” button on the top of receiver or and “Down” keys on the remote control to transmitter or press the remote change the IR Blaster frequency.

  • Page 22: Advanced Operation

    Advanced Operation Naming the Input Source Devices 1. Press and hold the Source button on the top of the transmitter for over 3 seconds. A source naming OSD will appear on the screen: CHANGE SOURCE NAME NAME= HDMI1 High def. Flat-panel TV HDMI IN HDMI OUT 2.

  • Page 23: Pairing An Additional Receiver (Part# Gwhdrx01) To The Existing Transmitter (Optional)

    Use the same operation method as the transmitter to enter pairing mode for the receiver. Once the receiver enters the pairing mode, the OSD shows: Searching... Both transmitter and receiver will enter the Pairing mode and it will search and pair automatically. The OSD shows: Adding GWHDMS52MB... Once the pairing is finished, both transmitter and receiver will re-boot and link to each other automatically.

  • Page 24: Supported Resolution

    Supported Resolution If the SOURCE LED continues to blink in green (slower than “no signal” mode); OSD display: , and there is no video displayed or the video quality suffers, it indicates that the video frame rate from your A / V source device is not supported. Ensure that the consumer timing of your HDMI device is compliant with the standard listed below: 2D Video Format Timings Resolution...

  • Page 25: Audio Bit Rate Support

    If the Source / Status LED continues to blink green (slower than “no signal” mode); or OSD display shows , please check that both TVs connected to the transmitter and receiver support 3D video format and try to switch the 3D video format to one of the 3D timings listed below.

  • Page 26: Specifications

    Specifications Supported Video HDMI Input 3D, 1080p, 1080i, 720p, 576p, 480p Resolutions Component Input 1080i, 720p, 576p, 576i, 480p, 480i Supported Audio Digital Audio Up to 6 Mbps AC3 and DTS Formats Analog Audio 48KHz and 24-bit Per Sample Transmission Distance The maximum video transmission range is 200ft (the minimum range is 6.5ft).

  • Page 27: Troubleshooting

    Troubleshooting 1. Problem: The power indicator LED doesn’t light up. Solution: Check the power adapters of the Transmitter / Receiver to see if they are properly inserted into a functioning power outlet. 2. Problem: No video is displayed on your TV screen. Solution: • Verify that the proper cables have been selected and installed between the transmitter input and your High-Definition device output.
  • Page 28 • Check if your source player’s audio volume has been turned up. • Ensure that the bit rate of audio from the source device can be supported by GWHDMS52MB. Please refer to the details in page 21 Audio Bit Rate Support. Problem: IR Blaster can’t control Source device.

  • Page 29: Federal Communications Commission (Fcc) Statement

    R&TTED (1999/5/EC). Limited Warranty WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support Warranty Information This product carries a 1 Year Limited Warranty. For the terms and conditions of this warranty, please go to http://www.iogear.com/support/warranty...
  • Page 30 ©2014 IOGEAR ®...
