Precision Analog Systems PAS 9406/AMP Engineering Specification

24 channel, +/- 30 volt, +/- 200 mamp, amplifier card

Advertisement

Quick Links

Revision A – 05/12/15
PAS 9406/AMP
ENGINEERING SPECIFICATION
24 CHANNEL, +/- 30 VOLT,
+/- 200 mAMP, AMPLIFIER CARD
Rev A (05/12/15)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAS 9406/AMP and is the answer not in the manual?

Questions and answers

Summary of Contents for Precision Analog Systems PAS 9406/AMP

  • Page 1 Revision A – 05/12/15 PAS 9406/AMP ENGINEERING SPECIFICATION 24 CHANNEL, +/- 30 VOLT, +/- 200 mAMP, AMPLIFIER CARD Rev A (05/12/15)
  • Page 2 Additional copies of this manual or other Precision Analog Systems (PAS) literature may be obtained from: Precision Analog Systems Co. 1021 SW 75 Avenue Plantation, Florida 33317 Phone: (954) 587-0668 E-mail: inquiry@precisionanalog.com The information in this document is subject to change without notice.
  • Page 3: Table Of Contents

    24 Channel, +/- 30Volt, +/- 200 mAmp Amplifier Card TABLE OF CONTENTS Section Title Page INTRODUCTION General Description Card Features SPECIFICATIONS Electrical Specifications Environmental Specifications Physical Specifications CIRCUIT DESCRIPTION POWER DISSIPATION AND POWER SUPPLY REQUIREMENTS Precision Analog Systems (954) 587-0668 / www.precisionanalog.com...
  • Page 4 24 Channel, +/- 30 Volt, +/- 200 mAmp Amplifier Card LIST OF TABLES Table Title Page P1 Connector Definitions P2 Connection Definitions Precision Analog Systems (954) 587-0668 / www.precisionanalog.com...
  • Page 5: Iintroduction

    INTRODUCTION GENERAL DESCRIPTION The PAS 9406/AMP provides twenty four channels of voltage amplification on a 1U x 19” rack mountable panel. Two PCBs with 12 channels each are mounted on the panel. Different types of amplifier boards can be mounted in the different locations on the panel to tailor the amplifier to your application.
  • Page 6: Card Features

    Each panel mounts 2 amplifier boards with 12 channels each Input and Output signals available on DB37 connectors Thermal shut down and over current protection provided by the OPA551 op-amp. Custom versions available Precision Analog Systems (954) 587-0668 / www.precisionanalog.com...
  • Page 7: Specifications

    +/- 30 Volts Typical, 60 Volt Spread PAS 9406/AMP-000 Specifications Number of channels Transfer characteristics CH 0-1 Gain = 2.8 Amplifier Type OPA551 Maximum Output Current 200 mAmps Maximum Power Supply +/- 30 Volts Typical, 60 Volt Spread Precision Analog Systems (954) 587-0668 / www.precisionanalog.com...
  • Page 8: Environmental Specifications

    -20 to 85° C Relative Humidity Range 20 % to 80 %, non-condensing Physical Specifications 19.0” Length 1.75” Height 4.00” Depth Weight 2 lbs Connectors Input 2 Ea, DB37 Female Output 2 Ea, DB37 Male Precision Analog Systems (954) 587-0668 / www.precisionanalog.com...
  • Page 9 P1 Connector Definitions IN0LO IN0HI IN1LO IN1HI IN2LO IN2HI IN3LO IN3HI IN4LO IN4HI IN5LO IN5HI IN6LO IN6HI IN7LO IN7HI IN8LO IN8HI IN9LO IN9HI IN10LO IN10HI IN11LO IN11HI AGND AGND AGND AGND AGND AGND Precision Analog Systems (954) 587-0668 / www.precisionanalog.com...
  • Page 10 P2 Connector Definitions AGND OUT0 AGND OUT1 AGND OUT2 AGND OUT3 AGND OUT4 AGND OUT5 AGND OUT6 AGND OUT7 AGND OUT8 AGND OUT9 AGND OUT10 AGND OUT11 AGND AGND AGND AGND AGND AGND Precision Analog Systems (954) 587-0668 / www.precisionanalog.com...
  • Page 11: Iii. Circuit Description

    III. CIRCUIT DESCRIPTION The PAS 9406/AMP-000 card contains 12 high power amplifier circuits. Channels are configured to provide a gain of 1.0, 2.7 or a gain used to simulate a speed sensor, with an output current drive of 100 mAmps. Output current and voltage range will be increased significantly when compared with a standard analog output card.
  • Page 12: Power Dissipation And

    7.5 Volts x 7.5 Volts divided by 110 Ohms = 511 mW. The total power is 511 mW + 240 mW = 751 mW. This puts the maximum junction temperature at about 18.7° above ambient. Precision Analog Systems (954) 587-0668 / www.precisionanalog.com...
