Summary of Contents for Leica Geosystems LINO L2
- Page 1 Leica LINO L2 Self leveling alignment tool...
- Page 4 1.5 m...
-
Page 5: Start Up
Operation Start up ..............1 Operation ............. 1 Keypad and control elements Technical data ............. 5 Refer to drawing {B }: Safety instructions ..........5 LASER ON/OFF key PULSE/POWERSAVE MODE key Lock switch Leica LINO L2 757665 gb Start up... - Page 6 By pressing the ON-key {B, 1} again, the previous Applications function status is repeated. Examples of applications can be found on the outside of the back cover of this User Manual. Operation Leica LINO L2 757665 gb...
-
Page 7: Operation
Now of tolerance. determine the maximum deviation of the laser line to | (A1 - A2) - (B1 - B2) | ≤ 2 mm the plumb bob over the entire length of the line. Leica LINO L2 757665 gb Operation... - Page 8 The laser beam is not levelled and the Lock symbol Warranty {B, 7} lights up. The Leica LINO comes with a two (2) year warranty from Leica Geosystems AG. More detailled information can be found at: www.disto.com Operation Leica LINO L2 757665 gb...
-
Page 9: Technical Data
All rights reserved for changes (on drawings, descrip- tions and technical data). Permitted use • Projecting a vertical laser line • Projecting a horizontal laser line • Projecting a vertical and a horizontal laser line simultaneously (laser crosshairs) Leica LINO L2 757665 gb Technical data... - Page 10 Carry out periodic test measurements. Partic- ularly after the instrument has been subject to The Leica LINO L2 is designed for use in areas perma- abnormal use, and before, during and after important nently habitable by humans, do not use the product measurements.
- Page 11 Leica Geosystems home page at Laser Class 2/ II products: http://www.leica-geosystems.com/treatment Do not stare into the laser beam or direct it towards or received from the Leica Geosystems dealer. other people unneccesarily. Eye protection is normally afforded by aversion responses including Electromagnetic Compatibility the blink reflex.
- Page 12 Laser Radiation Do not stare into the beam Laser class 2 nach IEC 60825-1:2001 Maximum radiation power *: <4.2mW Emitted wavelength: 620-690nm Beam divergence 120° Position of the product label see last page! Safety instructions Leica LINO L2 757665 gb...
- Page 13 Leica Geosystems AG, Heerbrugg, Switzerland has been certified as being equipped with a quality system which meets the International Standards of Quality Management and Quality Systems (ISO standard 9001) and Environmental Management Systems (ISO standard 14001). Total Quality Management - Our commitment to total customer satisfaction.
